MULTIFUNCTION SCREENS
54

Choice of language
Once this menu has been selected, you
can choose the language used by the
display from a pre-defi ned list.
For safety reasons, confi gura-
tion of the multifunction screen
by the driver must only be done
when stationary.
)

Press the "
" or "
" buttons to set the
value required (15, 30 or 60 seconds),
then press the "OK"
button to confi rm.


)
Press the "
" or "
" buttons, then
the "OK"
button to select the "OK"

box and confi rm or press the "ESC"

button to cancel.
For example: setting of the duration of
the "follow-me-home" lighting


)
Press the "
" or "
" buttons, to se-
lect the "Defi ne the vehicle param-
eters" menu, then the " OK
" button.

)
Press the "
" or "
" buttons to
select the "Interior lighting" line,
then the "OK"
button; then follow
the same procedure to select the
"Follow-me-home headlamps" line.
Display confi guration
This menu gives access to the following
settings:


- "Choice of units",

- "Date and time adjustment",

- "Display parameters",

- "Brightness".


Choice of sounds
This menu allows you to choose a fam-
ily of polyphonic sounds from the four
available. These sounds are grouped
together in a family and are adapted
to suit the situation and context (alert,
confi rmation, rejection, direction indica-
tors, lighting left on, key in ignition...).


- "Driving assistance":


●
"Parking brake automatic" (Auto-
matic electric parking brake; see
the "Driving" section),

●
"Rear wipe in reverse gear" (Rear
wiper coupled to reverse gear;
see the "Visibility" section),

●
"Speeds memorised" (Memoris-
ing speeds; see the "Driving" sec-
tion).



- "Vehicle lighting" (see the "Visibility"
section):


●
"Directional headlamps" (Main/
additional directional lighting),

●
"Daytime lights" (Daytime running
lamps).



- "Interior lighting" (see the "Visibility"
section:


●
"Follow-me-home headlamps"
(Automatic operation of headlamps
after switching off the ignition),

●
"Welcome lighting" (Exterior and
interior welcome lighting).

2
MULTIFUNCTION SCREENS
57

Vehicle parameters
This menu is used to activate or deac-
tivate certain driving and comfort sys-
tems, classifi ed in different categories:


- "Access to the vehicle" (see
"Access" section):


●
"Plip action" (Selective unlocking
of the driver's door),

●
"Unlocking only boot" (Selective
unlocking of the boot).



- "Driving assistance":


●
"Parking brake automatic" (Auto-
matic electric parking brake; see
"Driving" section),

●
"Rear wipe in reverse gear" (Rear
wiper coupled to reverse gear;
see "Visibility" section),

●
"Speeds memorised" (Memoris-
ing speeds; see "Driving" sec-
tion).



- "Vehicle lighting" (see "Visibility"
section):


●
"Directional headlamps" (Main/
additional directional lighting),

●
"Daytime lights" (Daytime running
lamps).



- "Interior lighting" (see "Visibility"
section):


●
"Follow-me-home " (Automatic
timed operation of headlamps),

●
"Welcome lighting" (Interior/exte-
rior welcome lighting).


Display confi guration
This menu is used to confi gure:


- the display language of the central
colour screen, from a pre-defi ned
list,

- the units: temperature (°Celsius ou
°Fahrenheit) and fuel consumption
(l/100 km, mpg or km/l),

- the colour schemes of the central
screen.


Choice of sounds
This menu allows you to choose a fam-
ily of polyphonic sounds from the four
available. These sounds are grouped
together in a family and are adapted
to suit the situation and context (alert,
confi rmation, rejection, direction indica-
tors, lighting left on, key in ignition...).

3
COMFORT
78







Automatic day/night model
By means of a sensor, which measures
the light from the rear of the vehicle,
this system automatically and progres-
sively changes between the day and
night uses.

In order to ensure optimum vis-
ibility during your manoeuvres,
the mirror lightens automatically
when reverse gear is engaged.
STEERING WHEEL ADJUSTMENT




)
When stationary
, pull the control
lever to release the adjustment
mechanism.

)
Adjust the height and reach to suit
your driving position.

)
Push the control lever to lock the
adjustment mechanism.
As a safety precaution, these op-
erations should only be carried out
while the vehicle is stationary.

Adjustable mirror providing a central
rearward view.
Equipped with an anti-dazzle system,
which darkens the mirror glass: this re-
duces the nuisance to the driver caused
by the headlamps from following vehicles,
low sun...


Manual day/night model

Adjustment


)
Adjust the mirror so that the glass is di-
rected correctly in the "day" position.


Day/night position


)
Pull the lever to change to the "night"
anti-dazzle position.

)
Push the lever to change to the nor-
mal "day" position.


As a safety measure, the mirrors
should be adjusted to reduce the
"blind spot".

5
VISIBILITY
96
LIGHTING CONTROLS
System for selection and control of the
various front and rear lamps providing
the vehicle's lighting.
Main lighting

The various front and rear lamps of the
vehicle are designed to adapt the driv-
er's visibility progressively according to
the climatic conditions:


- sidelamps, to be seen,

- dipped beam headlamps to see
without dazzling other drivers,

- main beam headlamps to see clearly
when the road is clear.



Additional lighting

Other lamps are installed to fulfi l the
requirements of particular driving con-
ditions:


- rear foglamps,

- front fog lamps with static intersec-
tion lighting,

- directional headlamps for improved
visibility when cornering,

- daytime running lamps to be more
visible during the day,

- guide-me-home and welcome light-
ing to facilitate access to the vehicle,

- parking lamps as vehicle position
markers.



Programming

Various automatic lighting control
modes are also available depending on
whether the following options are fi tted:


- guide-me-home lighting,

- welcome lighting,

- daytime running lamps,

- directional lighting,

- automatic illumination of headlamps.



Model without AUTO lighting



Model with AUTO lighting

A.
Main lighting mode selection ring:
turn it to position the symbol required
facing the mark.
Manual controls
The lighting commands are issued di-
rectly by the driver by means of the
ring A
and the stalk B
.
Lamps off.





Automatic illumination of head-
lamps.

B.
Stalk for switching headlamps: pull
the stalk towards you to switch the
lighting between dipped and main
beam headlamps.
In the lamps off and sidelamps modes, the
driver can switch on the main beam head-
lamps temporarily ("headlamp fl ash") by
maintaining a pull on the stalk.
Sidelamps only.
Dipped headlamps or main
beam headlamps.
Displays
Illumination of the corresponding indi-
cator lamp in the instrument panel con-
fi rms that the lighting selected is on.

5
VISIBILITY
97









C.
Foglamp selection ring.
The foglamps operate with the dipped
and main beam headlamps.
They operates with the dipped beam
headlamps and main beam headlamps.


)
To switch on the rear foglamps, turn
the ring C
forwards.


)
To switch off the rear foglamps, turn
the ring C
rearwards.

When automatic illumination of headlam-ps is on (with AUTO model), the dipped
beam headlamps and sidelamps remain
on while the rear foglamps are on.


Model with rear foglamps only
rear foglamps
Rotate and release the ring C
:


)
forwards a fi rst time to switch on the
front foglamps,

)
forwards a second time to switch on
the rear foglamps,

)
rearwards a fi rst time to switch off
the rear foglamps,

)
rearwards a second time to switch
of the front fog lamps.

Model with front and rear foglamps
front and rear foglamps
When the headlamps switch off with
automatic illumination of headlamps
(AUTO model) or when the dipped
beam headlamps are switched off
manually, the foglamps and sidelamps
remain on.


)
Turn the ring rearwards to switch
off the foglamps, the sidelamps will
then switch off.

In good or rainy weather, by both
day and night, the front foglamps
and the rear foglamps are pro-
hibited. In these situations, the
power of their beams may dazzle
other drivers. They should only
be used in fog or falling snow.
In these weather conditions, you
should switch on the foglamps
and dipped beam headlamps
manually, as the sunshine sen-
sor may detect suffi cient light.
Do not forget to switch off the
front and rear foglamps when
they are no longer necessary.

5
VISIBILITY
98

Switching off the lighting when
switching off the ignition
When the ignition is switched off,
all of the lamps switch off immedi-
ately, except for the dipped beam
headlamps if automatic guide-
me-home lighting is activated.
In some weather conditions (e.g.
low temperature or humidity),
the presence of misting on the
internal surface of the glass of
the headlamps and rear lamps
is normal; it disappears after the
lamps have been on for a few
minutes.






Daytime running lamps

Daytime lighting, compulsory in certain
countries, which comes on automati-
cally when the engine is started making
the vehicle more visible to other users.
Manual guide-me-home lighting
Temporarily keeping the dipped beam
headlamps on after the vehicle's igni-
tion has been switched off makes the
driver's exit easier when the light is poor.

Switching on


)
With the ignition off, "fl ash" the
headlamps using the lighting stalk.

)
A further "headlamp fl ash" switches
the function off.


Switching off

The manual guide-me-home lighting
switches off automatically after a set time.



This function is assured:


- in countries where it is imposed by
regulations,
by illumination of the dipped beam
headlamps with the sidelamps and
number plate lamps; this function
cannot be deactivated.

- for other countries where it is pro-
vided,
by the use of dedicated lamps; this
function can be activated or deac-
tivated via the vehicle confi guration
menu.


The instruments and controls (instru-
ment panel, multifunction screen, air
conditioning control panel, ...) are not
illuminated, except in night mode with
manual or automatic illumination of
headlamps.

Switching on the lighting
when switching on the ignition
To reactivate the lighting control stalk, turn the ring A
to position "0"
- lighting off, then to the position of
your choice.
If the lighting is switched on manu-
ally after switching off the ignition,
there is an audible signal when a
front door is opened to warn the
driver that they have forgotten to
switch off the vehicle's lighting, with
the ignition off.
They switch off automatically after a
period which depends on the state
of charge of the battery (entry to en-
ergy economy mode).

5
VISIBILITY
99
Automatic illumination of
headlamps
The sidelamps and dipped beam head-
lamps are switched on automatically,
without any action on the part of the
driver, when a low level of external light
is detected or in certain cases of activa-
tion of the windscreen wipers.
As soon as the brightness returns to a
suffi cient level or after the windscreen
wipers are switched off, the lamps are
switched off automatically.

Activation


)
Turn ring A
to the "AUTO"
position.
The automatic illumination of head-
lamps is accompanied by a mes-
sage in the screen.


Deactivation


)
Turn ring A
to a position other than
"AUTO"
. Deactivation is accompa-
nied by a message in the screen.

Coupling with the automatic "Guide-
me-home" lighting
Association with the automatic illumi-
nation of headlamps provides "guide-
me-home" lighting with the following
additional options:


- selection of the lighting duration to
15, 30 or 60 seconds in the settings
in the vehicle confi guration menu
(except in the case of the mono-
chrome screen A, for which the du-
ration is set: 60 seconds),

- automatic activation of "guide-me-
home" lighting when automatic illumi-
nation of headlamps is in operation.


In the event of a fault with the
sunshine sensor, the lighting
come on, this warning lamp
is displayed on the instrument
panel and/or a message appears in the
screen, accompanied by an audible signal.
Contact a CITROËN or a qualifi ed work-
shop workshop.

Operating fault
In fog or snow, the sunshine sen-
sor may detect suffi cient light.
Therefore, the lighting will not
come on automatically.
Do not cover the sunshine sen-
sor, coupled with the rain sensor
and located in the centre of the
windscreen behind the rear view
mirror; the associated functions
would no longer be controlled.

Parking lamps

Side markers for the vehicle by illumi-
nation of the sidelamps on the traffi c
side only.


)
Within one minute of switching off
the ignition, operate the lighting con-
trol stalk up or down depending on
the traffi c side (for example: when
parking on the left; lighting control
stalk upwards; the right hand side-
lamps are on).
This is confi rmed by an audible signal
and illumination of the corresponding
direction indicator warning lamp in the
instrument panel.
To switch off the parking lamps, return
the lighting control stalk to the central
position.

5
VISIBILITY
100
EXTERIOR WELCOMELIGHTING

Switching on


)
Press the open padlock on
the remote control.

Switching off
The exterior welcome lighting switches
off automatically after a set time, when
the ignition is switched on or on locking
the vehicle.

Programming
To avoid causing a nuisance to other
road users, the height of the halogen
headlamps should be adjusted accord-
ing to the load in the vehicle.

0.
1 or 2 people in the front seats.

-.
3 people.

1.
5 people.

-.
Intermediate setting.

2.
5 people + maximum authorised
load.

-.
Intermediate setting.

3.
Driver + maximum authorised load.







MANUAL ADJUSTMENT OFHALOGEN HEADLAMPS

The initial setting is position "0"
.
AUTOMATIC ADJUSTMENT OFXENON HEADLAMPS


The remote switching on of the light-
ing and side spotlamps makes your ap-
proach to the vehicle easier in poor light.
It is activated depending on the light level
detected by the sunshine sensor.
The dipped beam headlamps and the
sidelamps come on, as well as the side
spotlamps, located under the door mir-
rors; your vehicle is also unlocked.
In order to avoid causing a nuisance to
other road users, this system corrects
the height of the xenon headlamp beams
automatically and when stationary, in re-
lation to the load in the vehicle.
If a malfunction occurs, this
warning lamp is displayed
on the instrument panel, ac-
companied by an audible
signal and a message in the screen.
The system then places your headlamps
in the lowest position.
Do not touch the xenon head-
lamp bulbs.
Contact a CITROËN dealer or a
qualifi ed workshop. The lighting duration is select-
ed via the vehicle confi guration
menu.
