2011 NISSAN LEAF tire pressure

.NISSAN recommends using only
NISSAN Genuine Emergency Tire
Sealant provided with your vehicle.
Other tire sealants may damage the
valve stem seal which can cause the
tire to lose air pressure.

6 In case of emergency
Roadside assistance program .............................................. 6-2
Emergency EV (Electric Vehicle) shut off .......................... 6-2 Flat tire ........................................................................................ 6-2
Tire Pressure Monitoring System (TPMS) ................... 6-2
Repairing flat tire ................................................................ 6-3
Jump starting ............................................................................. 6-9
If the Li-ion battery becomes completely discharged ... 6-11 Push starting .......................................................................... 6-12
Tools ........................................................................................ 6-12
Towing your vehicle ............................................................. 6-13
Towing recommended by NISSAN .......................... 6-14
Vehicle recovery (freeing stuck vehicle) ................. 6-15
Parking brake mechanical release ................................... 6-16

and increase the likelihood of tire
failure. Serious vehicle damage
could occur and may lead to an
accident and could result in serious
personal injury. Check the tire pres-
sure for all four tires. Adjust the tire
pressure to the recommended COLD
tire pressure shown on the Tire and
Loading Information label to turn
the low tire pressure warning light
OFF. If the light still illuminates
while driving after adjusting the tire
pressure, a tire may be flat. If you
have a flat tire, repair it as soon as
possible.
. When a wheel is replaced, the TPMS
will not function and the low tire
pressure warning light will flash for
approximately 1 minute. The light
will remain on after 1 minute. Con-
tact a NISSAN certified LEAF dealer
as soon as possible for tire replace-
ment and/or system resetting.
. Replacing tires with those not ori-
ginally specified by NISSAN could
affect the proper operation of the
TPMS. .
If you used the Emergency Tire
Sealant to repair a minor tire punc-
ture, your NISSAN certified LEAF
dealer will also need to replace the
TPMS sensor in addition to repair-
ing or replacing the tire.
. NISSAN recommends using only
NISSAN Genuine Emergency Tire
Sealant provided with your vehicle.
Other tire sealants may damage the
valve stem seal which can cause the
tire to lose air pressure.
REPAIRING FLAT TIRE

5. Remove the protective cap*Aof the hose
and screw the hose securely onto the tire
valve. Make sure that the pressure release
valve
*Bis securely tightened. Make sure
that the air compressor switch is in the OFF
(O) position, and then insert the power plug
into the power outlet in the vehicle.

If the tire pressure does not increase to26
psi (180 kPa) within 10 minutes, the tire
may be seriously damaged and the tire
cannot be repaired with this tire repair
kit. Contact a NISSAN certified LEAF
dealer.
7. When the tire pressure is at the specified amount, turn the air compressor off. If the
tire cannot be inflated to the specified
amount, the air compressor can be turned
off at the minimum of 26 psi (180 kPa) .
Remove the power plug from the power
outlet and quickly remove the hose from the
tire valve. Attach the protective cap and
valve cap. Properly stow the emergency tire
puncture repair kit in the cargo area.

Incorrect tire pressure, including un-
der inflation, may adversely affect tire
life and vehicle handling.

5.Three-digit code: Date of Manufacture
6.Four numbers represent the week and
year the tire was built. For example, the
numbers 3103 means the 31st week of
2003. If these numbers are missing,
then look on the other sidewall of the
tire.
*3Tire ply composition and material
The number of layers or plies of rubber-
coated fabric in the tire.
Tire manufacturers also must indicate
the materials in the tire, which include
steel, nylon, polyester, and others.
*4Maximum permissible inflation pressure
This number is the greatest amount of
air pressure that should be put in the
tire. Do not exceed the maximum
permissible inflation pressure.
*5Maximum load rating
This number indicates the maximum
load in kilograms and pounds that can
be carried by the tire. When replacing
the tires on the vehicle, always use a
tire that has the same load rating as the
factory installed tire.
*6Term of “tubeless” or “tube type”
Indicates whether the tire requires aninner tube (“tube type”) or not (“tube-
less”) .
*7The word “radial”
The word “radial” is shown, if the tire
has radial structure.
*8Manufacturer or brand name
Manufacturer or brand name is shown.
Other tire-related terminology:
In addition to the many terms that are
defined throughout this section, Intended
Outboard Sidewall is (1) the sidewall that
contains a whitewall, bears white lettering
or bears manufacturer, brand and/or model
name molding that is higher or deeper than
the same molding on the other sidewall of
the tire, or (2) the outward facing sidewall
of an asymmetrical tire that has a particular
side that must always face outward when
mounted on a vehicle.
TYPES OF TIRES

Interior light replacement........................................... 8-22
Interior lights................................................................. 2-56
ISOFIX child restraint................................................. 1-20
J
Jump starting.................................................................. 6-9
K
Keyless entryWith Intelligent Key system (See Intelligent
Key system) ........................................................... 3-13
Keys.................................................................................. 3-2 For Intelligent Key system..................................... 3-6
L
LabelsAir bag warning labels........................................ 1-50
Air conditioner specification label....................... 9-8
Emission control information label...................... 9-7
F.M.V.S.S./C.M.V.S.S. certification label ........... 9-7
Motor serial number ............................................... 9-7
Tire and Loading information label ......... 8-27, 9-8
Vehicle identification number (VIN) .................... 9-6
LATCH system............................................................. 1-20
License plate, Installing front license plate ............ 9-9
Light Air bag warning light........................................... 1-50
Bulb replacement................................................. 8-20
Ceiling light............................................................ 2-57
Fog light switch.................................................... 2-44
Headlight switch................................................... 2-41
Headlights bulb replacement............................ 8-21
Indicator lights....................................................... 2-18
Interior lights.......................................................... 2-56 Map lights .............................................................. 2-56
Replacement.......................................................... 8-20
Warning lights....................................................... 2-13
Light reminder warning.............................................. 2-25
Lights, Exterior and interior light replacement ..... 8-22
Li-ion battery................................................................. EV-2
Li-ion battery available charge gauge...................... 2-9
Li-ion battery capacity level gauge......................... 2-10
Li-ion battery heater ................................................... EV-5
Li-ion battery status check ................................... CH-24
Li-ion battery temperature gauge.............................. 2-7
Limited power .............................................................. 2-32
Loading information (See vehicle
loading information) .................................................... 9-10
Lock Automatic door locks ............................................. 3-5
Door locks................................................................. 3-4
Power door lock...................................................... 3-4
Rear hatch lock..................................................... 3-17
Long life mode......................................................... CH-21
Low tire pressure warning light............................... 2-16
Low tire pressure warning system (See tire
pressure monitoring system (TPMS)) ...................... 5-2
Luggage side hook..................................................... 2-53
M
Maintenance 12-volt battery....................................................... 8-11
General maintenance ............................................. 8-2
Indicators for maintenance ................................ 2-33
Inside vehicle............................................................ 8-3
Maintenance precautions...................................... 8-4
Maintenance requirements.................................... 8-2
Outside vehicle........................................................ 8-2
Seat belt maintenance........................................ 1-16
Manual front seat adjustment..................................... 1-3 Map lights ..................................................................... 2-56
Mechanical key (Intelligent Key system) ................. 3-3
Meters and gauges....................................................... 2-5
Mirror
Inside rearview mirror.......................................... 3-20
Outside mirrors..................................................... 3-21
Vanity mirror........................................................... 3-22
Motor..................................................................... 5-11, 9-5 Before starting system........................................ 5-10
Motor compartment ...................................................... 8-6
N
NISSAN Vehicle Immobilizer System..................... 2-36
Normal charge Home charge........................................................ CH-9
Occasional charge.............................................. CH-9
Public charge ....................................................... CH-9
O
Odometer........................................................................ 2-6
Off-road recovery.......................................................... 5-5
Oil Capacities and recommended lubricants ......... 9-2
Opening rear hatch .................................................... 3-11
Outside air temperature ............................................ 2-10
Outside mirrors............................................................ 3-21
Owner’s Manual/Service Manual
order information ......................................................... 9-19
P
Panic alarm................................................................... 3-14
Parking Electric parking brake operation ...................... 5-15
Parking on hills ..................................................... 5-20
Index10-3
