6.2L V8 ENGINE
1. Auxiliary switch circuit pass through circuits
2. Windshield washer fluid reservoir
3. Engine oil dipstick
4. Brake fluid reservoir
5. Engine coolant reservoir
6. Auxiliary power distribution box
7. Air filter assembly
8. Power steering fluid reservoir
9. Power distribution box
10. Engine oil filler cap
11. Battery
21
11
345
10987
6
Engine/Transmission
6
2011 F-150(f12)
Supplement, 1st Printing
USA(fus)
MAINTENANCE PRODUCT SPECIFICATIONS AND CAPACITIES
Item CapacityFord part name or
equivalentFord part number /
Ford Specification
Engine oil (includes
filter change)
5
7.0 quarts
(6.6L)•Motorcraft SAE 5W-20
Premium Synthetic
Blend Motor Oil (US)
•Motorcraft SAE 5W-20
Full Synthetic Motor Oil
(US)
•Motorcraft SAE 5W-20
Super Premium Motor
Oil (Canada)
•Motorcraft SAE 5W-20
Synthetic Motor Oil
(Canada)•XO-5W20-QSP (US)
•XO-5W20-QFS (US)
•CXO-5W20–LSP12
(Canada)
•CXO-5W-20-LFS12
(Canada) /
WSS-M2C930-A and API
Certification Mark
Engine coolant
1
16.0L
(16.9 quarts)Motorcraft Specialty
Orange Engine Coolant
with bittering agent (US)
/
Motorcraft Specialty
Orange Engine Coolant
(Canada)VC-3-B (US)
CVC-3-B (Canada) /
WSS-M97B44-D
Front axle lubricant 1.7L (3.6 pints)Motorcraft SAE 80W-90
Premium Rear Axle
LubricantXY-80W-90–QL /
WSP-M2C197–A
Maintenance
23
2011 F-150(f12)
Supplement, 1st Printing
USA(fus)
A
Air cleaner filter .........................22
Automatic transmission
fluid, refill capacities ................23
Axle
refill capacities ..........................23
B
Battery
replacement, specifications .....22
C
Capacities for refilling fluids ......23
Coolant
refill capacities ..........................23
E
Engine ............................................7
refill capacities ..........................23
service points ..............................6
Engine oil
filter, specifications ..................22
refill capacities ..........................23
F
Fluid capacities ...........................23
Fuel
capacity .....................................23
filter, specifications ..................22
octane rating .........................7, 25I
Ignition ...........................................7
M
Motorcraftparts ........................22
O
Octane rating ..............................25
P
Parts (see Motorcraftparts) ...22
S
Spark plugs, specifications .........22
T
Tires
changing ..............................25–26
rotating ......................................25
Towing
wrecker ......................................20
Transmission
fluid, refill capacities ................23
U
Upfitter controls .........................13
W
Wrecker towing ...........................20
Index
31
2011 F-150(f12)
Supplement, 1st Printing
USA(fus)
