CAUTION!
If the “Water In Fuel Indicator Light” remains on, DO
NOT START the engine before you drain water from
the fuel filter to avoid engine damage.
If the “Water In Fuel Indicator Light” comes on and a
single chime is heard while you are driving, or with the
ignition switch in the ON position, there may be a
problem with your water separator wiring or sensor. See
your authorized dealer for service.
Upon proper draining of the water from the fuel filter, the
“Water In Fuel Indicator Light” will remain illuminated
for approximately 10 seconds. If the water was drained
while the engine was running, the “Water In Fuel Indi-
cator Light” may remain on for approximately three
minutes. NOTE:
Care should be taken in disposing of used fluids
from your vehicle. Used fluids, indiscriminately dis-
carded, can present a problem to the environment. Con-
tact an authorized dealer, service station, or government
agency for advice on recycling programs and for where
used fluids and filters can be properly disposed of in
your area.
Drain the fuel/water separator filter when the “Water In
Fuel Indicator Light” is ON. Within 10 minutes of vehicle
shutdown, turn the drain valve (located on the side of the
filter) counterclockwise 1/4 turn, turn the ignition switch
to the ON position, and allow any accumulated water to
drain. Leave the drain valve open until all water and
contaminants have been removed. When clean fuel is
visible, close the drain valve by turning it clockwise, and
turn the ignition switch to OFF.
6
MAINTAINING YOUR VEHICLE 105

Refer to the following messages that may be displayed on
your Electronic Vehicle Information Center (EVIC):
WARNING!
A hot exhaust system can start a fire if you park over
materials that can burn. Such materials might be
grass or leaves coming into contact with your exhaust
system. Do not park or operate your vehicle in areas
where your exhaust system can contact anything that
can burn.
Perform Service
Your vehicle will require emissions maintenance at a set
interval. To help remind you when this maintenance is
due, the Electronic Vehicle Information Center (EVIC)
will display “Perform Service”. When the “Perform Ser-
vice” message is displayed on the EVIC it is necessary to
have the emissions maintenance performed. Emissionsmaintenance may include replacing the Closed Crank-
case Ventilation (CCV) filter element, and cleaning of the
EGR Cooler. The procedure for clearing and resetting the
Perform Service
indicator message is located in the
appropriate Service Information.
Exhaust System – Regeneration Required Now
“Exhaust System — Regeneration Required Now” will be
displayed on the Electronic Vehicle Information Center
(EVIC) if the exhaust particulate filter reaches 80% of its
maximum storage capacity. Under conditions of exclu-
sive short duration and low speed driving cycles, your
Cummins diesel engine and exhaust after-treatment
system may never reach the conditions required to re-
move the trapped PM. If this occurs, the “Exhaust System
— Regeneration Required Now” message will be dis-
played in the EVIC. If this message is displayed, you will
hear one chime to assist in alerting you of this condition.
110 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULES
CONTENTS
Maintenance Schedule .................. 136
▫ Oil Change Indicator System ............ 137▫
Perform Service Indicator .............. 138
▫ Required Maintenance Intervals .......... 138
7

Ram Truck Chassis Cab (3500, 4500, and 5500
Models)
Replace the engine oil and oil filter every 7,500 miles
(12 000 km) or six months, or sooner if prompted by the
oil change indicator system (if equipped). Under no
circumstances should oil change intervals exceed
7,500 miles (12 000 km) or six months, whichever comes
first.
Perform Service Indicator
Your vehicle will require emissions maintenance at a set
interval. To help remind you when this maintenance is
due, the Electronic Vehicle Information Center (EVIC)will display “Perform Service”. When the “Perform Ser-
vice” message is displayed on the EVIC it is necessary to
have the emissions maintenance performed. Emissions
maintenance may include replacing the Closed Crank-
case Ventilation (CCV) filter element, and cleaning of the
EGR Cooler. The procedure for clearing and resetting the
“Perform Service” indicator message is located in the
appropriate Service Information.
Required Maintenance Intervals
Refer to the Maintenance Schedules on the following
pages for the required maintenance intervals.
138 MAINTENANCE SCHEDULES

7,500 Miles (12,000 km) or 6 Months Maintenance Service
Schedule
❏When prompted by the Engine Oil Indicator System, the engine oil and filter must be
changed. If not prompted by the Engine Oil Indicator System within 7,500 miles
(12 000 km) or six months since the last oil and filter change, change the engine oil and
engine oil filter.
❏ Check the Diesel Exhaust Fluid (DEF) tank, refill if necessary (Chassis Cab Only).
❏ Rotate tires.
❏ Lubricate front drive shaft fitting (4x4).
❏ Lubricate outer tie rod ends.
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
7
MAINTENANCE SCHEDULES 139

15,000 Miles (24,000 km) or 12 Months Maintenance Service
Schedule
❏When prompted by the Engine Oil Indicator System, the engine oil and filter must be
changed. If not prompted by the Engine Oil Indicator System within 7,500 miles
(12 000 km) or six months since the last oil and filter change, change the engine oil and
engine oil filter.
❏ Check the Diesel Exhaust Fluid (DEF) tank, refill if necessary (Chassis Cab Only).
❏ Rotate tires.
❏ Replace fuel filter element.
❏ Lubricate front drive shaft fitting (4x4).
❏ Lubricate outer tie rod ends.
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for
damage, wear, improper looseness or end play; replace if necessary.
❏ Inspect the front (4x4) and rear axle fluid, change if using your vehicle for police, taxi, fleet,
off-road or frequent trailer towing.
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
140 MAINTENANCE SCHEDULES

22,500 Miles (36,000 km) or 18 Months Maintenance Service
Schedule
❏When prompted by the Engine Oil Indicator System, the engine oil and filter must be
changed. If not prompted by the Engine Oil Indicator System within 7,500 miles
(12 000 km) or six months since the last oil and filter change, change the engine oil and
engine oil filter.
❏ Check the Diesel Exhaust Fluid (DEF) tank, refill if necessary (Chassis Cab Only).
❏ Rotate tires.
❏ Inspect drive belt, replace if necessary.
❏ Lubricate front drive shaft fitting (4x4).
❏ Lubricate outer tie rod ends.
❏ Inspect brake linings.
❏ Inspect and adjust parking brake if necessary.
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
7
MAINTENANCE SCHEDULES 141

30,000 Miles (48,000 km) or 24 Months Maintenance Service Schedule
❏When prompted by the Engine Oil Indicator System, the engine oil and filter must be changed. If not prompted by the Engine Oil Indicator
System within 7,500 miles (12 000 km) or six months since the last oil and filter change, change the engine oil and engine oil filter.
❏ Check the Diesel Exhaust Fluid (DEF) tank, refill if necessary (Chassis Cab Only).
❏ Rotate tires.
❏ Replace fuel filter element.
❏ Lubricate front drive shaft fitting (4x4).
❏ Lubricate outer tie rod ends.
❏ Inspect the wheel bearings.
❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play;
replace if necessary.
❏ Inspect the front (4x4) and rear axle fluid, change if using your vehicle for police, taxi, fleet, off-road or frequent trailer towing.
❏ Check the transfer case fluid (4x4).
❏ Change automatic transmission fluid (Chassis Cab Only).
Odometer Reading Date
Repair Order #Dealer Code
Signature Authorized Chrysler Dealer
