2010 TOYOTA TUNDRA washer fluid

598 5-2. Steps to take in an emergency
Tire pressure warning
light
• When the light comes on: Low tire inflation pres-
sure. Adjust the tire
inflation pressure.
• When the light comes on after blinking for 1
minute: Malfunction in
the tire pressure warning
system. Have the system
checked by your
Toyota dealer.
Low fuel level warning
light
Low level of fuel. Refuel the vehicle.
*4Low washer fluid warn-
ing light
Low level of washer fluid. Fill the tank.
*4
(U.S.A.)Engine oil replacement
reminder light
• Illuminates for about 3
seconds and then flashes
for about 12 seconds: Indi-
cates that the engine oil is
scheduled to be changed. Check the engine oil,
and change if neces-
sary.
• Comes on and remains: Indicates that the engine
oil should be changed. Check and change the
engine oil.
*5
Master warning light
A buzzer sounds and the
warning light comes on
and flashes to indicate
that the master warning
system has detected a
malfunction. P. 604
Warning lightWarning light/DetailsCorrection procedure

5
When trouble arises
605
5-2. Steps to take in an emergency
Follow the correction procedures.
After taking the specified steps to correct the suspected problem,
check that the warning light turns off.
Warning messageDetailsCorrection procedure
Indicates that one or
more of the doors is not
fully closed. The system also indi-
cates which doors are
not fully closed.
flashes and a
buzzer sounds to indi-
cate that one or more of
the doors is not fully
closed (with the vehicle
having reached a speed
of 3 mph [5 km/h]).
Open door warning light
also comes on. Make sure that all of
the doors are closed.
(Flashing) Indicates that the park-
ing brake is still
engaged with the vehicle
having reached a speed
of more than 3 mph (5
km/h).
A buzzer also sounds
intermittently. Release the parking
brake.
Indicates that the
washer fluid level is low. A buzzer also sounds. Add washer fluid.

711
Alphabetical index
Preparing and checking
before winter ...................... 260
Engine coolan t temperature
gauge ..................................... 194
Engine immobilizer system .... 114
Engine oil
Capacity ............................... 656
Checking .............................. 530
Preparing and checking before winter ...................... 260
Warning light ........................ 596
Engine oil maintenance data ........................................ 532
Engine switch .......................... 183
Event data recorder ................ 593
FFV ................................... 109, 669
Flex-fuel ........................... 109, 669
Flexible fuel vehicle ........ 109, 669
Floor mat .................................. 497
Fluid Brake .................................... 535
Washer ................................. 540
Fog lights Replacing light bulbs ............ 576
Switch ................................... 217
Wattage ................................ 668
Four-wheel drive system ........ 236
Front fog lights
Replacing light bulbs ............ 576
Switch ................................... 217
Wattage ................................ 668
Front passenger occupant classification system............ 136
Front passenger’s seat belt reminder light ........................ 597
Front passenger’s seat belt
warning buzzer.............. 597, 599
Front seats Adjustment ............................. 60
Front side marker lights Replacing light bulbs ............ 575
Switch ................................... 213 Wattage .................................668
Front turn signal lights
Replacing light bulbs .............574
Switch....................................191
Wattage .................................668
Fuel Capacity ................................656
Fuel gauge ............................194
Fuel pump shut off system ....592
Gas station information .........724
Information ............................669
Refueling ...............................109
Type ......................................656
Warning light .........................598
Warning message .................606
Fuel door...................................109
Fuel filler door ..........................109
Fuel pump shut off system .....592
Fuses.........................................560
Garage door opener.................501
Gas station information...........724
Gauges ......................................194
Glove box..................................449
Hands-free system (for cellular phone) ................413
Hazard lights switch ................584
Head restraints Adjusting ................................73
Headlights Replacing light bulbs .....572, 573
Switch....................................213
Wattage .................................668
High mounted stoplight Replacing ..............................578
Wattage .................................668
Heaters Seat heaters ..........................491
Seat heaters and
ventilators ...........................493
Side mirror.....................305, 307
F
G
H

716 Alphabetical index
Checking ............................... 542
Identification number ............. 674
If you have a flat tire .............. 608
Inflation pressure........... 549, 666
Information ............................ 673
Inflation pressure sensor ....... 543
Replacing .............................. 608
Rotating tires ......................... 542
Size ....................................... 666
Snow tires ............................. 260
Tire pressure warning reset switch ......................... 543
Tire pressure warning system ........................ 542, 598
Warning light ......................... 598
Tissue pocket ........................... 461
Tools ......................................... 608
Total load capacity................... 258
TOW/HAUL switch ................... 189
Towing Bumper towing ...................... 275
Dinghy towing........................ 285
Emergency towing................. 585
Fifth wheel trailer ................... 273
Trailer towing......................... 264
Traction control........................ 243
TRAC ......................................... 243
Trip information ....................... 204
Trip meter ................................. 198
Turn signal lights
Replacing light bulbs ..... 574, 577
Switch.................................... 191
Wattage ................................. 668
Valet key .....................................42
Vanity lights Vanity lights ........................... 475
Wattage ................................. 668
Vanity mirrors........................... 475
Vehicle identification number ................................... 653
Vehicle stability control........... 243
VSC............................................ 243 Warning buzzers
Brake system ........................ 595
Key reminder................... 50, 599
Open door ..................... 597, 599
Seat belt reminder......... 597, 599
Warning lights ABS ....................................... 596
Airbag system ....................... 596
Anti-lock brake system .......... 596
Automatic transmission fluid temperature................. 597
Brake assist system .............. 596
Brake system ........................ 595
Charging system .... ............... 595
Electronic engine control system ................................ 596
Engine oil pressure ............... 596
Four-wheel drive system
warning buzzer ................... 599
Driver’s seat belt ................... 597
Front passenger occupant
classification system ........... 596
Front passenger’s
seat belt .............................. 597
Low brake fluid ...................... 595
Low engine oil pressure ........ 596
Low fuel level ................ 598, 606
Low tire inflation pressure.............................. 598
Malfunction indicator lamp .... 596
Master warning light .............. 598
Open door ............................. 597
Power steering warning light ..................................... 597
Pretensioners ........................ 596
Seat belt reminder light ......... 597
SRS airbags .......................... 596
Tire pressure warning light.... 598
VSC/TRAC ............................ 597
Warning messages .................. 604
Washer Checking ............................... 540
V
W

721
What to do if...
■
Warning lights
P. 597
or(if equipped)
P. 595 P. 596
P. 595 P. 598
P. 596 P. 597
P. 598
or
P. 5 9 6P. 597
P. 5 9 8P. 598
P. 5 9 6P. 597
P. 5 9 7P. 597
*: Slip indicator comes on.P. 5 9 8
Brake system warning
lightPower steering warning
light
Low engine oil pressure
warning light
Charging system warning
lightMaster warning light
Malfunction indicator
lampSlip indicator*
ABS warning lightTire pressure warning
light
Open door warning light
Engine oil replacement
reminder lightLow fuel level warning
light
SRS warning lightDriver’s seat belt reminder
light
Front passenger’s seat belt
reminder light
Low washer fluid
warning light
Automatic transmission
fluid temperature
warning light
The warning message is displayedP. 604If a warning message is displayed
