WT-64
< REMOVAL AND INSTALLATION >
ROAD WHEEL TIRE ASSEMBLY
REMOVAL AND INSTALLATION
ROAD WHEEL TIRE ASSEMBLY
Exploded ViewINFOID:0000000006225547
Removal and InstallationINFOID:0000000006225548
REMOVAL
1. Remove wheel nuts.
2. Remove tire assembly.
INSTALLATION
Note the following, install in the reverse order of removal.
When replacing or rotating wheels, perform the ID registration. Refer to WT-29, "
Work Procedure".
InspectionINFOID:0000000006225549
ALUMINUM WHEEL
1. Check tires for wear and improper inflation.
2. Check wheels for deformation, cracks and other damage. If deformed, remove wheel and check wheel
runout.
a. Remove tire from aluminum wheel and mount on a tire balance machine.
b. Set dial indicator as shown in the figure.
c. Check radial runout, if the latera l deflection (A) or vertical deflec-
tion (B) for radial runout value exceeds the limit, replace alumi-
num wheel.
1. Tire assembly
Refer to GI-4, "
Components" for symbols in the figure.
JPEIC0088GB
Limit
Lateral deflection (A) : Refer to WT-69, "
Road Wheel".
Vertical deflection (B) : Refer to WT-69, "
Road Wheel".
SEIA0737E
Revision: 2010 May2011 QX56
WT-66
< REMOVAL AND INSTALLATION >
TRANSMITTER
TRANSMITTER
Exploded ViewINFOID:0000000006225552
Removal and InstallationINFOID:0000000006225553
REMOVAL
1. Deflate tire. Unscrew transmitter retaining nut and allow transmitter to fall into tire.
2. Gently bounce tire so that trans mitter falls to bottom of tire.
Place on tire changing machine and break both tire beads
ensuring that the transmitter remains at the bottom of the tire.
3. Turn tire so that valve hole is at bottom and bounce so that transmitter (1) is near valve hole. Carefully lift tire onto turntable
and position valve hole (and transmitter) 270 degree from
mounting/dismounting head (2).
4. Lubricate tire well and remove first side of the tire. Reach inside the tire and remove the transmitter.
INSTALLATION
JPEIC0081GB
1. Transmitter 2. Grommet seal 3. Valve nut
4. Valve core 5. Cap
Refer to GI-4, "
Components" for symbols in figure.
SEIA0047E
JPEIC0014GB
Revision: 2010 May2011 QX56
TRANSMITTERWT-67
< REMOVAL AND INSTALLATION >
C
DF
G H
I
J
K L
M A
B
WT
N
O P
1. Put first side of tire onto rim.
2. Mount transmitter on rim and tighten nut. CAUTION:
Speed for tightening nut sh ould be less than 10 rpm.
3. Place wheel on turntable of tire machine. Ensure that transmitter (1) is 270 degree from mounting head (2) when second side of
tire is fitted.
NOTE:
Do not touch transmitter at mounting head.
4. Lubricate tire well and fit second side of tire as normal. Ensure that tire does not rotate relative to rim.
5. Inflate tire and fit to appropriate wheel position.
6. Perform the transmitter wake-up after replacing transmitter. Refer to WT-28, "
Work Procedure".
SEIA0049E
JPEIC0014GB
Revision: 2010 May2011 QX56
