Page 80 of 722

This shows the temperature of the
engine’s coolant. During normal
operation, the pointer should rise
from the bottom mark to about the
middle of the gauge. In severe
driving conditions, such as very hot
weather or a long period of uphill
driving, the pointer may rise to the
upper zone. If it reaches the red
(hot) mark, pull saf ely to the side of
the road. Turn to page for
instructions and precautions on
checking the engine cooling system.
This shows how much f uel you have.
It may show slightly more or less
than the actual amount. The needle
returns to the bottom after you turn
of f the ignition.667
Temperature Gauge
Fuel Gauge
Gauges
Instruments and Controls
77
INFORMATION DISPLAY/
MULTI-INFORMATION DISPLAY
TACHOMETER SPEEDOMETER
FUEL GAUGE
TEMPERATURE
GAUGE
SELECT/RESET KNOB
U.S. Touring model is shown.
Avoid driving with an extremely low
f uel level. Running out of f uel could
cause the engine to misf ire, damaging
the catalytic converter.
10/07/17 09:44:53 31TK8600_082
2011 Odyssey
Page 81 of 722

The odometer shows the total
distance your vehicle has been
driven. It measures miles in U.S.
models and kilometers in Canadian
models. It is illegal under U.S.
f ederal law and Canadian provincial/
territorial regulations to disconnect,
reset, or alter the odometer with the
intent to change the number of miles
or kilometers indicated.
To switch the display, press and
release the select/reset knob
repeatedly. When you turn the
ignition switch to the ON (II)
position, your last selection is
displayed. This meter shows the number of
miles (U.S.) or kilometers (Canada)
driven since you last reset it.
There are two trip meters: Trip A
and Trip B. Switch between these
displays by pressing the select/reset
knob repeatedly.
Each trip meter works independently,
so you can keep track of two
dif f erent distances.
To reset a trip meter, display it, and
then press and hold the select/reset
knob until the number resets to ‘‘0.0’’.
For inf ormation about the multi-
inf ormation display, see page .
The inf ormation display shows the
odometer, trip meter, engine oil lif e,
outside temperature (if equipped),
instant f uel economy, average f uel
economy, range (estimated distance),
and maintenance item code(s).
83
On Touring models
On LX, EX, EX-L models
GaugesInf ormation Display
Odomet er
Trip Meter
78
OUTSIDE
TEMPERATURE
INDICATOR
U.S. model with outside temperature indicator is shown. INFORMATION DISPLAY
TRIP METER B
ODOMETER
RANGE
(ESTIMATED DISTANCE)
: Press the select/reset knob.
AVERAGE
FUEL
ECONOMY
ENGINE
OIL LIFE TRIP METER A INSTANT FUEL
ECONOMY
10/07/17 09:45:05 31TK8600_083
2011 Odyssey
Page 82 of 722
When either of the trip meters (trip
A or B) is displayed, your vehicle’s
average f uel economy since you last
resetthattripmetercanbeshown
on the inf ormation display (mpg on
U.S. models and l/100 km on
Canadian models). This number is
updated once per 10 seconds. To see
the average f uel economy, press and
release the select/reset knob
repeatedly.
When you reset a trip meter, the
average f uel economy f or that trip
meter also resets.This display shows the estimated
distance you can travel on the fuel
remaining in the tank.
This distance is estimated f rom the
f uel economy you have achieved
over the last f ew miles (kilometers),
so it will vary with changes in speed,
traffic condition, etc.
This display shows the instant f uel
economy you are getting.
It shows the number of mpg (U.S.)
or l/100 km (Canada).
Gauges
A verage Fuel Economy
Range (Est imat ed Dist ance)
Inst ant Fuel Economy
Instruments and Controls
79
10/07/17 09:45:12 31TK8600_084
2011 Odyssey
Page 83 of 722

¶¶To adjust the outside temperature
display, press and hold the select/
reset knob f or 10 seconds. The
display changes as shown above.
This indicator displays the outside
temperature in Fahrenheit (U.S.
models) or Celsius (Canadian
models).
The temperature sensor is in the
f ront bumper. The temperature
reading can be affected by heat
ref lection f rom the road surf ace,
engine heat, and the exhaust f rom
surrounding traf f ic. This can cause
an incorrect temperature reading
when your vehicle speed is under
19 mph (30 km/h). When you start
your trip, the sensor is not f ully
acclimatized, theref ore it may take
several minutes until the proper
temperature is displayed. If the outside temperature is
incorrectly displayed, you can adjust
it up to 5°F in U.S. models ( 3°C
in Canadian models) warmer or
cooler.
The temperature must be
stabilized bef ore doing this
procedure.
Except LX modelGaugesOut side T emperat ure Indicat or80
NOTE:
OUTSIDE
TEMPERATURE
DISPLAY
: Press and release the select/reset knob.
10/07/17 09:45:19 31TK8600_085
2011 Odyssey
Page 84 of 722

µµµµ
µµ µ
µ µ
µ
Select the outside temperature
display by pressing and releasing the
select/reset knob. Press and hold
the same knob f or a f ew seconds to
enter this setting, then turn it to
adjust the temperature. The
f ollowing sequence will appear f or
each:0,1,2,3,4,5, 5, 4, 3, 2,
1,0(U.S.)or0,1,2,3, 3, 2,
1, 0 (Canada). IGN ON (II) Immediately turn of f
all electrical devices (interior lights,
air conditioning, audio, heated seats,
etc.). Try not to operate other
electrically operated controls such as
the power windows. Driving the
vehicle will recharge the battery. If
the message continues to display
while driving, see your dealer.
IGN ACCESSORY (I) or LOCK (0)
Follow the message and turn of f
all electrical devices. Driving the
vehicle will recharge the battery,
however the vehicle may not start. If
it does not start, see jump starting
(see page ), or contact your
dealer.
When the temperature reaches the
desired value, release the select/
reset knob. You should see the new
outside temperature displayed.
In certain weather conditions,
temperature readings near f reezing
(32°F, 0°C) could mean that ice is
f orming on the road surf ace. Whenthebattery’sstateof chargeis
low, the vehicle’s battery
management system triggers a
‘‘BATT LOW’’ message if the
ignition switch is on or of f .
Depending on how low the battery’s
state of charge dropped and how
long it remained low, these
messages may occur f requently. It
may take a number of trips to
sufficiently recharge the battery and
the messages to no longer appear.
665
Gauges
Battery Charge Low
Instruments and Controls
81
10/07/17 09:45:25 31TK8600_086
2011 Odyssey
Page 85 of 722

The inf ormation display in the
instrument panel shows you the
engine oil lif e and maintenance
service items when the ignition
switch is in the ON (II) position. This
inf ormation helps to keep you aware
of the periodic maintenance your
vehicle needs f or continued trouble-
f ree driving. Ref er to page f or
more inf ormation.Your vehicle’s onboard diagnostic
system will detect a loose or missing
f uel f ill cap as an evaporative system
leak. The f irst time a leak is detected
a ‘‘CHECK FUEL CAP’’ message
appears on the inf ormation display.
Turn the engine of f , and conf irm the
f uel f ill cap is installed. If it is, loosen
it, then retighten it until it clicks at
least once. The message should go
off after several days of normal
driving once you tighten or replace
the f uel f ill cap. To scroll to another
display, press the select/reset knob.
The ‘‘CHECK FUEL CAP’’ message
will appear each time you restart the
engine until the system turns the
message of f . If the system still detects a leak in
your vehicle’s evaporative emissions
system, the malf unction indicator
lamp (MIL) comes on. If the f uel f ill
cap was not already tightened, turn
the engine of f , and check or
retighten the f uel f ill cap until it
clicks at least once. The MIL should
go of f af ter several days of normal
driving once the cap is tightened or
replaced. If the MIL does not go of f ,
have your vehicle inspected by a
dealer. For more inf ormation, see
page .
599
671GaugesMaint enance MinderCheck Fuel Cap Message82
TM
10/07/17 09:45:32 31TK8600_087
2011 Odyssey
Page 86 of 722

Û
Ý
ÛÝ
CONT INUED
The multi-inf ormation display in the
instrument panel displays various
inf ormation and messages when the
ignition switch is in the ON (II)
position. Some of the messages help
you operate your vehicle more
comf ortably. Others help to keep
you aware of the periodic
maintenance your vehicle needs f or
continued trouble-f ree driving.
To change the display, press the
SEL/RESET button or INFO ( /)buttononthesteeringwheel
repeatedly until the desired
information appears (see page ).
When you turn the ignition switch to
the ON (II) position, your last
selection is displayed.
The multi-inf ormation display
consists of two segments: an upper
segment and a lower segment.
In the normal display mode, the
upper segment displays trip
computer inf ormation, such as f uel
economy or average speed. The
lower segment displays the
odometer/trip meter (A/B), outside
temperature, and engine oil lif e and
maintenance item code(s).
There are two types of messages;
normal display messages and system
messages.
You can select the displayed
language and also customize some
vehicle control settings to your liking
with the multi-information display
and the three buttons on the steering
wheel.
84On Touring models
Multi-Inf ormation Display
Normal Display Messages
Instruments and Controls
83
INFO ( / ) BUTTON
SEL/RESET BUTTON
UPPER SEGMENT
LOWER SEGMENT
U.S. model is shown.
10/07/17 09:45:40 31TK8600_088
2011 Odyssey
Page 87 of 722
ÛÝ
Multi-Inf ormation Display84
: Press the SEL/RESET button. : Press the INFO ( / ) button.
U.S. model is shown.
