06 Maintenance and specifications
Fuses
06
252* Option/accessory, for more information, see Introduction.
FunctionA
Overhead courtesy lighting,
Control panel driver's door/
Power passenger seat*7.5
Information display5
Power driver's seat*5
Tailgate wiper15
Remote key receiver, Alarm
sensors5
Fuel pump20
Electric steering column lock20
–
Lock, tank/tailgate10
Alarm siren. ECC5
START/STOP ENGINE button5
Brake light switch5

06 Maintenance and specifications
Wheels and tires
06
272
CAUTION
If your vehicle is equipped with the Tire
Pressure Monitoring System (TPMS), the
use of the sealing compound may lead to
incorrect tire pressure readings or in rare
cases, damage to the tire pressure sensor.
Use the tire sealing system to check and
adjust the damaged tire's inflation pressure.
NOTE
•Safely stow the tire sealing system in a
convenient place as it will soon be used
again to check the tire’s inflation pres-
sure.
•The empty bottle of sealing compound
cannot be removed from the bottle
holder. Consult a trained and qualified
Volvo service technician to have the
bottle removed and properly disposed
of.
WARNING
If heavy vibrations, unsteady steering
behavior, or noises should occur while driv-
ing, reduce speed and park the vehicle in a
safe place. Recheck the tire for bumps,
cracks, or other visible damage, and
recheck its inflation pressure. If the pressure
is below 19 psi (1.3 bar), do not continue
driving. Have the vehicle towed to a trained
and qualified Volvo service technician.
Stage 2: Checking inflation pressure1. Connect the tire sealing system as descri-
bed in stage 1.
2. Refer to the inflation pressure tablesfor the
correct inflation pressure. If the tire needs
to be inflated, start the tire sealing system’s
compressor. If necessary, release air from
the tire by turning the air release knob
counterclockwise.
CAUTION
The compressor should not be used for
more than 10 minutes at a time to avoid
overheating.
WARNING
If you interrupt your trip for more than 1
hour, check the inflation pressure in the
damaged tire again before continuing.
Replacing the sealing compound
container
The sealing compound container must be
replaced if:
•the tire sealing system has been used to
repair a tire
•the container’s expiration date has passed
(see the date on decal).
NOTE
•After use, the sealing compound bottle,
the hose, and certain other system
components must be replaced. Please
consult your Volvo retailer for replace-
ment parts.
•If the sealing compound bottle’s expi-
ration date has passed, please take it to
a Volvo retailer or a recycling station
that can properly dispose of harmful
substances.

06 Maintenance and specifications
Wheels and tires
06

273 Inflating tires
The tire sealing system can be used to inflate
the tires. To do so:
1. Park the car in a safe place.
2. The compressor should be switched off.
Ensure that the on/off switch is in position
0 (the 0 side of the switch should be
pressed down).
3. Take out the electrical wire and hose.
4. Remove the valve cap from the tire’s infla-
tion valve and screw the hose connector
onto the valve as tightly as possible by
hand.
5. Connect the electrical wire to the nearest
12-volt socket in the vehicle.
6. Start the vehicle’s engine.
WARNING
•The vehicle’s engine should be running
when the tire sealing system is used to
avoid battery drain. Therefore, be sure
the vehicle is parked in a well ventilated
place, or outdoors, before using the sys-
tem.
•Children should never be left unattended
in the vehicle when the engine is running.
7. Check the tire’s inflation pressure on the
gauge. Switch off the compressor briefly to
get a clear reading from the pressure
gauge.
8. Refer to the tire inflation tables for the cor-
rect inflation pressure. If the tire needs to
be inflated, start the tire sealing system’s
compressor (press the on/off switch to
position I). If necessary, release air from the
tire by turning the air release knob coun-
terclockwise.
CAUTION
The compressor should not be used for
more than 10 minutes at a time to avoid
overheating.
9. Turn off the compressor (press the on/off
switch to position 0) when the correct infla-
tion pressure has been reached.
10. Unscrew the hose from the tire’s inflation
valve and reinstall the valve cap.
11. Disconnect the electrical wire from the
12-volt socket.
Tire Pressure Monitoring System
(TPMS)–U.S models only
NOTE
USA – FCC ID: KR5S122780002
This device complies with part 15 of the
FCC rules. Operation is subject to the fol-
lowing conditions: (1) This device may not
cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
The tire pressure monitoring system uses sen-
sors mounted in the tire valves to check infla-
tion pressure levels. When the vehicle is mov-
ing at a speed of approximately 20 mph
(30 km/h) or faster, these sensors transmit
inflation pressure data to a receiver located in
the vehicle.
When low inflation pressure is detected, TPMS
will light up the tire pressure warning light
(
) (also referred to as a telltale) in the
instrument panel and will display one of the
following messages in the text window:
LOW
TIRE PRESS. CHECK TIRES or VERY LOW
TIRE PRESSURE.

06 Maintenance and specifications
Wheels and tires
06
275
Changing wheels with TPMSPlease note the following when changing or
replacing the factory installed TPMS wheels/
tires on the vehicle:
•Only the factory-mounted wheels are
equipped with TPMS sensors in the valves.
•If the vehicle is equipped with a temporary
spare tire, this tire does not have a TPMS
sensor.
•If wheels without TPMS sensors are moun-
ted on the vehicle, TIRE PRESS SYST
SERVICE REQUIRED will be displayed
each time the vehicle is driven above
25 mph (40 km/h) for 10 minutes or more.
•Once TPMS sensors are properly installed,
the warning message should not reappear.
If the message is still displayed, drive the
vehicle for several minutes at a speed of
20 mph (30 km/h) or faster to erase the
message.
•Volvo recommends that TPMS sensors be
fitted on all wheels used on the vehicle.
Volvo does not recommend moving sen-
sors back and forth between sets of
wheels.
NOTE
•If you change to tires with a different
recommended inflation pressure, the
TPMS system must be recalibrated to
these tires. This must be done by a
trained and qualified Volvo service tech-
nician.
•If a tire is changed, or if the TPMS sen-
sor is moved to another wheel, the sen-
sor's seal, nut, and valve core should be
replaced.
•When installing TPMS sensors, the
vehicle must be parked for at least
15 minutes with the ignition off. if the
vehicle is driven within 15 minutes, a
TPMS error message will be displayed.
CAUTION
When inflating tires with TPMS valves, press
the pump's mouthpiece straight onto the
valve to help avoid bending or otherwise
damaging the valve.

06 Maintenance and specifications
Vehicle care
06

277
CAUTION
•Avoid waxing or polishing plastic or rub-
ber components
•Polishing chromed strips can wear
away or damage the surface
•Polishes containing abrasive sub-
stances should not be used
Automatic car wash
•We do NOT recommend washing your car
in an automatic wash during the first six
months (because the paint will not have
hardened sufficiently).
•An automatic wash is a simple and quick
way to clean your car, but it is worth
remembering that it may not be as thor-
ough as when you yourself go over the car
with sponge and water. Keeping the under-
body clean is most important, especially in
the winter. Some automatic washers do
not have facilities for washing the under-
body.
CAUTION
•Before driving into an automatic car
wash, turn off the optional rain sensor to
avoid damaging the windshield wipers.
•Make sure that side view mirrors, auxil-
iary lamps, etc, are secure, and that any
antenna(s) are retracted or removed.
Otherwise there is risk of the machine
dislodging them.
•Chromed wheels: Clean chrome-
plated wheels using the same deter-
gents used for the body of the vehicle.
Aggressive wheel-cleaning agents can
permanently stain chrome-plated
wheels.
WARNING
•When the vehicle is driven immediately
after being washed, apply the brakes,
including the parking brake, several
times in order to remove any moisture
from the brake linings.
•Engine cleaning agents should not be
used when the engine is warm. This
constitutes a fire risk.
Exterior lightingCondensation may form temporarily on the
inside of the lenses of exterior lights such as
headlights, fog lights, or taillights. This is nor-mal and the lights are designed to withstand
moisture. Normally, condensation will dissi-
pate after the lights have been on for a short
time.
Polishing and waxing
•Normally, polishing is not required during
the first year after delivery, however, wax-
ing may be beneficial.
•Before applying polish or wax the vehicle
must be washed and dried. Tar spots can
be removed with kerosene or tar remover.
Difficult spots may require a fine rubbing
compound.
•After polishing use liquid or paste wax.
•Several commercially available products
contain both polish and wax.
•Waxing alone does not substitute for pol-
ishing a dull surface.
•A wide range of polymer-based waxes can
be purchased today. These waxes are easy
to use and produce a long-lasting, high-
gloss finish that protects the bodywork
against oxidation, road dirt and fading.
•Do not polish or wax your vehicle in direct
sunlight (the surface of the vehicle should
not be warmer than 113 °F (45 °C).

07 Index
07
294
E
ECC.................................................129, 130
Economical driving.................................. 204
Electric parking brake.............................. 117
Electronic Climate Control.......128, 129, 130
air distribution table............................ 131
Interior Air Quality System.................. 130
Emergency brake lights............................. 90
Emergency locking retractor...................... 36
Emergency starting.................................. 108
Emergency towing...........................221, 222
Emission inspection readiness................ 227
Engine
overheating........................................... 76
specifications...................................... 285
starting................................................ 106
switching off....................................... 108
Engine compartment overview................229
Engine oil
checking............................................. 230
low pressure warning light.............. 75, 76
specifications...................................... 287
volumes.............................................. 288
Environment............................................... 11Eyelets for anchoring loads..................... 213
F
Federal Clean Air Act............................... 226
Fluid specifications.................................. 288
Fog lights
front...................................................... 75
front/rear............................................... 90
rear...................................................... 238
Four C (active chassis system)................158
Front airbags.............................................. 20
disconnecting passenger’s side air-
bag.................................................. 24, 25
Front fog lights..................................... 75, 90
Front park assist.............................. 188, 190
Front seats...........................................81, 83
Fuel filler cap........................................... 210
Fuel filler door, opening........................... 210
Fuel level warning light.............................. 75
Fuel requirements............................ 208, 209
Fuel tank volume.....................................288
Fuses............................... 247, 248, 251, 253
G
Gasoline requirements............................. 209
Gas tank volume...................................... 288
Gauges...................................................... 73
Geartronic................................................ 111
Geartronic automatic transmission.......... 111
Generator warning light............................. 76
Glossary of tire terminology..................... 262
Grocery bag holder.................................. 214
Gross vehicle weight...............................262
H
Hazard warning flashers............................ 91
HD digital radio........................................ 138
Headlights
Active Bending Lights........................... 89
changing bulbs...........................235, 236
high/low beams.................................... 88
high beam flash.................................... 88
Headlight washers..................................... 95
Head restraints, rear seat.......................... 85
Heartbeat sensor (alarm system).........57, 58

07 Index
07
295
Heated oxygen sensors........................... 211
Heated rear seats.................................... 129
High beams................................................ 88
indicator light........................................ 75
Hill Descent Control................................. 115
Hoisting the vehicle.................................227
Home safe lighting..................................... 92
Hood, opening/closing............................229
Horn........................................................... 87
I
Ignition modes........................................... 79
Immobilizer..........................................54, 55
Important information.................................. 8
Indicator lights.........................73, 74, 75, 76
Infant seats................................................ 39
Inflatable Curtain........................................ 30
Inflation pressure.............................257, 258
Inflation pressure tables.......................... 260
Information lights.....................73, 74, 75, 76
Information symbol.................................... 75
Inspection readiness................................ 227Instrument lighting..................................... 88
Instrument overview............................72, 73
Instrument panel...................................... 124
Integrated two-stage booster cushion...... 47
Interior Air Quality System....................... 127
Interior lighting........................................... 92
iPodŸ connector (audio system)............. 136
ISOFIX anchors.......................................... 44
J
Jack
attaching.............................................266
location of........................................... 266
Jump starting........................................... 108
K
Key blade.............................................54, 59
Keyless drive
general description............................... 61
starting the vehicle.............................106
L
Labels
list of................................................... 282
location of........................................... 281
Laminated panoramic roof...................... 101
LATCH anchors......................................... 44
Leather care............................................. 278
Lighting panel............................................ 88
Load anchoring eyelets...........................213
Loading the vehicle.......................... 212, 262
roof loads............................................ 214
Locking the vehicle.................................... 56
Locks, child safety..................................... 50
Low beams................................................ 88
Low fuel level warning light........................ 75
Low oil pressure warning light................... 76
M
Main instrument panel............................. 124
Maintenance............................................ 226
hoisting the vehicle............................. 227
performed by the owner.....................227

07 Index
07
296
Malfunction indicator light......................... 74
Menu system........................................... 122
overview.............................................. 122
Messages in the instrument panel........... 124
Mirrors
defroster............................................. 100
power door........................................... 99
rearview, auto-dim function................ 100
retractable............................................. 99
vanity.................................................. 200
Motor oil
checking............................................. 230
specifications...................................... 287
volumes.............................................. 288
N
Net in cargo area..................................... 216
O
Occupant safety........................................ 14
Occupant weight sensor...................... 24, 25
Octane recommendations.......................209Odometer, trip........................................... 78
Oil
specifications...................................... 287
volumes.............................................. 288
On Call Roadside Assistance.................. 290
Overhead courtesy lighting........................ 92
Overheating, engine................................... 76
Oxygen sensors, heated.......................... 211
P
Paint, touching up.................................... 279
Park assist.......................................188, 190
Park Assist Camera................................. 191
Parking brake
electric, applying/releasing................. 117
warning light......................................... 76
Parking lights............................................. 89
Personal Car Communicator, unique func-
tions........................................................... 57
Polishing.................................................. 277
Power front seat
memory function................................... 82
with keyless drive................................. 83Power mirrors............................................ 99
defroster............................................. 100
Power steering
fluid..................................................... 233
speed-dependent............................... 158
Power steering fluid................................. 288
Power tailgate.......................................... 212
Power windows......................................... 97
laminated glass..................................... 98
Pregnancy, using seat belts during........... 18
PROPOSITION 65 WARN-
ING..................................... 11, 108, 246, 289
R
Radio
Sirius satellite radio............................141
Radio functions........................................ 135
HD digital radio................................... 138
Rain sensor................................................ 94
READ button............................................ 124
Rear fog light..................................... 90, 238
Rear park assist............................... 188, 190
Rear seat head restraints........................... 85
