Your vehicle has been approved in accordance
with the new
ISOFIX regulation
.
The seats, represented below, are fitted with
regulation ISOFIX mountings:




















"ISOFIX" mountings

There are three rings for each seat:


- two rings A
, located between the vehicle
seat back and cushion, indicated by a label,

- a ring B
behind the seat for fixing the upper
strap, referred to as the To p Te t h e r
. This ISOFIX mounting system provides fast,
reliable and safe fitting of the child seat in your
vehicle.
The incorrect installation of a child seat
in a vehicle compromises the child's
protection in the event of an accident.
For information regarding the ISOFIX child
seats which can be installed in your vehicle,
refer to the table showing the locations for
installing ISOFIX child seats. When fitting an ISOFIX child seat to
the left hand rear seat, before fitting
the seat, first move the centre rear seat
belt towards the middle of the vehicle,
so as to avoid the seat inter fering with
the operation of the seat belt.
The ISOFIX child seats
are fitted with two
latches which are secured on the two rings A
.
Some seats also have an upper strap
, known
as the Top Tether, which is attached to ring B
.
To attach this strap, raise the vehicle seat's
head restraint then pass the hook between its
rods. Then fix the hook on ring B
and tighten
the upper strap.

167Child safety










ISOFIX child seat recommended by CITROËN and approved for
your vehicle
This child seat can also be used on seats which are not fitted with ISOFIX mountings. In this case, it must be attached to the vehicle seat using
the three point seat belt.

Follow the instructions for fitting the child seat given in the seat manufacturer's installation guide.
"

RÖMER
Duo Plus ISOFIX
"
(size category B1
)


Group 1: from 9 to 18 kg





Installed only in the for wards-facing position.
Fitted with an upper strap to be secured on the upper ring B
, referred to as the TOP TETHER.
Three seat body angles: sitting, reclining, lying.


)
Adjust the front seat of the vehicle so that the child's feet do not touch the back of the seat.

Locations for ISOFIX child seats
In accordance with European Regulations, this table indicates the options for installing ISOFIX child seats on seats in the vehicle fitted with ISOFIX
mountings.
In the case of universal and semi-universal ISOFIX child seats, the ISOFIX size category, determined by a letter from A
to G
, is indicated on the child
seat next to the ISOFIX logo.

IUF:
seat suitable for the installation of an I
sofix U
niversal seat, " F
or ward facing" secured using the upper strap.

IL-SU:
seat suitable for the installation of an I
sofix S
emi- U
niversal seat either:


- "rear facing" fitted with an upper strap or a stay,

- "for ward facing" fitted with a stay,

- an infant car seat fitted with an upper strap or a stay.
For advice on securing of the upper strap, refer to the paragraph "ISOFIX mountings".

* Infant car seats and "car cots" cannot be installed on the front passenger seat.

** The ISOFIX infant car seat, secured on the lower rings of a vehicle ISOFIX seat, occupies two rear seats.



Weight of the child
/indicative age


Less than 10 kg
(group 0)


Up to approx.
6 months

Less than 10 kg


(group 0)
Less than 13 kg


(group 0+)


Up to approx. 1 year

From 9 to 18 kg (group 1)


From approx. 1 to 3 years


Type of ISOFIX child seat



Infant car seat

*


"rear facing"



"rear facing"



"forward facing"




ISOFIX size category



F


G


C



D



E



C



D



A



B



B1




ISOFIX child seats universal and semi-universal
which can be installed on the rear outer seats


IL-SU

**


IL-SU



IL-SU



IUF


IL-SU

The driver must ensure that passengers use
the seat belts correctly and that they are all
restrained securely before setting off.
Wherever you are seated in the vehicle,
always fasten your seat belt, even for short
journeys.
Do not interchange the seat belt buckles as
they will not fulfil their role fully.
The seat belts are fitted with an iner tia reel
permitting automatic adjustment of the length
of the strap to your size. The seat belt is
stowed automatically when not in use.
Before and after use, ensure that the seat
belt is reeled in correctly.
The lower part of the strap must be
positioned as low as possible on the pelvis.
The upper par t must be positioned in the
hollow of the shoulder.
The iner tia reels are fitted with an automatic
locking device which comes into operation in
the event of a collision, emergency braking
or if the vehicle rolls over. You can release
the device by pulling firmly on the strap and
releasing it so that it reels in slightly. In order to be effective, a seat belt must:


- be tightened as close to the body as
possible,

- be pulled in front of you with a smooth
movement, checking that it does not
twist,

- be used to restrain only one person,

- not bear any trace of cuts or fraying,

- not be conver ted or modified to avoid
affecting its per formance.
In accordance with current safety regulations,
for all repairs on your vehicle, go to a
qualified workshop with the skills and
equipment needed, which a CITROËN dealer
is able to provide.
Have your seat belts checked regularly by
a CITROËN dealer or a qualified workshop,
par ticularly if the straps show signs of
damage.
Clean the seat belt straps with soapy water or
a textile cleaning product, sold by CITROËN
dealers.
After folding or moving a seat or rear bench
seat, ensure that the seat belt is positioned
and reeled in correctly.

Recommendations for children

Use a suitable child seat if the passenger is
less than 12 years old or shor ter than one
and a half metres.
Never use the same seat belt to secure
more than one person.
Never allow a child to travel on your lap.


In the event of an impact


Depending on the nature and
seriousness of the impact
, the
pretensioning device may be deployed
before and independently of the airbags.
Deployment of the pretensioners is
accompanied by a slight discharge of
harmless smoke and a noise, due to the
activation of the pyrotechnic car tridge
incorporated in the system.
In all cases, the airbag warning lamp
comes on.
Following an impact, have the seat belts
system checked, and if necessary replaced,
by a CITROËN dealer or a qualified
workshop.

For the airbags to be fully effective, observe the following safety rules:

Front airbags

Do not drive holding the steering wheel by its
spokes or resting your hands on the centre
part of the wheel.
Passengers must not place their feet on the
dashboard.
If possible, do not smoke as deployment of
the airbags can cause burns or the risk of
injury from a cigarette or pipe.
Never remove or pierce the steering wheel or
hit it violently.




Lateral airbags

Use only approved covers on the seats,
compatible with the deployment the lateral
airbags. For information on the range of seat
covers suitable for your vehicle, you can
contact a CITROËN dealer (see "Practical
information - § Accessories").
Do not fix or attach anything to the seat
backs (clothing...). This could cause injury
to the chest or arms if the lateral airbag is
deployed.
Do not sit with the upper par t of the body any
nearer to the door than necessary.


Curtain airbags

Do not fix or attach anything to the roof.
This could cause injury to the head if the
cur tain airbag is deployed.
If fitted on your vehicle, do not remove the
grab handles installed on the roof, they play
a par t in securing the cur tain airbags.
Sit in a normal upright position.
Wear a correctly adjusted seat belt.
Do not leave anything between the occupants
and the airbags (a child, pet, object...). This
could hamper the operation of the airbags or
injure the occupants.
After an accident or if the vehicle has been
stolen or broken into, have the airbag
systems checked.
All work on the airbag system must be carried
out by a CITROËN dealer or a qualified
workshop.
Even if all of the precautions mentioned
are obser ved, a risk of injury or of minor
burns to the head, chest or arms when an
airbag is deployed cannot be ruled out. The
bag inflates almost instantly (within a few
milliseconds) then deflates within the same
time discharging the hot gas via openings
provided for this purpose.

231Checks











Bonnet


Opening



)
Open the front left door.

)
Pull the interior bonnet release lever A
,
located at the bottom of the door aper ture.
)
Push the exterior safety catch B
to the left
and raise the bonnet.

)
Unclip the stay C
from its housing.

)
Fix the stay in the notch to hold the bonnet
open. The location of the interior bonnet
release lever prevents opening of
the bonnet while the front left door is
closed. Do not open the bonnet in high winds.
When the engine is hot, handle the
exterior safety catch and the bonnet
stay with care (risk of burns).





Before doing anything under the
bonnet, switch off the Stop & Start
system to avoid any risk of injury
resulting from an automatic change to
START mode.


Closing



)
Take the stay out of the suppor t notch.

)
Clip the stay in its housing.

)
Lower the bonnet and release it at the end
of its travel.

)
Pull on the bonnet to check that it is
secured correctly.

237Checks









Additive level (Diesel with
particle emissions filter)

Topping up

The reser voir must be topped up without delay
by a CITROËN dealer or a qualified workshop.











Used products

Avoid prolonged contact of used oil or
fluids with the skin.
Most of these fluids are harmful to
health or indeed very corrosive.
Do not discard used oil or fluids into
sewers or onto the ground.
Take used oil to a CITROËN dealer or
a qualified workshop (France) or to an
authorised waste disposal site.

)
Open the bonnet and secure it with
the stay.

)
Open the screenwash reser voir filler cap.

)
Take and pinch the level gauge to block its
breather.

)
Remove the gauge completely from
the reser voir to read the level in the
transparent section.

)
Top up if necessary.

)
Refit the filler cap to the reservoir and
close the bonnet.


Specifi cation of the fl uid

To ensure optimum cleaning and to avoid
freezing, the fluid should never be topped up or
replaced by plain water.
According to your version of instrument panel,
the additive reser voir low level is indicated by:


-
fixed illumination of the par ticle
emissions filter warning lamp,
accompanied by an audible signal and
a message that the particle emissions
filter additive level is too low,

or

- fixed illumination of the ser vice
warning lamp, accompanied by
an audible signal and a message
that the par ticle emissions filter
additive level is too low.

249Practical information














Changing a wheel
Procedure for changing a faulty wheel for the spare wheel using the tools provided with the vehicle.
The tools are installed in the boot under the
floor.
To gain access to them:


)
open the boot,

)
raise the floor,

)
secure it by hooking its cord on the hook
on the rear shelf suppor t,

)
with a standard size spare wheel, unclip
and remove the box in the middle of the
wheel containing the tools,
or

)
with a "space-saver" spare wheel; lift the
wheel at the rear towards you for access
to the storage box containing the tools.


Access to the tools


List of tools

All of these tools are specific to your vehicle.
Do not use them for other purposes.

Wheel with trim


When removing the wheel
, detach the
trim first using the wheelbrace 1
pulling
at the valve passage hole.

When refitting the wheel
, refit the trim
star ting by placing its notch facing the
valve and press around its edge with
the palm of your hand.


3.
"Bolt cover" tool.
For removing the bolt protectors (covers)
on alloy wheels.

4.
Socket for the security bolts (located in the
glove box).
For adapting the wheelbrace to the special
"security" bolts.


1.
Wheelbrace.
For removing the wheel trim and the wheel
fixing bolts.

2.
Jack with integral handle.
For raising the vehicle.
