Black plate (2,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
11-2 Service and Maintenance
{ WARNINGPerforming maintenance work can
be dangerous. Some jobs can
cause serious injury. Perform
maintenance work only if you
have the required know-how and
the proper tools and equipment.
If in doubt, see your dealer to
have a qualified technician do the
work. See Doing Your Own
Service Work on page 10 ‑ 4 .
At your dealer, you can be
certain that you will receive the
highest level of service available.
Your dealer has specially trained
service technicians, uses genuine
replacement parts, as well as,
up ‐ to ‐ date tools and equipment
to ensure fast and accurate
diagnostics. The proper replacement parts,
fluids, and lubricants to use are
listed in Recommended Fluids and
Lubricants on page 11 ‑ 7 and
Maintenance Replacement Parts on
page 11 ‑ 9 . We recommend the use
of genuine parts from your dealer.
Rotation of New Tires
To maintain ride, handling, and
performance of the vehicle, it is
important that the first rotation
service for new tires be performed.
Tires should be rotated every
12 000 km/7,500 miles. See Tire
Rotation on page 10 ‑ 59 .Scheduled
Maintenance When the Change Engine Oil
Soon Message Displays Change engine oil and filter. See
Engine Oil on page 10 ‑ 7 . An
Emission Control Service.
When the CHANGE ENGINE OIL
SOON message displays, service is
required for the vehicle as soon as
possible, within the next 1 000 km/
600 miles. If driving under the best
conditions, the engine oil life system
might not indicate the need for
vehicle service for more than a year.
The engine oil and filter must be
changed at least once a year and
the oil life system must be reset.
Your dealer has trained service
technicians who will perform this
work and reset the system.

Black plate (3,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Service and Maintenance 11-3If the engine oil life system is reset
accidentally, service the vehicle
within 5 000 km/3,000 miles since
the last service. Reset the oil life
system whenever the oil is changed.
See Engine Oil Life System on
page 10 ‑ 10 .
When the Change Engine Oil Soon
message displays, certain services,
checks, and inspections are
required.
Every Engine Oil Change .
Change engine oil and filter.
See Engine Oil on page 10 ‑ 7 .
An Emission Control Service. .
Engine coolant level check. See
Engine Coolant on page 10 ‑ 16 . .
Engine cooling system
inspection. Visual inspection
of hoses, pipes, fittings, and
clamps and replacement,
if needed. .
Windshield washer fluid level
check. See Washer Fluid on
page 10 ‑ 24 . .
Windshield wiper blade
inspection for wear, cracking,
or contamination and windshield
and wiper blade cleaning,
if contaminated. See Exterior
Care on page 10 ‑ 90 . Worn or
damaged wiper blade
replacement. See Wiper Blade
Replacement on page 10 ‑ 32 ..
Tire inflation pressures check.
See Tire Pressure on
page 10 ‑ 52 . .
Tire wear inspection. See Tire
Inspection on page 10 ‑ 58 . .
Rotate tires if necessary. See
Tire Rotation on page 10 ‑ 59 . .
Fluids visual leak check (or
every 12 months, whichever
occurs first). A leak in any
system must be repaired and
the fluid level checked. .
Engine air cleaner filter
inspection. See Engine Air
Cleaner/Filter on page 10 ‑ 14 . .
Brake system inspection (or
every 12 months, whichever
occurs first). .
Lubricate the front suspension,
steering linkage, and parking
brake cable guides. Control arm
ball joints are maintenance ‐ free.

Black plate (7,1)Cadillac Escalade/Escalade ESV Owner Manual - 2011
Service and Maintenance 11-7
Recommended Fluids, Lubricants, and Parts Recommended Fluids and Lubricants Fluids and lubricants identified below by name, part number, or specification can be obtained from your dealer.
Usage Fluid/Lubricant
Engine Oil The engine requires engine oil approved to the dexos specification. Oils
meeting this specification can be identified with the dexos certification
mark. Look for and use only an engine oil that displays the dexos
certification mark of the proper viscosity grade. See Engine Oil on
page 10 ‑ 7 .
Engine Coolant 50/50 mixture of clean, drinkable water and use only DEX-COOL Coolant.
See Engine Coolant on page 10 ‑ 16 .
Hydraulic Brake System DOT 3 Hydraulic Brake Fluid (GM Part No. 12377967, in
Canada 89021320).
Windshield Washer Optikleen ®
Washer Solvent.
Power Steering System GM Power Steering Fluid (GM Part No. 89021184, in Canada 89021186).
Automatic Transmission DEXRON ®
-VI Automatic Transmission Fluid.
Key Lock Cylinders Multi-Purpose Lubricant, Superlube (GM Part No. 12346241, in
Canada 10953474).
Chassis Lubrication Chassis Lubricant (GM Part No. 12377985, in Canada 88901242) or
lubricant meeting requirements of NLGI #2, Category LB or GC-LB.
