2011 Lexus IS220d tow

460
5-1. Essential information
IS250/220d/200d_EETowing eyelets
Emergency towing procedure
Release the parking brake.
Shift the shift lever to N.
Put the “ENGINE START STOP” switch in ACCESSORY mode
or IGNITION ON mode.
CAUTION
Caution while towing
Use extreme caution when towing the vehicle.
Avoid sudden starts or erratic driving maneuvers which place excessive
stress on the emergency towing eyelets and the cables or chains. Always
be cautious of the surroundings and other vehicles while towing.
If the engine is not running, the power assist for the brakes and steering
will not function, making steering and braking more difficult.
NOTICE
To prevent causing serious damage to the transmission
(vehicles with an automatic transmission)
Never tow this vehicle from the front with the rear wheels on the ground.
This may cause serious damage to the transmission.
When towing a vehicle without using a towing dolly
(vehicles with a manual transmission)
The “ENGINE START STOP” switch must not be OFF.
STEP1
STEP2
STEP3

5
461
5-1. Essential information
When trouble arises
IS250/220d/200d_EE
Installing towing eyelets
Remove the eyelet cover using
a flathead screwdriver.
To protect the bodywork, place
a rag between the screwdriver
and the vehicle body, as shown
in the illustration.
Insert the towing eyelet into the
hole and tighten partially by
hand.
Tighten down the towing eyelet
securely using a wheel nut
wrench.
STEP1
STEP2
STEP3
Location of the emergency towing eyelet
P. 4 8 5

462
5-1. Essential information
IS250/220d/200d_EE
Towing with a sling-type truck
CAUTION
Installing towing eyelets to the vehicle
Make sure that towing eyelets are installed securely.
If not securely installed, towing eyelets may come loose during towing. This
may lead to accidents that cause serious injury or even death.
NOTICE
To prevent body damage
Do not tow with a sling-type truck, either from the front or rear.

5
463
5-1. Essential information
When trouble arises
IS250/220d/200d_EE
Towing with a wheel lift-type truck
From the front
Vehicles with an automatic
transmission: Use a towing
dolly under the rear wheels.
Vehicles with a manual trans-
mission: We recommend to use
a towing dolly under the rear
wheels.
When not using a towing dolly,
release the parking brake and
shift the shift lever to N.
From the rear
Switch to ACCESSORY mode
so that the steering wheel is
unlocked.
NOTICE
To prevent causing serious damage to the transmission
(vehicles with an automatic transmission)
Never tow this vehicle from the front with the rear wheels on the ground.

464
5-1. Essential information
IS250/220d/200d_EE
Using a flat bed truck
If your Lexus is transported by
a flat bed truck, it should be
tied down at the locations
shown in the illustration.
If you use chains or cables to tie
down your vehicle, the angles
shaded in black must be 45.
Do not overly tighten the tie
downs or the vehicle may be
damaged.
NOTICE
To prevent damaging the vehicle
Do not tow the vehicle from the rear with the “ENGINE START STOP”
switch OFF.
The steering lock mechanism is not strong enough to hold the front wheels
straight.
When raising the vehicle, ensure adequate ground clearance for towing at
the opposite end of the raised vehicle. Without adequate clearance, the
vehicle could be damaged while being towed from the rear.

5
487
5-2. Steps to take in an emergency
When trouble arises
IS250/220d/200d_EE
If you have a flat tire (vehicles with a spare tire)
Remove the flat tire and replace it with the spare provided.
Before jacking up the vehicle
Stop the vehicle on a hard, flat surface.
Set the parking brake.
Shift the shift lever to P (vehicles with an automatic trans-
mission) or R (vehicles with a manual transmission).
Stop the engine.
Turn on the emergency flashers.
Location of the spare tire, jack and tools
With a compact spare tire
Jack
Jack handle
Tighte Loosen
Spare tire
Tool bag
(including towing eye-

488
5-2. Steps to take in an emergency
IS250/220d/200d_EE
Taking out the spare tire (with a compact spare tire)
Remove the luggage tray.
Loosen the center fastener that
secures the spare tire.
With a full-size spare tire
Tool bag
(including towing eye-
Spare tireTool bag
(jack handle)JackTighte Loosen

5
493
5-2. Steps to take in an emergency
When trouble arises
IS250/220d/200d_EELower the vehicle.
Firmly tighten each nut two or
three times in the order shown
in the illustration.
Tightening torque:
103 N•m (10.5 kgf•m, 76 ft•lbf)
Stow the flat tire, tire jack and all tools.
STEP3
STEP4
STEP5
