2011 Lexus IS F USB

272
3-2. Using the audio system
IS F_EE
USB memory
Compatible devices
USB memory that can be used for MP3 and WMA playback
Compatible device formats
The following device formats can be used:
• USB communication formats: USB2.0 FS (12 mbps)
• File formats: FAT16/32 (Windows)
• Correspondence class: Mass storage class
MP3 and WMA files written in any format other than those listed above
may not play correctly, and their file names and folder names may not be
displayed correctly.
Items related to standards and limitations are as follows:
• Maximum directory hierarchy: 8 levels
• Maximum number of folders in a device: 999 (including the root)
• Maximum number of files in a device: 65025
• Maximum number of files per folder: 255
MP3 and WMA files
MP3 (MPEG Audio LAYER 3) is a standard audio compression format.
Files can be compressed to approximately 1/10 of their original size using
MP3 compression.
WMA (Windows Media Audio) is a Microsoft audio compression format.
This format compresses audio data to a size smaller than that of the MP3
format.
There is a limit to the MP3 and WMA file standards that can be used and
to the media/formats on which the files are recorded.
MP3 file compatibility
• Compatible standards
MP3 (MPEG1 AUDIO LAYERII, III, MPEG2 AUDIO LAYERII, III,
MPEG2.5)
• Compatible sampling frequencies
MPEG1 AUDIO LAYERII, III: 32, 44.1, 48 (kHz)
MPEG2 AUDIO LAYERII, III: 16, 22.05, 24 (kHz)
MPEG2.5: 8, 11.025, 12 (kHz)

273
3-2. Using the audio system
3
Interior features
IS F_EE
• Compatible bit rates (compatible with VBR)
MPEG1 AUDIO LAYERII, III: 32-320 (kbps)
MPEG2 AUDIO LAYERII, III: 32-160 (kbps)
MPEG2.5: 32-160 (kbps)
• Compatible channel modes: stereo, joint stereo, dual channel and mon-
aural
WMA file compatibility
• Compatible standards
WMA Ver. 9
• Compatible sampling frequencies
HIGH PROFILE 32, 44.1, 48 (kHz)
• Compatible bit rates
HIGH PROFILE 32-320 (kbps, VBR)
File names
The only files that can be recognized as MP3/WMA and played are those
with the extension .mp3 or .wma.
ID3 and WMA tags
ID3 tags can be added to MP3 files, making it possible to record the track
title, artist name, etc.
The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3, 2.4 ID3
tags. (The number of characters is based on ID3 Ver. 1.0 and 1.1.)
WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.
MP3 and WMA playback
• When a device containing MP3 or WMA files is connected, all files in
the USB memory are checked. Once the file check is finished, the first
MP3 or WMA file is played. To make the file check finish more
quickly, we recommend that you do not include any files other than
MP3 or WMA files or create any unnecessary folders.
• When the USB memory is connected and the audio source is changed
to USB memory mode, the USB memory will start playing the first file
in the first folder. If the same device is removed and reinserted (and the
contents have not been changed), the USB memory will resume play
from the same point in which it was last used.

274
3-2. Using the audio system
IS F_EE
Extensions
If the file extensions .mp3 and .wma are used for files other than MP3 and
WMA files, they will be skipped (not played).
Playback
• To play MP3 files with steady sound quality, we recommend a fixed
bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz.
• There is a wide variety of freeware and other encoding software for
MP3 and WMA files on the market, and depending on the status of the
encoding and the file format, poor sound quality or noise at the start of
playback may result. In some cases, playback may not be possible at
all.
• Microsoft, Windows, and Windows Media are registered trademarks
of Microsoft Corporation in the U.S.A. and other countries.
CAUTION
Caution while driving
Do not connect USB memory or operate the controls.
NOTICE
To prevent damage to USB memory
Do not leave USB memory in the vehicle. The temperature inside the
vehicle may become high, resulting in damage to the player.
Do not push down on or apply unnecessary pressure to the USB memory
while it is connected as this may damage the USB memory or its terminal.
Do not insert foreign objects into the port as this may damage the USB
memory or its terminal.

278
3-2. Using the audio system
IS F_EE
Using the steering wheel audio switches
Turning on the power
Press when the audio system is turned off.
The audio system can be turned off by holding down until you
hear a beep.
Some audio features can be controlled using the switches on the steer-
ing wheel.
Turns the power on, selects
an audio source
Increases/decreases vol-
ume
Radio mode:Selects a
radio station
CD mode: Selects a track,
file (MP3 and
WMA) and disc
Bluetooth
® audio mode:
Selects a track
and album
iPod mode:Selects a song
USB memory mode:
Selects a file and

279
3-2. Using the audio system
3
Interior features
IS F_EE
Changing the audio source
Press when the audio system is turned on. The audio source
changes as follows each time is pressed. If no discs are
inserted in the player, or if the external device is not connected,
that mode will be skipped.
FM1FM2FM3CD playerBluetooth
®audioAUX
iPod or USB memoryMWDAB
Adjusting the volume
Press “+” on to increase the volume and “-” to decrease the
volume.
Hold down to continue increasing or decreasing the volume.
Selecting a radio station
Press to select radio mode.
Press “” or “” on to select a radio station.
To scan for receivable stations, press and hold until you
hear a beep.
Selecting a track/file or song
Press to select CD, Bluetooth
® audio, iPod or USB
memory mode.
Press “” or “” on to select the desired track/file or
song.
STEP1
STEP2
STEP1
STEP2

280
3-2. Using the audio system
IS F_EE
Selecting an album
Press to select Bluetooth
® audio mode.
Press and hold “” or “” on until you hear a beep.
Selecting a folder
Press to select USB memory mode.
Press and hold “” or “” on until you hear a beep.
Selecting a disc in the CD player
Press to select CD mode.
Press and hold “” or “” on until you hear a beep.
CAUTION
To reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
STEP1
STEP2
STEP1
STEP2
STEP1
STEP2

491
IS F_EE
Alphabetical index
Alphabetical index
A/C* ..........................................228
ABS ...........................................206
ACCESSORY mode .................146
Air conditioning filter ...............386
Air conditioning system
Air conditioning filter ...........386
Automatic air conditioning
system.................................228
Airbags
Airbag manual ON/OFF
system.................................135
Airbag operating conditions .107
Airbag precautions for your
child....................................111
Airbag warning light ............426
Curtain shield airbag operating
conditions ...........................107
Curtain shield airbag
precautions .........................111
General airbag precautions ...111
Locations of airbags .............105
Modification and disposal of
airbags ................................115
Proper driving posture ..103, 111
Side airbag operating
conditions ...........................107
Side airbag precautions.........111
SRS airbags ..........................105Alarm .......................................... 97
Antenna* .................................. 244
Anti-lock brake system............. 206
Armrest ..................................... 341
Ashtrays .................................... 336
Audio input* ............................. 277
Audio system*
Antenna................................ 244
Audio input .......................... 277
AUX port ............................. 277
Bluetooth
® audio ................. 279
CD player/changer ............... 245
iPod ...................................... 260
MP3/WMA disc................... 252
Optimal use .......................... 275
Portable music player .......... 277
Radio.................................... 241
Steering wheel audio switch 278
USB memory ....................... 268
USB port ...................... 260, 268
Automatic air conditioning
system* .................................. 228
Automatic headlight leveling
system .................................... 174
Automatic light control system 172
A
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s

500
Alphabetical index
IS F_EE
Tachometer ................................161
Tail lights
Switch ...................................172
Talk switch* ..............................301
Telephone switch* ....................301
Theft deterrent system
Alarm ......................................97
Double locking system ...........96
Engine immobilizer system ....92
Tire inflation pressure ...............382
Tires
Chains ...................................222
Checking ...............................379
If you have a flat tire ............444
Inflation pressure ..................382
Replacing ..............................444
Rotating tires ........................379
Size .......................................480
Snow tires .............................222
Tools ..........................................444
Towing
Emergency towing ................417
Trailer towing .......................225
Traction control .........................206
Transmission shift switches ....153,
155
TRC ...........................................206
Trip meter ..................................161Trunk
Extending trunk space ......... 342
Opener ................................... 59
Trunk light
Trunk light ............................. 60
Wattage ................................ 481
Turn signal lights
Replacing light bulbs ........... 407
Switch .................................. 159
Wattage ................................ 481
USB port* ......................... 260, 268
Vanity lights
Vanity lights ........................ 331
Wattage ................................ 481
Vanity mirrors .......................... 331
VDIM ....................................... 207
Vehicle dynamics integrated
management ........................... 207
Vehicle identification number .. 473
Vehicle stability control ........... 206
VSC .......................................... 206T
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s
U
V
