2011 SUBARU IMPREZA display

40 Navigation
Setting Route
5When there are two or more candidates, a list of intersec-
tions will be displayed. Select an intersection of your des-
tination.
6Select (destination) or (waypoint).
NOTE
No intersection is defined if• the two streets do not cross each other,
• the two streets are a freeway and a highway,
• either street is for right or left turns only,
• both are one-way streets,
• either street is for U-turns,
• the two streets cross on the inside lane,
• either street is an on/off ramp,
• either street is a frontage street, and/or
■ "Phone number" method
This function allows buildings and th e like to be located using their
phone numbers.
1Press the button, sele ct , and then select
(phone number).
2Enter the phone number starting with the area code.
3Select .
Impreza_B1962BE-A.book Page 40 Wednesday, May 7, 2008 9:01 PM

Navigation 41
Setting Route
4Select your destination.
5Select (destination) or (waypoint).
NOTE
If a number of candidates exist as a result of, for example, different area codes,
these will be displayed in a list. Your desired destination can then be selected
from the list.
■Using "Change Search Area" function
This function designates a general geographical area where the desti-
nation or waypoint you wa nt to set is located.
This function can be used in the methods marked with an asterisk (*) on
Page 30.
1Press the button and select (change).
2Select the desired area.
The DESTINATION ENTRY menu screen will appear.
NOTE
• The SEARCH AREA screen shown above is a sample image. It may be slightly
different from the actual screen image.
• Three map discs are contained in this system. When performing a search for a
different area in your destination sear ch, it is necessary to change the map
disc with another map disc. If an area you want to find is not displayed on the
screen shown above, take out the map disc and change it with a map disc
containing the relevant area.
For details of the map disc, refer to the description below.
■ Map Discs
The three map discs contai n different areas, respectively. ( West, Mid and
East) Select the map disc containing the destination area you wish and
insert the disc in the navigation system.
Make sure to reselect your destin ation when you change the map disc.
Refer to the section Set Route in the Instruction Manual for instructions
on reselecting the destination.
Impreza_B1962BE-A.book Page 41 Wednesday, May 7, 2008 9:01 PM

42 Navigation
Setting Route
■Area (West)
Arizona, California, Colorado, Id aho, Kansas, Montana, Nebraska,
Nevada, New Mexico, North Dakota, Oklahoma, Oregon, South Dakota,
Texas, Utah, Washington, Wyoming, Canada
■ Area (Mid)
Alabama, Arkansas, Illinois, Indiana, Iowa, Kansas, Kentucky, Louisiana,
Michigan, Minnesota, Mississippi, Mi ssouri, Nebraska, North Dakota,
Ohio, Oklahoma, South Dakota, Tennessee, Texas, Wisconsin, Canada
■ Area (East)
Alabama, Connecticut, Delaware, Flor ida, Georgia, Kentucky, Maine,
Massachusetts, Maryland, New Hampshire, New Jersey, New York, North
Carolina, Ohio, Pennsylvania, Rhode Island, South Carolina, Tennessee,
Vermont, Virginia, Washington D.C., West Virginia, Canada
NOTE
• Road information for all of the above locations is included on the map discs.
This means that the following operatio ns can be performed regardless of
which map disc is lo aded in the system;
- Scrolling Map to Select Destination (Select from Map)
- Selecting Destination from the previously registered points as a memory
point (Home, Memory Point, Previous Destination) within the same area.
- Selecting Destination by Latitude an d Longitude (Coordinates), Phone num-
ber, Emergency, and Quick POI.
• After replacing the map disc, stored da ta including the POI icon on the map
and stored Avoid Street settings will be deleted, and Quick POI selections will
return to default.
• In the Current Location display, the arrival time and the distance to the desti-
nation are displayed for Next Way Point.
Impreza_B1962BE-A.book Page 42 Wednesday, May 7, 2008 9:01 PM

44 Navigation
Route Guidance
Zoom-in Map at Intersection
Before you arrive at an intersection, the system will automati-
cally show a zoom-in map of the intersection on a second
screen to make the guidance clearer.
As you approach an intersection du ring route guidance, a zoom-in map
of the intersection automatically appe ars on a second screen. After you
drive past the intersection, the zoom-in map disappears.
As you approach a fork on a freeway during route guidance, a zoom-in
map of the freeway automatically a ppears on a second screen, making
the route guidance clearer.
NOTE
Use the following procedure to recall the most recently displayed zoom-in map
of an intersection or a freeway fork.
1. Select (screen configuration).
2. Select (re-display of intersection/range guidance).
If you need not make any further selection, select . The relevant keys
will disappear.
Impreza_B1962BE-A.book Page 44 Wednesday, May 7, 2008 9:01 PM

Navigation 45
Route Guidance
Dual Map Display
You can configure the screen for a dual map display.
1Select (screen configuration).
2Select (dual map).
If you wish to return to the single map display, select (sin-
gle map).
If you need not make any further selection, select . The rele-
vant keys will disappear.
NOTE
If you wish to modify the display select ions that have been made for a second
screen, touch the top of the screen. After completing the modification,
select . • See Page 25 for details on scale changes.
• See Page 79 for details on setting with .


Impreza_B1962BE-A.book Page 45 Wednesday, May 7, 2008 9:01 PM

46 Navigation
Route Guidance
Freeway Information
A list of buildings and facilities along a freeway can be dis-
played on the screen.
1Select (screen configuration).
2Select (freeway information).
If you need not make any further selection, select .
The relevant keys will disappear.
The information of a freeway is displayed.Select to display the map in
the neighborhood together
with the icons of hotels and banks.
This map allows you to set your de stination and waypoints. It also
allows you to register them with the Memory Point with the cur-
sor placed on the icon.
Impreza_B1962BE-A.book Page 46 Wednesday, May 7, 2008 9:01 PM

48 Navigation
Route Guidance
Compass Mode
Longitude and latitude of present location can be displayed
on the screen.
1Select (screen configuration).
2Select (compass).
3Longitude and latitude of present location are displayed
at upper right of the screen.
Impreza_B1962BE-A.book Page 48 Wednesday, May 7, 2008 9:01 PM

Navigation 49
Route Options
Setting Route Options
Using the functions available from the Route Options screen,
you can change the route options, stop the route guidance or
check the route. Use the following procedures:
1Press the button.
2Select (route options).
The Route Options screen will appear. Select any of the following
displayed functions as necessary:(search condition):
This function allows you to spec ify the way in which the system
calculates the route to th e destination. (See Page 50.)
(detour):
This function allows you to prompt the system to calculates an
alternative route from your curren t position within a specified dis-
tance. (See Page 51.)
(route preferences):
This function allows you to prompt the system to alter the route
search conditions and recalculate the route accordingly. (See Page
52 .)
(destination and waypoint):
This function allows yo u to modify the destination and waypoints,
and prompt the system to recalcul ate the route accordingly. (See
Page 52.)
(display route):
This function allows you to confirm the entire route and, if neces-
sary, prompt the system to recalculate the route according to your
specification. (See Page 56.)
(route preview):
This function allows you to simulate a drive along the system-cal-
culated route before departure. (See Page 57.)
(calculate):
Selecting this key prompts the system to recalculate the route.
Impreza_B1962BE-A.book Page 49 Wednesday, May 7, 2008 9:01 PM
