Page 151 of 244

Citroen C3 PICASSO RHD 2011.5 1.G Owners Manual 11
149
PRACTICAL INFORMATION

Dashboard fuses

The fusebox is located in the glove box.

Access to the fuses

�)
refer to the paragraph "Access to
the tools".

Fuse tables

Page 152 of 244

Citroen C3 PICASSO RHD 2011.5 1.G Owners Manual 11
150
PRACTICAL INFORMATION

Fuse N°

Rating

Functions

F8

20 A

Multifunction screen, audio system, navigation
radio.

F9

30 A

Audio s

Page 162 of 244

Citroen C3 PICASSO RHD 2011.5 1.G Owners Manual 11
160
PRACTICAL INFORMATION
TOWING A TRAILER, ...
Your vehicle is primarily designed for
transporting people and luggage, but it
may also be used for towing a trailer.
Driving advice
The max

11
160
PRACTICAL INFORMATION
TOWING A TRAILER, ...
Your vehicle is primarily designed for
transporting people and luggage, but it
may also be used for towing a trailer.
Driving advice
The maximum towed load on a long in-
cline depends on the gradient and the
ambient temperature.
In all cases, keep a check on the coolant
temperature.

Side wind

)
Take into account the increased
sensitivity to side wind.

Cooling
Towing a trailer on a slope increases
the temperature of the coolant.
As the fan is electrically controlled, its
cooling capacity is not dependent on
the engine speed.

)
To lower the engine speed, reduce
your speed.
Braking
Towing a trailer increases the braking
distance.
To avoid overheating of the brakes on a
long mountain type of descent, the use
of engine braking is recommended.

Tyres

)

Check the tyre pressures of the towing
vehicle and of the trailer, observing the
recommended pressures.

Lighting

)
Check the electrical lighting and sig-
nalling on the trailer.
The rear parking sensors will
be deactivated automatically if
a genuine CITROËN towbar is
used.

)
If the warning lamp and the
STOP
warning lamp come
on, stop the vehicle and
switch off the engine as
soon as possible.

Towbar suitable for the attachment of a
trailer with additional lighting and sig-
nalling.

Distribution of loads

)
Distribute the load in the trailer so
that the heaviest items are as close
as possible to the axle and the nose
weight approaches the maximum
permitted without exceeding it.
Air density decreases with altitude, thus
reducing engine performance. Above
1 000 metres, the maximum towed load
must be reduced by 10 % for every
1 000 metres of altitude.
Refer to the "Technical Data" section for
details of the weights and towed loads
which apply to your vehicle. Driving with a trailer places greater de-
mands on the towing vehicle and the
driver must take particular care.
We recommend the use of gen-
uine CITROËN towbars and
their harnesses that have been
tested and approved from the
design stage of your vehicle,
and that the ﬁ tting of the tow-
bar is entrusted to a CITROËN
dealer or a qualiﬁ ed workshop.
If the towbar is not ﬁ tted by a
CITROËN dealer, it is impera-
tive that it is ﬁ tted in accordance
with the vehicle manufacturer's
instructions.

Page 164 of 244

Citroen C3 PICASSO RHD 2011.5 1.G Owners Manual 11
162
PRACTICAL INFORMATION

"Comfort":
front and rear parking sensors, insu-
lated module, reading lamp, sun blinds,
head restraint-mounted coat hanger,
centre armrest, air deﬂ

Page 233 of 244

Citroen C3 PICASSO RHD 2011.5 1.G Owners Manual 231
ALPHABETICAL INDEX
P Paint colour code .......................171
Panoramic glass sunroof ..............67
Parking brake ..................... 110, 132
Parking sensors, rear ...............

231
ALPHABETICAL INDEX
P Paint colour code .......................171
Panoramic glass sunroof ..............67
Parking brake ..................... 110, 132
Parking sensors, rear .................123
Particle emission ﬁ lter ........131, 132
Passenger compartment
ﬁ lter ..........................................131
Player, CD MP3 ..................193, 213
Port, USB .....................80, 214, 216
Priming the fuel system ..............127
Protecting
children ................. 90-98, 105, 107
Puncture .....................................133
R Radio .................................. 191, 211
Reading lamps, rear .....................78
Rear foglamp ..............................145
Rear parcel shelf ....................87, 89
Rear screen (demisting) ...............47
Recharging the battery ...............156
Reduction of electrical load ........156
Reinitialising the electric
windows .....................................63
Reinitialising the remote
control ........................................60
Remote control .......................58, 61
Removing a wheel ......................140
Removing the mat ........................83
Repair kit, puncture ....................133
Replacing bulbs ..........................142
Replacing fuses ..........................148
Replacing the air ﬁ lter ................131
Replacing the oil ﬁ lter .................131
Replacing the particle
emission ﬁ lter ...........................132R Replacing the passenger
compartment ﬁ lter ....................131
Replacing wiper blades ........77, 157
Resetting the service indicator .....32
Resetting the trip recorder ............34
Rev counter ..................................22
Reversing lamp ..........................145
Risk areas (update) ....................188
Roof bars ....................................161
Roof blind .....................................67
Routine checks ...................131, 132
Running out of fuel (Diesel) ........127
S Safety for children .... 90-98, 105, 107
Scented air freshener ...................51
Screen, colour 16/9 ............178, 199
Screen,
monochrome ............210, 222, 224
Screen, multifunction (with audio
equipment) .....................35, 37, 39
Screen-wash reservoir ...............130
Screen menu map ......199, 222, 224
Screenwash .................................76
Screenwash ﬂ uid level ...............130
Seat, rear bench ...........................54
Seat adjustment .....................52, 54
Seat back storage pockets ...........84
Seat belts ............................102-105
Serial number, vehicle ................171
Service indicator ...........................31
Servicing ......................................20
Setting the clock ...36, 198, 220, 221
Short-cut menus .................179, 180
Sidelamps ....................71, 143, 145
Side repeater ..............................143 L Localised emergency call ...........174
Locating your vehicle ...................59
Locking from the inside ................65
Long objects, transporting ............86
Low fuel level ...............................68
M Main beam ...........................71, 143
Maintenance .................................20
Map reading lamps ...............78, 147
Markings, identiﬁ cation ...............171
Mat ...............................................83
Menu, main ................................210
Mirror, rear view ...........................57
Mirrors, door .................................56
Misfuel prevention ........................70
Motorway function
(direction indicators) ...................99
Mountings
for ISOFIX seats .........................95
MP3 CD ..............................193, 213
Music media players ..........192, 213
MyWay ................................175-206
N Navigation ..................................181
Number plate lamps ...................145
O Oil ﬁ lter .......................................131
Oil level ................................33, 130
Opening the bonnet ....................126
Opening the boot ....................58, 66
Opening the doors ..................58, 64
Opening the fuel ﬁ ller ﬂ ap ............68
Operation indicator lamps .......23-30
