5-1. Essential information
CT200h_EE (OM76041E)
CAUTION
Caution while towing
Use extreme caution when towing the vehicle.
Avoid sudden starts or erratic driving maneuvers which place excessive
stress on the emergency towing eyelets and the cables or chains. Always
be cautious of the surroundings and other vehicles while towing.
Do not turn the “POWER” switch off.
This may lead to an accident as the front wheels will be locked by the
parking lock.
If the hybrid system is off, the power assist for the brakes and steering will
not function, making steering and braking more difficult.
Installing towing eyelets to the vehicle
Make sure that towing eyelets are installed securely.
If not securely installed, towing eyelets may come loose during towing. This
may lead to accidents that cause serious injury or even death.
NOTICE
To prevent damaging the vehicle
When raising the vehicle, ensure adequate ground clearance for towing at
the opposite end of the raised vehicle. Without adequate clearance, the vehi-
cle could be damaged while being towed.
To prevent causing serious damage to the hybrid transmission when towing
using a wheel-lift type truck
Never tow this vehicle from the front with the rear wheels on the ground.
To prevent body damage when towing with a sling-type truck
Do not tow with a sling-type truck, either from the front or rear.
To prevent causing serious damage to the hybrid transmission in emergency
towing
Never tow a vehicle from the rear with four wheels on the ground. This may
cause serious damage to the hybrid transmission.

586
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
If you have a flat tire (vehicles with a spare tire)
Remove the flat tire and replace it with the spare tire provided.
Before jacking up the vehicle
Stop the vehicle on a hard, flat surface.
Set the parking brake.
Shift the shift position to P.
Stop the hybrid system.
Turn on the emergency flashers.
Location of the spare tire, jack and tools
Center auxil-
iary
Jack Spare Jack han- Wheel
nut
Towing eye-

592
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)Firmly tighten each wheel nut
two or three times in the order
shown in the illustration.
Tightening torque:
103 N•m (10.5 kgf•m, 76 ft•lbf)
Stow the flat tire, tire jack and all tools.
STEP4
STEP5

5
593
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Stowing the flat tire
Vehicles with a 16 or 17 inch
wheel: Before stowing the flat
tire, remove the center wheel
ornament by pushing from the
reverse side.
Place the flat tire on the deck
board, and pass the belt through
the lower-right cargo hook and
then through the hole in the
center of the tire.
Pass the belt through the lower-
left cargo hook.
Pass the belt through the buckle
and secure the tire firmly.
Check that the belt is securely
held by the buckle.
The belt cannot be fastened
securely if the buckle is facing
the wrong direction.
STEP1
STEP2
STEP3
STEP4

5
599
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
CAUTION
After using the tools and jack
Before driving, make sure all the tools and jack are securely in place in their
storage location to reduce the possibility of personal injury during a colli-
sion or sudden braking.
When stowing the flat tire
Make sure the rear seatbacks are in their original position.
Secure it using a tire tie-down belt. Otherwise, the flat tire may fly out in
case of sudden braking or an accident, resulting in death or serious injury.
NOTICE
Do not drive the vehicle with a flat tire.
Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the
wheel beyond repair.
Be careful when driving over bumps with the compact spare tire installed on
the vehicle.
The vehicle becomes lower when driving with the compact spare tire com-
pared to when driving with standard tires. Be careful when driving over
uneven road surfaces.
Driving with tire chains and the compact spare tire
Do not fit tire chains to the compact spare tire.
Tire chains may damage the vehicle body and adversely affect driving per-
formance.

600
5-2. Steps to take in an emergency
CT200h_EE (OM76041E)
If you have a flat tire (vehicles without a spare tire)
Your vehicle is equipped with an emergency tire puncture repair kit.
A puncture caused by a nail or screw passing through the tire tread can
be repaired temporarily with the emergency tire puncture repair kit.
Before repairing the vehicle
Stop the vehicle in a safe place on a hard, flat surface.
Set the parking brake.
Shift the shift position to P.
Stop the hybrid system.
Turn on the emergency flashers.
Location of the emergency tire puncture repair kit, jack and
tools
Center auxil-
iary
Jack*Towing eye-
Wheel
nut
Jack han-
Emergency tire
puncture repair

5
623
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
Starting the hybrid system when the 12-volt battery is discharged
The hybrid system cannot be started by push-starting.
To prevent 12-volt battery discharge
Turn off the headlights and the audio system while the hybrid system is
off.
Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic.
When the 12-volt battery is removed or discharged
The hybrid system may not start. (P. 499)
If the 12-volt battery discharges while the shift position is in P, it may not
be possible to shift the shift position to other positions. In this case, the
vehicle cannot be towed without lifting both front wheels because the
front wheels will be locked. (P. 551)
When the 12-volt battery is reconnected, start the hybrid system and
confirm that the shift position can be changed to each position using the
shift position indicator.
Charging the 12-volt battery
The electricity stored in the 12-volt battery will discharge gradually even
when the vehicle is not in use, due to natural discharge and the draining
effects of certain electrical appliances. If the vehicle is left for a long time,
the 12-volt battery may discharge, and the hybrid system may be unable to
start. (The 12-volt battery recharges automatically while the hybrid system
is operating.)

5
633
5-2. Steps to take in an emergency
When trouble arises
CT200h_EE (OM76041E)
NOTICE
To avoid damage to the hybrid transmission and other components
Avoid spinning the wheels and depressing the accelerator pedal more than
necessary.
If the vehicle remains stuck even after these procedures are performed, the
vehicle may require towing to be freed.
