2011 Lexus IS F parking sensors

199
2-4. Using other driving systems
2
When driving
IS F_EE
Lexus parking assist-sensor
: If equipped
The distance to obstacles measured by the sensors is communicated
via the multi-information display and a buzzer when parallel parking
or maneuvering into a garage. Always check the surrounding area
when using this system.
For vehicles equipped with a navigation system, refer to the separate
“Navigation System Owner’s Manual” for further details.
Types of sensors
Front corner sensors
Rear corner sensors
Rear center sensors
Multi-information display (P. 167)
Front corner sensor opera-
tion
Rear corner sensor opera-
tion
Rear center sensor opera-
tion

200
2-4. Using other driving systems
IS F_EE
The distance display and buzzer
When a sensor detects an obstacle, the direction of and the approx-
imate distance to the obstacle are displayed and the buzzer sounds.
Front corner sensors
Multi-information
displayApproximate distance
to obstacleBuzzer
50 to 40 cm
(1.6 to 1.3 ft.)Medium
40 to 30 cm
(1.3 to 1.0 ft.)Fast
30 cm (1.0 ft.) or lessContinuous
Switching the Lexus parking assist-sensor on (P. 333)
When on, an indicator is dis-
played to inform the driver
that the function is opera-
tional.

204
2-4. Using other driving systems
IS F_EE
Sensor detection information
Certain vehicle conditions and the surrounding environment may affect
the ability of the sensor to correctly detect obstacles. Particular instances
where this may occur are listed below.
• There is dirt, snow or ice on the sensor.
• The sensor is frozen.
• The sensor is covered in any way.
• The vehicle is leaning considerably to one side.
• On an extremely bumpy road, on an incline, on gravel, or on grass
• The vicinity of the vehicle is noisy due to vehicle horns, motorcycle
engines, air brakes of large vehicles, or other loud noises producing
ultrasonic waves.
• There is another vehicle equipped with parking assist sensors in the
vicinity.
• The sensor is coated with a sheet of spray or heavy rain.
• The vehicle is equipped with a fender pole or wireless antenna.
• A towing eyelet is installed.
• The bumper or sensor receives a strong impact.
• The vehicle is approaching a tall or curved curb.
• In harsh sunlight or intense cold weather
In addition to the examples above, there are instances in which, because of
their shapes, signs and other objects may be judged by the sensor to be
closer than they are.
The shape of the obstacle may prevent the sensor from detecting it. Pay
particular attention to the following obstacles.
• Wires, fences, ropes etc.
• Cotton, snow and other materials that absorb radio waves
• Sharply-angled objects
•Low obstacles
• Tall obstacles with upper sections projecting outwards in the direction
of your vehicle
If the display flashes and a message is displayed
P. 4 3 1
Customization that can be configured at any authorized Lexus dealer or
repairer, or another duly qualified and equipped professional
Settings (e.g. buzzer volume) can be changed. (Customizable features P.
484)

497
Alphabetical index
IS F_EE
Maintenance
Do-it-yourself maintenance ..359
Maintenance data ..................472
Maintenance requirements....356
Meter
Instrument panel light control ....
162
Meters ...................................161
Mirrors
Inside rear view mirror ...........79
Side mirror heater .................236
Side mirrors ............................81
Vanity mirrors ......................331
Moon roof....................................85
MP3 disc*..................................252
Multi-information display .........167
Odometer ...................................161
Oil
Engine oil .............................369
Opener
Fuel filler door ........................89
Hood .....................................363
Trunk ......................................59
Outer foot lights
Outer foot lights....................320
Wattage .................................481
Outside rear view mirrors
Adjusting and folding .............81
Mirror position memory .........62
Outside temperature display ......168
Overhead courtesy lights
Overhead courtesy lights ......320
Wattage .................................481
Overheating, Engine ..................465Parking assist sensors* ............. 199
Parking brake............................ 160
PCS ........................................... 213
Personal lights
Switch .................................. 323
Pollen removal mode* .............. 232
Power outlet.............................. 338
Power windows .......................... 82
Pre-crash safety system ............ 213
Radar cruise control.................. 184
Radiator .................................... 374
Radio* ...................................... 241
RDS* ........................................ 242
Rear fog lights
Replacing light bulbs ........... 407
Switch .................................. 175
Wattage ................................ 481
Rear turn signal lights
Replacing light bulbs ........... 407
Wattage ................................ 481
Rear window defogger* ........... 236
Replacing
Electronic key battery .......... 390
Fuses .................................... 393
Light bulbs ........................... 407M
