EC-64
< SYSTEM DESCRIPTION >[VK56VD]
DIAGNOSIS SYSTEM (ECM)
*: This function is not necessary
in the usual service procedure.
SELF-DIAG RESULTS MODE
Self Diagnostic Item
Regarding items of DTC and 1st trip DTC, refer to EC-98, "DTC Index".
How to Read DTC and 1st Trip DTC
DTCs and 1st trip DTCs related to the malfunction are displayed in “Self-diag results”.
When ECM detects a 1st trip DTC, “1t” is displayed for “TIME”.
When ECM has detected a current DTC, “0” is displayed for “TIME”.
If “TIME” is neither “0” nor “1t”, the DTC occurred in the past and ECM shows the number of times the vehi-
cle has been driven since the last detection of the DTC.
How to Erase DTC and 1st Trip DTC
NOTE:
If the ignition switch stays ON after repair work, be su re to turn ignition switch OFF once. Wait at least 10
seconds and then turn it ON (engine stopped) again.
If the DTC is not for A/T related items (see EC-98, "
DTC Index"), skip step 1.
1. Erase DTC in TCM. Refer to TM-60, "
Diagnosis Description".
2. Select “ENGINE” with CONSULT-III.
3. Select “SELF-DIAG RESULTS”.
4. Touch “ERASE”. (DTC in ECM will be erased.)
WORK ITEM CONDITION USAGE
IDLE AIR VOL LEARN THE IDLE AIR VOLUME THAT KEEPS THE ENGINE
WITHIN THE SPECIFIED RANGE IS MEMORIZED IN
ECM. When learning the idle air volume
EVAP SYSTEM CLOSE CLOSE THE EVAP CANISTER VENT CONTROL VALVE IN
ORDER TO MAKE EVAP SYSTEM CLOSE UNDER THE
FOLLOWING CONDITIONS.
IGN SW ON
ENGINE NOT RUNNING
AMBIENT TEMPERATURE IS ABOVE 0
°C (32 °F).
NO VACUUM AND NO HIGH PRESSURE IN EVAP SYS-
TEM
FUEL TANK TEMP. IS MORE THAN 0 °C (32 °F).
WITHIN 10 MINUTES AFTER STARTING “EVAP SYS-
TEM CLOSE”
WHEN TRYING TO EXECUTE “EVAP SYSTEM CLOSE” UNDER THE CONDITION EXCEPT ABOVE, CONSULT-
III WILL DISCONTINUE IT AND DISPLAY APPROPRI-
ATE INSTRUCTION.
NOTE:
WHEN STARTING ENGINE, CONSULT-III MAY DIS-
PLAY “BATTERY VOLTAGE IS LOW. CHARGE BAT-
TERY”, EVEN WHEN USING A CHARGED BATTERY. When detecting EVAP vapor leak
in the EVAP system
FUEL PRESSURE RELEASE FUEL PUMP WILL STOP BY TOUCHING “START” DUR-
ING IDLING.
CRANK A FEW TIMES AFTER ENGINE STALLS. When releasing fuel pressure from
fuel line
SELF-LEARNING CONT THE COEFFICIENT OF SELF-LEARNING CONTROL
MIXTURE RATIO RETURNS TO THE ORIGINAL COEF-
FICIENT. When clearing mixture ratio self-
learning value
TARGET IDLE RPM ADJ* IDLE CONDITION When setting target idle speed
VIN REGISTRATION IN THIS MODE, VIN IS REGISTERED IN ECM. When registering VIN in ECM
TARGET IGN TIM ADJ* IDLE CONDITION When adjusting target ignition tim-
ing
CLSD THL POS LEARN IGNITION ON AND ENGINE STOPPED. When learning the throttle valve
closed position
VVEL POS SEN ADJ PREP USE THIS ITEM ONLY WHEN REPLACING VVEL ACTU-
ATOR SUB ASSEMBLY.
IGNITION ON AND ENGINE STOPPED. When adjusting VVEL control
shaft position sensor
Revision: 2010 May2011 QX56
EC-104
< ECU DIAGNOSIS INFORMATION >[VK56VD]
ECM
*2: This number is prescribed by SAE J2012/ISO 15031-6.
*3: In Diagnostic Test
Mode II (Self-diagnostic results), this number is controlled by NISSAN.
*4: The troubleshooting for this DTC needs CONSULT-III.
*5: When the fail safe operations for both self-diagnoses occur, the MIL illuminates.
*6: When the ECM is in the mode that displays SRT status, MIL may blink. For the details, refer to “How to Display SRT Status”.
*7: When erasing this DTC, al ways use CONSULT-III or GST.
*8: SRT code will not be set if the self-diagnostic result is NG.
Test Value and Test LimitINFOID:0000000006217734
The following is the information specified in Service $06 of ISO 15031-5.
The test value is a parameter used to determine whether a system/circuit diagnostic test is OK or NG while
being monitored by the ECM during self-diagnosis. The test limit is a reference value which is specified as the
maximum or minimum value and is compared with the test value being monitored.
These data (test value and test limit) are specified by On Board Monitor ID (OBDMID), Test ID (TID), Unit and
Scaling ID and can be displayed on the GST screen.
The items of the test value and test limit will be di splayed with GST screen which items are provided by the
ECM. (e.g., if bank 2 is not applied on this v ehicle, only the items of bank 1 are displayed)
ItemOBD-
MID Self-diagnostic test item DTC Test value and Test
limit
(GST display) Description
TID Unit and
Scaling ID
HO2S 01H
Air fuel ratio (A/F) sensor 1
(Bank 1) P0131 83H 0BH
Minimum sensor output voltage for test
cycle
P0131 84H 0BH Maximum sensor output voltage for test
cycle
P0130 85H 0BH Minimum sensor output voltage for test
cycle
P0130 86H 0BH Maximum sensor output voltage for test
cycle
P0133 87H 04H Response rate: Response ratio (Lean to
Rich)
P0133 88H 04H Response rate: Response ratio (Rich to
Lean)
P2A00 89H 84H The amount of shift in air fuel ratio
P2A00 8AH 84H The amount of shift in air fuel ratio P0130 8BH 0BH Difference in sensor output voltage
P0133 8CH 83H Response gain at the limited frequency
02H Heated oxygen sensor 2
(Bank 1) P0138 07H 0CH
Minimum sensor output voltage for test
cycle
P0137 08H 0CH Maximum sensor output voltage for test
cycle
P0138 80H 0CH Sensor output voltage
P0139 81H 0CH Difference in sensor output voltage
03H Heated oxygen sensor 3
(Bank 1) P0143 07H 0CH
Minimum sensor output voltage for test
cycle
P0144 08H 0CH Maximum sensor output voltage for test
cycle
P0146 80H 0CH Sensor output voltage
P0145 81H 0CH Difference in sensor output voltage
Revision: 2010 May2011 QX56
EC-136
< BASIC INSPECTION >[VK56VD]
DIAGNOSIS AND REPAIR WORKFLOW
1.GET INFORMATION FOR SYMPTOM
Get the detailed information from the customer about the symptom (the condition and the environment when
the incident/malfunction occurred) using t he “Diagnostic Work Sheet”. (Refer to EC-138, "
Diagnostic Work
Sheet".)
>> GO TO 2.
2.CHECK DTC
1. Check DTC.
2. Perform the following procedure if DTC is displayed.
- Record DTC and freeze frame data. (Print them out with CONSULT-III or GST.)
- Erase DTC. (Refer to “How to Erase DTC and 1st Trip DTC” in EC-63, "
CONSULT-III Function" or
EC-60, "
On Board Diagnosis Function".)
- Study the relationship between the cause detected by DTC and the symptom described by the customer.
(Symptom Matrix Chart is useful. Refer to EC-524, "
Symptom Table".)
3. Check related service bulletins for information.
Are any symptoms described and any DTCs detected?
Symptom is described, DTC is detected>>GO TO 3.
Symptom is described, DTC is not detected>>GO TO 4.
Symptom is not described, DTC is detected>>GO TO 5.
3.CONFIRM THE SYMPTOM
Try to confirm the symptom described by the customer (except MIL ON).
Also study the normal operation and fail-s afe related to the symptom. Refer to EC-529, "
Description" and EC-
93, "Fail-safe".
Diagnosis Work Sheet is useful to verify the incident.
Verify relation between the symptom and the condition when the symptom is detected.
>> GO TO 5.
4.CONFIRM THE SYMPTOM
Try to confirm the symptom described by the customer.
Also study the normal operation and fail-s afe related to the symptom. Refer to EC-529, "
Description" and EC-
93, "Fail-safe".
Diagnosis Work Sheet is useful to verify the incident.
Verify relation between the symptom and the condition when the symptom is detected.
>> GO TO 6.
5.PERFORM DTC CONFIRMATION PROCEDURE
Perform DTC CONFIRMATION PROCEDURE for the disp layed DTC, and then check that DTC is detected
again.
If two or more DTCs are detected, refer to EC-96, "
DTC Inspection Priority Chart" and determine trouble diag-
nosis order.
NOTE:
Freeze frame data is useful if the DTC is not detected.
Perform Component Function Check if DTC CONFIR MATION PROCEDURE is not included on Service
Manual. This simplified check procedure is an effect ive alternative though DTC cannot be detected during
this check.
If the result of Component Function Check is NG, it is the same as the detection of DTC by DTC CONFIR-
MATION PROCEDURE.
Is DTC detected?
YES >> GO TO 10.
NO >> Check according to GI-40, "
Intermittent Incident".
6.PERFORM BASIC INSPECTION
Perform EC-139, "
Work Procedure".
Revision: 2010 May2011 QX56
BASIC INSPECTIONEC-139
< BASIC INSPECTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
BASIC INSPECTION
Work ProcedureINFOID:0000000006217739
1.INSPECTION START
1. Check service records for any recent repairs that ma y indicate a related malfunction, or a current need for
scheduled maintenance.
2. Open engine hood and check the following:
- Harness connectors for improper connections
- Wiring harness for improper connections, pinches and cut
- Vacuum hoses for splits, kinks and improper connections
- Hoses and ducts for leakage
- Air cleaner clogging
- Gasket
3. Check that electrical or mechanical loads are not applied.
- Headlamp switch is OFF.
- Air conditioner switch is OFF.
- Rear window defogger switch is OFF.
- Steering wheel is in the straight-ahead position, etc.
4. Start engine and warm it up until engine coolant temperature indicator points to the middle of gauge.
Check that engine stays below 1,000 rpm.
5. Run engine at approximately 2,000 rpm for approximately 2 min- utes under no load.
6. Check that no DTC is displayed with CONSULT-III or GST.
Are any DTCs detected?
YES >> GO TO 2.
NO >> GO TO 3.
2.REPAIR OR REPLACE
Repair or replace components as necessary according to corresponding Diagnosis Procedure.
>> GO TO 3
3.CHECK IDLE SPEED
1. Run engine at approximately 2,000 rpm for approximately 2 minutes under no load.
SEF983U
SEF976U
SEF977U
Revision: 2010 May2011 QX56
ADDITIONAL SERVICE WHEN REPLACING ECMEC-143
< BASIC INSPECTION > [VK56VD]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
ADDITIONAL SERVICE WHEN REPLACING ECM
DescriptionINFOID:0000000006217740
When replacing ECM, the following procedure must be performed.
Work ProcedureINFOID:0000000006217741
1.PERFORM INITIALIZATION OF IVIS (NATS) SYSTEM AND REGISTRATION OF ALL IVIS (NATS) IGNI-
TION KEY IDS
Perform initialization of IVIS (NATS) system and registration of all IVIS (NATS) ignition key IDs. Refer to SEC-
51, "ECM : Work Procedure".
>> GO TO 2.
2.PERFORM VIN REGISTRATION
Perform VIN registration. Refer to EC-145, "
Work Procedure".
>> GO TO 3.
3.PERFORM ACCELERATOR PEDAL RE LEASED POSITION LEARNING
Perform accelerator pedal released position learning. Refer to EC-146, "
Work Procedure".
>> GO TO 4.
4.PERFORM THROTTLE VALVE CL OSED POSITION LEARNING
Perform throttle valve closed position learning. Refer to EC-147, "
Work Procedure".
>> GO TO 5.
5.PERFORM IDLE AIR VOLUME LEARNING
Perform idle air volume learning. Refer to EC-148, "
Work Procedure".
>> END
Revision: 2010 May2011 QX56
EC-144
< BASIC INSPECTION >[VK56VD]
ADDITIONAL SERVICE WHEN REPL
ACING VVEL CONTROL MODULE
ADDITIONAL SERVICE WHEN REPLACING VVEL CONTROL MODULE
DescriptionINFOID:0000000006217742
When replacing VVEL control module, t he following procedure must be performed.
Work ProcedureINFOID:0000000006217743
1.PERFORM IDLE AIR VOLUME LEARNING
Perform idle air volume learning. Refer to EC-148, "
Work Procedure".
>> END
Revision: 2010 May2011 QX56
EC-152
< BASIC INSPECTION >[VK56VD]
MIXTURE RATIO SELF-LEARNING VALUE CLEAR
MIXTURE RATIO SELF-LEARNING VALUE CLEAR
DescriptionINFOID:0000000006217754
This describes how to erase the mixture ratio self-learni
ng value. For the actual procedure, follow the instruc-
tions in “Diagnosis Procedure”.
Work ProcedureINFOID:0000000006217755
1.START
WITH CONSULT-III
1. Start engine and warm it up to normal operating temperature.
2. Select “SELF-LEARNING CONT” in “WORK SUPPORT” mode with CONSULT-III.
3. Clear mixture ratio self-learning value by touching “CLEAR”.
WITH GST
1. Start engine and warm it up to normal operating temperature.
2. Turn ignition switch OFF.
3. Disconnect mass air flow sensor harness connector.
4. Restart engine and let it idle for at least 5 seconds.
5. Stop engine and reconnect mass air flow sensor harness connector.
6. Select Service $03 with GST. Check DTC P0102 is detected.
7. Select Service $04 with GST to erase the DTC P0102.
>> END
Revision: 2010 May2011 QX56
EC-156
< BASIC INSPECTION >[VK56VD]
HOW TO SET SRT CODE
HOW TO SET SRT CODE
DescriptionINFOID:0000000006265593
OUTLINE
In order to set all SRTs, the self-diagnoses as in
the “SRT ITEM” table must have been performed at least
once. Each diagnosis may require actual driving for a long period of time under various conditions.
SRT ITEM
The table below shows required self-diagnostic items to set the SRT to “CMPLT”.
*1: Though displayed on the CONSULT-III screen, “HO2S HTR” is not SRT item.
SRT SERVICE PROCEDURE
If a vehicle has failed the state emissions inspection due to one or more SRT items indicating “INCMP”, review
the flowchart diagnostic sequence, refe rring to the following flowchart.
SRT item*1
(CONSULT-III indication)Required self-diagnostic items to set the SRT to “CMPLT” Corresponding DTC No.
CATALYST Three way catalyst function P0420, P0430
EVAP SYSTEM EVAP control system purge flow monitoring P0441
EVAP control system P0456
HO2S Air fuel ratio (A/F) sensor 1 P0130, P0133, P0150, P0153 Heated oxygen sensor 2 P0137, P0157
Heated oxygen sensor 2 P0138, P0158
Heated oxygen sensor 2 P0139, P0159
EGR/VVT SYSTEM Intake value timing control function P0011, P0021
Revision: 2010 May2011 QX56
