2011 MERCEDES-BENZ E-CLASS SALOON belt

Battery (key)
Checking .......................................... 85
Important safety notes ....................84
Replacing ......................................... 85
Battery (vehicle)
Charging ........................................ 352
Connecting .................................... 352
Disconnecting ................................ 352
Display message ............................ 264
Important safety notes ..................350
Jump starting ................................. 354
Location ......................................... 351
Removing/fitting ........................... 352
Belt
see Seat belt
Belt force limiters (activation) ...........43
Belt tensioner Activation ......................................... 43
Function .......................................... .53
Blind Spo tAssist
Activating/deactivating .................242
Display message ............................ 269
Notes/function .............................. 212
Trailer towing ................................. 214
see Active Blind Spot Assist
BlueTEC (AdBlue ®
) ............................. 388
Bonnet Active bonnet (pedestrian protec-
tion) ............................................... 320
Closing .......................................... .322
Display message ............................ 276
Opening ......................................... 321
Boot
Emergency release ..........................94
Important safety notes ....................91
Opening/closing (automatically
from inside) ...................................... 93
Opening/closing (automatically
from outside) ................................... 92
Boot lid
Display message ............................ 276
Opening/closing .............................. 91
Opening dimensions ......................394
Bottle holder ...................................... 309
Box (boot) .......................................... .302
Brake Assist System see BAS (Brake Assist System) Brake fluid
Display message ............................ 256
Notes ............................................. 390
Brake lamps
Adaptive .......................................... .71
Display message ............................ 260
Brakes
ABS .................................................. 70
BAS .................................................. 70
BAS PLUS ........................................ 70
Brake fluid (notes) .........................390
Display message ............................ 254
Driving tips .................................... 178
High-performance brake system ....179
Important safety notes ..................178
Parking brake ................................ 177
Warning lamp ................................. 281
Breakdown
see Flat tyre
see Towing away/tow-starting
Bulbs
see Changing bulbs C
Calling up a fault see Display messages
Capacities
see Technical data
Car
see Vehicle
Care
Automatic car wash .......................327
Carpets .......................................... 333
Display ........................................... 331
Exterior lighting ............................. 329
Gea rors electo rlever .................... 332
High-pressure cleaner .................... 328
Interior ........................................... 331
Matt paintwork .............................. 328
Nigh tView Assist Plus ...................331
Notes ............................................. 326
Paint .............................................. 328
Plastic trim .................................... 331
Reversing camera ..........................330
Roof lining ...................................... 333
Seat bel t........................................ 332
Seat cover ..................................... 3326
Index

Sensors
......................................... 330
Steering wheel ............................... 332
Tai lpipes ....................................... 330
Trim pieces .................................... 332
Washing by hand ........................... 327
Wheels ........................................... 328
Windows ........................................ 329
Wiper blades .................................. 329
Wooden trim .................................. 332
Car key
see Key
Car wash (care) ................................. 327
CD player/CD changer(on-board
computer) .......................................... 238
Cell phone see Mobile phone
Central locking
Automatic locking (on-board com-
puter) ............................................. 246
Locking/unlocking (key ).................. 82
Centre console
Lowe rsection .................................. 35
Lowe rsection (AMG vehicles) ..........37
Uppe rsection .................................. 34
Changing bulbs
Dipped-bea mheadlamps ............... 131
Important safety notes ..................129
Infrared lamp ................................. 132
Main-beam headlamps ................... 131
Overview of bul btypes .................. 130
Parking lamps (front) .....................131
Standing lamps .............................. 131
Turn signals (front) ......................... 132
Child-proof locks
Important safety notes ....................68
Rea rdoors ....................................... 68
Children
Fastening seat belts ......................... 61
In the vehicle ................................... 53
Restraint systems ............................ 53
Child seat
Automatic recognition .....................56
Display message ............................ 258
Integrated ........................................ 60
Integrated, ICS padded pla ytable ....62
Integrated, side head restraints .......63
Integrated ,storing ........................... 64
ISOFIX .............................................. 57 On the front-passenger sea
t............ 55
Problem (malfunction) .....................60
Recommendations ...........................67
Suitable positions ............................ 65
Cigarette lighter ................................ 311
Cleaning Mirro rturn signal ........................... 330
Trailer tow hitch ............................. 330
Climate control
Auxiliary heating/ventilation .......... 145
Controlling automatically ...............140
Convenience opening/closing
(air-recirculatio nmode) ................. 144
Cooling with aird ehumidification..139
Demisting the windows .................. 143
Demisting the windscreen .............142
Important safety notes ..................136
Indicator lamp ................................ 140
Notes on using THERMATIC auto-
matic climate control .....................137
Notes on using THERMOTRONIC
automatic climate control ..............139
Overview of systems ......................136
Problems with cooling with air
dehumidification ............................ 140
Problem with the rear window
heating .......................................... 143
Rea rcontrol panel ......................... 138
Setting the aird istribution.............141
Setting the airflow .........................142
Setting the airv ents...................... 149
Setting the climate mode .............. .140
Setting the temperature ................141
Switching air-recirculation mode
on/off ............................................ 144
Switching on/off ........................... 139
Switching residual hea ton/off ......145
Switching the rear window heat-
ing on/off ...................................... 143
Switching the ZONE function on/
off .................................................. 142
THERMATIC automatic climate
control (2-zone) ............................. 137
THERMOTRONIC (3-zone) auto-
matic climate control .....................138
Clock( on-board computer) ...............244
Coat hooks ......................................... 301 Index
7

Park Assist
Parking Guidance ........................... 203
Parking ............................................... 176
Important safety notes ..................176
Parking brake ................................ 177
Position of exterior mirror, front-
passenger side ............................... 118
Reversing camera ..........................206
see PARKTRONIC
Parking aid
see Exterior mirrors
see PARKTRONIC
Parking brake .................................... 177
Display message ............................ 255
Notes/function .............................. 177
Parking Guidance
Display message ............................ 269
Important safety notes ..................203
Trailer towing ................................. 206
Parking lamps
Changing bulbs .............................. 131
Display message ............................ 261
Switching on/off ........................... 122
Parking lamps (changing bulbs) ......131
PARKTRONIC Deactivating/activating .................202
Driving system ............................... 200
Function/notes ............................. 200
Important safety notes ..................200
Problem (fault) ............................... 203
Sensor range ................................. 200
Trailer towing ................................. 202
Warning displa y............................. 201
PASSENGE RAIRBAG OFF warning
lamp ...................................................... 56
Permanent four-wheel drive see 4MATIC (permanen tfour-
wheel drive)
Petrol .................................................. 385
Plastic hooks ..................................... 298
Plastic trim (cleaning instructions) .331
Power windows see Side windows
PRE-SAFE ®
(preventive occupant
safety system) Display message ............................ 256
Operation ........................................ .48PRE-SAFE
®
Brake
Activating/deactivating .................241
Display message ............................ 257
Function/notes ................................ 75
Warning lamp ................................. 287
Preventive occupant safety sys-
tem
see PRE-SAFE ®
(preventive occu-
pant safety system)
Program selector button ..................168
Pulling away Automatic transmission .................158
Manual transmission ..................... .157 Q
Qualifie dspecialis tworkshop ...........25 R
RACE START (AMG vehicles) .............196
RACETIMER (on-board computer) ....250
Radar sensor system Activating/deactivating .................247
Country overview ........................... 398
Display message ............................ 268
Radiator cover ................................... 322
Radio Selecting astation ......................... 237
see separate operating instructions
Rain closing feature
Panorama sliding sunroo f.............. 100
Sliding sunroo f................................. 99
Reading lamp ..................................... 128
Rear bench seat Folding the backres tforwards/
back ............................................... 295
Rear compartment
Setting the airflow .........................142
Setting the airv ents...................... 150
Setting the temperature ................141
Rear-compartment seat belt sta-
tus indicator ........................................ 52
Rear foglamp Display message ............................ 261
Switching on/off ........................... 123
Rear seat
Display message ............................ 27716
Index

Rear-view mirror
Anti-dazzle mode (automatic) ........118
Dipping (manual )........................... 116
Rear window blind ............................310
Rear window heating Problem (fault) ............................... 143
Switching on/off ........................... 143
Rear window wiper
Switching on/off ........................... 133
Refuelling
Fuel gauge ....................................... 30
Important safety notes ..................172
Refuelling proces s......................... 173
see Fuel
Releasing the parking loc kman-
ually (automatic transmission) ........172
Remote control Auxiliary heating/ventilation .......... 146
Changing the batteries (auxiliary
heating) ......................................... 148
Garage door opene r....................... 315
Programming (garage door
opener) .......................................... 315
Replacing the battery (auxiliary
heating remote control) .................... 148
Reserve (fuel tank) see Fuel
Reserve fuel
Display message ............................ 264
Warning lamp ................................. 285
Residual heat (climate control) ........145
Restraint system see SRS (Supplemental Restraint
System)
Rev counter ........................................ 230
Reverse gear Engaging (automatic transmis-
sion) ............................................... 165
Engaging (manual transmission) ....164
Reversing camera
Cleaning instructions .....................330
Function/notes ............................. 206
Reversing lamp (display message) ..261
Roller blind see Roller sunblind Roller sunblind
Panorama sliding sunroo f.............. 100
Rea rwindow .................................. 310
Roof carrier ........................................ 306
Roof lining and carpets (cleaning
instructions) ...................................... 333
Roof load (maximum) ........................392
Route (navigation) see Route guidance (navigation)
Route guidance (navigation) ............236 S
Safety Childre ninthe vehicle ..................... 53
Child restraint systems ....................53
Safety net .......................................... .301
Attaching ....................................... 301
Safety systems
see Driving safety systems
Seat
Active multicontour sea t................ 109
Folding the backres t(rear com-
partment) forwards/back ..............297
Seat belt
Adjusting the driver's and front-
passenger sea tbelt ......................... 51
Adjusting the height ......................... 51
Belt force limiter .............................. 53
Belt tensione r.................................. 53
Centre rear-compartment sea t........ 52
Cleaning ......................................... 332
Display message ............................ 257
Fastening ......................................... 51
Important safety guidelines .............49
Rea rseat belt status indicator .........52
Releasing ......................................... 52
Switching belt adjustment on/off
(on-board computer) ......................249
Warning lamp ................................. 280
Warning lamp (function) ................... 52
Seats
Adjusting (electrically). ..................106
Adjusting (manually and electri-
cally) .............................................. 106
Adjusting lumba rsuppor t.............. 110
Adjusting the 4-way lumba rsup-
por t................................................ 110 Index
17

Warning and indicator lamps
Function Page
:
ESP
®
OFF 283
;
Diesel engine: preglow 157
=
Front foglamps 123
?
Rea
rfoglamp 123
A
Only for certain vehicles:
brakes (yellow)
281
B
SPORT handling mode in
AMG vehicles
284
C
Turn signal 124
D
ESP
® 283
E
Distance warning signal
287 Function Page
F
Main-beam headlamps 125
G
Dipped-beam headlamps 123
H
Seat belt 280
I
SRS 284
J
Engine diagnostics 285
K
Brakes (red) 281
L
Tyre pressure monitor 287
M
Coolant 285
N
ABS 282
O
Reserve fuel 28532
Instrument clusterAt a glance

Useful information
i This Owner's Manual describes all models
and all standard and optional equipment
available to your vehicle at the time of pub-
lication of the Owner's Manual. Country-
specific deviations are possible. Please
note that your vehicle may not be equipped
with all features described. This also
applies to safety-relevan tsystems and
functions.
i Please read the information on qualified
specialist workshops (Y page 25).Occupant safety
Important safety notes
The seat belts, together wit hSRS (Supple-
mental Restrain tSystem), are complemen-
tary, co-ordinated restrain tsystems
(Y page 43). They reduce the ris kofinjury
in specific, pre-defined types of accident sit-
uations and thereby increase occupant
safety .However, seat belts and airbags gen-
erally do not protec tagainst objects pene-
trating the vehicle from the outside.
To ensure that the restraint systems can
deliver their full potential protection, make
sure that:
R the seat and head restraint are adjusted
properly (Y page 104).
R the seat belt has been fastened properly
(Y page 51).
R the airbags can inflate unrestricted if
deployed (Y page 44).
R the steering wheel is adjusted properly
(Y page 104).
R the restraint systems have not been modi-
fied.
i An airbag increases the protection of
vehicle occupants wearing a seat belt.
However, airbags are only an additional
restraint system which complements, but
does not replace, the seat belt. All vehicle occupants must wear their seat belt cor-
rectly at all times, even if the vehicle is
equipped with airbags. The airbags are not
deployed in all types of accidents. For
example, if the protective capacity of cor-
rectly fastened seat belts is not increased
by deploying the airbags, the airbags will
not deploy. Airbag deployment only pro-
vides increased protection if the seat belt
is worn correctly because:
R
the seat belt helps to keep the vehicle
occupant in the best position in relation
to the airbag.
R in a head-on collision, for example, the
seat belt prevents the vehicle occupant
from being propelled towards the point
of impact. It can thus reduce the risk of
injury.
In accidents in which an airbag is deployed,
it provides increased protection only if the
seat belt is worn correctly. G
WARNING
If service work is not carried out correctly, the
operating safety of your vehicle may be affec-
ted. This could cause you to lose control of
your vehicle and cause an accident .More-
over, the safety systems may no longer be
able to protect you or others as they are
designed to do.
Always have service work carried out at a
qualified specialist workshop. G
WARNING
Modifications to or work performed incor-
rectly on the following parts can result in the
restraint systems not functioning as intended:
R the restraint system, consisting of seat
belts and their anchorage points, belt ten-
sioners, belt force limiters and airbags
R the wiring
R networked electronic systems
Airbags and belt tensioners could fail to
deploy or be triggered in an accident despite
the deceleration force being sufficient to trig-
ger the systems, or could be triggered unin- 42
Occupant safetySafety

tentionally. For this reason, never make any
modifications to the restraint systems.
Therefore, you must not tampe rwith elec-
tronic components or their software. SRS (Supplemental Restraint System)
Introduction SRS consists of:
R
the 6 SRS warning lamp
R airbags
R airbag control unit (with crash sensors)
R belt tensioners
R belt force limiters
SRS reduces the risk of occupants coming
into contact with the vehicle's interior in the
event of an accident. It can also reduce the
effect of the forces to which occupants are
subjected during an accident.
SRS warning lamp SRS functions are checked regularly when
you switch on the ignition and when the
engine is running. Therefore, malfunctions
can be detected in good time.
The 6 SRS warning lamp in the instrument
cluster lights up when the ignition is switched
on. It goes out no later than a few seconds
after the engine is started. G
WARNING
If SRS is malfunctioning, individual systems
may be triggered unintentionally or might not
be triggered in the event of an accident with
a high rate of vehicle deceleration.
A malfunction has occurred if:
R the 6 SRS warning lamp does not light
up when the ignition is switched on.
R the engine is running and the 6SRS
warning lamp does not go out after a few
seconds.
R the engine is running and the 6SRS
warning lamp lights up again. In this case, have SRS checked immediately
at a qualified specialist workshop.
Triggering of belt tensioners, belt force
limiters and airbags During the firs
tstage of a collision, the airbag
control uni tevaluates important physical
data relating to vehicle deceleratio noraccel-
eration, such as:
R duration
R direction
R magnitude
Based on the evaluation of this data, the air-
bag control uni tpre-emptively triggers the
beltt ensioners in the first stage.
i The fron tbelt tensioners can only be trig-
gered if the seat belt tongues on the front
seats are correctly engaged in the seat belt
buckles.
If there is an even higher rate of vehicle decel-
eration or acceleration in a longitudinal direc-
tion, the fron tairbags are also deployed.
Your vehicle has adaptive, two-stage front air-
bags. The airbag control unit evaluates vehi-
cle deceleration or acceleration in the event
of a collision. In the firs tdeployment stage,
the fron tairbag is filled with enough propel-
lant gas to reduce the risk of injuries. The
front airbag is fully deployed if a second
deploymen tthreshold is exceeded within a
few milliseconds.
The belt tensioner and airbag triggering
thresholds are variable and are adapted to the
rate of deceleration or acceleration of the
vehicle. This process is pre-emptive in nature.
The triggering process must take place in
good time at the start of the collision.
i Airbags are not deployed in all types of
accidents. Also, not all airbags are
deployed together in an accident. The dif-
ferent airbag systems work independently
of each other. Occupant safety
43Safety Z

How the airbag system works is deter-
mined by the severity of the collision detec-
ted, especially the vehicle deceleration or
acceleration, and the apparent type of acci-
dent:
R
head-on collision
R side impact
R overturn
The rate of vehicle deceleration or accelera-
tion and the directio nofthe force are essen-
tially determined by:
R the distribution of forces during the colli-
sion
R the collision angle
R the deformation characteristics of the vehi-
cle
R the characteristics of the object with which
the vehicle has collided
Factors which can only be seen and measured
after a collision has occurred do not play a
decisive role in the deployment of an airbag,
nor do they provide an indication of airbag
deployment.
The vehicle may be deformed significantly,
e.g. the bonnet or the wing, without an airbag
being deployed. This is the case if only parts
which are relatively easily deformed are affec-
ted and the rate of deceleration is not high.
Conversely, airbags may be deployed even
though the vehicle suffers only minor defor-
mation. This is the case if, for example, very
rigid vehicle parts such as longitudinal body
members are hit, and sufficient deceleration
occurs as a result. Airbags
Important safety notes Airbag deployment slows down and restricts
the movement of the vehicle occupant.
If the airbags are deployed, you will hear a
bang and a small amount of powder may also
be released. Only in rare cases will the bang
affect your hearing. The powder that is released generally does not constitute a
health hazard. The
6SRS warning lamp
lights up.
The airbag installation locations are identified
by the AIRBAG symbol. G
WARNING
Airbags provide additional protection; they
are not, however, a substitute for seat belts.
Observe the following notes to reduce the risk
of serious or even fatal injury caused by airbag
deployment:
R all vehicle occupants –inparticular, preg-
nant women – must wear their seat belt
correctly at all times and lean back against
the backrest, which should be positioned
as close to the vertical as possible. The
head restraint must support the back of the
head at about eye level.
R always secure childre nless than
1.50mt all or unde r12years of age in suit-
able child restraint systems.
R all vehicle occupants must select a seat
position that is as far away from the airbag
as possible. The driver's seat position must
allow the vehicle to be driven safely. The
driver's chest should be as far away from
the centre of the driver's airbag cover as
possible.
R move the front-passenger seat as far back
as possible. This is especially important if
you have secured a child in a child restraint
system on the front-passenger seat.
R vehicle occupants –inparticular, children
–m ust no tlean their heads into the area of
the window in which the sidebag/window-
bag is deployed.
R rearward-facing child restraint systems
must not be fitted to the front-passenger
seat unless the front-passenger airbag has
been disabled. On the front-passenger
seat, the front-passenger airbag is disabled
if a child restraint system with a trans-
ponder for automatic child seat recognition
is fitted to the front-passenger seat in a
vehicle equipped with automatic child seat 44
Occupant safetySafety
