Upfitter controls
The auxiliary switch board on the
center console makes aftermarket
customization easier, with four
prewired switches attached to the
power distribution box for electrical
accessories.
These switches are labeled AUX 1,
AUX 2, AUX 3 and AUX 4. They will
only operate while the ignition is in the on position, whether the engine
is running or not. It is, however, recommended that the engine remain
running to maintain battery charge when using the switches for extended
duration or higher current draws. When switched on by the operator
they provide 10 amps, 15 amps or 30 amps of electrical battery power
for a variety of uses.
The switches control relays and fuses that are located under the hood in
the auxiliary power distribution box. Refer to theRoadside Emergencies
chapter of your Owner’s Guide for information on fuse and relay
locations. See your authorized dealer for service.
There will also be one power lead for each switch found as a blunt-cut
and sealed wire located to the right of the glove box door and just above
the passenger side kick panel.
Additional pass through circuits that run through the dash panel to
under the hood are located in the same location.
The relays are coded as follows:
Switch Circuit number Wire color Fuse
AUX 1 CAC05 Yellow 30A
AUX 2 CAC06 Green with
Brown Trace30A
AUX 3 CAC07 Violet with
Green Trace15A
AUX 4 CAC08 Brown 10 A
DRIVING YOUR F-150 SVT RAPTOR OFF-ROAD
In addition to providing an excellent on-road driving experience, the
F-150 SVT Raptor excels at all types of off-road driving. The truck has
been designed and equipped to allow you to explore those places where
the road doesn’t take you whether it’s a forest trail or the open desert.
