2011 Lexus CT200h bluetooth

384
3-3. Using the Bluetooth® audio system
CT200h_EE (OM76041E)

385
3-3. Using the Bluetooth® audio system
3
Interior features
CT200h_EE (OM76041E)

386
3-3. Using the Bluetooth® audio system
CT200h_EE (OM76041E)
CAUTION
Caution while driving
Do not connect portable players or operate the controls.
NOTICE
To prevent damage to portable players
Do not leave portable players in the vehicle. The temperature inside the
vehicle may become high, resulting in damage to the player.

387
3-3. Using the Bluetooth® audio system
3
Interior features
CT200h_EE (OM76041E)
Using the Bluetooth® audio system
Audio unit
Type A
Display
A message, name, num-
ber, etc. is displayed.
Lower-case characters and
special characters cannot
be displayed.
Displays information that
is too long to be displayed
at one time on the display
(press and hold)
Selects items such as menu
and number
Turn: Selects an item
Press: Inputs the selected
item
Bluetooth
® connection
condition
If “BT” is not displayed,
the Bluetooth® audio sys-
tem cannot be used.
Type B

388
3-3. Using the Bluetooth® audio system
CT200h_EE (OM76041E)
Steering wheel switches
Ta l k s w i t c h
Turns the voice command
system on (press)/turns the
voice command system off
(press and hold)
Microphone

389
3-3. Using the Bluetooth® audio system
3
Interior features
CT200h_EE (OM76041E)
Using the Bluetooth® audio system for the first time
Before using the Bluetooth
® audio system, it is necessary to regis-
ter a Bluetooth® enabled portable player in the system. Follow the
procedure below to register (pair) a portable player:
Press
(type A) or (type B) and select “BTA
MENU” using .
Press the talk switch or select “BTA Setup” using .
The introductory guidance and portable player name registration
instructions are heard.
Select “Pair Audio Player (Pair Audio)” using a voice com-
mand or .
Register a portable player name by either of the following
methods:
a. Select “Record Name” using , and say the name
to be registered.
b. Press the talk switch and say the name to be registered.
A voice guidance instruction to confirm the input is heard.STEP1
STEP2
STEP3
STEP4

390
3-3. Using the Bluetooth® audio system
CT200h_EE (OM76041E)Select “Confirm” using a voice command or .
A passkey is displayed and heard, and a voice guidance instruction
for inputting the passkey into the portable player is heard.
Input the passkey into the portable player.
Refer to the manual that comes with the portable player for the
operation of the portable player.
Guidance for registration completion is heard.
If the portable player has a Bluetooth
® phone, the phone can be
registered at the same time. A voice guidance instruction to regis-
ter a Bluetooth
® phone is heard.
Select “Yes” or “No” using a voice command or .
(Bluetooth
® phone P. 406)
STEP5
STEP6
STEP7

391
3-3. Using the Bluetooth® audio system
3
Interior features
CT200h_EE (OM76041E)
Menu list of the Bluetooth® audio system
First menuSecond
menuThird menuOperation detail
“BTA
MENU”“BTA
Setup”
“Pair Audio”Registering a portable audio
player
“Select Audio”Selecting a portable audio
player to be used
“Change Name”Changing the registered
name of a portable player
“List Audios”Listing the registered porta-
ble players
“Set Passkey”Changing the passkey
“Delete Audio”Deleting a registered porta-
ble player
Operations that cannot be performed while driving
Operating the system with
Registering a portable player to the system
Changing the passkey
P. 3 9 9
