2011 Ram 2500 engine

JOBNAME: 288987 2011 Maint-Wa PAGE: 33 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
221,000 km or 102 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
102 Months or
221,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 34 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
221,000 km or 102 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 35 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
234,000 km or 108 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
❏Inspect the engine air filter if using your vehicle in dusty or off-road conditions;
replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using your vehicle for any of
the following: police, fleet, off-road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and boot seals; replace if
necessary.
❏Replace the top row of spark plugs on 4.7L engines.**
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one set is located on the top of the
engine under the coils and the second set is located on the side of the engine. The spark plugs located under the
coils are a standard plug and must be change every 78,000 kilometres. The spark plugs located on the side of the
engine are a premium plug and must be changed every 156,000 kilometres.
Perform Maintenance
At
108 Months or
234,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 36 SESS: 60 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
❏Inspect the engine air filter if using your vehicle in dusty
or off-road conditions; replace if necessary.
❏Inspect the brake linings; replace if necessary.
❏Inspect the front (4x4) and rear axle fluid; change if using
your vehicle for any of the following: police, fleet, off-
road or frequent trailer towing.
❏Inspect the CV joints.
❏Inspect the exhaust system.
❏Inspect the front suspension components, tie rod ends and
boot seals; replace if necessary.
❏Replace the top row of spark plugs on 4.7L engines.**
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
** Vehicles built with the 4.7L engine are equipped with sixteen spark plugs, one
set is located on the top of the engine under the coils and the second set is
located on the side of the engine. The spark plugs located under the coils are a
standard plug and must be change every 78,000 kilometres. The spark plugs
located on the side of the engine are a premium plug and must be changed
every 156,000 kilometres.
Perform Maintenance At
234,000 km or 108 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 37 SESS: 59 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
Perform Maintenance At
247,000 km or 114 Months
❏Change the engine oil and oil filter.Under no circumstances should the oil change
interval exceed 13,000 km or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if it occurs prior to this
service.
❏Lubricate the front drive shaft fitting. (All 4x4 models except 1500)
* Oil changes that are prompted by the oil change indicator system prior to this schedule maintenance interval can
be recorded in the oil change log section.
Perform Maintenance
At
114 Months or
247,000 km
Odometer Reading
DateRetailer Copy
Remove and attach to Repair Order
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 38 SESS: 60 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/01bintervals-gas
❏Change the engine oil and oil filter.Under no circum-
stances should the oil change interval exceed 13,000 km
or 6 months whichever occurs first.*
❏Rotate tires, rotate at the first sign of irregular wear even if
it occurs prior to this service.
❏Lubricate the front drive shaft fitting. (All 4x4 models ex-
cept 1500)
* Oil changes that are prompted by the oil change indicator system prior to this
schedule maintenance interval can be recorded in the oil change log section.
Perform Maintenance At
247,000 km or 114 Months
Odometer Reading
Date
Repair Order No.
CHRYSLER
RETAILERSTAMP
Signature of authorized Chrysler Canada Retailer
................................................................................................

JOBNAME: 288987 2011 Maint-Wa PAGE: 1 SESS: 26 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02aintervals-diesel
SCHEDULED MAINTENANCE
DIESEL ENGINES

JOBNAME: 288987 2011 Maint-Wa PAGE: 2 SESS: 26 OUTPUT: Wed May 26 09:12:27 2010
/chrysler/chry-intl/warr-maint/288987-ram-gasdsl-en/02aintervals-diesel
INTRODUCTIONYour vehicle is equipped with an engine oil change
indicator system. This system will alert you when it is
time to change your engine oil by displaying the words
“Oil Change Required” on your Electronic Vehicle Infor-
mation Center (EVIC). The engine oil change indicator
system is duty cycle based, which means the engine oil
change interval may fluctuate depending on your per-
sonal driving style. Driving styles such as frequent stop
and go type driving can increase the frequency of the
engine oil change. This is the result of more frequent
regeneration of the exhaust aftertreatment system, which
can decrease the life of the engine oil. Failure to change
the engine oil per the maintenance schedule can result in
internal engine damage.
Under no circumstances should the oil change interval
exceed 12,000 km or six months whichever occurs first.
For information on resetting the Oil Change Indicator
message, refer to “Oil Change Required If
Equipped,” under “System Status (EVIC Displays)”
in the “Electronic Vehicle Information Center
(EVIC)” Section of the Owner’s Manual.The performance of all scheduled service work is
required to maintain your vehicle in good operating
condition. Chrysler Canada Inc. reserves the right to
deny warranty coverage if the vehicle has not been
properly maintained. While we do not insist that such
work be performed by factory authorized retailers,
we strongly recommend that an authorized Chrysler,
Jeepor Dodge Retailer perform this work.
AT EACH STOP FOR FUEL
•Check the engine oil level about 5 minutes after a
fully warmed engine is shut off. Checking the oil
level while the vehicle is on level ground will
improve the accuracy of the oil level reading. Add
oil only when the level is at or below the ADD or
MIN mark.
•Check the windshield washer solvent and add if
required.
ONCE A MONTH
•Check tire pressure and look for unusual wear or
damage.
•Inspect the batteries, clean and tighten the termi-
nals as required.
•Check the fluid levels of coolant reservoir, brake
master cylinder, and transmission and transfer
case (if equipped) add as needed.
•Drain water from the fuel filter.•Check and clean wiper blades. Replace if required.
AT EACH OIL CHANGE
•
Change the engine oil filter.•Inspect the exhaust system.•Inspect the brake hoses and lines.•Check the automatic transmission fluid level.•Check the manual transmission fluid level.•Check the engine coolant level, hoses, and clamps.•Lubricate outer tie rod ends.
Inspection and service should also be performed any-
time a malfunction is observed or suspected. Retain all
receipts.
VISUAL INSPECTIONS —
INSPECT FOR SIGNS OF COMPONENT
DETERIORATION AND PHYSICAL DAMAGE.
MAINTENANCEScheduled maintenance must be completed to provide the best vehicle performance and reliability. The limited warranties in the
warranty booklet DO NOT COVER repairs required due to improper maintenance. We strongly suggest you keep track of scheduled maintenance and keep receipts
or other documents. Use only recommended MoparLubricants and genuine MoparParts. In the event that a condition arises between maintenance intervals,
please contact your retailer. AVOID PROLONGED PERIODS OF IDLING.
NOTE: WHERE TIME (MONTHS) AND METRAGE ARE INDICATED, FOLLOW THE INTERVAL THAT OCCURS FIRST.
