2011 Lexus HS250h display

2
Hands-free System For Cellular Phone (with navigation system)*
Bluetooth® phone pairing ......................................................................................................... 52
Phonebook transfer ......................................................................................................................53
Registering a voice tag ................................................................................................................54
Registering a speed dial ..............................................................................................................55
Calling by name.............................................................................................................................. 57
Calling by speed dial ................................................................................................................... 58
Receiving a call ...............................................................................................................................59
Headlights...............................................................................................................................................36
Head-up Display..................................................................................................................................33
Hybrid System........................................................................................................................................ 10
Hybrid transmission............................................................................................................................. 19
Intuitive Parking Assist.......................................................................................................................35
Keys............................................................................................................................................................. 14
Lexus Enform with Safety Connect............................................................................................. 83
LKA (Lane-Keeping Assist).............................................................................................................32
Moon Roof.............................................................................................................................................. 87
Multi-information Display.................................................................................................................23
Navigation System
*
Register home ................................................................................................................................. 44
Destination input - Search by address .................................................................................. 45
Destination input - Search points of interest by name.................................................... 47
Destination input - Search points of interest by category............................................. 49
Destination input - Search points of interest by telephone number ........................ 50
Voice Command System ............................................................................................................73
Portable Audio Device Adapters.................................................................................................. 78
Power (Ignition) Switch....................................................................................................................... 17
Po we r Wi n d o w s................................................................................................................................... 86
Remote Touch......................................................................................................................................... 41
Safety Connect...................................................................................................................................... 81
Smart Access System with Push-button Start.......................................................................... 15
Theft Deterrent System...................................................................................................................... 16
Tu r n S i g n a l L e v e r..................................................................................................................................25
Voice Command System
*
Basic operation ............................................................................................................................... 73
Command list ...................................................................................................................................74
Wide View Front Monitor.................................................................................................................35
Windshield Wipers and Washer....................................................................................................39
*: This feature may be operated by Voice Command (See P. 73)

3
OverviewInstrument Panel
Headlight switch
Automatic high
beam

Turn signal lever
Fog light switch
*1
P.36
P.38
P.25
Power (ignition) switch P.17
See P.6
See P.7Windshield wiper and
washer switch
P.39
EV drive mode switch
“ECO MODE” switch
Power mode switch P.22
P.21
P.21
Hybrid transmission shift lever P.19
P position switch P.20
Tilt and telescopic steering control switch *1
Pre-collision braking off switch *1
Tilt and telescopic steering control lever *1
Parking brake pedal *1
Hood lock release lever *1 Door lock switches
P.85
Power window switches P.86
Window lock switch
P.86
Inside door lock buttons
P.85
Driving position
memory switches
*1
Multi-information
display
P.23

7
OverviewInstrument Panel
VIEW switch 
Windshield wiper
de-icer switch
*1, *2
P. 35
VSC OFF switch*1
Trunk opener*1
Fuel filler door
opener
P.88
Rear sunshade
switch
*1
HUD (Head-up Dis-
play) position
adjustment switch

P. 33
HUD (Head-up Dis-
play) contrast adjust-
ment switch

P. 33
HUD (Head-up Display)
main switch
P. 33
Instrument panel light control switches*1
Outside rear view
mirror switches
*1
Headlight cleaner switch *1
NAVI switch 
P. 33

12
Energy Monitor / Consumption Screen
■Energy monitor
The energy monitor can be displayed on both the navigation system screen and the multi-
information display.
●How to display on the navigation system screen (P. 4 1 ) :
Press the “MENU” button on the Remote Touch and select “Info. Phone” after that select
“Fuel consumption”.
If the “Consumption” or “Past Record” screen is displayed, select the “Energy” and press
the “ENTER” button on the Remote Touch.
●How to display on the multi-information display:
Toggle the “ENTER” switch on the steering wheel upward or downward through several
times to select the energy monitor display.
●The flow of energy is displayed on the
navigation system screen.
Amber: gasoline energy
Yellow: electrical energy
Green: energy recovery
A green arrow appears when regen-
erative braking occurs.
●The flow of energy is indicated by the
movement of the arrows on the multi-
information display.
You can view the status of your hybrid system on the multi-information display and the
navigation system screen.
The displayed energy flow, battery level, etc. will change in response to the current driving
conditions.

13
■Consumption (with navigation system)
Press the “MENU” button on the Remote Touch and select “Info. Phone”, after that select
“Fuel consumption” and press the “ENTER” button on the Remote Touch.
If the
“Consumption” screen does not appear, select “Consumption” and press the “ENTER”
button on the Remote Touch.
Fuel consumption in the past 30 minutes
Regenerated energy in the past 30 min-
utes
One symbol indicates 50 Wh. Up to 4
symbols are shown.
Cruising range
■Past record (with navigation system)
Press the “MENU” button on the Remote Touch and select “Info. Phone”, after that select
“Fuel consumption” and press the “ENTER” button on the Remote Touch.
If the “Past Record” screen does not appear, select “Past Record” and press the “ENTER”
button on the Remote Touch.
Best past fuel consumption
Average fuel consumption
Displays the average fuel consumption
between each reset of the total average
fuel consumption on the multi-informa-
tion display.
When resetting, if the total average fuel
consumption is better than the best past
fuel consumption, the best past fuel con-
sumption will be updated.
■Hybrid warning message
A message is automatically displayed when a malfunction occurs in the hybrid system or an
improper operation is attempted.
If a warning message is shown on the multi-
information display, read the message and
follow the instructions.

22
■EV drive mode
In EV drive mode, the electric motor (traction motor), powered by the hybrid battery (trac-
tion battery), is used to drive the vehicle.
This mode allows you to drive in residential areas late at night, or in indoor parking lots etc.
without concern for noises and exhaust gas emissions.
Turns EV drive mode on/off
When EV drive mode is turned on, the
EV drive mode indicator will come on.
Pressing the switch when in EV drive
mode will return the vehicle to normal
driving (using the gasoline engine and
electric motor [traction motor]).
■Situations in which EV drive mode cannot be turned on
It may not be possible to turn EV drive mode on in the following situations. If it cannot be
turned on, a buzzer will sound and a message will be shown on the multi-information dis-
play.
• Vehicle speed is about 19mph (30km/h) or more.
• The hybrid battery (traction battery) is low.
In general, the remaining battery level indicated in the “Energy Monitor” display is level 3
or lower.
• The temperature of the hybrid system is high.
The vehicle has been left in the sun, driven on a hill, driven at high speeds, etc.
• The temperature of the hybrid system is low.
The vehicle has been left in temperatures lower than about 32°F (0°C) for a long
period of time etc.
• The gasoline engine is warming up.
• The accelerator pedal is depressed firmly or the vehicle is on a hill etc.
• The windshield defogger is in use.

23
Multi-information Display
■Multi-information switches
Menu switch
Changes modes to electronic feature
control mode (if equipped), customiza-
tion mode or back to normal display
mode.
“ENTER” switch
Changes trip information items. This
switch is also used to turn on/off elec-
tronic feature controls and to change
customization settings.
■Display contents
The multi-information display presents the driver with a variety of driving-related data
including the current outside air temperature.
Trip information contentsSwitching display items
Energy monitor
Press the “ENTER” switch upward or
downward.
Total distance/Total average fuel con-
sumption
Current fuel consumption/Average
fuel consumption after refueling
Cruising range
Average vehicle speed
Outside temperature
Tire inflation pressure
Blank

24
Display order may vary depending on vehicle condition.
Electronic features control contentsSetting electronic feature controls
AFS (if equipped)P. 3 7
Intuitive parking assist (if equipped)Refer to “Navigation System Owner’s
Manual”
Other contentsDetails
CustomizationSettings of functions such as the door lock
and light illumination time can be changed
Dynamic radar cruise control
(if equipped)Automatically displayed when using the
dynamic radar cruise control
LKA (Lane Keeping Assist) (if equipped)Automatically displayed when using the
lane keeping assist
PCS (Pre-Collision System) (if equipped)Automatically displayed if there is a possi-
bility of collision
Wa r n i n g m e s s a g eAutomatically displayed when a malfunc-
tion occurs in any of the vehicle’s systems
