5
When trouble arises
501
5-2. Steps to take in an emergency
If your vehicle overheats
If your engine overheats:
Stop the vehicle in a safe place and turn off the automatic air
conditioning system.
Check to see if steam is coming out from under the hood.
If you see steam: Stop the engine. Carefully lift the hood after the steam sub-
sides and then restart the engine.
If you do not see steam: Leave the engine running and carefully lift the hood.
Remove the engine compartment cover. ( P. 388)
Check to see if the cool ing fans are operating.
If the fans are operating: Wait until the temperature of the engine (shown on the
instrument cluster) begins to fall and then stop the engine.
If the fans are not operating: Stop the engine immediately and call your local Lexus
dealer.
After the engine has cooled
down sufficiently, check the
engine coolant level and inspect
the radiator core (radiator) for
any leaks.STEP1
STEP2
STEP3
STEP4
STEP5

504
5-2. Steps to take in an emergency
If the vehicle becomes stuck
CAUTION
■When attempting to free a stuck vehicle
If you choose to rock the vehicle back and forth to free it, make sure the surround-
ing area is clear, to avoid striking other vehicles, objects or persons. The vehicle
may also lunge forward or lunge back suddenly as it becomes free. Use extreme
caution.
■When shifting the shift lever
With automatic transmission vehicles, be careful not to shift the shift lever with the
accelerator pedal depressed.
This may lead to unexpected rapid acceleration of the vehicle that may cause an
accident and result in death or serious injury.
Carry out the following procedures if the tires spin or the vehicle becomes
stuck in mud, dirt, or snow.
Stop the engine. Set the parking brake and shift the shift lever
to P (vehicles with an automatic transmission) or N (vehicles
with a manual transmission).
Remove the mud, snow, or sand from around the stuck tire.
Place wood, stones or some ot her material to help provide
traction under the tires.
Restart the engine.
Shift the shift lever to the D or R position (vehicles with an auto-
matic transmission) or 1 or R position (vehicles with a manual
transmission), release the parking brake and carefully apply
the accelerator to free the vehicle.
Turn off TRAC and VSC if these functions are hampering your
attempts to free the vehicle. (  P. 1 8 7 )
STEP1
STEP2
STEP3
STEP4
STEP5

506
5-2. Steps to take in an emergency
If your vehicle has to be stopped in an emergency
CAUTION
■If the engine has to be turned off while driving
Power assist for the brakes and steering wheel will be lost, making the brake pedal
harder to depress and the steering wheel heavier to turn. Decelerate as much as
possible before turning off the engine.
Only in an emergency, such as if it becomes impossible to stop the vehicle
in the normal way, stop the vehicle using the following procedure:
Steadily step on the brake pe dal with both feet and firmly
depress it.
Do not pump the brake pedal repeatedly as this will increase the
effort required to slow the vehicle.
Shift the shift lever to N.
If the shift lever is shifted to N After slowing down, stop the vehicl e in a safe place by the road.
Stop the engine.
If the shift lever cannot be shifted to N Keep depressing the brake pedal with both feet to reduce vehi-
cle speed as much as possible.
Stop the engine by pressing and
holding the “ENGINE START
STOP” switch for 3 consecutive
seconds or more.
Stop the vehicle in a safe place by the road.
STEP1
STEP2
STEP3
STEP4
STEP3
Press and hold for 3 seconds or more
STEP4
STEP5

544
6-2. Customization
Windshield
wipers and
washer
(
P. 1 6 9 )
Switching operation when
the vehicle is stationaryOnOff
Drip prevention functionOnOff
Time elapsed before the
drip prevention function
operatesVa r i a b l e
depending on
the vehicle
speed
3 seconds
Intuitive park-
ing assist
(
P. 1 7 9 )
Back sensor operation
display and buzzerOnOff
Buzzer volumeLevel 3Level 1 to 5
Distance which a sensor
detects4.9 ft. (150 cm)2.0 ft. (60 cm)
Illumination
(
P. 3 1 5 )
Time elapsed before lights
turn off15 seconds7. 5 s e c o n d s
30 seconds
Operation when the
doors are unlockedOnOff
Operation after the
“ENGINE START STOP”
switch is turned OFF
OnOff
Front footwell lightsOnOff
Shift lever lightOnOff
Outer foot lightOnOff
Seat belt
reminder
(
P. 4 6 3 )
Vehicle speed linked seat
belt reminder buzzerOnOff
ItemFunctionDefault settingCustomizedsetting

566
Alphabetical index
Cruise control ......................................... 175
Cup holder .............................................. 322
Curtain shield airbags............................ 93
Customizable features ...................... 540
Daytime running light system ........... 166
DefoggerRear window .......................................... 214
Side mirror .............................................. 214
Dimension ............................................... 508
Dinghy towing ............................. 200, 201
Display Satellite switch mode ....................... 329
Trip information ..................................... 161
Warning message............................. 470
Do-it-yourself maintenance ............ 380
Door courtesy lights Door courtesy lights...........................315
Wattage.................................................. 524
Door pockets.......................................... 324
Doors Door lock................................ 28, 40, 43
Door windows ....................................... 75
Side mirrors .............................................. 72
Driver's seat belt reminder light .....463
Driving Correct posture ...................................... 91
Procedures ............................................. 124
Driving position memory ...................... 53 Electric power steering....................... 185
Electronic key
If the electronic key does not operate properly............................ 494
Emergency, in case of If the engine will not start ............... 490
If the shift lever cannot be shifted from P....................................492
If the vehicle has a discharged battery ................................................. 498
If the warning buzzer sounds........ 461
If the warning light turns on............ 461
If a warning message is displayed ............................................ 470
If you have a flat tire .......................... 481
If you lose your keys ........................ 493
If you think something is wrong ...................................................457
If the electronic key does not operate properly............................ 494
If your vehicle becomes stuck .... 504
If your vehicle has to be stopped in an emergency ............................ 506
If your vehicle needs to be towed ..................................................... 451
If your vehicle overheats..................501
Emergency flashers Switch ...................................................... 450
Engine Compartment ..................................... 386
Engine switch ........................................ 134
Hood ....................................................... 383
How to start the engine ................... 134
Identification number ...................... 509
If the engine will not start ............... 490
Ignition switch ....................................... 134
Overheating ..........................................501
D
E
