ACCESS
89
*
According to country.






ALARM *

System which protects and provides a de-
terrent against theft and break-ins. It pro-
vides the following types of monitoring.

- exterior perimeter
The system checks for opening of the
vehicle.
The alarm is triggered if anyone tries to
open a door, the boot, the bonnet...



- interior volumetric
The system checks for any variation in the
volume in the passenger compartment.
The alarm is triggered if anyone breaks a
window, enters the passenger compart-
ment or moves inside the vehicle.



- tilt
The system checks for any change in
the attitude of the vehicle.
The alarm is triggered if the vehicle is
lifted, moved or knocked.



Self-protection function
The system checks for the putting out
of service of its components.
The alarm is triggered if the battery, the
central control or the siren wiring are
put out of service or damaged.
For all work on the alarm sys-
tem, contact a CITROËN dealer
or a qualifi ed workshop.


Locking the vehicle with full
alarm system

Activation


)
Switch off the ignition and get out of
the vehicle.

)
Press the locking button on the re-
mote control.
The monitoring system is active: the in-
dicator lamp in the button fl ashes once
per second.
After the locking button on the remote
control is pressed, the exterior perime-
ter monitoring is activated after a delay
of 5 seconds and the interior volumetric
and anti-tilt monitoring after a delay of
45 seconds. If an opening (door, boot...) is
not closed fully, the vehicle is not
locked but the exterior perimeter
monitoring will be activated af-
ter a delay of 45 seconds at the
same time as the interior volu-
metric and anti-tilt monitoring.

Deactivation


)
Press the unlocking button on the
remote control.
The alarm system is deactivated: the
indicator lamp in the button goes off.

9
DRIVING
166





LANE DEPARTURE WARNING
SYSTEM
The lane departure warning sys-
tem cannot, in any circumstances,
replace the need for vigilance and
responsibility on the part of the
driver.

Activation



)
Press this button, the indicator lamp
comes on.



Deactivation



)
Press this button again, the indicator
lamp goes off.
The status of the system remains in the
memory when the ignition is switched
off.


Detection

You are warned by the vibration of the
driver's seat cushion:


- on the right-hand side, if the mark-
ing on the ground has been crossed
on the right,

- on the left-hand side, if the marking
on the ground has been crossed on
the left.
No warning is transmitted while the
direction indicator is active and for
approximately 20 seconds after the di-
rection indicator is switched off.
A warning may be transmitted if a direc-
tion marking (e.g. arrow) or non-standard
marking (e.g. graffi ti) is crossed.


Operating fault


The detection may be impeded:


- if the sensors are dirty (mud,
snow...),

- if the markings on the ground
are worn,

- if there is little contrast be-
tween the markings on the
ground and the road surface.

System which detects the involuntary
crossing of longitudinal traffi c lane mark-
ings on the ground (solid or broken
line).
Sensors, fi tted below the front bumper,
trigger a warning if the vehicle drifts
over a lane marking (speed higher than
50 mph (80 km/h)).
This system is particularly useful on
motorways and main roads. In the event of a malfunction,
the service warning lamp
comes on, accompanied by
an audible signal and a message in the
screen.
Contact a CITROËN dealer or a qualifi ed
workshop.

10
CHECKS
184

























CHECKING LEVELS

Check all of these levels regularly and
top them up if necessary, unless other-
wise indicated.
If a level drops signifi cantly, have the
corresponding system checked by a
CITROËN dealer or a qualifi ed work-
shop.

When working under the bonnet,
take care, as certain areas of the
engine may be extremely hot (risk
of burns).
The reading will only be correct if
the vehicle is on level ground and
the engine has been off for more
than 30 minutes.
The check is carried out either when the
ignition is switched on using the oil level
indicator in the instrument panel, or using
the dipstick.
It is normal to top up the oil level between
two services. CITROËN recommends that
you check the oil level, and top up if neces-
sary, every 3 000 miles (5 000 kilometres).

Oil level


Engine oil change
Refer to the servicing booklet for the
interval for this operation.
In order to maintain the reliability of the
engine and emission control system,
the use of additives in the engine oil is
prohibited.
Oil specifi cation
The oil must correspond to your engine
and conform to the manufacturer's rec-
ommendations.



Brake fluid level

The brake fl uid level should be
close to the "MAX" mark. If it is
not, check the brake pad wear.

Changing the fl uid
Refer to the servicing booklet for the
interval for this operation.

Fluid specifi cation
The brake fl uid must conform to the
manufacturer's recommendations and
meet the DOT4 standard.



Power steering fluid level

The power steering fl uid level
should be close to the "MAX"
mark. Unscrew the cap, with
the engine cold, to check the
level.


Coolant level

The coolant level should be
close to the "MAX" mark but
should never exceed it.
When the engine is warm, the
temperature of the coolant is regulated
by the fan. This can operate with the ig-
nition off.

On vehicles which are fi tted with a par-
ticle emission fi lter, the fan may oper-
ate after the vehicle has been switched
off, even if the engine is cold.
In addition, as the cooling system is
pressurised, wait at least one hour after
switching off the engine before carrying
out any work.
To avoid any risk of scalding, unscrew
the cap by two turns to allow the pres-
sure to drop. When the pressure has
dropped, remove the cap and top up
the level.

Changing the coolant
The coolant does not have to be
changed.

Coolant specifi cation
The coolant must conform to the manu-
facturer's recommendations.

230








EMERGENCY OR ASSISTANCE CALL


EMERGENCY CALL


In an emergency, press this button for more than
2 seconds. Flashing of the green indicator lamp and a
voice message confi rm that the call has been made to the
CITROËN Emergency team * .

Pressing this button again immediately cancels the request. The green
indicator lamp goes off.
A press (at any time) of more than 8 seconds on this button, cancels
the request.


ASSISTANCE CALL

When the ignition is switched on, the green
indicator lamp comes on for 3 seconds
indicating that the system is operating correctly.


If the orange indicator lamp fl ashes: there
is a system fault.
If the orange indicator lamp is on continuously:
the backup battery must be replaced.
In either case, contact a CITROËN.
Pressing this button again immediately cancels the request.
The cancellation is confi rmed by a voice message.

Press this button for more than 2 seconds to request
assistance if the vehicle breaks down.
A voice message confi rms that the call has been made * .


OPERATION OF THE SYSTEM

The green indicator lamp remains on (without fl ashing) when
communication is established. It goes off at the end of communication.

This call is dealt with by the CITROËN Emergency team which receives
locating information from the vehicle and can send a detailed alert to the
appropriate emergency services. In countries in which the team is not
operational, or when the locating service has been expressly declined,
the call is dealt with directly by the emergency services (112) without the
vehicle location.

If an impact is detected by the airbag ECU, and independently
of the deployment of any airbags, an emergency call is made
automatically.


* These services are subject to conditions and availability.
Consult a CITROËN dealer.
If you purchased your vehicle outside the CITROËN dealer network,
we invite you to have a dealer check the confi guration of these services
and, if desired, modifi ed to suit your wishes. In a multi-lingual country,
confi guration is possible in the offi cial national language of your choice.
If you benefi t from the CITROËN eTouch offer, you also have available
additional services in your MyCITROEN personal space, via the CITROËN
Internet website www.citroen.co.uk.

For technical reasons, particularly to improve the quality of telematic
services for customers, the manufacturer reserves the right to carry out
updates to the vehicle's on-board telematic system.

323
ALPHABETICAL INDEX
L Lane Departure Warning System
(LDWS) ....................................166
Level, brake fl uid ........................184
Level, power steering fl uid .........184
Levels and checks ...............182-185
Lighting, guide-me home ....102, 103
Lighting, interior ...................111, 112
Lighting bulbs
(replacement) ...................197, 201
Lighting control stalk ............99, 102
Lighting dimmer .................28-31, 49
Loading ................................26, 210
Load reduction mode .................209
Load space cover .......................125
Locating your vehicle ...................82
Locking from the inside ................87
Locking the boot ...........................92
Long objects, transporting ..........121
LPG ............................................221
Luggage retaining strap .............122
M Main beam ...................99, 197, 199
Maintenance .................................26
Map reading lamps ..................... 111
Markings, identifi cation ...............228
Massage function .........................74
Mat .............................................120
Menu, main ................................286
Mini fuel level ...............................96
Mirror, rear view ...........................79
Mirrors, door ...................77, 78, 167
Misfuel prevention ........................98
Motorway function
(direction indicators) .................135
Mountings for ISOFIX seats .......131
MP3 CD ..............................291, 292
Music media players ..................266N Navigation ..........................237, 238
Number plate lamps ...................202
O Oil fi lter .......................................186
Oil level ................................44, 184
Opening the bonnet ....................180
Opening the boot ..........................92
Opening the doors ........................91
Opening the panoramic
sunroof blind ...............................95
Operation indicator
lamps ........................35, 40, 41, 43
P Paint colour code .......................228
Panoramic glass sunroof ..............95
Parcel shelf, rear ................123, 125
Parking brake .....................154, 187
Parking brake, electric ........147, 150
Parking lamps ............................102
Parking sensors, front ................178
Parking sensors, rear .................177
Parking space sensor .................175
Particle emission fi lter ........185, 186
Passenger compartment fi lter ....186
Personalisation .............................50
Player, CD MP3 ..................291, 292
Port, USB ........................... 115, 293
Priming the fuel system ..............181
Protecting
children ..... 126, 129, 131-133, 143
Puncture .....................................188
R Radio ..........................263, 264, 287
Radio pre-equipment ..................214
Rear screen (demisting) ...............70
Recharging the battery ...............207
Reduction of electrical load ........209R Reinitialising the electric
windows .....................................93
Reinitialising the remote
control ..................................84, 85
Remote control .................80, 82, 86
Removable screen
(snow shield) ............................210
Removing a wheel ......................195
Removing the mat ......................120
Repair kit, puncture ....................188
Replacing bulbs ..................197, 201
Replacing fuses ..........................203
Replacing the air fi lter ................186
Replacing the oil fi lter .................186
Replacing the particle
emission fi lter ...........................186
Replacing the passenger
compartment fi lter ....................186
Replacing wiper blades ...... 110, 209
Resetting the service indicator .....46
Resetting the trip recorder ............48
Rev counter .............................28-32
Reversing lamps ........................201
Risk areas (update) ....................242
Roof bars ....................................210
Roof blind .....................................95
Routine checks ...................186, 187
Running out of fuel (Diesel) ........181
S Safety for children ................93, 134
Satellite navigation system ...........56
Screen, colour and
mapping ...............56, 57, 235, 274
Screen,
monochrome ........51, 53, 286, 310
Screen, multifunction (with audio
equipment) .............51, 53, 56, 286

324
ALPHABETICAL INDEX
S Screen menu map ...... 274, 310-312
Screenwash, front ......................109
Seat, rear bench ...........................76
Seat adjustment .....................71, 72
Seat belts ............................140-142
Seats, electric ...............................72
Seats, rear ....................................76
Serial number, vehicle ................228
Service indicator .....................45, 47
Servicing ......................................26
Setting the clock ...................48, 273
Short-cut menus .........................236
Sidelamps ....99, 102, 197, 199, 201
Side repeater ..............................200
Ski fl ap .......................................121
Spare wheel ...............................193
Speakers (fi tting) ........................214
Speed limiter ......................170, 171
Speedometer ...........................28-31
Spotlamps, side ..................104, 200
Starting the vehicle .......83, 156, 159
Steering mounted
controls .............................234, 285
Stopping the vehicle .....83, 156, 159
Stop & Start ............... 62, 68, 70, 96,
163, 180, 186, 207, 309
Storage .........113, 114, 116-118, 122
Storage compartments ............... 116
Storage drawer ...........................120
Storage net .................................122
Storing driving positions ...............75
Stowing rings ..............................122
Sun visor .................................... 114
Synchronising the remote
control ..................................84, 85
Synthesiser, voice ......................248
System, navigation .....................238T Table of weights .........217, 221, 223
Tables of engines .......217, 221, 223
Tables of fuses ...........................203
Tank, fuel ......................................98
Technical data ............217, 221, 223
Telephone ...................254, 258, 299
Temperature control
for heated seats .........................73
Temporary tyre repair kit ............188
Ticket holder ............................... 113
Time ...........................................308
TMC (Traffi c info) .......................251
Tools ...........................................193
Torch ..........................................124
Total distance recorder .................48
Towbar ........................................213
Towed loads ...............217, 221, 223
Towing another vehicle ............... 211
Traction control (ASR) ................138
Traffi c information
(TA) ..........................252, 265, 288
Traffi c information
(TMC) ...............................251, 252
Trajectory control systems .........138
Trip computer ..........................59-62
Trip distance recorder ..................48
Tyre pressures ...........................228
Tyres ............................................26
Tyre under-infl ation
detection .............................47, 136
U Under-infl ation (detection) ..........136
Under fl oor storage ....................124
Unlocking from the inside .............87
Unlocking the boot ...........80, 81, 92
Unlocking the doors ...............80, 81
Update risk areas .......................242U Updating the date .......................273
Updating the time .................48, 273
USB Box ..................................... 115
V Vehicle
confi guration .............51, 53, 56, 57
Ventilation ................................63-65
W Warning lamps ...........33, 35, 41, 47
Wash-wipe, rear ......................... 110
Weights ......................217, 221, 223
Welcome lighting ........................104
Window controls ...........................93
Wiper, rear .................................. 110
Wiper control stalk ............... 108-110
Wipers ..........................42, 108, 109
X Xenon headlamps ......................197
