2011 DODGE NITRO mirror controls

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust both
inside and outside mirrors, and fasten your seat belts.
WARNING!
Never leave children alone in a vehicle. Leaving
children in a vehicle unattended is dangerous for a
number of reasons. A child or others could be seri-
ously or fatally injured. Do not leave the keys in the
ignition. A child could operate power windows,
other controls, or move the vehicle.
Start the engine with the shift lever in the NEUTRAL or
PARK position. Apply the brake before shifting to any
driving range.
Normal Starting
NOTE: Normal starting of either a cold or a warm
engine is obtained without pumping or pressing the
accelerator pedal. Turn the ignition switch to the START position and
release when the engine starts. If the engine fails to start
within 10 seconds, turn the ignition switch to the LOCK
position, wait 10 to 15 seconds, then repeat the “Normal
Starting” procedure.
Tip Start Feature
Turn the ignition switch to START position and release it
as soon as the starter engages. The starter motor will
continue to run, but will automatically disengage itself
when the engine is running. If the engine fails to start, the
starter will disengage automatically in 10 seconds. If this
occurs, turn the ignition switch to the LOCK position,
wait 10 to 15 seconds, then repeat the “Normal Starting”
procedure.
Extreme Cold Weather (below –20°F or –29°C)
To ensure reliable starting at these temperatures, the use
of an externally powered electric engine block heater
(available from your authorized dealer) is recommended.
5
STARTING AND OPERATING 291

About Your Brakes....................... 309
ABS (Anti-Lock Brake System) .............. 311
Adding Engine Coolant (Antifreeze) .......... 419
Adding Fuel ........................... 356
Air Cleaner, Engine (Engine Air Cleaner Filter) . . . 410
Air Conditioner Maintenance ............... 412
Air Conditioning ........................ 274
Air Conditioning Controls ................. 274
Air Conditioning Filter .................... 284
Air Conditioning Refrigerant ............... 413
Air Conditioning System ................274,278
Air Conditioning, Operating Tips ............ 285
Air Filter .............................. 410
Air Pressure, Tires ....................... 330
Airbag ................................ 58
Airbag Deployment ....................... 72
Airbag Light ..................... 66,75,89,205
Airbag Maintenance ....................... 74
Airbag, Window (Side Curtain) ............... 62Alarm (Security Alarm)
.................... 17
Alarm Light ........................... 200
Alarm System (Security Alarm) ............... 17
Alarm, Panic ............................ 24
Alterations/Modifications, Vehicle ............. 8
Antenna, Satellite Radio ................243,268
Anti-Lock Brake System (ABS) ............ 311,314
Anti-Lock Warning Light .................. 205
Anti-Theft System ........................ 17
Antifreeze (Engine Coolant) ................ 443
Appearance Care ........................ 427
Assistance Towing ....................... 114
Auto Down Power Windows ................ 35
Automatic Dimming Mirror ................. 98
Automatic Door Locks ..................... 30
Automatic Temperature Control (ATC) ......... 278
Automatic Transaxle ...................... 294
Automatic Transmission .............295,300,424
Fluid and Filter Changes ............... 424
474 INDEX

HomeLink® (Garage Door Opener) Transmitter . . 169
Hood Release.......................... 149
Ignition ............................... 12
Key ............................... 12
Ignition Key Removal ..................... 12
Illuminated Entry ........................ 19
Immobilizer (Sentry Key) ................... 14
Infant Restraint ........................ 76,77
Information Center, Vehicle ................. 216
Inside Rearview Mirror .................... 97
Instrument Cluster .................... 197,198
Instrument Panel and Controls .............. 196
Instrument Panel Lens Cleaning ............. 431
Integrated Power Module (Fuses) ............ 432
Interior Appearance Care .................. 430
Interior Lights .......................... 155
Intermittent Wipers (Delay Wipers) ........... 158
Introduction ............................. 4 Jack Location
........................... 382
Jack Operation ....................... 381,384
Jacking Instructions ...................... 384
Jump Starting .......................... 388
Key-In Reminder ......................... 14
Key, Programming ........................ 16
Key, Replacement ........................ 15
Key, Sentry (Immobilizer) ................... 14
Keyless Entry System ...................... 20
Keys ................................. 12
Lane Change Assist ...................... 154
Lap/Shoulder Belts ....................... 43
LATCH
(Lower Anchors and Tether for CHildren) .....81,82
Latches ................................ 91
Lead Free Gasoline ...................... 351
Leaks, Fluid ............................ 91
10
INDEX 481
