2011 Citroen DS5 ESP

87
Comfort
4. Automatic visibilityprogramme


For maximum cooling or heating of thepassenger compar tment, it is possibleto exceed the minimum value 14 or themaximum value 28.)
Turn control 2or 3
to the left until "LO"is displayed or to the right until "HI"
is displayed. See "Front demistin
g - defrosting".


3. Driver's-passenger's side
settings
The driver and front passenger can each adjust the temperature to their requirements.
The value indicated on the display corresponds to a level of comfor t and not to a
temperature in degrees Celsius or Fahrenheit.
)Turn control 2or 3to the left or to the right respectively to decrease or increase this
value.

A setting around the value 21 provides
optimum comfort. However, depending on your
requirements, a setting between 18 and 24 isnormal.
You are advised to avoid a left /right settingdifference of more than 3.

Manual operation

If you wish, you can make a different choice from that offered by the system by changing asetting. The "AUTO"
indicator lamps go off; theother functions, except the air conditioning, willstill be controlled automatically.)
Pressing the "AUTO"
button returns the system to completely automatic operation.
With Stop & Star t, when demisting hasbeen activated, the STOP mode is not available.

107
Driving











Gear shift indicator * System which reduces fuel consumption by advising the driver to change up on vehicles fitted with a manual gearbox.


Operation
The system intervenes only when driving economically.
Depending on the driving situation and your
vehicle's equipment, the system may advise you to skip one or more gears. You can
follow this instruction without engaging the
intermediate gears.
The gear engagement recommendations mustnot be considered compulsory. In fact, the configuration of the road, the amount of traffic
and safety remain determining factors whenchoosing the best gear. Therefore, the driver
remains responsible for deciding whether or not
to follow the advice given by the system.
This function cannot be deactivated.

* Accordin
g to engine. -
You are in third gear.
Example:
-
You press the accelerator pedalmoderately.
-
The system may suggest that you engage
a higher gear, if appropriate.

The information appears in the instrument
panel in the form of an arrow accompanied b
y
the suggested gear.

In the case of driving which makes
par ticular demands on the performance of the engine (firm pressure on theaccelerator pedal, for example, whenover taking...), the system will not recommend a gear change.
The system never suggests:


- engaging first gear,

- engaging reverse gear,

- engaging a lower gear.

Displays in the instrument panel

When you move the lever in the gate to select aposition, the corresponding indicator comes on in the instrument panel. P Park R Reverse
N Neutral D Drive (automatic driving)SSport
programme 7
Snowprogramme 1 to 6Gear engaged during manual operation-
Invalid value during manual operation
Six speed automatic gearbox which offers a
choice between the comfor t of fully automatic
operation, enhanced by spor t and snow programmes, or manual gear changing.
Four driving modes are offered:-automaticoperation for electronic
management of the gears by the gearbox, -sport
programme for a more dynamic style
of driving,- snowprogramme to improve driving when
traction is poor,
- manualoperation for sequential changing
of the gears by the driver.














Automatic gearbox
1.
Gear lever.2.
Button "S"
(sport) . 3.Button "7"(snow).
Gear lever
Gear selection
gate
P.Park.


- Immobilisation of the vehicle, parking brake on or off.

- Starting the engine.R.
Reverse.


- Reversing manoeuvres, vehicle stationary,engine at idle. N.Neutral.


- Immobilisation of the vehicle, parking brake on.

- Starting the engine.D.Automatic operation.M. +/-
Manual operation with sequential changing of the six gears. )
Push for wards to change up through the gears.
or ) Pull backwards to change down through
the gears.

6-speed electronic gearbox system
Six-speed electronic gearbox system which
o
ffers a choice between the comfor t of fully automatic operation or the pleasure of manualgear changing.
There are two driving modes: -automaticmode for automatic control of
t
he gears by the gearbox,-manualmode for sequential gear changingby the driver.
For each of these two modes, there is a a Sport
setting, corresponding to a more
dynamic driving style.
In automatic mode, it remains possible to
change gear manually by using the steering mounted control paddles when required, when
over taking, for example.
R. Reverse)
With your foot on the brake, lift the lever
and push forwards.N.Neutral. ) With your foot on the brake, select this
position to start.
A
. Automatic mode. )
Move the lever backwards to select this
mode. M.
Manual mode with sequential gear changing.)
Lift the lever then move it backwards to select this mode, then use the steeringmounted control paddles to change gear.
S. Sport setting. )
Press the button to switch it on or off.


Gear lever
+.
Change up paddle to the right of the steeringwheel.)Press the back of the "+"
steering mounted paddle to change up a gear.-.
Change down paddle to the left of the
steerin
g wheel. )Press the back of the "-"steering mounted paddle to change down a gear.


Steering mounted control paddles


The steering mounted paddles cannotbe used to select neutral or to engageor disengage reverse gear.

119Driving





Lane departure warning system
System which, using a camera which
recognises solid or broken lines, detects the
involuntary crossing of longitudinal traffic lane markings on the ground.
To provide safe driving, the camera analyses
the image then, if the driver's attention drops,
triggers a warning if the vehicle drifts over a
lane marking (speed higher than 50 mph (80 km/h)).
This system is par ticularly useful on motor waysand main roads.
Activation
)
Press this button, the indicator
lamp comes on.


The lane depar ture warning system
cannot, in any circumstances, replacethe need for vigilance and responsibility on the par t of the driver.
Deactivation
You are warned by the vibration of the driver's seat cushion:
- on the right-hand side, if the marking on theground has been crossed on the right,
- on the left-hand side, if the marking on the ground has been crossed on the left.
No warning is transmitted while the direction indicator is active and for approximately 20 seconds after the direction indicator is switched off.
Detection - alert
Operatin
g fault


The detection may be impeded:


- if the markings on the ground are worn,

- if there is little contrast between the markings on the ground and the road surface.

- if the windscreen is dir ty,

- in certain severe weather conditions: fog, heavy rain, snow, bright sunlight or direct exposure to the sun (low sun, leaving a tunnel, ...) and shade.

)
Press this button again, the
indicator lamp goes off. In the event of a fault, the indicator lamp in the
button flashes.
Contact a CITROËN dealer or a qualified
wor
kshop.
The status of the s
ystem remains in the
memory when the ignition is switched off.

123Driving
The programmed information is grouped
together in the instrument panel screen.
6. Speed limiter on/off indication. 7. Speed limiter mode selection indication. 8.
Programmed speed value.9. Selection of a memorised speed.
(see "Memorising speeds")


Displays in the instrument panel





Speed limiter System which prevents the vehicle fromexceeding the speed programmed by the driver.
When the programmed speed limit is reached, pressing the accelerator pedal no longer has
any effect.
The speed limiter cannot, in any
circumstances, replace the need to respect speed limits, nor can it replace the need for vigilance and responsibilityon the par t of the driver.The functions of this s
ystem are grouped
together on the steering mounted controls. 1.Speed limiter mode selection dial. 2. Programmed value decrease button. 3.
Programmed value increase button.
4. Speed limiter on/off button.
5. List of memorised speeds display button. (see "Memorising speeds")
Steering mounted controls

O
peration

The speed limiter is switched onmanually:
it requires a programmed speed of at least
20 mph (30 km/h).
The speed limiter is switched offby manual foperation of the control.
The programmed speed can be exceeded
temporaril
y by pressing the accelerator firmlybeyond the point of resistance.
To return to the programmed speed, simply
release the accelerator pedal.
The pro
grammed speed remains in the memory
when the i
gnition is switched off.
This information also appears in the head-up display.
For more information on the head-updisplay, refer to the relevant page in this"Driving" section.

Programming
) Turn dial 1to the "LIMIT"
position: the speed limiter mode is selected but is not
switched on (Pause).You do not have to switch the speed limiter onin order to set the speed. ) Set the speed value by pressing button 2or 3
(e.g.: 55 mph (90 km/h)).
You can then change the programmed speed using buttons 2 and 3
:
- by + or - 1 mph (km/h) = shor t press,
- in steps of + or - 5 mph (km/h) = maintained press.
If speed memorisation is available and activated on your vehicle, theprogrammed speed will stop at the closest memorised speed; refer the
the corresponding paragraph.)Switch the speed limiter on by pressing button 4.)Switch the speed limiter off by pressing button 4: the display confirms that it has been switched off (Pause).
Exceeding the programmed speed
Pressing the accelerator pedal to exceed the programmed speed will not have any effect unless you press the pedal firmlypast the ypoint of resistance .
The speed limiter is deactivated temporarily and the programmed speed,
which is still displayed, flashes.
Returning to the programmed speed, by means of intentional or unintentional
deceleration of the vehicle, automatically cancels the flashing of the programmed speed.

Exiting the speed limiter mode
)Turn dial 1to the "0"
position: the speed
limiter mode is deselected. It disappears
from the screen.



Operating fault

In the event of a fault with the speed limiter,
the speed is cleared resulting in flashing of the dashes.
Have it checked by a CITROËN dealer or a qualified workshop.
On a steep descent or in the event of sharp acceleration, the speed limiter willnot be able to prevent the vehicle from exceeding the programmed speed.
To avoid any risk of jamming of the pedals:


- ensure that the mat is positioned correctly,

- do not fit one mat on top of another.

)Switch the speed limiter back on by pressing button 4
again.

125
Driving
The cruise control system cannot, in any circumstances, replace the need to respect speed limits, nor can it replacethe need for vigilance and responsibility on the par t of the driver.
You are advised to keep your feet near the pedals at all times.






Cruise control System which automatically maintains thespeed of the vehicle at the value programmed
by the driver, without any action on the
accelerator pedal.
The functions of this s
ystem are grouped
together on the steering mounted controls. 1.Cruise control mode selection dial.2. Speed programming/value decreasebutton.3.
Speed programming/value increase button.4.
Cruise control off/resume button.
5. Stored speeds display button.
(see "Storing speeds")

Steering mounted controls

The programmed information is grouped
together in the instrument panel screen.
6. Cruise control off/resume indication.7. Cruise control mode selection indication. 8.
Programmed speed value.9. Selecting a stored speed.
(see "Storing speeds")

Displays in the instrument panel


Operation
The cruise control is switched on
manually:
it requires a minimum vehicle speed of 25 mph(40 km/h) and engagement of:


- fourth gear on the manual gearbox,

- second gear on the electronic gearbox system or automatic gearbox, in sequential
driving mode,

- position A
on the electronic gearboxsystem or Don the automatic gearbox.
The cruise control is switched off manually for by pressing the brake or clutch pedal or on
triggering of the "electronic stability control" system for safety reasons.
It is possible to exceed the programmed speed
temporarily by pressing the accelerator pedal.
To return to the programmed speed, simply
release the accelerator pedal.

Switching off the ignition cancels any programmed speed value. This information also appears in thehead-up display.
For more information on the head-updisplay, refer to the relevant page in this"Driving" section.
