Monitoring

On switching on, the dial needles go to the
extent of their travel then return to 0.


A.
With the ignition on, the fuel gauge bars for
the fuel remaining should light up.

B.
With the engine running, the associated
low level warning lamp should go off.

C.
With the ignition on, the oil level indicator
should display "OIL OK"
for a few
seconds.
If the levels are not correct, top up the level
which is low.

Instrument panels




26, 28



1.
With the ignition on, the orange and red
warning lamps come on.

2.
With the engine running, these warning
lamps should go off.
If a warning lamp remains on, refer to the page
concerned.

Warning lamps



30, 35

Illumination of the indicator lamp indicates the
state of the corresponding function.


A.
Deactivation of the ESP/ASR system.


Switch panel

14 4


B.
Deactivation of Stop & Start.
167

27Monitoring

Screen


E.
Ser vice indicator

(miles or km), then
Total mileage recorder

These two functions are displayed
successively when switching on the ignition

F.
Engine oil level indicator

Appears a few seconds after switching on
the ignition, then disappears.



A.
Speed limiter

(mph or km/h) or
Cruise control.


B.
Gear shift indicator.


C.
SensoDrive
or automatic gearbox
information.


D.
Range

(miles or km) or
Trip mileage recorder.

29Monitoring

Screen


C.
Ser vice indicator

(miles or km), then
Total mileage recorder .
These two functions are displayed
successively when switching on
the ignition.

D.
Engine oil level indicator.

Appears a few seconds after switching on
the ignition, then disappears.



A.
Speed limiter

(mph or km/h) or
Cruise control.


B.
Range

(miles or km) or
Trip mileage recorder.

31Monitoring

Operation indicator lamps

If one of the following indicator lamps comes on, this confirms that the corresponding system has come into operation.



Warning lamp



is on



Cause



Action/Observations








Left-hand
direction indicato

r

flashing with buzzer. The lighting stalk is pushed down.







Right-hand
direction indicator

flashing with buzzer. The lighting stalk is pushed up.







Sidelamps


fixed. The lighting stalk is in the "Sidelamps"
position.






Dipped beam
headlamps


fixed. The lighting stalk is in the "Dipped
beam headlamps" position.






Main beam
headlamps


fixed. The lighting stalk is pulled towards
you. Pull the stalk to return to dipped beam headlamps.






Front foglamps


fixed. The front foglamps are switched on. Turn the ring on the stalk rear wards twice to switch off
the front foglamps.





Rear foglamps


fixed. The rear foglamps are switched on. Turn the ring on the stalk rear wards to switch off the
rear foglamps.






Hazard warning
lamps


flashing with audible
signal. The hazard warning lamps switch,
located on the dashboard, has been
operated. The left-hand and right-hand direction indicators and
their associated indicator lamps flash simultaneously.

33Monitoring






Foot on the
brake pedal


fixed. The brake pedal must be pressed. With the SensoDrive gearbox, press the brake pedal
to star t the engine (lever in position N
).
With an automatic gearbox, with the engine running,
press the brake pedal before releasing the parking
brake, to unlock the lever and come out of position P
.
If you wish to release the parking brake without
pressing the brake pedal, this warning lamp will
remain on.

flashing. With a SensoDrive gearbox, if you
hold the vehicle on an incline using
the accelerator for too long, the clutch
overheats. Use the brake pedal and/or the parking brake.






Automatic wiping


fixed. The wiper control is pushed
downwards. Automatic front wiping is activated.






Passenger's
airbag system
fixed. The control switch, located in the
glove box, is in the " ON
" position.
The passenger's front airbag is
activated.
In this case, do not install a rear-
facing child seat. Turn the control switch to the " OFF
" position to
deactivate the front passenger's airbag.
In this case you can install a rear-facing child seat.

Warning lamp



is on



Cause



Action/Observations

35Monitoring










Warning lamps

When the engine is running or the vehicle is
being driven, the illumination of one of the
following warning lamps indicates a fault which
requires action on the par t of the driver. Any fault resulting in the illumination of a warning lamp must be investigated fur ther by
reading the associated message in the multifunction screen.
If you encounter any problems, do not hesitate to contact a CITROËN dealer or a qualified
workshop.



Warning lamp



is on



Cause



Action/Observations








STOP


fixed, alone or
associated with
another warning lamp,
accompanied by an
audible signal and
a message on the
screen. Illumination of the warning lamp is
associated with a serious braking
system or engine coolant temperature
problem. Stop as soon as it is safe to do so as the engine may
cut out when driving.
Park, switch off the ignition and call a CITROËN dealer
or a qualified workshop.





Service


temporarily. Minor problems have occurred for
which there is no specific warning
lamp. Identify the problem by reading the message shown in
the screen, such as, for example:


- the engine oil level,

- the screenwash level,

- the remote control battery,

- saturation of the par ticle emission filter on Diesel
vehicles (see "Checks - § par ticle emissions
filter").
For any other faults, contact a CITROËN dealer or a
qualified workshop.

fixed. Major problems have occurred for
which there is no specific warning
lamp. Identify the problem by reading the message shown
in the screen and contact a CITROËN dealer or a
qualified workshop.

37Monitoring


Warning lamp



is on



Cause



Action/Observations









Engine
autodiagnosis
system


fixed. The emission control system has a
fault. The warning lamp should go off when the engine is
started.
If it does not go off, contact a CITROËN dealer or
qualified workshop without delay.

flashing. The engine management system has
a fault. Risk of destruction of the catalytic conver ter.
Have it checked by a CITROËN dealer or a qualified
workshop.





Low fuel level


fixed. When it first comes on there remains
approximately 5 litres of
fuel
in the
tank. You must refuel as soon as possible to avoid running
out of fuel.
This warning lamp will come on every time the ignition
is switched on, until a sufficient addition of fuel
is made.
Fuel tank capacity: approximately 50 litres (petrol) or
46 litres (Diesel); depending on version: approximately
30 litres (petrol or Diesel).
Never continue to drive until you run out of fuel as
this could damage the emission control and injection
systems.





Maximum coolant
temperature


fixed red. The temperature of the cooling system
is too high. Stop as soon as it is safe to do so.
Wait until the engine has cooled down before topping
up the level, if necessary.
If the problem persists, contact a CITROËN dealer or
qualified workshop.
