4-16
Display screen,heaterandaircondition er,and audio system
and achime willsound once.While theMOD system
continues todetect moving objects, theyellow frame
continues tobe
displayed.
JVH0872X
bird's-eye view
JVH0873X
front view/rear view
In the bird's-eye view,the yellow frame
*
1
is
displayed oneach camera image(front,rear,right,
left) depending onwhere moving objects aredetected.
The yellow frame
*
2
is displayed onview inthe front
view orrear view modes.
While thesensor isbeeping, theMOD system does
not chime.
The MOD icon
*
3
is displayed inblue inthe view
where theMOD system isoperative. TheMOD icon
*
3
is displayed ingray inthe view where theMOD
system isnot operative.
If the MOD system isturned off,the MOD icon
*
3
is
not displayed.
The MOD system willactivate automatically underthe
following conditions:
. When theshift lever isin the ªRº (Reverse)
position.
. When theCAMERA/DISP buttonispushed to
switch fromadifferent screentothe camera view
on the display .
. When vehicle speeddecreases belowapproxi-
mately 8km/h (5MPH) .
. When theignition switchisplaced inthe ªOFFº
position andthen back tothe ªONº position.
The MOD system canbeset toremain inactive inthe
vehicle information display.(See ªDriver Assistanceº
(P .2-21) .)
WARNING:
. Excessive noise(forexample, audiosystem
volume oropen vehicle window) willinter-
fere with thechime sound, anditmay notbe
heard.
. The MOD system performance willbelim-
ited according toenvironmental conditions
and surrounding objectssuchas:
Ð When thereislow contrast between
background andthemoving objects.
Ð When thereisblinking sourceoflight.
Ð When strong lightsuch asanother
vehicle's headlight orsunlight ispre-
sent. Ð
When thereisdirt, water drops orsnow
on the camera lens.
Ð When theposition ofthe moving objects
in the display isnot changed.
. The MOD system mightdetect flowing water
droplets onthe camera lens,white smoke
from themuffler, movingshadows, etc.
. The MOD system maynotfunction properly
depending onthe speed, direction, distance
or shape ofthe moving objects.
. Ifyour vehicle sustains damagetothe parts
where thecamera isinstalled, leavingit
misaligned orbent, thesensing zonemaybe
altered andtheMOD system maynotdetect
objects properly.
. When thetemperature isextremely highor
low, thescreen maynotdisplay objects
clearly. Thisisnot amalfunction.
T urning theMOD system onoroff
GUID-A A5B2549-6C 8A-49E4-B44 8-E087C02404EF
The MOD system isturned onoroff using thevehicle
information display.See ªDriver Assistanceº (P.2-21) .
MOD malfunction
GUID-1ECC1 104-D4DE-4EF2-996D-E9161CFD D1F3
When theorange MODiconisdisplayed inthe view ,
the system isnot functioning properly.This willnot
hinder normal drivingoperation butthesystem should
be inspected byaNISSAN dealer.
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
Camera maintenance
GUID-7A0D AC5C-4528 -4068-A95F-D3E26A2A8BFA
If dirt, rainorsnow accumulates onthe camera, the
MOD system maynotoperate properly.Clean the
camera.
The camera washeroperates automatically whendirtis
detected onthe camera duringdriving. Thewasher
then stops operation afteraperiod oftime.
P ARK ASSIST (PA) (ifequipped)
GUID-E6 40D1F9-8120 -4679-81C7-8BB968C41799
Park Assist (PA) isdesigned toassist drivers with
parallel andperpendicular parking.
This system willoperate thesteering wheeltopark the
vehicle inthe parking spacesetbythe driver onthe
bird's-eye viewscreen (perpendicular mode),or
measured byparking sensors (sonar)inthe left/right
side ofthe front bumper (parallel mode).Screen
guidance forthe shift lever operation isalso provided
during theparking maneuvers.
WARNING:
. PA is designed tosupport thedriver's
steering wheeloperation inaparking lot.It
does notautomatically lowerthevehicle
speed oravoid contact withobjects. As
when performing ordinaryparkingmaneu-
vers, always lookoutthewindows andcheck
with your owneyes tobe sure thatthe
surrounding androad conditions aresafe for
the maneuvers beforeoperating thevehicle.
Operate thevehicle slowlyduring thepark -
ing maneuvers. Ifthe vehicle getsclose to
people orobjects nearthevehicle, avoid
making contactbyusing thebrakes and
performing othermaneuvers.
. Do not touch thespoke ofthe steering
wheel whilethePA is operating. Itcould cause
injuries tohands orfingers. Keep
neckties, scarves.etc.away fromthesteer-
ing wheel sincetheymaygetentangled and
cause unexpected accidents.
Parallel parking
GUID-BA4 0D95E-DF24-468C-84 62-B4899000 9BD2
Displayed keysandicons:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94A EAE0
JVH1017X
JVH1016X
JVH1021X
*
1
:
T ouch thiskeytoactivate thePA system.
*
2
:
The green PA icon indicates thatthePA is
operating.
*
3
Cancel:
T ouch thiskeytocancel thePA operation.
*
4
:
T ouch thiskeytoselect perpendicular mode.
*
5
:
Indicates thatanautomated steeringcontrolis
operating.
Display screen,heaterandairconditioner ,and audio system
4-17
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
. Make surethatthere isenough spacefor
parking maneuvers beforestarting touse
the PA .
. Keep inmind thatthefront ofthe vehicle
may swing outtowards oncoming traffic
while thePA functions.
CAUTION:
Do not use thePA under thefollowing condi-
tions.
. Onunpaved roads.
. Onslippery roadssuchassnow-covered or
frozen roads.
. Onuneven roadswithslants, bumps, curb-
stones, wheeltracks, etc.
. Oncurved roads.
. Atmechanical parkingfacilities.
. Where parking orstopping isprohibited.
. When tirechains oraspare tireareinstalled.
. When thevehicle isbeing towed.
. When thedoors (including theback door)
are not closed.
. When transporting aload thatprotrudes
from yourvehicle.
. When thevehicle isladen withheavy loads.
NO TE:
. Under theconditions listedbelow, theremay
be instances inwhich surrounding objectsor
vehicles cutinto thevehicle pathway, or
when thevehicle cannotbeparked inthe
correct spotfollowing thePA operation, etc. Ð
When theshift lever isoperated while
driving.
Ð When sudden start,sudden stopor
sudden operation ofthe shift lever oc-
curs.
Ð When thetire pressure istoo low orthe
tire isworn out.
Ð When tiresareinstalled thatareofa
different sizefrom theones thatwere
equipped atthe time offactory shipment.
. When usingtheparallel parking mode,itis
not always possible forthe system tofind an
appropriate parkingspaceandmay indicate
parking spacesthatarenot suitable for
parking. Following areexample conditions
for which thesystem maynotfind aparking
space correctly.
Ð Parking spaceswithobjects located
above theheight rangeofparking sen-
sors (sonars) (i.e.,overhanging loads,tail
sections orloading rampsofgoods
vehicles) .
Ð Parking spacesthatarepartially occu-
pied bytrailer drawbars.
Ð Parking spacesthatarelittered orover-
grown.
Ð Parking spaceswhereacurb exists
(causing damageofthe wheels andtires) .
Ð Parking spacesthatareblocked by
foliage, grass,paving, blocks,etc.
Ð Parking spacesbordered byan obstacle
(i.e., atree, apost oratrailer) .
Ð Parking spaceswithobjects thatabsorb
ultrasonic wavessuchasfabric andsnow. Ð
During snowfall orheavy rain.
Ð Near objects thatemits ultrasonic waves
such ashorns ofother vehicle, noisefrom
a motorcycle engineandlarge automo-
bile airbrake, orsensors ofsurrounding
vehicles.
Ð When theconditions surrounding the
parking spacechange (i.e.,another vehi-
cle enters thetarget parking spaceafter
you pass it).
Operating tips:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
. The parking sensor(sonar) willautomatically turn
on when thePA is activated. WhenthePA
operation ends,thestatus ofthe parking sensor
(sonar) willreturn tothe mode thatitwas inbefore
the PA was activated.
. Depending onthe situation, theshift lever opera-
tions mayberequired severaltimes.
Malfunction:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
A warning message willbedisplayed andthesystem
will terminate operation whenamalfunction isdetected
in the PA .
When thewarning message isdisplayed duringthePA
operation, parkthevehicle inasafe place andrestart
the engine.
If the warning message isshown onthe display
repeatedly orifthe PA cannot beoperated after
restarting theengine, thismay indicate asystem
malfunction. Itshould nothinder normal driving, but
the vehicle shouldbeinspected byaNISSAN dealer.
Display screen,heaterandairconditioner ,and audio system
4-23
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
4-24
Display screen,heaterandaircondition er,and audio system
Maintenance
GUID-1BAC6 224-3866-47EB-B1C3 -361B4F698 45E
Refer toªAround viewmonitorº (P.4-10) formain-
tenance ofthe camera lens.
Blockages likedirt, ice,and objects suchasstickers
and accessories installedwithinthedetection rangeof
the parking sensor(sonar) maycause incorrect
function ofthe PA .Clean thesensors regularly with
care, anddonot scratch ordamage
them.
JVH0916X
Parking sensors (sonar)arelocated onthe bumpers: 6
on the front bumper and4on the rear bumper.
HOW TO ADJUST THESCREEN
GUID-81 8DAAB9-9049 -4E59-8622-4E833C2CFC8C
Adjusting screen(formodels withnavigation
system)
GUID-62022A5 F-F9E8-4734-9FFC-33 55CDF49BCA
Operation withtouch screen:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
1. Push theSETUP button.
2. Select theªSystemº key.
3. Select theªCamera DisplaySettingsº key.
4. Select theitem youwish toadjust.
. Display Mode:
Adjusts tofitthe level oflighting inthe vehicle.
T ouch theªDisplay Modeºkeytocycle through
options ofthe mode (Day,Night andAuto) .
. Brightness:
Adjusts thebrightness ofthe display .
. Contrast :
Adjusts thelevel ofcontrast.
. Color:
Adjusts thelevel ofthe color.
Operation withbuttons:
GUID-2201 8305-9BAB- 4201-B6FC-C08EB94AEAE0
JVH0649X
T o adjust thescreen brightness whentheAround View
Monitor isdisplayed, pushthedisplay control/display on´off
ª
º button
*
1
.
Adjust brightness tothe preferred settingusingthe
ENTER/Scroll dial
*
2
.
Adjust screen (formodels without navigation
system)
GUID-24EA 2981-374F-43 F8-AF7E-16E6099FDB6 A
JVH0660X
T o set upthe Around ViewMonitor toyour preferred
settings, pushtheENTER/SETTING button
*
1
while
the Around ViewMonitor screenisdisplayed. Each
time theENTER/SETTING button
*
1
is pushed, the
next setting itemisselected. Turn theTUNE´FOLDER
dial
*
2
to adjust eachitem.
Available settingitems:
. Brightness
. Contrast
The setting itemswilldisappear andthedisplay will
return tothe original screenifENTER/SETTING button
*
1
is pushed whenthelast setting itemisselected or
if the screen isnot operated forsome time.
Choosing alanguage:
The warning message onthe camera screenflashes
when theDISP button
*
3
is pushed andheld formore
than 6seconds. Thelanguage ofthe warning message
changes whentheDISP button
*
3
is pushed again
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
For models withStop/Start SystemorIdling
Stop System:
While theengine isstopped bythe Stop/Start System
or the Idling StopSystem, switching theairflow tothe
front defogger willcause theengine toautomatically
restart.
While theengine isrunning, selecting airflowtothe
front defogger willprevent theStop/Start Systemor
Idling StopSystem fromautomatically stoppingthe
engine.
When theengine isstopped bythe Stop/Start System
or Idling StopSystem, heaterandairconditioner
performance maybereduced. To keep fullheater and
air conditioner performance, restarttheengine by
pushing theStop/Start SystemOFFswitch orthe
Idling StopSystem OFFswitch, orby placing the
ignition switchinthe ªONº position. Formore details
see ªStop/Start SystemorIdling StopSystemº (P.5-
18) .
OPERA TINGTIPS(forautomatic aircondi-
tioner)
T32A1308 27-94E48E 8C-CACC-4 A8C-8478-31C 17097E10D
JVH0727X
JVH0728X
When theengine coolant temperature andoutside air
temperature arelow,the airflow from thefoot outlets
may notoperate. However, thisisnot amalfunction.
After thecoolant temperature warmsup,the airflow
from thefoot outlets willoperate normally.
The sensors
*
1
and
*
2
, located onthe instrument
panel, helpmaintain aconstant temperature. Donot
put anything onoraround thesensors.
Display screen,heaterandairconditioner ,and audio system
4-27
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
Blind SpotWarning (BSW) system(ifequipped forEurope) ....
.... 5-36
BSW system operation ....
................................................. ...............5-36
BSW driving situations ....
...................................................... ...........5-38
BSW temporary disabledstatus....
................................................ 5-39
BSW automatic deactivation ....
....................................... ...............5-39
BSW malfunction ....
................................................................ ...........5-39
Camera unitmaintenance ....
................................................. ...........5-39
Lane Departure Warning (LDW) system (ifequipped
for Europe) ....
............................................ ................................................. 5-39
LDW system operation ....
...................................................... ...........5-40
T emporary disabledstatusathigh temperature ....
..................... 5-41
Multi-sensing cameraunitmaintenance ....
................................... 5-41
Speed limiter(ifequipped) ....
................................................. ...............5-41
Speed limiteroperations ....
.............................................................. 5-41
Cruise control (ifequipped) ....
.............................................................. 5-43
Precautions oncruise control ....
..................................................... 5-43
Cruise control operations ....
................................................. ...........5-44
Forward emergency brakingsystem(ifequipped) ....
...................... 5-45
System operation ....
................................................................ ...........5-45
ECO mode system (ifequipped) ....
..................................................... 5-47
ECO Pedal Guide function ....
......................................................... 5-47
Ambient ECO....
...................................................... ............................5-47
ECO Drive Report ....
................................................. ........................5-48
Parking ....
....................................... .............................................................. 5-48
Parking sensor(sonar) system(ifequipped) ....
................................ 5-50
Parking sensor(sonar) systemOFFswitch (ifequipped) ....
.... 5-51
Parking sensor(sonar) systemsetting ....
..................................... 5-52T
railer towing (except forAustralia, NewZealand, SouthAfrica
and Europe) ....
................................................. .........................................5-52
T railer towing (forAustralia, NewZealand, SouthAfrica
and Europe) ....
................................................. .........................................5-52
Operating precautions ....
....................................... ........................5-52
Maximum loadlimits (forAustralia andNew Zealand) ....
...... 5-53
Tire pressure ....
................................................. ................................5-55
Safety chains ....
....................................... ......................................... 5-55
T railer brakes ....
....................................... ......................................... 5-55
T railer detection (ifequipped) ....
....................................... ...........5-55
Coupling deviceinstallation (forEurope) ....
.............................. 5-56
Electric powersteering system....
................................................. .......5-56
Brake system ....
................................................................ ........................5-57
Brake precautions ....
....................................... ................................5-57
Brake assist ....
...................................................... ............................5-58
Anti-lock BrakingSystem(ABS)....
............................................. 5-58
V ehicle security ....
............................................ .........................................5-59
Cold weather driving....
................................................................ ...........5-59
Battery ....
................................................................ ............................5-59
Engine coolant ....
................................................. ............................5-59
Tire equipment ....
................................................. ............................5-59
Special winterequipment ....
.......................................................... 5-60
Parking brake....
....................................... ......................................... 5-60
Corrosion protection ....
....................................... ............................5-60
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
soon aspossible, andinflate themtothe proper
pressure. Drivingonasignificantly under-inflated tire
causes thetiretooverheat andcanlead totire failure.
Under-inflation alsoreduces fuelefficiency andtire
tread life,and may affect thevehicle's handlingand
stopping ability.
Please notethattheTPMS isnot asubstitute for
proper tiremaintenance, anditis the driver's respon-
sibility tomaintain correcttirepressure, evenifunder-
inflation hasnotreached thelevel totrigger illumination
of the TPMS lowtirepressure telltale.
Y our vehicle hasalso been equipped withaTPMS
malfunction indicatortoindicate whenthesystem is
not operating properly.The TPMS malfunction indica-
tor iscombined withthelow tirepressure telltale.
When thesystem detects amalfunction, thetelltale will
flash forapproximately oneminute andthen remain
continuously illuminated.Thissequence willcontinue
upon subsequent vehiclestart-ups aslong asthe
malfunction exists.Whenthemalfunction indicatoris
illuminated, thesystem maynotbeable todetect or
signal lowtirepressure asintended. TPMSmalfunc-
tions mayoccur foravariety ofreasons, including the
installation ofreplacement oralternate tiresorwheels
on the vehicle thatprevent theTPMS fromfunctioning
properly .Always checktheTPMS malfunction telltale
after replacing oneormore tiresorwheels onyour
vehicle toensure thatthereplacement oralternate tires
and wheels allowtheTPMS tocontinue tofunction
properly .
Additional information
GUID-2100EB 5C-6E9C-4DF0-9BA3-E30F03EA4 592
. The TPMS doesnotmonitor thetirepressure of
the spare tire.
. The TPMS willactivate onlywhen thevehicle is
driven atspeeds above25km/h (16MPH) .Also,
this system maynotdetect asudden dropintire
pressure (forexample aflat tire while driving) .
. The lowtirepressure warninglightmaynot
automatically turnoffwhen thetirepressure is
adjusted. Afterthetireisinflated tothe recom-
mended pressure, resetthetire pressures regis-
tered inyour vehicle andthen drive thevehicle at
speeds above25km/h (16MPH) toactivate the
TPMS andturn offthe low tirepressure warning
light.
. Depending onachange inthe outside tempera-
ture, thelow tirepressure warninglightmay
illuminate evenifthe tire pressure hasbeen
adjusted properly.Adjust thetirepressure tothe
recommended COLDtirepressure againwhen
the tires arecold, andreset theTPMS.
. You can check thepressure ofall tires inthe
vehicle information display.(See ªTrip computerº
(P .2-34) .)
For additional information, seeªLow tirepressure
warning lightº(P.2-14) .
WARNING:
. Ifthe low tirepressure warninglightillumi-
nates whiledriving, avoidsudden steering
maneuvers orabrupt braking, reducevehicle
speed, pulloffthe road toasafe location
and stop thevehicle assoon aspossible.
Driving withunder-inflated tiresmayperma-
nently damage thetires andincrease the
likelihood oftire failure. Serious vehicle damage
couldoccurandmay lead toan
accident andcould result inserious personal
injury. Check thetire pressure forallfour
tires. Adjust thetire pressure tothe recom-
mended COLDtirepressure shownonthe
tire placard toturn thelow tirepressure
warning lightoff.Ifthe light stillilluminates
while driving afteradjusting thetire pres-
sure, atire may beflat. Ifyou have aflat tire,
replace itwith aspare tireassoon as
possible. (SeeªFlat tireº(P.6-2) forchanging
a flat tire.)
. After adjusting thetire pressure, besure to
reset theTPMS. Otherwise, theTPMS will
not warn oflow tirepressure.
. When aspare tireismounted orawheel is
replaced, theTPMS willnotfunction andthe
low tirepressure warninglightwillflash for
approximately 1minute. Thelight willre-
main onafter the1minute. Contact a
NISSAN dealerassoon aspossible fortire
replacement and/orsystem resetting.
. Replacing tireswiththose notoriginally
specified byNISSAN couldaffect theproper
operation ofthe TPMS.
. Donot inject anytireliquid oraerosol tire
sealant intothetires, asthis may cause a
malfunction ofthe tire pressure sensors.
CAUTION:
. The TPMS maynotfunction properly when
the wheels areequipped withtirechains or
the wheels areburied insnow.
. Do not place metalized filmorany metal
parts (antenna, etc.)on the windows. This
may cause poorreception ofthe signals
Starting anddriving
5-5
&RQGLWLRQ
([FHSWIRU&KLQD



> (GLW    0RGHO 7$@
5-6
Starting anddriving
from thetire pressure sensors,andthe
TPMS willnotfunction properly.
Some devices andtransmitters maytemporarily inter-
fere with theoperation ofthe TPMS andcause thelow
tire pressure warninglighttoilluminate. Someexam-
ples are:
. Facilities orelectric devices usingsimilar radio
frequencies arenear thevehicle.
. Ifatransmitter settosimilar frequencies isbeing
used inor near thevehicle.
. Ifa computer (orsimilar equipment) oraDC/AC
converter isbeing usedinor near thevehicle.
FCC Notice:
For USA:
This device complies withPart15ofthe FCC
Rules. Operation issubject tothe following two
conditions: (1)This device maynotcause harm-
ful interference, and(2)this device mustaccept
any interference received,including interference
that may cause undesired operation.
Note: Changes ormodifications notexpressly
approved bythe party responsible forcompli-
ance could voidtheuser's authority tooperate
the equipment.
For Canada:
This device complies withIndustry Canada
licence-exempt RSSstandard(s) .Operation is
subject tothe following twoconditions: (1)this
device maynotcause interference, and(2)this
device mustaccept anyinterference, including
interference thatmay cause undesired operation
of the device.
TPMS resetting
GUID-F7 6622F1-0B9 8-4141-BFE3 -22038209B548
T o keep theTPMS functioning properly,the reset
operation mustbeperformed inthe following cases.
. when thetirepressure isadjusted
. when atire orawheel isreplaced
. when thetires arerotated
Perform thefollowing procedures toreset theTPMS.
1. Park thevehicle inasafe andlevel place.
2. Apply theparking brakeandplace theshift lever in
the ªPº (Park) position.
3. Adjust thetire pressure onallfour tires tothe
recommended COLDtirepressure shownonthe
tire placard. Useatire pressure gaugetocheck
the tirepressure.
4. Place theignition switchinthe ªONº
position.
JVS0434X
Steering-wheel- mountedcontrols(leftside)
5. Use the
switch
*
1
until ªSettingsº appears,
and press ENTER
*
1
.
6. Use the
switch
*
1
until ªTire Pressuresº is
selected, andpress ENTER
*
1
.
7. Use the
switch
*
1
until ªCalibrateº is
selected, andpress ENTER
*
1
. 8.
Use the
switch
*
1
until ªStartº isselected,
and press ENTER
*
1
to reset theTPMS. When
the TPMS resetting starts,themessage ªTPMS
resettingº willbedisplayed.
9. After resetting theTPMS, drivethevehicle for
several minutes atspeeds above25km/h (16
MPH) .
If the low tirepressure warninglightilluminates after
the resetting operation, itmay indicate thattheTPMS
is not functioning properly.Have thesystem checked
by aNISSAN dealer.
For information regardingthelow tirepressure warning
light, seeªLow tirepressure warninglightº(P.2-14) .
DIESEL PARTICULA TEFILTER (DPF) (if
equipped)
GUID-5A9 CD1A0-AAA1 -48F8-8DC8-EB7CA86C2 ADF
WARNING:
. Becareful nottoburn yourself withexhaust
gases.
. Do not park thevehicle overflammable
materials suchasdry grass, wastepaperor
rags, asthey mayburn easily.
. Use thespecified engineoilfor Diesel
Particulate Filter(DPF) equipped models.
For details, seeªRecommended Fluids/lu-
bricants andcapacitiesº (P.9-2) .
CAUTION:
The DPF becomes extremely hotafter burning
particulate matter.
&RQGLWLRQ
([FHSWIRU&KLQD
