PASSENGER AIR BAG OFF light
Fig. 199 Section from
the in strument pa nel:
PASSENGER AIR BAG
OFF light
T he PASSENGER AIR BAG OFF light is located in the center of the
ins trume nt panel ~ fig. 199 .
Th e
PASSENGER AIR BAG OFF ligh t will come on and stay on to tell
you when the front Advanced Airbag on the passenger side has been
t ur ne d off by the ele ct ronic control unit. Each t ime you t urn on t he
ign ition, the
PASSENGER AIR BAG OFF light will flash fo r a few
se conds a nd:
• will stay on if t he front passenger seat is not occupied,
• will stay on if th ere is a small c hild or child re strain t on the front
passenger seat,
• will go ou t if th e fron t passe nger sea t is o ccup ied by an adul t as
registe red by t he weight-sens ing mat.
Th e
PASSENGER AIR BAG OFF light must come on and stay on if the
ign ition is on and
• a car bed has been insta lled on t he front seat, o r
• a rearward-facing c hild rest raint has been installed on the front
passenger seat, or
• a forward-faci ng chi ld restraint has bee n in stalled on the front
passenge rseat,or
• the weight reg istered on the front passenger seat is equal to or
less th an the co m bined we ig ht of a ty pical 1 year-o ld re strained in
Controls and equip­
ment Safety first
Vehicle operation
one of the rear-facing or forward- facing infa nt restraints listed in
F ede ral Mo tor Ve hicl e Sa fe ty S tan dard 20 8 wit h w hich th e Adv anced
Airbag System in your vehicle was certified .
If the front passenger seat is not occ upied, the front a irbag w ill not
dep loy, and the
PASSENGER AIR BAG OFF l igh t will s tay o n. N ever
install a rearward -facing chi ld restraint on the front passenge r seat,
t he s afest pla ce f or a ch ild in any kind o f ch ild re st ra int is at one of the
seating positions on t he rear seat~
page 201, "Child restra ints on
t he fr ont sea t- som e impo rtant t hings to know" and ~
page 2 21,
"Ch ild Safety" .
If the PASSENGER AIR BAG OFF light comes on when one of t he
co ndi tion s list ed above is m et, be sur e to che ck the light re gu la rly to
ma ke certain that the
PASSENGER AIR BAG OFF lig ht stays on
con tinu ously wheneve r the ignition is o n.
If the PASSENGER AIR BAG
OFF
lig ht does not appear and not stay on all the t ime, stop as soon
as it is safe to do so and
• reactivate the system by turni ng the ignition off and then t urning
it on agai n;
• remove and reinstall the ch ild restraint. Make sure that the ch ild
restra in t is prope rly installed and tha t the sa fety belt fo r the fron t
passenger seat has bee n correctly routed around the c hild restra int as
desc rib ed in the c hild restraint manufacturer's i nstr uctions;
• make s ure that the convertib le loc kin g feature o n the safety belt
for the front passenge r seat has been a ct ivated and t hat t he safety
belt has bee n pulled t ight. The be lt must not be loose or have loops
of slac k so that the senso r be low t he safety belt latch on the seat ca n
do its job~
page 23 1.
• make s ure tha t thi ngs tha t may inc rease the wei ght o f th e chi ld
and c hild safety seat are not bei ng transported on the front
passenge r seat;
• make s ure that the safety belt tension sensor is not blocked.
S hake the sa fety belt la tch on the front passen ger seat back an d
fort h;
• If a strap or teth er i s be ing used to tie the chi ld sa fe ty se at to the
front passe nger seat, make sure that it is not so tight that it causes .,
Vehicle care Do-it-yourself service Technical data

Airbag system Ill
----------------=--=---
& WARNING (co ntinued )
seating position and have the airbag system inspected by your
authorized Audi dealer.
• A tight tether o r other strap on a rearward -facing child
restraint attached to the front pa ssenger seat can put too much
pressure on the weight -sensing mat in the seat and register more
weight than i s actually on the seat . The heavier weight regi stered
can make the system work as though an adult were on the seat
and deploy the Advan ced Airbag when it mu st be suppre ssed
causing serious or even fatal injury to the child .
• If , in exceptional circumstanc es, you must install a forward­
facing child restraint on the front passenger seat, always move
the seat into its rearmost po sition in the seat' s fore and aft adjust­
ment range, as far away from the airbag as possible . The backrest
must be adjusted to an upright position. Make sure that the PASSENGER AIR BAG OFF light comes on and stays on all the time
whenever the ignition is switched on.
& WARNING
• If the PASSENGER AIR BAG OFF light doe s not go out when an
adult is sitting on the front passenger seat after taking the steps
described above, make sure the adult is properly seated and
restrained at one of the rear seating positions.
• Have the airbag system inspected by your authorized Audi
dealer before transporting anyone on the front passenger seat .
[ i ] Tips
If the we ight-sens ing mat in the front passenger seat detects an
em pty seat, the front airbag on the passenge r side will be t urne d off,
and PASSENGER AIR BAG OFF will stay on.•
Controls and equip­ ment Safety first Vehicle operation
Repair, care and disposal of the airbags
Parts of the airbag system a
re insta lled at many different places on
your Audi. I nstall ing, remov ing, serv icing o r rep airi ng a pa rt in an
area of the vehicle ca n damage a part of a n airbag system and prevent
t ha t sys tem from working prope rly in a coll is io n.
Th ere are some importa nt things you have to know to ma ke sure t hat
the effectiveness of the system will not be impai red and that
dis ca rded compo nents do not cause injury or po llute t he e nvir on­
ment .
& WARNING
Improper care , serv icing and repair procedures can increase the
risk of personal injury and death by preventing an airbag from
deploying when needed or deploying an airbag unexpectedly:
• Never cover, obstruct, or change the steering wheel horn pad or
airbag cover or the instrument panel or modify them in any way .
• Never attach any objects such as cupholders or telephone
mountings to the surfaces covering the airbag units .
• For cleaning the horn pad or instrument panel, use only a soft ,
dry cloth or one moistened with plain water . Solvent s or cleaners
could damage the airbag cover or change the stiffness or strength
of the material so that the airbag cannot deploy and protect prop ­
erly.
• Never repair, adjust, or change any part s of the airbag system .
• All work on the steering wheel, instrument panel , front seats
or electrical sy stem (including the installation of audio equip­
ment, cellular telephones and CB radios, etc. ) must be performed
by a qualified technician who has the training and special equip­ ment necessary .
• For any work on the airbag system, we strongly recommend
that you see your authorized Audi dealer or qualified workshop.
• Never modify the front bumper or parts of the vehicle body . ..,_
Vehicle care Do-it-yourself service Technical data

& WARNING
Changing the vehicle's susp ension including use of unapproved
tire -rim combination s can change Advan ced Airbag performance
and increase the risk of serious personal injury in a crash .
• Never install suspension component s that do not have the
same performance characteristics as the components originally
installed on your vehicle.
• Ne ver use tire-rim combinations that have not been approved
by Audi.
& WARNING
Items stored between the safety belt buckle and the center
console can cause the sensors in the buckle to send the wrong
information to the electronic control module and prevent the
Advanced Airbag System from working properly.
• Always make sure that nothing can interfere with the safety
belt buckles and that they a re not obstructed .
<£> For the sake of the environment
Undeployed airbag modu les and pretensioners might be class ified as
P erch lo rate Mate rial -special handling m ay app ly, see
www.dtsc.ca.gov/hazardouswaste/perchlorate . When the vehicle or
parts o f th e re st ra int system includin g airb ag modu les s afety belts
with pretens io ners are scrapped, all applicable laws and regulat ions
must be observed . Your authorized Aud i dealer is fam iliar with these
req uirements and we recommend that you have your dealer perform
this service for yo u.•
Safety first Vehicle OP-eration
Airbag system
Knee airbags
App lies to ve hi cle s: w ith K nee air b ags
Description of knee airbags
The airbag system can provid e su pplemental protection
to properly restrained front seat occupants .
....
! 00 m
Fig . 2 00 Driv er' s knee
a ir bag
T he kne e airbag fo r the driver is located in the instrument panel
undernea th the s teer ing whee l~ fig. 20 0, the knee airbag for the
passenge r is at about the same height in the instr ument pane l u n de r­
neath the g love compa rtment.
Th e knee air bag offers ad diti onal protec tion t o th e driver's and
passenger 's knees and upper and lower thigh areas as a supplement
t o the sa fety belts .
If the front airbags deploy , the knee airbags also deploy i n frontal
co llisions above a certain severity ~
pag e 208, "M ore important
things to know about front airbags" .
Bes ides the ir no rmal safety function, safety be lts work to help keep
t he drive r o r fro nt pa ssenger i n posi tion in cas e o f a fr ontal coll isio n
so that the airbags can prov ide p rotect io n.
Th e a irbag system is not a substitute for your safety be lt. Rather, it is
part o f the ove rall occ upant rest rai nt system in your veh icle . Always
r emember t hat the airbag system can only help to protect you if you •
Vehicle care Do-it-yourselt service iTechnical data

----------------------------------------------~A....::..:.... ir:....: b.::..:;; a..::g ~ s~y -=s:....: t:...: e:...: m...:....:.. __ lffll
If the front air bags deploy, th e knee a irbags also dep loy i n fronta l
coll is ions ab ove a c ertain s everity.
When the sys tem is d epl oyed , the ai rb a gs s ta rt to fill wi th a propel­
lant gas, a nd inflate between the lowe r pa rt of t he instr ument pane l
and th e drive r an d th e l owe r part of the in strum ent pan el a nd t he
front passenger ~
page 208, fig. 198.
Al th ou gh they are no t a soft pil low, they can cus hion th e impact and
in t his way th ey can help to red uce the risk of in jury to t he lower
extremities.
A ll thi s t akes pla ce in stan tan eously , so fas t th at ma ny pe opl e don 't
even rea lize that t he airbags have deployed. The airbags a lso inflate
w ith a g reat d eal o f for ce and it is im portant for o ccupa nt saf ety th at
nothing sh ould be in their way when t hey deploy .
F ully in flated airba gs i n com binatio n with pr ope rly wo rn safety belts
slow dow n and limit the occ upant's forwa rd movement a nd he lp to
re duce the risk. •
Applies to veh icles : w it h Kn ee air ba gs
Important safety instructions on the knee
airbag system
Airbags ar e only supp lem en tal r estra ints . Alw ays wear
s a fe ty be lts cor re ctly and ride in a proper seating pos i­
ti on .
Th ere is a lot that you an d yo ur passe ngers m ust know an d do to help
the sa fet y b elts and airbags to p rov id e su pp lemen tal protec tio n.
& WARNING
An inflating knee airbag can cause serious injury. Wearing safety
belts incorrectly and improper seating positions increase the risk
of serious personal injury and death whenever a vehicle is being
used.
Controls and equip­ ment Safety first Vehicle operation
& WARNING
(cont inued )
• The airbag system cannot protect you properly if you are seated
too close to any of the airbag locations. When adjusting their seat positions, it is important that both the driver and the front
passenger keep their upper bodies and knees at the following
minimum safe distances:
- 10 inches (25 cm) between the chest and the steering
wheel/instrument panel.
-4 inches (10 cm) between the knees and the lower part of
the instrument panel.
• The risk of personal injury increases if you lean forward or to
the side, or if the seat is improperly positioned and you are not
wearing your safety belt. The risk increases even more should the
airbag deploy .
• Always make sure that the knee airbag can inflate without
interference. Objects between yourself and the airbag can increase
the risk of injury in an accident by interfering with the way the
airbag deploys or by being pushed into you as the airbag deploys.
-No persons (children) or animals should ride in the footwell
in front of the passenger seat. If the airbag deploys, this can
result in serious or fatal injuries.
- No objects of any kind should be carried in the footwell area
in front of the driver's or passenger's seat. Bulky objects (shop­
ping bags, for example) can hamper or prevent proper deploy­
ment of the airbag. Small objects can be thrown through the
vehicle if the airbag deploys and injure you or your passengers.
• Make sure there are no cracks, deep scratches or other damage
in the area of the instrument panel where the knee airbags are
located.
• If children are incorrectly seated, their risk of injury increases
in the case of an accident~
page 221, "Child Safety". •
Vehicle care Do-it-yourself service Technical data

• in rear-end collisions
• in rollover s.
In some types of accide nts the front a irbags a nd side a irbags may be
t rig gere d together.
& WARNING
• Safety belts and the airbag system will only provide prote ction
when occupants are in the proper seating position=> page
219 .
• If the airbag indicator light comes on when the vehicle is being
used, have the system inspected immediately by your authorized
Audi dealer. The airbag may not work properly when the vehicle acceleration in a side collision is high enough to activate the
airbag. •
How supplemental side airbags work
Side airbags deploy ins tan tly an d can help reduce the risk
o f upper torso injuries for occupants who are properly
restrained.
Fig . 203 I nflated side
a ir ba gs on left side of
v eh icle
Wh en the system is trigge red, the airbag is filled w ith prop ellan t gas
and breaks through a seam in the seat s urface area marked
" AIR BAG".
It expand s between the side trim panel and the pa ssenger.
In order to he lp provide this additional protection, the s ide airbag
Safety
first Vehicle OP-eration
Airbag system
must inflate w ith in a fract ion of a seco nd at ve ry high speed and w it h
great for ce. T he supp lemen tal side air bag cou ld injure you if yo ur
seating position is not proper or upr ight o r if items ar e located in the
area w here the s upplementa l side ai rbag expands. This applies espe­
cially to children=>
page 221, ''Child Safety" . S upplementa l side
air bags inflate between the occupant and the door panel on the side
of the ve hicl e that is st ruck in certain side collision=> fig. 203 .
Altho ugh they are not a soft pillow, they can "cushion" the impact
and in this way they ca n help to re duc e the ris k of injury to the u pper
part of the body.
A fine dust may develo p when the airbag deploys. This is normal an d
does not mea n the re is a fire in the vehicle. •
Important safety instructions on the side
airbag system
Airbag s are o nly su pplemen tal rest raints . A lway s pr op ­
e rl y wear safety b elts and ride i n a pr op er se ating p osi­
tion .
There is a lot that you and yo ur passengers must k now and act accord­
ingly to help t he safety be lts and a irbags do t he ir job to provide
supplementa l protection.
& WARNING
An inflating side airbag can cau se serious or fatal injury. Improp­
erly wearing safety belts and improper seating position s increase
the risk of serious personal injury and death whenever a vehicle is
being used .
• In order to redu ce the risk of injury when the supplemental
side airbag inflate s:
- Alway s sit
in an upright position and never lean against the
area where the supplemental side airbag is located . •
Vehicle care Do-it-yourselt service Technical data

Child Safety -
-------------------"'---.,,.
Child Safety
Important things to know
Introduction
The rear seat is generally the safest place in a collision.
The physical pr in ci ples o f wha t happens w hen yo ur vehicl e is in a crash
app ly a lso to children=>
page 191, "What happens to occupants not
wearing safety be lts?". But unlik e adu lts and teenagers, the ir
muscles and bones are not fully developed. In many respects c hildren
are at greate r risk of ser io us injury in cras hes than adults .
Because children 's bodies a re not f ully deve loped, they require
restraint systems especially designed fo r their size, weight, and body
st ruct ure. Many cou ntries and all states of t he Unite d States and
prov inces of Canada have laws req uiring the use of approved ch ild
restrain t sys tems for infan ts an d sm all ch ild ren .
I n a fronta l crash at a speed of 20 -35 mph (30-56 km/h) the forces
act ing o n a 13- pound (6 kg) infant w ill be more than 20 times the
we ight of the ch ild . This means the we ight of the child wo uld
suddenly be more than 260 po unds (120 kg). Unde r these conditions,
only a n app ropr iat e child restra int proper ly used can red uce the risk
o f serious injury. Child restrai nts must be used properly to be e ffec­
t ive. Used i mpro perly, t hey can increase the risk of serio us injury in an
acc ident.
C onsult the ch ild safety seat manufacturer's instr uctions in order to
be sure the seat is r ight for you r child's size=>
page 224, "Important
safety instructions fo r using child safety seats". P lease be s ure to
read and heed a ll of the important informa tion and WAR NINGS
about chi ld safety, Advanced Airbags, an d the installation of child
restra in ts in this chapte r.
There is a lot you need to know about the Advanced Airbags in your
vehicle and how t hey wo rk when inf ants and childre n in child
restra ints are on the front passenger seat. Beca use of t he large
Controls and equip­
ment Safety first Vehicle operation
amou
nt of importa nt info rmation, we cannot repeat i t all he re. We
urge you to read the detailed information in th is owne r's man ua l
abou t airbags and t he Advanced A irbag Syste m in your vehicle and the
very important information abo ut transporting c hildren on the front
p assenger se at. P lea se be sure to heed the WARNIN GS - they a re
extremely important for your safety and the safety of your passe n­
gers, especially infan ts and small ch il dre n.
& WARNING
• Accid ent statisti cs have shown that children are generally safer
in the rear seat area than in the front seating position. Always
re strain any child age 12 and under in the rear.
• All vehicle occupants and especially children must be
restrained properly when ever riding in a vehicle. An unre strained
or improperly restrained child could be injured by striking the
interior or by being ejected from the vehicle during a sudden
maneuver or impact. An unrestrained or improperly rest rained
child is also at greater risk of injury or death through contact with
an inflat ing airbag .
• A suitable child restraint properly installed and used at one of
the rear seating posi tions provides the highest degree of protec­
tion for infants and small children in most accident situations.
& WARNING
Children on the front seat of any car even with Advanced Airbags
can be seriously injured or even killed when an airbag inflates. A
c hild in a rearward -facing child safety seat ins talled on the front
passenger seat will be seriously injured and can be killed if the
front airbag inflate s.
• The inflating airbag will hit the child safety seat or infant
c arrier with great force and will sma sh the child safety seat and
child aga inst the backrest, or door. •
Vehicle care Do-it-yourself service Technical data

__________________________________________ ___:C~ h~il ~d ~ S~a ~f ~e ~t ¥_Y __ _
and for the different models of the same kind of child restraint
offered by child restraint manufacturers.
The weight ranges for the individual types, makes and models of ch ild
restraints that the NHTSA has specified in the Safety Standard
together with the weight ranges of typical infants and typical 1 year­
old child have been stored in the control unit of the Advanced Airbag
System. When a child restraint is being used on the front passenger
seat with a typical 1 year-old chi ld, the Advanced Airbag System
compares the weight meas ured by the weight sensing mat with the
information stored in the electronic control unit .
The electronic contro l unit a lso registers the tension on the front
passenger safety belt. The tension on the safety belt for the front
passenger seat will be different for an adult who is properly using the
safety belt as compared to the tension on the belt when it is used to
attach a child restraint to the seat . The sensor below the latch for the
safety belt for the front seat passenger measures the tension on the
belt. The input from this sensor is then used with the weight to
"decide", whether there is a child restraint with a typical 1 year-old
child on the front passenger seat and whether or not the airbag must
be turned off .•
Child restraints and Advanced Airbags
Regardless of the child restraint that you use, ma ke sure that it has
been certified to meet United States Federal Motor Vehicle Safety
Standards and has been ce rtified by its manufacturer for use with an
airbag . Always be sure that the child restraint is properly installed at
one of the rear seating positions. If in exceptional circumstances you
must use it on the front passenger seat, carefully read all of the infor­
mation on ch ild safety and Advanced Airbags and heed all of the
app licab le WARNINGS. Make certain that the child restra int is
correctly recognized by the weight-sensing mat inside the front
passenger seat, that the front passenger airbag is turned off and that
the airbag status is always correctly signaled by the
PASSENGER AIR
BAG OFF
light.
Controls and equip­ ment Safety first Vehicle operation
Many types and models of child restra
ints have been available over
t he years, new models are introduced reg ularly incorpo rating new
and improved designs and older models are taken out of product ion.
Chi ld restraints are not standardized. Child restraints of the same
type typ ically have d ifferent weights and sizes and differe nt 'foot­
prints,' the size and shape of the bottom of the child restraint that
sits on the seat, when they are installed on a vehicle seat . These
differences make it virtually impossib le to certify compliance with
t he requirements for advanced airbags with each and every chil d
restra int that has ever been sold in the past or will be sold over the
course of the useful life of your vehicle.
For this reason, the United States Nationa l Highway Traffic Safety
Administration has published a list of specific type, makes and
mode ls of child restra ints that must be used to cert ify compliance of
the Advanced Airbag System in yo ur vehicle with the suppression
requirements of Federal Motor Veh icle Safety Standard 208. These
child restraints are:
Subpart A - Car bed child restraints
Model
Angel Gua rd Angel Ride
AA2403 FOF
Manufactured on or
after
September 25, 2007
Subpart B -Rear-facing child restraints
Model
Century SmartF it 4543
Cosco Ar riva 22-013PAW and
base 22-999 WHO
Evenflo D iscovery Ad just Right
21 2
Evenflo First Cho ice 204
Manufactured on or
after
December 1, 1999
September 25, 20 07
December 1, 1999
December 1, 1999
Vehicle care Do-it-yourself service Technical data

_____________________________________________ C_h _i_ld _ S_ a_ f_ e_ t_. y'--- __
- If a stra p or tet her is be ing us ed to tie t he chil d safety seat
to t he fro nt passenger seat, make sure that it is no t so
tight that i t causes the weight-sens ing ma t to measure
more weight t han is act ually on the seat.
Alw ays reme mbe r: Even though yo ur vehicle is equip ped with an
Adva nced Airbag system, all ch ild ren, especially those 12 years a nd
younger, should a lways ride in the bac k seat proper ly rest ra ined for
their age and size .
& WARNING
Not using a child safety seat, us ing the wrong child safety seat or
improperly in stalling a child re straint in crea se s the ri sk of serious
personal injury and death .
• All vehicle oc cupants and e specially children mu st always be
restrained properly whenever riding in a vehicle.
- An unrestrained or improperly restrained child can be injured or killed by being thrown against the inside of the
vehicle or by being ejected from it during a sudden maneuver
or impact .
- An unre strained or improperly restrained child is at much
greater risk of injury or death by being struck by an inflating
airbag .
• Commercially a vailable child safety seats are requi red to
c omply with U .S. Federal Motor Vehicle Safety Standard (FMVSS )
213 (in Canada CMVSS 213 ).
- When buying a child restraint, select one that fits your child
and the vehicle.
- Only u se child restraint sy stem s that fully contact the flat
portion of the seat cushion . The child rest raint must not tip or
lean to either side . Audi does not recommend using child
s a fety seats that rest on legs or tube-like frames. They do not
provide adequate contact with the seat .
Controls and equip­ ment Safety first Vehicle operation
& WARNING
(co ntinued )
-Always heed all legal requirements pe rtaining to the in stal­
lation and use of child safety seat s and carefully follow the
inst ructions provided by the manufacturer of the seat you are
using.
• Never allow child ren under 57 inches (1.5 meters ) to wear a
normal safety belt . They must always be restrained by a prop er
child restraint system . Otherwise , they could sustain injuries to
the abdomen and neck areas during sudden braking maneuvers or accidents.
• Never let more than one child occupy a child safety seat.
• Never let babies or olde r children ride in a vehicle while sitting
on the lap of another passenger.
-Holding a child in your arms is never a sub stitute for a child
restraint system .
- The stronge st p ers on could not hold the child with the force s
that e xist in an accident . The child will strike the interio r of the
v ehicle and can also be struck by the pa ssenger.
- The child and the passenger can also injure each other in an
accident.
• Never install rear-facing child safety seats or infant carriers on
the front pas senger seat. A child will be seriously injured and can
be killed when the passenger airbag inflates - e ven with an
Advanced Airbag Sy stem .
• The inflating airbag will hit the child safety seat or infant
c arrier with great force and will sma sh the child safety seat and
child aga inst the bac krest, center arm rest, door o r roof.
• Always in stall rear -facing child safety seats or infant carriers
on the rear seat .
• Forward-facing child safety seats installed on th e front
passenger 's seat can interfere w ith the airbag when it inflates and
c ause seriou s injury to the child . Always install forward-facing
c hild safet y seats on the rear seat . .,
Vehicle care Do-it-yourself service Technical data
