2011 JAGUAR XF Winter mode

R
(FM8) SEMCON JLR OWNER GUIDE VER 1.00 EURO
LANGUAGE: english-en; MARQUE: jaguar; MODEL: XF
Stability control
83
Stability controlWINTER MODE
Winter mode optimises stability of the vehicle
to suit slippery conditions, when grip is
reduced. This helps the vehicle to perform in a
more gentle and controlled manner, to avoid
skidding, allowing more confident progress
under adverse conditions.
Note: Winter mode cannot be active at the
same time as Dynamic m ode. Winter mode will
remain selected indefinitely, even after the
ignition is switched off. Winter mode must be
deselected if no longer required.
DYNAMIC MODE
Note: When the transmission is set to
permanent manual mode and Dynamic mode is
selected, transmission upshifts are fully
controlled by the driver . The transmission will
not change up automatically, even when the rev
limit is reached (the ge ar position indicator in
the message centre will gl ow amber, to indicate
that the next gear should be selected).
Note: Dynamic mode cannot be active at the
same time as Winter mode. Dynamic mode will
remain selected for approximately six hours
after the ignition is switched off, after which
point it will need to be reselected if required.
TRACDSC
Vehicle safety may be reduced by
inappropriate use of of Trac DSC. Trac
DSC should only be used in suitable
conditions.
Trac DSC is an alternative setting of DSC, with
reduced system interventions. With Trac DSC
engaged, traction may be increased, although
stability may be reduced compared to normal
DSC. Trac DSC is intended for use only on dry
tarmac, by suitably experienced drivers. Trac
DSC should not be selected for other surfaces
or by drivers with insuff icient skill and training
to operate the vehicle safely with Trac DSC
function engaged.
Press to operate. Designed for use
in slippery conditions, when
active, Winter mode selects 2nd
gear for driving away on level
ground (no incline), softens the
responsiveness of the engine and
modifies the gear change strategy.
This helps ensure that optimum
traction is maintained.
Press to operate. Dynamic mode
co-ordinates the vehicle's control
systems to deliver a high
performance driving experience.
This setting enhances key vehicle
systems so that the vehicle's full
potential can be exploited. The
vehicle's responses are aimed at
involving the driver more in
focused and purposeful driving.

L
(FM8) SEMCON JLR OWNER GUIDE VER 1.00 EURO
LANGUAGE: english-en; MARQUE: jaguar; MODEL: XF
Stability control
86
JAGUARDRIVE CONTROL SCENARIOS
The table below gives examples of the drive
control settings suggested for different driving
scenarios.
Scenario Suggested driver selection
Tyre fitment JaguarDrive ControlDynamic
Stability Control (DSC) Transmission
Wet grass Standard Winter mode Default (On) Drive (D)
Very wet tarmac
Slippery boat launch
ramp
Hill descents while
towing on slippery
surfaces Sport (S) +
Manual
Ice/light snow Standard or All
Season tyres Drive (D)
Snow ploughed
hard-topped roads
(including black ice) All Season tyres
Packed snow roads Winter tyres
Deep fresh snow Snow chains Sport (S)
Normal driving
conditions (e.g. dry
tarmac, town driving,
motorway cruising etc. Standard No driver
selection
required.
Special modes
off Drive (D)
Overtaking on a dry
road Drive (D) or
Sport (S)
Pulling out onto a busy
road in dry conditions
Favourite country lane
(public road) Standard Dynamic mode
Sport (S) or
Sport (S) +
Manual
Private track/race day Standard Trac DSC
(where
conditions
permit)

L
(FM8) SEMCON JLR OWNER GUIDE VER 1.00 EURO
LANGUAGE: english-en; MARQUE: jaguar; MODEL: XF
Tyre pressure monitoring system
90
TEMPORARY USE SPARE WHEEL
AND TYRE CHANGE
If the temporary use spare wheel is fitted the
system will automatically recognise the change
in wheel positions. The n after approximately
ten minutes of drivin g above 25 km/h (18
mph), a message deta iling which tyre is
affected (e.g. FRONT LEFT) and TYRE NOT
MONITORED will be displayed accompanied by
illumination of the warning telltale and the
corresponding block in the vehicle graphic.
The warning telltale will initially flash and will
subsequently revert to continuous illumination.
Extended use of the temporary use spare wheel
will produce an additional text message TYRE
PRESSURE MONITORING SYSTEM FAULT .
This TPM system display sequence will be
activated at every ignition cycle until the
temporary use spare wheel is replaced by a
fully operational full size wheel and tyre
assembly. Always replace the temporary use
wheel before having TPM system faults
investigated. The fault may well be rectified
with the fitment of a fu lly operational full size
running tyre in lieu of the temporary use spare
wheel assembly.
TYRE PRESSURE MONITORING
UNAVAILABLE
If all four running wheels and tyres are changed
for a set that are not fitted with TPM system
sensors (e.g. a set of winter wheels and tyres),
the message TYRE PRESSURE MONITORING
UNAVAILABLE is displayed. TPM system
sensors must be fitted to the wheels and tyres
for the system to be able to warn of low tyre
pressures.
When sensors are fitted to the replacement
wheel and tyre set, the vehicle needs to be
driven until the TPM system recognizes the
sensors before TPM will be available ( TYRE
PRESSURE MONITORING AVAILABLE is
displayed).
TYRE CHANGING
Always have your tyres serviced or changed by
a qualified technician.
Care must be taken to avoid contact between
the bead of the tyre and the sensor during
removal and refitting of the tyre, otherwise the
sensor may become damaged and or
inoperable.
Valve stem seal, washer, nut, valve core
and cap should be repl aced at every tyre
change. Valve stem seal, washer and
nut must be replaced if valve retention
nut is loosened. Sensor units and nuts
must be refitted using correct torque
figures and associated profile. Damage
to the vehicle may result if these
precautions are not taken.
Sensors can be removed from the wheel by the
unscrewing of the va lve retention nut.

L
(FM8) SEMCON JLR OWNER GUIDE VER 1.00 EURO
LANGUAGE: english-en; MARQUE: jaguar; MODEL: XF
Tyres
186
PUNCTURED TYRES
Do not drive the vehicle with a
punctured tyre. Even if the punctured
tyre has not deflated, it is unsafe to
use, as the tyre may deflate suddenly
at any time.
REPLACEMENT TYRES
Always fit replacement tyres of the
same type, and wherever possible of
the same make and tread pattern.
If the use of tyres not recommended by
Jaguar is unavoidable, ensure that
you read, and fully comply with, the
tyre manufacturer’s instructions.
Ideally, tyres should be re placed in sets of four.
If this is not possible, replace the tyres in pairs
(both front or both rear). When tyres are
replaced, the wheels should always be
re-balanced and alignment checked.
The correct tyre specification for your vehicle
can be found on the ty re placard label.
PRESSURE COMPENSATION FOR
TEMPERATURE CHANGES
A colder ambient local temperature will reduce
pressure within the tyre. An effect is to
decrease sidewall height and to increase tyre
shoulder wear with the potential for tyre failure.
Vehicle dynamics could also be adversely
affected.
Tyre pressures can be adjusted to compensate
before the start of the journey. Alternatively,
tyre pressures can be adjusted when the area
of lower ambient temperature is reached.
In this situation, the vehicle must be left in the
ambient local temperature for at least one hour
before tyre pressure is adjusted. To compensate for colder ambient
temperatures, tyre pressures should be
increased by 0.14 bar (2 psi, 14 kPa) for each
10°C (20°F) decrease.
Note:
Ensure that correct tyre pressures are
maintained when moving to areas of differing
ambient temperature.
AVOIDING FLAT SPOTS
In order to minimise fl at spotting, the tyre
pressures can be increased to the maximum as
stated on the tyre sidewall, for the period when
the vehicle is stationary. Tyres must be
returned to the specified running pressures
before driving.
TYRE DEGRADATION
Tyres degrade over time due to the effects of
ultraviolet light, extreme temperatures, high
loads, and environmen tal conditions. It is
recommended that tyres are replaced at least
every six years, but they may require
replacement more frequently.
USING WINTER TYRES
Do not exceed 240 km/h (150 mph) when
using Jaguar approv ed winter tyres.
Winter tyres must be fitted to all four wheels.
Note: Tyres with an all season icon or M+S
have a level of winter performance and need
not be replaced.

R
(FM8) SEMCON JLR OWNER GUIDE VER 1.00 EURO
LANGUAGE: english-en; MARQUE: jaguar; MODEL: XF
Tyres
187
APPROVED WINTER TYRE SIZES
Front :
• Dunlop Wintersport M3 - 235/55R17 99H,
245/45R18 96V, 245/45R18 100V,
245/40R19 98V.
• W240 Pirelli Sotto Zero - 245/45R18 100V,
245/40R19 98V, 255/35R20 97V.
Rear:
• Dunlop Wintersport M3 - 235/55R17 99H,
245/45R18 96V, 245/45R18 100V,
245/40R19 98V.
• W240 Pirelli Sotto Zero - 245/45R18 100V,
245/40R19 98V, 285/30R20 97V.
WINTER TYRE PRESSURES USING SNOW CHAINS
It is essential that
only snow chains of
the recommended type are fitted.
Snow chains can only be fitted to rear wheels.
They should not be used on temporary use
spare wheels.
Contact your Dealer/Authorised Repairer for
details and availabilit y of approved snow
chains.
The maximum speed when using snow chains
is 50 km/h (30 mph).
Note: When using snow chains, select
JaguarDrive Contro l Winter mode and switch
DSC off. DSC would reduce the deep snow
traction capability as it would limit wheel spin
to a level below that which is required to
generate maximum traction.
Up to 210 km/h (130 mph)
17 inch Wheels - Front and Rear 2.3 bar (34 psi,
230 kPa)
18 inch Wheels - Front and Rear 2.4 bar (35 psi,
240 kPa)
19 inch Wheels - Front and Rear 2.6 bar (38 psi,
260 kPa)
20 inch Wheels - Front and Rear 2.7 bar (40 psi,
270 kPa)

R
english-en (10, 18, 21 & 25)
Index
211
tank capacity . . . . . . . . . . . . . . . . . . . . 156
water in fuel . . . . . . . . . . . . . . . . . . . . . 153
Fuses changing . . . . . . . . . . . . . . . . . . . . . . . 188
engine compartment fuse box . . . . . . . 189
locations . . . . . . . . . . . . . . . . . . . . . . . 188
luggage compartment fuse box . . . . . . 192
Passenger compartment fuse box . . . . 191
G
Garage door opener. . . . . . . . . . . . . . . . . . 48entry gate . . . . . . . . . . . . . . . . . . . . . . . 50
erase all programming. . . . . . . . . . . . . . 49
programming. . . . . . . . . . . . . . . . . . . . . 48a single button . . . . . . . . . . . . . . . . . . 49
rolling code device . . . . . . . . . . . . . . . 49
Gear selector . . . . . . . . . . . . . . . . . . . . . . . 82 malfunction . . . . . . . . . . . . . . . . . . . . . . 82
Gearbox
automatic. . . . . . . . . . . . . . . . . . . . . . . . 81
identification number. . . . . . . . . . . . . . 201
limp home mode . . . . . . . . . . . . . . . . . . 82
operation . . . . . . . . . . . . . . . . . . . . . . . . 86
selector . . . . . . . . . . . . . . . . . . . . . . . . . 82
selector malfunction . . . . . . . . . . . . . . . 82
temporary manual selection . . . . . . . . . 82
winter mode . . . . . . . . . . . . . . . . . . . . . 83
Glass cleaning . . . . . . . . . . . . . . . . . . . . . 165
Global closing . . . . . . . . . . . . . . . . . . . . . . 10
Global opening . . . . . . . . . . . . . . . . . . . . . . 7
H
Handbrake . . . . . . . . . . . . . . . . . . . . . . . . . 88
Handling adaptive dynamics . . . . . . . . . . . . . . . . . 84
DSC warning lampactive . . . . . . . . . . . . . . . . . . . . . . . . . 53
off . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
dynamic mode . . . . . . . . . . . . . . . . . . . . 83
EBD (Electronic brake force distribution) 87
Head restraints . . . . . . . . . . . . . . . . . . . . . 20
active . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 manual . . . . . . . . . . . . . . . . . . . . . . . . . . 21
removing. . . . . . . . . . . . . . . . . . . . . . . . . 21
Headlamps adaptive . . . . . . . . . . . . . . . . . . . . . . . . . 37
AFS (Adaptive front li ghting system) . . . 37
approach lamps . . . . . . . . . . . . . . . . . . . 37
auto high beam . . . . . . . . . . . . . . . . . . . . 38
condensation . . . . . . . . . . . . . . . . . . . . . 38
controls. . . . . . . . . . . . . . . . . . . . . . . . . . 36
daylight running lamps . . . . . . . . . . . . . . 37
high beam warning lamp . . . . . . . . . . . . 54
warning lamp (AFS) . . . . . . . . . . . . . . . . 53
washers . . . . . . . . . . . . . . . . . . . . . . . . . 41
wiper detection . . . . . . . . . . . . . . . . . . . . 37
Heated screens . . . . . . . . . . . . . . . . . . . . . . 64
Heated seats . . . . . . . . . . . . . . . . . . . . . . . . 65
Heated steering wheel. . . . . . . . . . . . . . . . . 22
Heating and ventilation
auto. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
recirculation . . . . . . . . . . . . . . . . . . . . . . 64
High beam
automatic . . . . . . . . . . . . . . . . . . . . . . . . 38
warning lamp . . . . . . . . . . . . . . . . . . . . . 54
Homelink . . . . . . . . . . . . . . . . . . . . . . . . . . 48
programming a single button . . . . . . . . . 49
rolling code device programming . . . . . . 49
I
Identifying the vehicletransmission number . . . . . . . . . . . . . . 201
Ignition
rolling re-start . . . . . . . . . . . . . . . . . . . . . 77
switching off while moving . . . . . . . . . . . 77
switching on . . . . . . . . . . . . . . . . . . . . . . 74
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 36 warning lamp . . . . . . . . . . . . . . . . . . . . . 54
Information messages . . . . . . . . . . . . . . . . 56
Infotainment CD controls . . . . . . . . . . . . . . . . . . . . . . . 120
DAB radio controls . . . . . . . . . . . . . . . . . . . . . . . 111

R
english-en (10, 18, 21 & 25)
Index
215
used engine oil . . . . . . . . . . . . . . . . . . 160
One-touch operation (windows) . . . . . . . . 43
Opening alarm sensor faults . . . . . . . . . . . . . . . . 11
bonnet . . . . . . . . . . . . . . . . . . . . . . . . . 160
luggage compartment . . . . . . . . . . . . . . 67
Overriding speed and follow mode (cruise) 98
P
Paddle shift temporary manual selection . . . . . . . . . 82
Paintwork cleaning . . . . . . . . . . . . . . . . . . . . . . . . 165
repair . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Parking aid . . . . . . . . . . . . . . . . . . . . . . . . 92 rear view camera . . . . . . . . . . . . . . . . . . 93
sensor cleaning . . . . . . . . . . . . . . . . . . . 93
system fault . . . . . . . . . . . . . . . . . . . . . . 93
Parking brake . . . . . . . . . . . . . . . . . . . . . . 88
Passenger compartment fuse box . . . . . . 191
Passive arming . . . . . . . . . . . . . . . . . . . . . 11
Pedestrian protection system . . . . . . . . . 198
after deployment . . . . . . . . . . . . . . . . . 198
Perimeter alarm . . . . . . . . . . . . . . . . . . . . . 11
Petrol
consumption . . . . . . . . . . . . . . . . . . . . 157
enginestarting . . . . . . . . . . . . . . . . . . . . . . . 74
switching off . . . . . . . . . . . . . . . . . . . 75
octane rating . . . . . . . . . . . . . . . . . . . . 152
specification . . . . . . . . . . . . . . . . . . . . 156
Petrol engine starting . . . . . . . . . . . . . . . . . . . . . . . . . 77
Petrol filler flap . . . . . . . . . . . . . . . . 154, 155
Phone bluetooth . . . . . . . . . . . . . . . . . . . . . . . 129
call volume . . . . . . . . . . . . . . . . . . . . . 132
changing connected phone . . . . . . . . . 131
compatibility . . . . . . . . . . . . . . . . . . . . 130
controls
steering wheel . . . . . . . . . . . . . . . . . 132
dialling . . . . . . . . . . . . . . . . . . . . . . . . . 132 icons . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
last 10 . . . . . . . . . . . . . . . . . . . . . . . . . . 133
overview . . . . . . . . . . . . . . . . . . . . . . . . 128
pairing using mobile phone . . . . . . . . . 130
pairing using touch screen . . . . . . . . . . 130
phonebook . . . . . . . . . . . . . . . . . . . . . . 132
safety . . . . . . . . . . . . . . . . . . . . . . . . . . 129
settings . . . . . . . . . . . . . . . . . . . . . . . . . 133
POI (Points of interest) . . . . . . . . . . . . . . . 141
search . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Portable media automatic reconnection . . . . . . . . . . . . 118
changing device . . . . . . . . . . . . . . . . . . 118
connecting devices . . . . . . . . . . . . . . . . 113
connecting multiple devices . . . . . . . . . 117
connections . . . . . . . . . . . . . . . . . . . . . 113
controls. . . . . . . . . . . . . . . . . . . . . . . . . 115
lost connection . . . . . . . . . . . . . . . . . . . 118
pairing. . . . . . . . . . . . . . . . . . . . . . 117, 118
playing . . . . . . . . . . . . . . . . . . . . . . . . . 117
Positioning child restraints . . . . . . . . . . . . . 29
Power steering fluid check. . . . . . . . . . . . . . . . . . . . . . . . . 173
specification . . . . . . . . . . . . . . . . . . . 173
Pressure checking . . . . . . . . . . . . . . . . . . . . . . . . 185
Pressures checking after a repair . . . . . . . . . . . . . . . . . . . 150
tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
winter tyres . . . . . . . . . . . . . . . . . . . . . . 187
Previous destination (navigation system) . 140
Programming garage door opener. . . . . . . . . . . . . . . . . 48 erase all. . . . . . . . . . . . . . . . . . . . . . . . 49
Puncture repair kit . . . . . . . . . . . . . . . . . . 147 instructions for use . . . . . . . . . . . . . . . . 149
repair procedure . . . . . . . . . . . . . . . . . . 149
safety . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Punctured tyres . . . . . . . . . . . . . . . . . . . . 186

L
english-en (10, 18, 21 & 25)
Index
220
winter mode. . . . . . . . . . . . . . . . . . . . . . 83
Transmission (automatic) . . . . . . . . . . . . . 81
Transmitters smart key . . . . . . . . . . . . . . . . . . . . . . . 181
Transporting the vehicle . . . . . . . . . . . . . 197
Trim airbag covers (cleaning) . . . . . . . . . . . 167
Trip computer . . . . . . . . . . . . . . . . . . . . . . 56 change display . . . . . . . . . . . . . . . . . . . . 56
range . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Turning on the engine diesel engine . . . . . . . . . . . . . . . . . . . . . 74
petrol engine . . . . . . . . . . . . . . . . . . . . . 74
TV analogue/digital option . . . . . . . . . . . . 123
controls . . . . . . . . . . . . . . . . . . . . . . . . 122
Tyre pressure checking . . . . . . . . . . . . . . 185
Tyre pressure checking after repair . . . . . 150
Tyre pressure monitoring system (TPMS) replacement sensor . . . . . . . . . . . . . . . . 91
Tyre repair kit
repair procedure . . . . . . . . . . . . . . . . . 149
Tyres age degradation . . . . . . . . . . . . . . . . . . 186
changing . . . . . . . . . . . . . . . . . . . . . . . . 90
flat spots . . . . . . . . . . . . . . . . . . . . . . . 186
pressures . . . . . . . . . . . . . . . . . . . . . . . 185
winter tyres . . . . . . . . . . . . . . . . . . . 187
punctured . . . . . . . . . . . . . . . . . . . . . . 186
repair kit . . . . . . . . . . . . . . . . . . . 147, 149
repair procedure . . . . . . . . . . . . . . . 149
safety . . . . . . . . . . . . . . . . . . . . . . . . 147
replacements . . . . . . . . . . . . . . . . . . . . 186
snow chains. . . . . . . . . . . . . . . . . . . . . 187
temporary use spare . . . . . . . . . . . . . . . 90
TPMS (Tyre pressure monitoring
system) . . . . . . . . . . . . . . . . . . . . . . . 89
overview . . . . . . . . . . . . . . . . . . . . . . 89
unavailable . . . . . . . . . . . . . . . . . . . . . 90
warning lamp . . . . . . . . . . . . . . . . . . . 53
tyre care. . . . . . . . . . . . . . . . . . . . . . . . 185
valves . . . . . . . . . . . . . . . . . . . . . . . . . 185
winter . . . . . . . . . . . . . . . . . . . . . . . . . 186U
Underbonnet cleaning . . . . . . . . . . . . . . . . 165
Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . 4, 9
alarm sensor faults . . . . . . . . . . . . . . . . . 11
entry and exit mode . . . . . . . . . . . . . . . . 22
global opening . . . . . . . . . . . . . . . . . . . . . 7
keyless entry . . . . . . . . . . . . . . . . . . . . . . . 6
passive arming . . . . . . . . . . . . . . . . . . . . 11
Urban cycle . . . . . . . . . . . . . . . . . . . . . . . . 157
Used engine oil . . . . . . . . . . . . . . . . . . . . . 160
Using cruise control . . . . . . . . . . . . . . . . . . 94
V
Valet mode . . . . . . . . . . . . . . . . . . . . . . . . . 61 deselecting . . . . . . . . . . . . . . . . . . . . . . . 62
Vehicle alarm . . . . . . . . . . . . . . . . . . . . . . 158
Vehicle battery care . . . . . . . . . . . . . . . . . 182
Vehicle cleaning alloy wheels . . . . . . . . . . . . . . . . . . . . . 164
carpets and mats . . . . . . . . . . . . . . . . . 167
exterior . . . . . . . . . . . . . . . . . . . . . . . . . 164
interior . . . . . . . . . . . . . . . . . . . . . 165, 166
parking sensors . . . . . . . . . . . . . . . . . . . 93
rear screen . . . . . . . . . . . . . . . . . . . . . . 165
sunroof . . . . . . . . . . . . . . . . . . . . . . . . . 165
Vehicle data recording . . . . . . . . . . . . . . . 199
Vehicle handling . . . . . . . . . . . . . . . . . . . . . 84
Vehicle identification transmission number . . . . . . . . . . . . . . 201
Vehicle recovery
attaching the front tow eye . . . . . . . . . . 197
towing eyes . . . . . . . . . . . . . . . . . . . . . . 197
transporting the vehicle . . . . . . . . . . . . 197
Vehicle settings. . . . . . . . . . . . . . . . . . . . . . 61 valet mode . . . . . . . . . . . . . . . . . . . . . . . 61
Video
loading DVDs . . . . . . . . . . . . . . . . . . . . 125
Video media player controls. . . . . . . . . . . . . . . . . . . . . . . . . 124
inhibited playback . . . . . . . . . . . . . . . . . 125
VIN number . . . . . . . . . . . . . . . . . . . . . . . 200
Voice control. . . . . . . . . . . . . . . . . . . . . . . 126
