123Visibility
Model without AUTO lighting
Model with AUTO lighting
Manual controls
The lighting commands are issued directly
by the driver by means of the ring A
and the
stalk B
.
Sidelamps (luminous signature).
Automatic illumination of headlamps.
B.
Stalk for switching headlamps: pull the stalk
towards you to switch the lighting between
dipped and main beam headlamps.
In the lamps off and sidelamps modes, the
driver can switch on the main beam headlamps
temporarily ("headlamp flash") by maintaining a
pull on the stalk.
A.
Main lighting mode selection ring: turn it
to position the symbol required facing the
mark.
Lamps off.
Sidelamps.
Dipped headlamps or main beam
headlamps.
Displays
Illumination of the corresponding indicator
lamp in the instrument panel confirms that the
lighting selected is on. Daytime lighting, compulsory in cer tain
countries, which comes on automatically when
the engine is star ted making the vehicle more
visible to other users.
This function is assured:
- in countries where it is imposed by
regulations,
by illumination of the dipped beam
headlamps associated with illumination of
the sidelamps and number plate lamps; this
function cannot be deactivated.
- for other countries where it is provided,
by illumination of dedicated lamps
associated with illumination of the
sidelamps and number plate lamps; this
function can be activated or deactivated via
the vehicle configuration menu.
The instruments and controls (multifunction
screen, air conditioning control panel, ...) are
not illuminated, except in night mode with
manual or automatic illumination of headlamps.
Daytime running lamps
The lighting control must be in position "0"
or
"AU TO "
(day mode).
Page 127 of 396
125Visibility
Switching off the lighting
when switching off the ignition
When the ignition is switched off, all
of the lamps switch off immediately,
except for the dipped beam headlamps
if automatic guide-me-home lighting is
activated.
Temporarily keeping the dipped beam
headlamps on after the vehicle's ignition has
been switched off makes the driver's exit easier
when the light is poor.
Switching on
)
With the ignition off, "flash" the headlamps
using the lighting stalk.
)
A fur ther "headlamp flash" switches the
function off.
Switching off
The manual guide-me-home lighting switches
off automatically after a set time.
Manual guide-me-home
lighting
Switching on the lighting
when switching on the ignition
To reactivate the lighting control stalk, turn
the ring A
to position "0"
- lighting off, then
to the position of your choice.
If the lighting is switched on manually after
switching off the ignition, there is an audible
signal when a front door is opened to warn
the driver that they have forgotten to switch
off the vehicle's lighting, with the ignition off.
They switch off automatically after a period
which depends on the state of charge of the
battery (entry to energy economy mode).
Parking lamps
Side markers for the vehicle by illumination of
the sidelamps on the traffic side only.
)
Within one minute of switching off the
ignition, operate the lighting control stalk up
or down depending on the traffic side (for
example: when parking on the left; lighting
control stalk upwards; the right hand
sidelamps are on).
This is confirmed by an audible signal and
illumination of the corresponding direction
indicator warning lamp in the instrument panel.
To switch off the parking lamps, return the
lighting control stalk to the central position.
Page 132 of 396
Cornering lighting
With dipped or main beams, this function
makes use of the beam from a front foglamp to
illuminate the inside of a bend, when the vehicle
speed is below 25 mph (approximately 40 km/h)
(urban driving, winding road, intersections,
parking manouevres...).
Switching on
with cornering lighting
without cornering lighting
Switching off
The system does not operate:
- below a cer tain angle of rotation of the
steering wheel,
- above 25 mph (40 km/h),
- when reverse gear is engaged,
The system is activated by default.
Programming
The system is activated or
deactivated in the vehicle
configuration menu. This function starts:
- when the corresponding direction indicator
is switched on,
or
- from a cer tain angle of rotation of the
steering wheel.
Page 138 of 396
1.
Front cour tesy lamp
2.
Front map reading lamps
3.
Rear courtesy lamp
4.
Rear map reading lamps
Courtesy lamps
In this position, the courtesy
lamp comes on gradually:
Front and rear courtesy lamps
- when the vehicle is unlocked,
- when the key is removed from the ignition,
- on opening a door,
- when the remote control locking button is
used to locate your vehicle.
It switches off gradually:
- when the vehicle is locked,
- when the ignition is switched on,
- 30 seconds after the last door is closed.
Permanently off.
Permanent lighting. In permanent lighting mode, the
lighting time varies according to the
circumstances:
- with the ignition off, approximately
ten minutes,
- in energy economy mode,
approximately thirty seconds,
- with the engine running, unlimited.
When the cour tesy lamp is in the
"permanent lighting" position, the rear
courtesy lamp also comes on, except if
it is in the "permanently off " position.
To switch off the rear cour tesy lamp,
put it in the the "permanently off "
position.
Front and rear map reading
lamps
)
With the ignition on, press the
corresponding switch.
Take care not to put anything in contact
with the cour tesy lamps.
Page 176 of 396
Ty r e u n d e r - i nfl ation detection
System which automatically and continuously
checks the pressure of the tyres while driving.
Sensors fitted in each valve trigger a warning
in the event of problem (speed above 12 mph
(20 km/h)).
Puncture
The tyre under-inflation detection
system is an aid to driving which does
not replace the need for the driver to be
vigilant or to drive responsibly.
Under-infl ated tyre
This warning lamp is displayed on the
instrument panel and/or a message
appears in the screen, accompanied
by an audible signal, to identify the
wheel concerned. The STOP
warning lamp comes on
and/or this warning lamp is displayed on
the instrument panel, accompanied by
an audible signal and a message in the
screen identifying the wheel concerned.
)
Stop as soon as it is safe to do so, avoiding
any sudden movement of the steering
wheel and the brakes.
)
Repair or change the damaged wheel
(punctured or very deflated tyre), and have
the tyre pressure checked as soon as
possible.
)
Check the tyre pressures as soon as
possible.
This check must be carried out when the tyres
are cold.
Page 179 of 396
177
Safety
Emergency braking assistance
System which, in an emergency, enables you
to obtain the optimum braking pressure more
quickly, thus reducing the stopping distance.
Activation
It is triggered by the speed at which the brake
pedal is pressed.
The effect of this is a reduction in the
resistance of the pedal and an increase in
braking efficiency.
When braking in an emergency, press
firmly without releasing the pressure.
Trajectory control systems (ESP)
Anti-slip regulation (ASR)
and electronic stability
control (ESC)
The anti-slip regulation (also known as traction
control) optimises traction to prevent skidding
of the wheels, by acting on the brakes of the
driving wheels and on the engine.
The electronic stability control acts on the
brake of one or more wheels and on the engine
to keep the vehicle on the trajectory required
by the driver, within the limits of the laws of
physics.
Activation
These systems are activated automatically
each time the vehicle is star ted.
They come into operation in the event of a grip
or trajectory problem.
This is indicated by flashing of this
warning lamp in the instrument panel.
Intelligent traction control
system ("Snow motion")
Your vehicle has a system to help driving on
snow: intelligent traction control.
This system detects situations of difficult
sur face adhesion that could make it difficult to
move off or make progress on deep fresh snow
or compacted snow.
In these situations, the intelligent traction
control
limits the amount of wheel slip to
provide the best traction and trajectory control
for your vehicle.
The use of snow tyres is strongly
recommended on sur faces offering low
levels of adhesion.
Page 180 of 396
Deactivation
In exceptional conditions (starting a vehicle
which is bogged down, stuck in snow, on soft
ground...), if you are unable to make progress,
it may be advisable to temporarily deactivate
these systems, so that the wheels can spin
freely and allow the vehicle to move.
)
Press the "ESP OFF"
button,
located near the steering wheel.
Reactivation
These systems are reactivated automatically
each time the ignition is switched back on or
from 30 mph (50 km/h).
)
Press the "ESP OFF"
button again to
reactivate them manually.
Operating fault
The trajectory control systems offer
increased safety in normal driving, but
this should not encourage the driver to
take extra risks or drive at high speed.
The correct functioning of these
systems is assured provided that
manufacturer's recommendations are
observed on:
- wheels (tyres and rims),
- braking components,
- electronic components,
- assembly and repair procedures.
After an impact, have these systems
checked by a CITROËN dealer or a
qualified workshop.
If this warning lamp comes on,
accompanied by an audible signal
and a message in the screen, this
indicates a fault with these systems.
Have it checked by a CITROËN dealer or a
qualified workshop. It is recommended that the systems be
reactivated as soon as possible.
If this warning lamp comes on in the instrument
panel and the indicator lamp in the button
comes on, this indicates that these systems are
deactivated.
Page 182 of 396
Rear seat belts
Fastening
)
Pull the strap, then inser t the tongue in the
buckle.
)
Check that the seat belt is fastened
correctly by pulling the strap.
Unfastening
)
Press the red button on the buckle.
)
Guide the seat belt as it reels in.
)
On the outer seat belts, raise the bar to the
top of the backrest to prevent the tongue
from knocking against the side trim.
The rear seats are each fitted with a three-point
seat belt, with force limiter and, for the outer
seats, an effort limiter.
Seat belt not fastened/
unfastened warning lamps
display
1.
Driver's seat belt not fastened/unfastened
warning lamp.
2.
Front passenger's seat belt not fastened/
unfastened warning lamp.
The corresponding warning lamp 1
or 2
comes
on in red on the seat belt and passenger's front
airbag warning lamps display, accompanied by
an audible signal and a message in the screen,
if the seat belt is not fastened or is unfastened.
