2011 PORSCHE BOXSTER S display

1
2
52
5352
53
For ward thrust |
Chassis
Wheels.
The standard wheels on the new Boxster
models have been enlarged by one inch
compared with those of the previous
models. Made from a light weight alloy, the
larger wheels reinforce the car’s imposing
presence and further improve sport y
performance. The new Boxster is equipped with 18-inch
wheels. Their minimalist five-spoke design
is sport y and elegant in equal measure.
Tyre sizes are 235/45 ZR 18 and 265/45
ZR 18 at the front and rear respectively.
The Boxster S has 19-inch wheels with
a dynamic dual-spoke design. The t yre
size at the front is 235/40 ZR 19 and
265/40 ZR 19 at the rear.
The larger rolling circumference improves
comfort and performance. At the same time, the rolling resistance of the new gen
-
eration of t yres has been reduced which,
in turn, helps to reduce fuel consumption.
Wheels up to 20 inches are available as an
option.
Tyre Pressure Monitoring (TPM).
Optional Tyre Pressure Monitoring (TPM)
sends warnings to the on-board comput -
er’s display screen in the event of low t yre
pressure. The 4.6-inch TFT screen in the
instrument cluster enables the driver to
check the pressure in all four t yres. The system updates quickly and accurately
after an engine start, t yre pressure cor
-
rection or wheel change – for increased
comfort and safet y.
1 18 - inch Boxster wheel
2 19 - inch Boxster S wheel

1
2
3
62
63
Sport Chrono Package.
Time is precious and every hundredth
of a second counts. The optional Sport
Chrono Package makes your driving experi -
ence priceless thanks to an even sportier
tuning of throt tle response and handling
characteristics.
The package comprises dynamic gear-
box mounts, a per formance display,
a digital and analogue stopwatch and
the SPORT PLUS but ton. When this
is pressed, optional Porsche Active
Suspension Management (PASM) switches
to ‘Sport ’ mode for harder damping
and more direct steering and therefore,
even more intensive road holding.
The trigger threshold for PSM is raised.
Agilit y is perceptibly enhanced when
braking for corners with PSM, allowing
even sportier braking and exit acceleration.
For even greater dexterit y, PSM can be set to standby while the car is still in
SPORT PLUS mode. For safet y, it is set
to intervene automatically only when ABS
assistance is required.
In conjunction with optional PDK, the Sport
Chrono Package comes with t wo additional
functions for a sport y drive that borders
on a motorsport experience. The first
is ‘Launch Control’, which is designed to
produce a racing start.
The second function is the involving

‘motorsport- derived gearshif t strategy’.
Using this, Porsche Doppelkupplung (PDK)

is geared up for the shortest possible
shift times and optimum shift points,
while torque boosts during gear changes
provide the maximum possible accelera -
tion. This involving experience is further
enhanced by overrun downshifts
and the
throttle-blip function for uncompromising
driving pleasure.
An additional display in the steering wheel
or either the instrument cluster indicates
whether the SPORT or SPORT PLUS
but -
tons and, with PDK, Launch Control have
been activated. In conjunction with the
optional Porsche Communication
Management (PCM), a special display
enables you to view, store and evaluate
lap times or other driving times. It shows
the total driving time, lap distance, lap
number and lap times recorded so far.

Performance is further intensified by
dynamic gearbox mounts. Read on to find
out more.
1 Sport Chrono display on the PDK steering wheel
2 Sport Chrono stopwatch
3 SPORT and SPORT PLUS but ton

3
1 2
82
83
Free space |
Interior and comfort
Leather package.
You may have thought the interior of
your new Boxster couldn’t be any more
st ylish, but the optional leather package
en hances its overall appeal by adding a
leather finish to the instrument cowl, cen -
tre console storage compartment lid,
seat centres, side bolsters and headrests,
the door armrests and door pulls. With the
leather package, all of these feature

a silver- coloured trim strip, which

accentuates the dynamic and sweeping
design of the interior.
You have a choice bet ween a minimalist
single-tone interior, with one of the
standard colours Black, Platinum Grey,
Luxor Beige or Yachting Blue, and a t wo -tone combination of Agate Grey

and Pebble Grey
1) or, exclusively available
for the leather package, Agate Grey and
Lime Gold. The features in leather (on the
seats, only the seat centres) are finished
in the contrasting colour.
Instruments.
The powerful performance of the new
Boxster models may be indescribable, but
it can be measured. The three circular
instruments give you all the information
you need. The rev counter with digital
speedometer is positioned in the centre.
In the Boxster S, the dial face is alumini -
um-coloured; in the Boxster, it is finished in minimalist black. The instrument on the
left contains the analogue speedometer
with digital trip meter and total distance
d isp lay.
A new feature of the right-hand circular
instrument is the high-resolution 4.6-inch
TFT colour screen. It provides you with

a continuous stream of data from the on-board computer, reminds you of

your selected communication and audio
set tings, enables you to customise
vehicle settings, delivers various warn -
ings, including alerts from the optional
Tyre Pressure Monitoring (TPM) system
and in conjunction with the optional PCM,
displays the navigation system map.
1 Leather package in Agate Grey and Lime Gold
2 Boxster instruments
3 Boxster S instruments
1) Additionally available from 07/2012 at the earliest: t wo -tone combination of Agate Grey and Amber Orange.

21
3 4
84
85
Steering wheels.
Where your journey takes you is in
your hands. For this reason, all available
steering wheels feature a high-grip
rim in smooth-finish leather and offer
outstanding ergonomics. The reach from
the steering wheel to the gear lever is
short for sport y and fast gear changes.
In combination with the optional fully
electric seats, the steering wheel is also
electrically adjustable and for even more
convenience, a memory function is
included.
Sports steering wheel.
The three-spoke sports steering wheel is
fit ted as standard and offers up to 40 mm
of adjustment for both height and reach.
The steering wheel rim is upholstered in
smooth-finish leather. In conjunction with
optional PDK, the steering wheel features
t wo ergonomic switches. One press with the thumb and PDK shifts up. One pull
with the index finger and PDK shifts down.
Either the right or left hand can be used.
With the optional Sport Chrono Package
and PDK, there is an additional display
above the airbag module. It tells you
whether the SPORT, SPORT PLUS and
Launch Control functions are activated.
The optional multifunction steering wheel
provides extra operating comfort with

four function but tons and t wo thumb -
wheels for convenient operation of many
audio, telephone and navigation functions. SportDesign steering wheel.
Visually, the optional SportDesign steering
wheel is distinguished by its st ylish twin-
spoke design. It ’s in safe hands, even on
the sportiest of drives. In conjunction with PDK, the steering
wheel features t wo gearshift paddles.
Made from a strong alloy, they are ergo
-
nomically located behind the right and left
steering wheel spokes. Pull the right-hand
paddle and PDK shifts up. Pull the left-
hand paddle and PDK shifts down.
When combined with the optional Sport
Chrono Package and PDK, the steering
wheel has an additional display in the
left- and right-hand spokes to indicate
whether the SPORT, SPORT PLUS and
Launch Control functions are activated.

Steering wheel heating.
For extra comfort on those cold days, a
heating function is available as an option
for the sports steering wheel and the
multifunction steering wheel. The heating
is activated by a separate control but ton
on the steering wheel and the rim is
warmed to a pleasant temperature. Cold weather should never be a reason to

prevent you from enjoying your open-top
driving experience.
1 SportDesign steering wheel
2 Sports steering wheel
3 Multifunction steering wheel
4 SportDesign steering wheel with gearshif t
paddles in conjunction with PDK

12
3
90919091
Exterior mirrors and rear-view mirror.
The new Boxster models are equipped
as standard with electrically adjustable
and heated exterior mirrors.
Available as an option, electrically folding
exterior mirrors with door courtesy light -
ing on both sides of the vehicle make it
easier to find your way in the dark.
An auto-dimming function for the exterior
mirrors and rear-view mirror with an
integrated rain sensor for the windscreen
wipers, is available as an option.
ParkAssist.
Optional ParkAssist is activated the
moment you select reverse gear.
An audible signal gives a warning if you
reverse too close to an obstacle.
An enhanced version of Park Assist also
provides monitoring of the area to the front of the vehicle. Ultrasonic sensors
are neatly integrated into the front and
rear aprons. The audible alert is supple
-
mented by a visual warning in the central
display of the CDR audio system or option -
al
PCM, which shows a graphical repre -
sentation of the vehicle from overhead.
HomeLink®
(programmable garage door opener).
The optional programmable garage door
opener is integrated into the overhead
console and remotely controls up to
three different garage doors, gates, home
lighting and/or alarm systems.

Anti-theft protection.
Both new Boxster models are equipped
as standard with an immobiliser with in-
key transponder and an alarm system

with contact-sensitive exterior protection.

Preparation Vehicle Tracking System
(PV TS).
This standard preparation enables future
installation of the Porsche Vehicle Tracking
System (PV TS) available from Porsche
Tequipment. The system makes it possible
to locate a stolen vehicle across most of
the countries of Europe. The preparation
package includes a special wiring loom
and a tilt sensor for the alarm system.
Two luggage compartments.
The t wo luggage compartments are
further proof that the Boxster harmoni -
ously combines the spirit of sport with
everyday practicality like never before.
The front and rear compartments have
a capacit y of 150 and 130 litres respec -
tively, regardless of whether the hood is
up or down. The interior surfaces are
carpet-lined and the lids are made from
aluminium. The two service openings in
the rear luggage compartment provide convenient access to the coolant and
engine oil filler caps.
The separate Porsche Design Driver’s
Selection catalogue contains a selection
of matching luggage accessories.
1– 3 Loading options with luggage items from

the Porsche Design Driver’s Selection
(items of luggage from the PTS AluFrame
and PTS Sof t Top series)

13
2
CDR audio system.
The CDR audio system is an ideal com -
plement to the resonant engine sound
of the new Boxster models. It features
a 7-inch colour touchscreen, giving
you quick and easy access to the most
important functions and menus.
The integrated CD radio features
an FM dual tuner and RDS diversit y,
30 memor y presets, dynamic autostore
and speed -sensitive volume control.
The system also includes a sound system
with four loudspeakers and a total output
of 2 x 25 wat ts. For an even more intense listening

experience, the CDR audio system
can be combined with the Sound Pack -
age Plus (p. 99) or the BOSE
® Surround
Sound System (p. 100) on request.
Porsche Communication Management
(PCM) including navigation module.
PCM is your central information and
communication system. It is powerful
and multifunctional, yet easy to operate.
The focal point is the intuitive 7-inch
high-resolution touchscreen. Almost all functions can be controlled with just your
fingertips, although conventional rotary
pushbut ton controls are still provided.
Radio functions include up to 42 memory
presets, dynamic autostore and the

FM dual tuner with RDS diversit y, which
continuously scans in the background for
the best signal.
The CD/ DVD drive plays CDs and
audio DVDs and is MP3-compatible.
Audio playback of video DVDs is also
supported. A six-disc CD/ DVD auto -

changer integrated into PCM is available
as an option.
1, 3 Porsche Communication Management (PCM)
2 CDR audio system
We’ve shown you what rock ‘n’ roll looks like.
Now you want to know how it sounds.
Audio and communication.
A navigation module with high-speed
hard drive is included with PCM. For route
guidance, it is possible to select bet ween
a 2D display and a 3D perspective.
In some regions, even land and buildings
can be displayed in 3D. Split screen
mode enables you to view t wo functions
at once, such as the current navigation
map and a list of symbols that represent
the next navigation instruction.
Free space |
Audio and communication

12
3
4
6
5
96
97
Electronic logbook for PCM.
An electronic logbook is available for
PCM as an option. It enables automatic
logging for every journey of mileage,
route distance, date, time, starting
location and destination. After you have
downloaded your logbooks from the PCM
via the USB or Bluetooth
® inter face, you
can evaluate the data on your home PC using the soft ware supplied. The soft
-
ware fulfils all statutory requirements
for automatic logbooks as specified by
the German revenue authorities.
TV tuner for PCM.
The optional T V tuner is capable of
receiving unencrypted analogue and
digital television broadcasts (DVB -T) to provide entertainment bet ween journeys.
For your safet y, the T V picture is
switched off while the car is in motion.
Voice control system for PCM.
To get what you want, you like to get
straight to the point. Almost all of the
functions of PCM can be controlled using
the optional voice control system with word-by-word input. The menu item is
read aloud exactly as it is displayed on
the screen and the voice control system
recognises commands or sequences

of numbers, whoever the speaker. It then
gives an audible acknowledgement and
carries out the functions you request.
There is no need to ‘train’ the system.
Telephone module for PCM.*
The optional quadband GSM telephone
module offers convenience and excellent
reception. By inserting a SIM card directly
into the PCM’s integral SIM card reader,
calls can be made using the hands-free
facility. For even more convenience, the
Bluetooth
® capability of a mobile phone
can be used to make calls via the SIM Access Profile (SAP). Once automatic
pairing is complete, the mobile phone’s
aerial is switched off to conserve bat tery
charge and the phone operates via the
car aerial. Depending on the mobile
phone model, this gives access not only
to the numbers on the SIM card, but

also to the phone’s internal memory.
Depending on the phone, it can also be controlled using PCM, the optional

multifunction steering wheel or the
optional voice control system, without
it ever leaving your pocket.
* Notes: see page 116. 1 Electronic logbook for PCM

2 T V tuner for PCM
3, 4 Voice control system for PCM
5 Telephone module for PCM
6 Cordless handset for telephone module
Free space |
Audio and communication

3
2 1
98
99
* Notes: see page 116.
1 CD/ DVD autochanger for PCM
2
Universal audio interface (AUX) in conjunction with CDR
3 Universal audio inter face (AUX, USB e.g. for iPod®)
in conjunction with PCM
In addition, the telephone module enables
you to establish a Bluetooth
® link with
those mobile phones that only support the
Handsfree Profile (HFP). In this case, the
GSM connection is always established
through the aerial of the mobile phone.
PCM acts as a hands-free system and you
can leave the mobile phone tucked away.
On request, a cordless handset for the tele -
phone module is also available. Stored in
the centre console, it features a display
and keypad. However, the handset cannot
be used for Bluetooth
® links established
using the Handsfree Profile (HFP).
Mobile phone preparation
for PCM and CDR.*
To enable a Bluetooth® connection for
those mobile phones that only support
the Handsfree Profile (HFP), an optional
mobile phone preparation is available.
With HFP, the CDR audio system or PCM
acts as a hands-free system. The CDR
audio system and PCM are able to control
all the basic functions of the mobile
phone. The GSM connection is established
through the aerial of the mobile phone.
Universal audio interface
for PCM and CDR.
With this feature, the CDR audio system
is supplemented by an AUX inter face
(e.g. for connecting a compatible MP3
player) installed in the glove compart -
ment. In conjunction with optional PCM,
a USB port is included to enable you
to connect your iPod
® or a USB stick.
Whichever device is connected, it can be
controlled conveniently and safely using
PCM, the optional multifunction steering
wheel or the optional voice control
system. Through the USB port, it is also
possible to download data from the
performance display of the optional
Sport Chrono Package as well as data
from the optional electronic logbook.
CD or CD/DVD autochanger.
An integrated six- disc CD autochanger
is available for the CDR audio system on
request, while an integrated six- disc CD/
DVD autochanger is available for optional
PCM. Both support the playback of tracks
in MP3 format.
Sound Package Plus for PCM and CDR.
For sophisticated ears: the optionally
available Sound Package Plus.
With a total output of 185 wat ts, seven
loudspeakers combine to create the
perfect interior sound experience. Audio
set tings can be customised using the
CDR audio system or optional Porsche
Communication Management (PCM).
