Contents
6* Option/accessory, for more information, see Introduction.
06
06 Starting and driving
General information................................138
Fuel requirements................................... 142
Ignition switch......................................... 145
Starting the vehicle................................. 146
Starting the vehicle with keyless drive*... 148
Manual transmission, 5-speed*.............. 149
Manual transmission, 6-speed*.............. 150
Automatic transmission*......................... 151
Shiftlock override.................................... 153
All Wheel Drive*....................................... 154
Brake system.......................................... 155
Stability system....................................... 157
Towing.................................................... 159
Jump starting.......................................... 161
Towing a trailer....................................... 162
Detachable trailer hitch........................... 164
Transporting loads.................................. 165
Blind Spot Information System (BLIS)*. . . 166
Park assist*............................................. 170
07
07 Wheels and tires
General information................................176
Tire inflation............................................. 179
Inflation pressure—U.S. models ............ 181
Inflation pressure—Canadian models .... 182
Tire designations..................................... 183
Glossary of tire terminology.................... 185
Vehicle loading........................................ 186
Uniform tire quality gradings................... 188
Snow chains, snow tires, studded tires. . 189
Temporary spare..................................... 190
Wheel nuts.............................................. 191
Changing a wheel................................... 192
Tire Sealing System ............................... 194
Tire Pressure Monitoring System (TPMS) 199
08
08 Car care
Washing and cleaning the car................. 204
Paint touch up......................................... 208

06 Starting and driving
All Wheel Drive*
06
154* Option/accessory, for more information, see Introduction.
All Wheel Drive (AWD) – general
information
Your Volvo can be equipped with permanent
All Wheel Drive, which means that power is
distributed automatically between the front
and rear wheels. Under normal driving condi-
tions, most of the engine's power is directed to
the front wheels. However, if there is any ten-
dency for the front wheels to spin, an electron-
ically controlled coupling distributes power to
the wheels that have the best traction.
Tire dimensions
Volvo recommends that you always drive on
tires of the same brand, size, construction
(radial), tread pattern, load, speed, traction,
temperature, and treadwear rating. Never drive
on mixed tires, except for brief periods when
the temporary spare tire is in use.
Always use properly inflated tires of correct
dimensions. Tire size and inflation pressures
are shown on a placard located on the driver's
side B-pillar (the structural member at the side
of the vehicle, at the rear of the driver's door
opening). See also page 181 for the tire infla-
tion pressure tables beginning, .
Temporary Spare
The temporary spare tire is for temporary, low-
speed, short-distance use only. Replace it with
a full-sized tire as soon as possible. Do not
drive on the temporary spare at speeds above
50 mph (80 km/h).
Never install snow chains on a temporary
spare.

06 Starting and driving
Stability system
06

157 Stability Traction Control (STC)/
Dynamic Stability Traction Control
(DSTC)
The stability system consists of a number of
functions designed help reduce wheel spin,
counteract skidding, and to generally help
improve directional stability.
A pulsating sound will be audible when the
system is actively operating and is normal.
Function/
systemSTCDSTCA
TCXX
SCXX
AYCX
A*
Traction control (TC)This function is designed to help reduce wheel
spin by transferring power from a drive wheel
that begins to lose traction to the wheel on the
opposite side of the vehicle (on the same axle).
TC is most active at low speeds.
This is one of the stability system's permanent
functions and cannot be switched off.
G020349
Thumb wheel
RESET button
Spin control (SC)The spin control function is designed to help
prevent the drive wheels from spinning while
the vehicle is accelerating.
Under certain circumstances, such as when
driving with snow chains, or driving in deep
snow or loose sand, it may be advisable to
temporarily switch off this function for maxi-
mum tractive force
1.
Temporarily switching off Spin control1. Turn the thumbwheel (A) on the left-side
steering wheel lever until the STC/DSTCmenu is displayed.
2.
Hold down the RESET button (B) to toggle
between
STC/DSTC SPIN CONTROL
ON or OFF.
NOTE
•The message STC/DSTC SPIN
CONTROL OFF indicates that the sta-
bility system's spin control function has
temporarily been switched off.
•The stability control indicator light
will illuminate and remain on until spin
control has been reactivated.
•The spin control function is automati-
cally enabled each time the engine is
started.
•STC/DSTC ON indicates that all sys-
tem functions are active.
Active yaw control – AYC (DSTC only)This function helps maintain directional stabil-
ity, for example when cornering, by braking
one or more of the wheels if the vehicle shows
a tendency to skid or slide laterally.
1Models equipped with All Wheel Drive (AWD) have an integrated traction control function that cannot be disabled. DSTC is optional on AWD models.

G020918
174
General information............................................................................... 176
Tire inflation........................................................................................... 179
Inflation pressure—U.S. models .......................................................... 181
Inflation pressure—Canadian models .................................................. 182
Tire designations................................................................................... 183
Glossary of tire terminology..................................................................185
Vehicle loading...................................................................................... 186
Uniform tire quality gradings................................................................. 188
Snow chains, snow tires, studded tires................................................ 189
Temporary spare................................................................................... 190
Wheel nuts............................................................................................ 191
Changing a wheel................................................................................. 192
Tire Sealing System ............................................................................. 194
Tire Pressure Monitoring System (TPMS).............................................199

07 Wheels and tires
Snow chains, snow tires, studded tires
07
189 Snow chains
Snow chains can be used on your Volvo with
the following restrictions:
•Snow chains should be installed on front
wheels only. Use only Volvo approved
snow chains.
•If accessory, aftermarket or "custom" tires
and wheels are installed and are of a size
different than the original tires and wheels,
chains in some cases CANNOT be used.
Sufficient clearances between chains and
brakes, suspension and body components
must be maintained.
•Some strap-on type chains will interfere
with brake components and therefore
CANNOT be used.
•All Wheel Drive models: Snow chains
should only be installed on the front
wheels.
Consult your Volvo retailer for additional snow
chain information.
CAUTION
•Check local regulations regarding the
use of snow chains before installing.
•Always follow the chain manufacturer's
installation instructions carefully. Install
chains as tightly as possible and
retighten periodically.
•Never exceed the chain manufacturer's
specified maximum speed limit. (Under
no circumstances should you exceed
31 mph (50 km/h).
•Avoid bumps, holes or sharp turns
when driving with snow chains.
•The handling of the vehicle can be
adversely affected when driving with
chains. Avoid fast or sharp turns as well
as locked wheel braking.
Snow tires, studded tires
Tires for winter use:
•Owners who live in or regularly commute
through areas with sustained periods of
snow or icy driving conditions are strongly
advised to fit suitable winter tires to help
retain the highest degree of traction.
•It is important to install winter tires on all
four wheels to help retain traction during
cornering, braking, and accelerating. Fail-ure to do so could reduce traction to an
unsafe level or adversely affect handling.
•Do not mix tires of different design as this
could also negatively affect overall tire road
grip.
•Winter tires wear more quickly on dry roads
in warm weather. They should be removed
when the winter driving season has ended.
•Studded tires should be run-in
300–600 miles (500–1000 km) during
which the car should be driven as smoothly
as possible to give the studs the opportu-
nity to seat properly in the tires. The tires
should have the same rotational direction
throughout their entire lifetime.
NOTE
Please consult state or provincial regula-
tions restricting the use of studded winter
tires before installing such tires.

12 Index
12
287
Refueling.................................................. 144
fuel tank volume.................................273
Registering child restraints........................ 46
Remote key.............................................. 122
battery replacement............................ 123
functions............................................. 122
key blade............................................ 124
Replacing fuses....................................... 232
Reporting safety defects
Canada................................................. 17
USA....................................................... 16
Roof loads............................................... 165
S
Safety, occupant........................................ 16
Safety defects, reporting
Canada................................................. 17
USA....................................................... 16
Safety locks, child.................................... 132
Seat belt
reminder................................................ 19
Seat belts................................................... 18
Automatic locking retractor/Emergency
locking retractor.................................... 35buckling................................................ 18
maintenance......................................... 20
pretensioners........................................ 18
unbuckling............................................ 18
use during pregnancy........................... 19
Seats, front.............................................. 104
Shiftlock
override............................................... 153
Side door mirrors....................................... 80
Side impact airbags................................... 29
Side impact protection (SIPS) airbags....... 29
Sirius satellite radio.................................. 251
Snow chains............................................ 189
Snow tires................................................ 189
Sound control, automatic........................246
Sound settings, audio system................. 244
Spare tire................................................. 190
Stability system....................................... 157
Dynamic Stability Traction Control
(DSTC)................................................ 157
Starting the engine..................................146
with keyless drive...............................148
Start inhibitor (immobilizer)..............122, 146
STC, stability system............................... 157Steering wheel
adjusting............................................... 75
keypad................................................ 243
Storage compartments............................ 111
Studded tires........................................... 189
Subwoofer............................................... 245
Sunroof (moonroof).................................... 82
Supplemental restraint system.................. 21
T
Tachometer................................................ 53
Tailgate wipers................................... 73, 222
Temporary spare tire...............................190
Three-way catalytic converter................. 280
Tire inflation............................................. 179
Tire inflation pressure
Canadian models................................ 182
US models.......................................... 181
Tire Pressure Monitoring System (TPMS) 199
Tires.........................................................176
age...................................................... 176
changing............................................. 192
changing from summer to winter........ 177
