2010 TOYOTA xD display

BASIC FUNCTION
33
V573_E

Depending on the conditions, certain
screen configuration buttons cannot be
selected.
: To display the single map screen. (See page 33.)
: To display the dual map screen.
(See page 34.)
: To display the compass mode screen. (See page 34.)
: To display the turn list screen. (See page 68.)
: To display the arrow screen. (See page 68.)
: To display the freeway informa-
tion screen. (See page 66.)
: To display the intersection guid- ance screen or the guidance
screen on the freeway. (See page
67.) z
Screen configurations
SINGLE MAP
This is a regular map screen.
While on a different screen, touching
will display the single map screen.

The screen shows the single map.

BASIC FUNCTION

34
V573_E
DUAL MAP
A map can be displayed split in two.
While on a different screen, touching
will display the dual map screen.

The screen shows the dual map. The
map on the left is the main map.
The right side map can be edited by
touching any specific point on the right
side map.

This screen can perform the following
procedures.
1. Changing the map scale
2. Displaying the POI icons
3. Show XM
® NavTraffic info. (See page
90.)
4. Changing the orientation of the map
Touch “OK” when you complete edit-
ing.
The screen returns to the dual map
screen. COMPASS MODE
Current vehicle position is indicated with
a compass, not with a map.
While on a different screen, touching
will display the compass mode
screen.

Information about the destination and
current position, as well as a compass, is
displayed on the screen.
The destination mark is displayed in the
direction of the destination. When driv-
ing refer to the longitude and latitude
coordinates, and the compass, to make
sure that your vehicle is headed in the
direction of the destination.

INFORMATION
When the vehicle travels out of the
coverage area, the guidance screen
changes to the compass mode
screen.

BASIC FUNCTION
35
V573_E


Touch or to change the
scale of the map display. The scale bar
and indicator at the bottom of the screen
indicates the map scale menu. The
scale range is 150 feet (50 m) to 250
miles (400 km).
Touch
or until the scale bar
changes normally. By continuing to
touch the touch screen button, the scale
bar changes smoothly.
The scale of the map display can be
changed by touching the scale bar di-
rectly. It is not available while driving.
The map scale is displayed under the
North-up symbol or Heading-up symbol
at the top left of the screen.

INFORMATION
When the map scale is at the maximum
range of 250 miles (400 km),
is
not shown.
When the map scale is at the minimum
range of 150 feet (50 m),
is not
shown.

► North-up screen

► Heading-up screen

► 2.5D map
Touching the orientation symbol at the
top left of the screen changes the orien-
tation from North-up to Heading-up ori-
entation, and the configuration from 2D
to 2.5D.


— Ma
p scale
— Changing map
orientation and configuration

BASIC FUNCTION
37
V573_E


3. Enter the name of the destination.
Every touch on a letter key narrows the
selection.
Letters that cannot be selected in the
database are dimmed out.
When there are four or fewer database
items, these items are displayed in a list.
Even if the entered name is incomplete,
touching “List” displays the list.

4. Select the destination from the
displayed list.

5. Touch “Enter”.
The system starts route search and dis-
plays recommended routes.

6. Touch “Guide”.
Route guidance starts.
Guidance is done by both the screen and
voice. (See “Route guidance screen”
and “Typical voice guidance prompts” on
pages 66 and 69.)

INFORMATION
It is possible to change the route.
(See “Starting route guidance” on
page 61.)

BASIC FUNCTION

38
V573_E
The home touch screen button on the
“Destination” screen can be used if your
home has been registered. (See “ —
Destination search by Home” on page
44.)
1. Push the “NAVI” button.

2. Touch “My Places”.

3. Touch “Register”.

4. Touch “Address”.

5. Enter the street name.
Every touch on a letter key narrows the
selection.
Letters that cannot be selected in the
database are dimmed out.
When there are four or fewer database
items, these items are displayed in a list.
Even if the entered name is incomplete,
touching “List” displays the list.

6. Select the street name from the
displayed list.



— Re
gistering home

BASIC FUNCTION
39
V573_E


7. Enter the house number.
If the same street exists in more than
one city, the current screen changes to
the city list screen. Select the city
name.

8. Touch “Enter”.
Registration of home is complete and the
“Memory Point” screen is displayed.

Registered “Home” information will
be displayed.
The icon, quick access, name, location,
and phone number can be changed.
(See “ — Editing memory points” on
page 98.)

DESTINATION SEARCH
42
V573_E
Push the “DEST” button.

You can use one of 13 different methods
to search your destination. (See pages
44 through 60.)

INFORMATION
When searching the destination, the
response to the touch screen button
may be slow.

SELECTING THE SEARCH AREA ON
THE DESTINATION SCREEN
1. Push the “DEST” button.

2. Touch “Change” on the “Destina-
tion” screen to display a map of the
United States and Canada divided into
14 areas. (For map database informa-
tion and updates, see “Map database
information and updates” on page 272.)

3. Touch one of “US1” through “PR”
to select a search area.
4. Touch “OK” and the “Destination”
screen returns.


Destination search—

—Selectingthe search area

DESTINATION SEARCH

43
V573_E

SELECTING THE SEARCH AREA ON
THE INPUT SCREEN
Change the search area in order to set a
destination from a different area by using
“Address”, “POI Name”, “Intersection” or
“Freeway Ent./Exit”.

1. Touch the search area button like
“US9” on the input screen to display a
map of the United States and Canada
divided into 14 areas. (For map data-
base information and updates, see “Map
database information and updates” on
page 272.)

2. Touch one of “US1” through “PR”
to select a search area.
3. Touch “OK” and the previous
screen returns.
U.S.A.
Button States included in the
search area
“US1” Idaho
Oregon
Washington
“US2”
California
Nevada
“US3” Arizona
Colorado
Montana
New Mexico
Utah
Wyoming
“US4” Iowa
Kansas
Minnesota
Missouri
North Dakota
Nebraska
South Dakota
“US5”
Oklahoma
Texas
“US6” Illinois
Indiana
Kentucky
Michigan
Ohio
Wisconsin
“US7”
Arkansas
Alabama
Louisiana
Mississippi
Tennessee
“US8” Connecticut
Massachusetts
Maine
New Hampshire
New Jersey
New York
Rhode Island
Vermont
