The heating and air conditioning
system in your vehicle provides a
comf ortable driving environment in
all weather conditions.
The standard audio system has
many f eatures. This section
describes those f eatures and how to
use them.
Your vehicle has an anti-theft audio
system that requires a code number
to enable it.
The security system helps to.............
Vents, Heating, and A/C . 122
...............
Climate Control System . 128
................................
Audio System .136
..........
Playing the FM/AM Radio . 137
................................
Playing a Disc .144
.......
Disc Player Error Messages . 150
................................
Audio System .151
..........
Playing the FM/AM Radio . 152
................
Playing the XM
Radio . 159
.................................
Playing Discs .165
...
Disc Changer Error Messages . 175
............................
PlayinganiPod
. 176
.................
iPod
Error Messages . 184
Playing a USB Flash Memory ........................................
Device .185
USB Flash Memory Device ........................
Error Messages .193
................................
Audio System .194
..........
Playing the FM/AM Radio . 195
................
Playing the XM
Radio . 207
.................................
Playing Discs .214
...
Disc Changer Error Messages . 225............................
PlayinganiPod
. 226
.................
iPod
Error Messages . 234
Playing a USB Flash Memory ........................................
Device .235
USB Flash Memory Device ........................
Error Messages .244
..................
Protecting Your Discs . 245
............
FM/AM Radio Reception . 248
................
Remote Audio Controls . 250
......................
Auxiliary Input Jack .252
.................
Radio Thef t Protection . 253
..........................
Setting the Clock .254
............................
Security System .257
.........................................
Compass .259
...............................
Cruise Control .263
HomeLink
Universal ................................
Transceiver .266
........
HandsFreeLink
. 270
...
Rearview Camera and Monitor . 294
LX, LX-P,andU.S. SE models
EX, EX-L, Canadian SE, andV6
models without navigation system
Models with navigation system Bluetooth
Except LX
Except LX
,LX-P, and SE
Features
Features
121
10/06/18 18:02:48 31TA5630_126
discourage vandalism and theft of
your vehicle.
2011 Accord Sedan

µ
µ µ
µ
µ Adjusts the volume level
basedonthevehiclespeed.
Press the SOUND (TUNE) knob
repeatedly to display the BASS,
TREBLE, FADER, BALANCE, and
SVC (speed-sensitive volume
compensation) settings. Eachmodeisshowninthedisplayas
it changes. Turn the TUNE knob to
adjust the setting to your liking.
The SVC has f our modes: SVC OFF,
SVC LOW, SVC MID, and SVC
HIGH. Turn the TUNE knob toadjust the setting to your liking. If
you f eel the sound is too loud,
choose low. If you f eel the sound is
too quiet, choose high.
The SVC mode controls the volume
based on vehicle speed. The f aster
you go, the louder the audio volume
becomes. As you slow down, the
audio volume decreases. When the level reaches the center,
you will see ‘‘C’’ in the display.
Adjusts the bass.
Adjusts the treble.
Adjusts the front-to-back
strength of the sound.
Adjusts the side-to-
side strength of the sound. The system will return to the audio
display about 10 seconds af ter you
stop adjusting a mode.You can use the instrument panel
brightness control knob to adjust the
illumination of the audio system (see
page ). The audio system
illuminates when the parking lights
are on, even if the radio is turned of f .
72
Except SVC adjustment
Adjusting the Sound
SVC
BASS
TREBLE
FADER
BAL ANCE A udio System L ighting
Speed-sensit ive Volume
Compensat ion (SVC)
Playing the FM/AM Radio (LX, LX-P, and U.S. SE models)
Features
143
10/06/18 16:01:01 31TA5630_148
2011 Accord Sedan

To load or play a disc, the ignition
switch must be in the ACCESSORY
(I) or ON (II) position.This audio system can also play
CD-Rs and CD-RWs compressed in
MP3 or WMA f ormats. When
playing a disc in MP3, you will see
‘‘MP3’’ in the display. In WMA
f ormat, ‘‘WMA’’ will appear in the
display. You can select up to 99
f olders, or up to 255 tracks/f iles.
You operate the disc player with the
same controls used f or the radio. To
select the disc player, press the CD
button. You will see ‘‘CD’’ in the
display.
Video CDs and DVDs do not work in
this unit. If a f ile on a WMA disc is protected
by digital rights management
(DRM), the audio unit displays
UNSUPPORTED, and then skips to
the next f ile. Depending on the sof tware the f iles
were made with, it may not be
possible to play some f iles, or display
some text data.Insert a disc about half way into the
disc slot. The drive will pull the disc
intherestof thewaytoplayit.You
operate the disc player with the
same controls used f or the radio.
The number of the current track is
showninthedisplay.Whenplayinga
disc in MP3 or WMA, the numbers
of the current f older and f ile are
shown. The system will continuously
play a disc until you change modes.
You cannot load and play 3-inch
(8-cm)discsinthissystem.
For inf ormation on how to handle
and protect compact discs, see
CONT INUED
To Play a Disc
Playing a Disc (L X, L X-P, and U.S. SE models)
To Load a Disc
Features
145
NOTE:
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
10/06/18 16:01:14 31TA5630_150
page 245 .
2011 Accord Sedan

µµ
µ
µ µ
µ
Adjusts the bass.
Adjusts the side-to-
side strength of the sound. Adjusts the front-to-back
strength of the sound. Adjusts the treble. Adjusts the strength of
sound f rom the subwoof er speaker.
The SVC has f our modes: SVC OFF,
SVC LOW, SVC MID, and SVC
HIGH. Turn the selector knob to
adjust the setting to your liking. If
you f eel the sound is too loud,
choose low. If you f eel the sound is
too quiet, choose high. The SVC mode controls the volume
based on vehicle speed. The f aster
you go, the louder the audio volume
becomes. As you slow down, the
audio volume decreases.
Eachmodeisshowninthedisplayas
it changes. Turn the selector knob to
adjust the setting to your liking. If the fader adjustment is set to F9
(maximum f ront level), the
subwoof er is turned of f . Adjusts the volume level
basedonthevehiclespeed.
When the level reaches the center,
you will see ‘‘C’’ in the display.
To return to the normal play, push
the RETURN or MENU button after
you stop adjusting a mode. You can use the instrument panel
brightness control knob to adjust the
illumination of the audio system (see
page ). The audio system
illuminates when the parking lights
are on, even if the radio is turned of f .
72
If equipped
Except SVC adjustment
BASS
BAL ANCE FADER TREBLE SUBW
SVC
A udio System L ighting
Speed-sensit ive VolumeCompensat ion (SVC)
Playing the FM/AM Radio (EX, EX-L , Canadian SE, and V6 models without navigation system)
158
SUBWOOFER is selectable.
10/06/18 16:03:06 31TA5630_163
2011 Accord Sedan

To load or play discs, the ignition
switch must be in the ACCESSORY
(I) or ON (II) position.
You operate the disc changer with
the same controls used f or the radio.
To select the disc changer, press the
CD/AUX or CD button. You will see
‘‘CD’’ in the display. The disc and
track numbers, and the elapsed time
areshowninthedisplay.Youcan
also select the displayed inf ormation
with the TITLE button (see page). The system will continuously
play a disc until you change modes. This audio system can also play
CD-Rs and CD-RWs compressed in
MP3 or WMA f ormats. When
playing a disc in MP3, you will see
‘‘MP3’’ in the display. In WMA
f ormat, ‘‘WMA’’ will appear in the
display. You can select up to 99
f olders, or up to 255 tracks/f iles.
Video CDs and DVDs do not work in
this unit. Depending on the sof tware the f iles
were made with, it may not be
possible to play some f iles, or display
some text data.
If a f ile on a WMA disc is protected
by digital rights management
(DRM), the audio unit displays
UNSUPPORTED, and then skips to
the next f ile.Your vehicle’s in-dash disc changer
holdsuptosixdiscs.
Press the LOAD button until you
hear a beep and see ‘‘LOAD’’ in
the display. To load only one disc,
press and release the LOAD
button.
The disc number f or an empty
position begins blinking.
Insert the disc into the disc slot
when the green disc load indicator
comes on. Insert it only about
half way; the drive will pull it in the
rest of the way. You will see
‘‘BUSY’’ in the display while the
disc load indicator turns red and
blinks as the disc is loaded.
167 1.
2.
3.
To Play a Disc
Playing Discs (EX, EX-L, Canadian SE, and V6 models without navigation system)
L oading Discs
166
NOTE:
Do not use discs with adhesive labels.
The label can curl up and cause the
disc to jam in the unit.
10/06/18 16:04:12 31TA5630_171
2011 Accord Sedan

This audio system can select and
play the audio f iles on the iPod
with
the same controls used f or the disc
player. To play an iPod, connect it to
the USB adapter cable in the console
compartment by using your dock
connector, then press the CD/AUX
button (AUX button on models
without XM Radio). The ignition
switch must be in the ACCESSORY
(I) or ON (II) position. The iPod will
also be recharged with the ignition
switch in these positions.
The audio system reads and plays
playable sound f iles on the iPod. The
system cannot operate an iPod as a
mass storage device. The system will
only play songs stored on the iPod
with iTunes.
iPod and iTunes are registered
trademarks owned by Apple Inc. iPods compatible with your audio
system using the USB adapter cable
are:
UseonlycompatibleiPodswiththe
latest sof tware. iPods that are not
compatible will not work in this audio
unit.
CONT INUED
Model
iPod classic
(80/160 G)
iPod classic
(120 G)
iPod with video
(iPod 5th
generation)
iPod nano
iPod nano
2nd generation
iPod nano
3rd generation
iPod nano
4th generation
iPod nano
5th generation
iPod touch
iPod touch
2nd generation Sof tware
Ver. 1.1.2 or more
Ver. 2.0.1 or more
Ver. 1.3.0 or more
Ver. 1.3.1 or more
Ver. 1.1.3 or more
Ver. 1.1.3 or more
Ver. 1.0.3 or more
Ver. 1.0.1 or more
Ver. 1.1.5 or more
Ver. 2.2.1 or more
To Play an iPod
Playing an iPod(EX, EX-L and V6 models without navigation system)
Features
177
10/06/18 16:05:30 31TA5630_182
2011 Accord Sedan

Î
ÎDo not use a device such as a card
reader or hard drive as the device
or your f iles may be damaged.
Do not connect your USB f lash
memory device using a hub.
Do not use an extension cable to
the USB adapter cable equipped
with your vehicle.
Do not keep a USB f lash memory
device in the vehicle. Direct
sunlight and high heat will damage
it.
We recommend backing up your
data bef ore playing a USB f lash
memory device.
Some USB f lash memory devices
(such as devices with security lock-
out f eatures, etc.) will not work in
this audio unit. The recommended USB f lash
memory devices are 256 MB or
higher, and f ormatted with the FAT
f ile system. Some digital audio
players may be compatible as well. Only AAC f ormat f iles recorded
with iTunes are playable on this
audio unit.
The audio system reads and plays
the audio f iles on the USB f lash
memory device in MP3, WMA or
AAC f ormats. Depending on the
f ormat, the display shows MP3,
WMA or AAC when a USB flash
memory device is playing. The USB
f lash memory device limit is up to
700 f olders or up to 65535 f iles. This audio system can select and
play the audio f iles on a USB f lash
memory device with the same
controls used f or the disc player. To
play a USB f lash memory device,
connect it to the USB adapter cable
in the console compartment, then
press the CD/AUX button (AUX
button on models without XM Radio).
The ignition switch must be in the
ACCESSORY (I) or ON (II) position. :
To Play a USB Flash Memory
Device
Playing a USB Flash Memory Device (EX, EX-L and V6 models without navigation system)
186
NOTE:
10/06/18 16:06:37 31TA5630_191
2011 Accord Sedan

µµ µ
To adjust bass
and treble, select BASS or TREBLE,
andpressENTERontheinterface
selector. The current setting is
shownonthedisplay.Turnthe
interf ace knob to the desired level,
and enter your selection by pressing
ENTER on the interf ace selector. The SVC mode controls the volume
based on vehicle speed. The f aster
you go, the louder the audio volume
becomes. As you slow down, the
audio volume decreases.
The SVC has f our modes: SVC OFF,
SVC LOW, SVC MID, and SVC
HIGH. The def ault setting is MID.
To change the SVC mode, select
SVC, then press ENTER on the
interf ace selector. The current
setting is shown on the screen. Turn
the interface knob to the desired
level, and enter your selection by
pressing ENTER on the interf ace
selector. If you f eel the sound is too
loud, choose low. If you f eel the
sound is too quiet, choose high.
These
modes adjust the strength of the
sound coming f rom each speaker.
Fader adjusts the f ront-to-back
strength, while balance adjusts the
side-to-side strength. To adjust f ader
and balance, select FADER or
BALANCE, then press ENTER on
the interf ace selector. The current
setting is shown on the screen. Turn
the interface knob to the desired
level, and enter your selection by
pressing ENTER on the interf ace
selector. To equalize the f ader or
balance, turn the interf ace knob until
the marks on the sound grid come to
the center of the adjustment bar. To adjust the
strength of the sound f rom the
subwoof er speaker, select it and
press ENTER on the interf ace
selector. Turn the interf ace knob to
the desired level, and enter your
selection by pressing ENTER on the
interf ace selector.
If the fader adjustment is set to F9
(maximum f ront level), the
subwoof er is turned of f .
BASS/TREBL E
FADER/BALANCE
SUBWOOFERSpeed-sensit ive Volume
Compensat ion (SVC)
Playing the FM/A M Radio (Models with navigation system)
206
10/06/18 16:09:02 31TA5630_211
2011 Accord Sedan
