Snow screen
147
7
REMOVABLE SNOW SCREEN
According to country, the removable
snow screen is installed on the lower
p a r t o f t h e f r o n t b u m p e r t o p r e v e n t t h e
accumulation of snow at the radiator
cooling fan. FITTING
REMOVAL
- Pass a screwdriver into the hole
l o c a t e d n e a r e a c h o f t h e c l i p s .
- Use the screwdriver as a lever to u n c l i p t h e f o u r c l i p s B in turn.
- O f f e r u p t h e s n o w s c r e e n f a c i n g i t s
c e n t r i n g p i n A o n t h e f r o n t b u m p e r .
- P u t i t i n p l a c e b y p r e s s i n g a t e a c h c l i p B located in the four corners.
Do not forget to remove the
s n o w s c r e e n w h e n t h e e x t e r i o r
t e m p e r a t u r e i s h i g h e r t h a n 1 0 ° C
(no r i s k o f s n o w f a l l ) a n d w h e n
towing.
6. REFITTING THE REPAIRED
WHEEL
T h e w h e e l i s r e fi t t e d a s d e s c r i b e d i n
s t e p 5 , n o t f o r g e t t i n g t o r e fi t t h e w h e e l
embellisher.
R e f e r t o t h e " I d e n t i fi c a t i o n
m a r k i n g s " s e c t i o n o f c h a p t e r 8
to locate the tyre label.
R e f e r t o t h e " I n s t r u m e n t s a n d
c o n t r o l s " s e c t i o n o f c h a p t e r 2 ,
" T y r e u n d e r - i n fl a t i o n d e t e c t i o n "
p a r t , f o r r e c o m m e n d a t i o n s a f t e r
c h a n g i n g a w h e e l fi t t e d w i t h a t y r e
u n d e r - i n fl a t i o n d e t e c t i o n s e n s o r .
T h e s p a r e w h e e l i s n o t d e s i g n e d
to be used over long distances.
Have the tightening of the bolts
a n d t h e t y r e p r e s s u r e c h e c k e d b y a
C I T R O Ë N d e a l e r a s s o o n a s p o s s i b l e .
A l s o , h a v e t h e o r i g i n a l w h e e l r e p a i r e d
a n d r e fi t t e d b y a C I T R O Ë N d e a l e r a s
s o o n a s p o s s i b l e .
