2011 Lexus IS F stop start

237
3-1. Using the air conditioning system and defogger
3
Interior features
IS F_EE
Windshield wiper de-icer
The windshield wiper de-icer can be operated when
The “ENGINE START STOP” switch is in IGNITION ON mode.
CAUTION
When the windshield wiper de-icer is on
The surface of the glass at the lower part and sides of the windshield
become very hot. To prevent burning yourself, do not touch these areas.
This feature is used to prevent ice from building up on the windshield
and wiper blades.
On/off
The windshield wiper de-icer
will automatically turn off
after approximately 15 min-
utes.
: If equipped

290
3-3. Using the Bluetooth® audio system
IS F_EE
Registering a portable player
Select “Pair Audio” using , and , and perform
the procedure for registering a portable player. (P. 284)
Selecting a portable player to be used
Select “Select Audio” using , and .
Select the portable player to be used using , and
.
Select “From Car” or “From Audio” using ,
and .
If “From Car” is selected, the portable player will be automati-
cally connected whenever the “ENGINE START STOP” switch
is in either ACCESSORY or IGNITION ON mode.
Changing the registered name of a portable player
Select “Change Name” using , and .
Select the desired portable player name to be changed using
, and .
Select “Record Name” using , and , and
say the new name after the beep.
The name to be registered will be repeated aloud.
Select “Confirm” using , and .
Listing the registered portable players
Select “List Audios” using , and . The list of reg-
istered portable players will be read aloud.
When listing is complete, the system returns to “BT•A Setup”.
STEP1
STEP2
STEP3
STEP1
STEP2
STEP3
STEP4

320
IS F_EE
3-5. Using the interior lights
Interior lights list
Your Lexus is equipped with the illuminated entry system to assist in
entering the vehicle. Owing to the function of the system, the lights
shown in the following illustration automatically turn on/off according
to the presence of the electronic key, whether the doors are locked/
unlocked, whether the doors are opened/closed, and the “ENGINE
START STOP” switch mode.
Front personal lights (P. 323)
Shift lever light (when the “ENGINE START STOP” switch
is in ACCESSORY or IGNITION ON mode)
Front overhead courtesy light
Front interior lights (P. 322)
Rear personal lights (P. 323)
Rear overhead courtesy light
Rear interior light

325
3-6. Using the storage features
3
Interior features
IS F_EE
Glove box
Open (push button)
Lock with the mechanical
key
Unlock with the mechanical
key
Glove box light
The glove box light turns on when the “ENGINE START STOP” switch is
in IGNITION ON mode.
Trunk opener main switch
The trunk opener main switch is located in the glove box. (P. 5 9 )
CAUTION
Caution while driving
Keep the glove box closed.
Injuries may result in the event of an accident or sudden braking.
Glove box

326
3-6. Using the storage features
IS F_EE
Console box
Pull up the knob to release
the lock.
Slide the armrest.
Pull up the knob to release
the lock.
Lift the armrest to open.
Console box light
The console box light turns on when the “ENGINE START STOP” switch is
in IGNITION ON mode.
Using the console box to store CD cases
CAUTION
Caution while driving
Keep the console box closed.
Injuries may result in the event of an accident or sudden braking.
Store a CD case with the hinged portion
facing either the front or back of the con-
sole box.
Console box

332
3-7. Other interior features
IS F_EE
Clock
The clock is displayed when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION
ON mode.
Adjusts the hour.
Adjusts the minutes.
Rounds to the nearest
hour.
*
*: e.g. 1:00 to 1:29 1:00
1:30 to 1:592:00

335
3-7. Other interior features
3
Interior features
IS F_EE
Changing the settings
Each item is displayed and its setting can be changed only in the following
conditions:
Intrusion sensor: When the “ENGINE START STOP” switch is off and
the auto alarm is not set.
Lexus parking assist-sensor: When the “ENGINE START STOP” switch
is in IGNITION ON mode.
Items other than the above: When the “ENGINE START STOP” switch
is in IGNITION ON mode and the vehicle is stopped.
Display
The display will return to the original display if the satellite switches are not
operated for an extended period.
Even if the display is in satellite switch mode, it will switch in the event of a
warning or when the radar cruise control (if equipped) is used. If this occurs,
press any of the satellite switches or “DISP” switch on the steering wheel to
return the display to satellite switch mode.

337
3-7. Other interior features
3
Interior features
IS F_EE
Cigarette lighter
The cigarette lighter can be used when
The “ENGINE START STOP” switch is in ACCESSORY or IGNITION
ON mode.
CAUTION
When not in use
Keep the lid closed.
Injuries may result in the event of an accident or sudden braking.
To avoid burns or fires
Do not touch the metal parts of the cigarette lighter.
Do not hold the cigarette lighter down. It could overheat and cause a fire.
Do not insert anything other than the cigarette lighter into the outlet.
Push the back part of the lid
to open, and push the ciga-
rette lighter down.
The cigarette lighter will pop
up when it is ready for use.
: If equipped
