2011 Acura TL navigation system

Some phones may send battery,
signal strength, and roaming status
inf ormation to HFL.
As an incoming call notif ication, you
will see the f ollowing display:
To answer the call and show the
HFL inf ormation, press the PICK-UP
button on the steering wheel.
BluetoothHandsFreeL ink(Models with navigation system)
HFL Display
408
U.S. model is shown. CALLER NAME
PHONE DIALING
BATTERY LEVEL
STATUS
SIGNAL STRENGTH
LENGTH OF CALL TIME ROAM STATUS
BLUETOOTH INDICATOR
10/07/29 12:33:55 31TK4620_413
2011 TL

CONT INUED
BluetoothHandsFreeL ink(Models with navigation system)
How to Use HFL
Features
409
Pair your phone to the system.Delete a previously paired phone.
Switch from a currently linked phone to another paired phone. Create a user name for a paired phone.
Create a PIN number for a paired phone. Delete a user name and settings for a paired phone.
Setup
Bluetooth Phone
Search for next
phone
Cellular
Phone Pass-Key
Pair Phone
Delete Phone
Name
Delete PIN
Edit User Set a ‘‘fixed’’ or ‘‘random’’ pass-key code for phone pairing.
The power mode must be in ACCESSORY or ON
(see page
178).
Voice commands can be used for all above options.
Press and release the Talk button each time you give a command. Phone
Setup
10/07/29 12:34:01 31TK4620_414
2011 TL

BluetoothHandsFreeL ink(Models with navigation system)
410
CellularPhone Import
Cellular
Phonebook
Delete Voice TagStore Voice Tag
Store Speed-dial
Delete Speed-dial
Delete
Imported
Phonebook Import your entire cell phone’s phonebook data to the system.
Create a voice tag for a speed dial number.
Delete a voice tag for a speed dial number.Select a number from Call History or Phonebook to store as a
speed dial number.
Delete a previously stored speed dial number.
Delete a previously imported phonebook.
Press and release the Talk button each time you give a command. Voice commands can be used for all above options. Phone
Setup Edit
Speed Dial
10/07/29 12:34:05 31TK4620_415
2011 TL

ÎÎ
Î Î
Î
CONT INUED
BluetoothHandsFreeL ink(Models with navigation system)
Features
411
CellularPhone Dial
Phonebook
Call History
Speed dial entries
More Speed Dial Mute
Transfer Dial
Enter a phone number to dial.
Send numbers or names during a call.
Mute your voice during a call.
Transfer a call from HFL to your phone, or from your phone to HFL.
Display the paired phone’s previously imported phonebook (or import a new one).
Display a list of all 20 speed dial entries. Eric
Mike Lisa
John The first 4 speed dial numbers are
shown on the Cellular Phone screen.
: ExampleDial
Voice commands can be used for all above options.
Press and release the Talk button each time you give a command. Display the last 30 incoming, outgoing, or missed calls.
(Appears only when a phone is connected to the system via HFL.)
10/07/29 12:34:10 31TK4620_416
2011 TL

To use HFL, you need to pair your
Bluetooth-compatible cell phone to
the system.
HFLusesaClass2Bluetooth,which
means, the maximum range between
yourphoneandvehicleis30feet(10
meters).Press the PICK-UP button to go
directly to the Cellular Phone screen.Select ‘‘PHONE SETUP’’ f rom the
Cellular Phone screen. This menu group is f or phone pairing,
and user, phonebook, and speed dial
editing.
BluetoothHandsFreeL ink(Models with navigation system)
Phone Setup
Cellular Phone
412
Push the selector down for
PHONE SETUP.
10/07/29 12:34:17 31TK4620_417
2011 TL

CONT INUED
To pair a cell phone:On U.S. modelsOn Canadian models
Select ‘‘Setup Bluetooth Phone’’
f rom the Phone Setup screen.
Select ‘‘Pair Phone.’’
HFL gives you a 4-digit pass-key
that you will need to input on your
phone. When your phone prompts you,
input the 4-digit pass-key. Put your cell phone in ‘‘Discovery’’
or ‘‘Search’’ mode, and search f or
a Bluetooth device.
You will receive a notification to
set up an AcuraLink
connection.
If you want to do this, please see
page , or select ‘‘Setup Later.’’
You will receive a notif ication on
the screen and your phone if
pairing is successf ul.
1.
2.
3.
4.
5.
6.
425
BluetoothHandsFreeL ink(Models with navigation system)
Set up Bluet oot h Phone
Features
413
Example
U.S. model is shown.
10/07/29 12:34:29 31TK4620_418
2011 TL

To create your own pass-key, select
‘‘Fixed’’ and f ollow steps 3 and 4.Delete the current pass-key.
Enter a new pass-key, and select
‘‘OK.’’
Select ‘‘Setup Bluetooth Phone’’
f rom the Phone Setup screen.
Select ‘‘Pass-key.’’
The def ault pass-key ‘‘0000’’
is used until you change the setting.
For a randomly generated pass-key
each time you pair a phone, select
‘‘Random.’’
Up to six phones can be paired.
Your phone’s battery may drain
f aster when it is paired to HFL. You cannot pair your phone while
the vehicle is moving.
3.
1.
2.
4.
To change the pass-key setting:
BluetoothHandsFreeL ink(Models with navigation system)
Phone pairing tips
414
NOTE:
Example
Push the selector to left to delete.
10/07/29 12:34:40 31TK4620_419
2011 TL

CONT INUED
You can name up to six HFL users.
Each can be PIN protected, and have
its own phonebook, speed dial, and
call history.
Select the user you want to edit on
the Cellular Phone screen.
If the user you selected is PIN-
protected, the ‘‘Speed Dial’’ list on
the right side of the screen will not
appear until the PIN is entered.
To change f rom the currently linked
phone to another paired phone,
select ‘‘Search f or next phone’’ on
the Phone Setup screen.
HFL disconnects the linked phone
and starts searching f or another
paired phone.
If no other paired phone is f ound,
HFL will automatically link the
previous phone.
Select ‘‘Setup Bluetooth Phone’’
f rom the Phone Setup screen.
Select ‘‘Delete a phone.’’
Select the phone you want to
delete. The Bluetooth icon shows
you the currently linked phone.
A trash icon appears next to the
selected phone. Select ‘‘OK’’ to
continue.
1.
2.
3.
4.
To delete a paired phone:
BluetoothHandsFreeL ink(Models with navigation system)
Edit User
Search f or Next Connect ed Phone
Features
415
SPEED DIAL LIST
Select a user name.
TRASH ICON
BLUETOOTH ICON
10/07/29 12:34:53 31TK4620_420
2011 TL
