2011 Citroen C ZERO RHD technical data

.
.
Contents
1
ISOFIX child seats 65
Child lock 68
Child safety
Direction indicators 69
Hazard warning lamps 69
Horn 69
Emergency or assistance call 70
Braking assistance systems 70
Tr ajectory control systems 72
Front seat belts 73
Airbags 76
Safety
Charging the main battery 80
Ancillaries battery 86
Te m p o r a ry puncture repair kit 90
Changing a wheel 94
Changing a bulb 97
Changing a fuse 105
Changing a wiper blade 110
To w i ng the vehicle 110
Precautions for washing 111
Accessories 111
Practical information
Bonnet 114
Front compartment 115
Rear compartment 116
Checking levels 117
Checks 119
Checks
Electric motor 120
Weights 121
Dimensions 122
Identifi cation markings 123
Technical data
Emergency or assistance 125
Audio system 127
Audio and telematics
Visual search
Alphabetical index

Technical data
120
MODEL:MOTOR AND MAIN BATTERY
Model type code:1 N ZK Z Z
Electric motorY4F1
Technology Synchronous with neodymium permanent magnets
Max. power: EU standard
(kW)

49

Max. power speed
(rpm)

2 500 to 8 000

Max. torque: EU standard (Nm)
18 0

Max. torque speed (rpm)

0 to 2 500
Main batteryLithium-Ion
Ener
gy capacity (kWh)

16
Normal charge

Volt age (V)
220

Charging time (*)(**):


- 16 A

- 13 A

- 1
0 A
6 hours
7 hours
9 hours
Fast char
ge
Volt age (V) 330


Charging time (80 % charge) ** 30 minutes

*
Dependin
g on the power supply in the country.
**
Time measured for ambient temperatures between 20 and 25 °C. Range varies according to the exterior climatic conditions, the driver's style o
f driving, the use of electrical equipment, the frequency of normal or fast charges and ageing of the main battery.

10
!
Technical data
121
WEIGHTS (in kg)
Electric motorY4 F1
Main batteryLithium-Ion
Model type code:1 N ZK Z Z
Unladen weight

1 120

Kerb weight 1 195

Gross vehicle weight (GV W) 1 450

Gross train wei
ght (GTW)1 450

Maximum load on the roo
f (including the roof bars)43

Your vehicle cannot be fitted with a towbar. It cannot tow a trailer.

Technical data
122





Dimensions (in mm)

10
i
i
Technical data
123














Identifi cation markings
Various visible markings for the identification of your vehicle.
A. Ser vice - Replacement Par ts
identification plate.
This plate is riveted to the underside ofthe bonnet.
Tyre pressures must be checkedwhen the tyres are cold, at least oncea month.

Low tyre pressures increase the
electrical power consumption of your vehicle, which reduces its range. B. Tyre identification label
.This label is affixed to the driver's centre pillar.
It bears the
following information:
- the tyre pressures (in bars),
- the tyre specification,
- the type of tyre.C. Manufacturer's
plate This plate is riveted to the left hand centre pillar.
D. Vehicle identification number (VIN).
This number is is engraved on the inner wheel
arch, inside the boot, right hand side.
For information on fitting snow chains, contact a CITROËN dealer or aqualified workshop.
It bears in par ticular the
following information:


- the vehicle model,

- the paint code,

- the type, variant, version.

.
Visual search
155
Technical data - Maintenance
Front compartment 115Checking l e v e l s 117-11 8- ancillaries battery electrolyte- brake fluid - heating system fluid - screenwash fluid
Changing front bulbs 97-102


Ancillaries battery 86-89


Opening the bonnet 114

Checks 119
Electric motor 120
Weights 121
Dimensions 12 2
Identification markings 123

Rear compartment 11 6 Checking the coolant level 118
Front compartment fuses 108 -109
