Page 125 of 328
TELEPHONE AND INFORMATION
125
2010 TUNDRA Navigation from April.09 Prod.(OM34481U)
4Indicates the level of reception.
Poor Excellent
The level of reception does not always cor-
respond with the one of your cellular
phone.
The level of reception may not be dis-
played depending on the phone you have.
When you are out of the service area or in
a place inaccessible by radio waves, “No
Service” is displayed.
An antenna for the Bluetooth connec-
tion is built in the display. The indica-
tion of the Bluetooth connection may
turn yellow and the system may not
function when you use the Bluetooth
phone in the following conditions and
places.
Your cellular phone is hiding behind the display (behind the seat or in the
glove box and console box).
Your cellular phone touches or is
covered with metal materials.
Leave the Bluetooth phone on the place
where “Blue” indication is displayed. About the phonebook in this system
The following data is stored for every regis-
tered phone. When
another phone is con-
necting, you cannot read the registered
data.
Phonebook data
Voice tag
All of call history
Speed dial
When you delete the phone, the
above −mentioned data is also deleted.
When you release your car:
A lot of personal data is registered
when you use the Hands free system.
When you release your car, initialize
your data. (See “ Delete personal
data” on page 240.)
If you initialize it, the former state will never
come back again. Pay much attention
when initializing the data.
You can initialize the following data in the
system.
Phonebook data
Call history data
Speed dial data
Voice tag data
Bluetooth phone data
Volume setting
Details setting
Page 126 of 328
TELEPHONE AND INFORMATION
126
2010 TUNDRA Navigation from April.09 Prod.(OM34481U)
FCC ID : HYQDNNS025
Type : DNNS025
IC : 1551A DNNS025 Canada 310
This device complies with Part 15 of the
FCC Rules and RSS −210. Operation is
subject to the following two conditions :
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, in-
cluding interference that may cause un-
desired operation.
CAUTION
Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.
CAUTION: Radio Frequency Radi-
ation Exposure
This equipment complies with FCC
radiation exposure limits set forth for
uncontrolled equipment and meets the
FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65.
This equipment has very low levels of
RF energy that it deemed to comply
without maximum permissive expo-
sure evaluation (MPE). But it is desir-
able that it should be installed and op-
erated with at least 20 cm and more be-
tween the radiator and person’s body
(excluding extremities: hands, wrists,
feet and legs).
Co location: This transmitter must
not be co −located or operated in con-
junction with any other antenna or
transmitter. To use the hands free system, you
need to enter your phone into the sys-
tem. Once you have registered it, you
can make a hands free call.
If you haven’t yet registered any
Bluetooth
phones, you must first register
your phone according to the following
procedure.
Please see “ Registering a Bluetooth
phone” on page 257 of additional registra-
tion when registering.
U009AHNS
1. Push the “INFO/PHONE” button.
2. Touch “Phone”.
— Enter a Bluetooth phone
Page 128 of 328
TELEPHONE AND INFORMATION
128
2010 TUNDRA Navigation from April.09 Prod.(OM34481U)
Connecting a Bluetooth phone
AUTOMATICALLY
When you register your phone, auto
connection will be turned on. Always
set it to this mode and leave the
Bluetooth phone in a condition where
connection can be established.
When the engine switch is in the “ACC”
or “ON” position, a nearby cellular
phone you have registered is searched
for.
Next, the system automatically con-
nects with the latest of the phones con-
nected to in the past.
Then, the connection result is dis-
played.
This screen appears when the Bluetooth
phone is first connected after the engine
switch is in the “ACC” or “ON” position.
Page 129 of 328
TELEPHONE AND INFORMATION
129
2010 TUNDRA Navigation from April.09 Prod.(OM34481U)
INFORMATION
It may take time, the phone connec-
tion is carried out during Bluetooth
audio play.
MANUALLY
When the auto connection has failed or
“Handsfree power” is turned off, you
have to connect Bluetooth manually.
1. Push the “INFO/PHONE” button.
2. Touch “Phone”.
3. Touch “Connect Phone”.
4. Touch “Handsfree Power”, or select
the phone to connect.
Page 130 of 328
TELEPHONE AND INFORMATION
130
2010 TUNDRA Navigation from April.09 Prod.(OM34481U)
5. The “Connect Bluetooth∗” screen is
displayed.
6. When the connection is completed,
this screen is displayed.
Now you can use the Bluetooth phone.
∗: Bluetooth is a registered trademark of
Bluetooth SIG, Inc. When you connect the phone while
Bluetooth
audio is playing
This screen is displayed, and the
Bluetooth audio will stop temporarily.
Page 131 of 328
TELEPHONE AND INFORMATION
131
2010 TUNDRA Navigation from April.09 Prod.(OM34481U)
Reconnecting the Bluetooth
phone
If the Bluetooth phone is discon-
nected with a poor reception from the
Bluetooth network when the engine
switch is in the “ACC” or “ON” position
the system automatically reconnects
the Bluetooth phone. In this case, the
connection result is not displayed.
If the Bluetooth is disconnected on pur-
pose such as you turned your cellular
phone off, this does not happen. Recon-
nect it by the following methods.
Select the Bluetooth phone again.
Enter the Bluetooth phone. After you enter the Bluetooth
phone,
you can call by using hands free sys-
tem. You can call using the 6 methods
described below.
By dial
You can call by inputting the phone
number.
This cannot be operated while driving.
1. Push the “INFO/PHONE” button.
You can also push
of the steering
wheel to display the “Phone” screen.
2. Touch “Phone”.
— Call on the Bluetooth
phone
Page 138 of 328
TELEPHONE AND INFORMATION
138
2010 TUNDRA Navigation from April.09 Prod.(OM34481U)
By POI∗ call
You can call by touching when it is
displayed on the screen from naviga-
tion system. (See “POI INFORMA TION”
on page 36 for details.)
∗: Point of Interest
When a call is received, this screen is
displayed with a sound. Touch
or
push
of the steering wheel to talk on
the phone.
To refuse to receive the call:
Touch
or push of the steering
wheel.
To adjust the volume of received call: Touch “
–” or “+” or use the volume
switch of the steering wheel.
On the international phone call, the other
party’s name may not be displayed cor-
rectly depending on the cellular phone
which you have.
— Receive on the
Bluetooth phone
Page 139 of 328
TELEPHONE AND INFORMATION
139
2010 TUNDRA Navigation from April.09 Prod.(OM34481U)
While you are talking on the phone, this
screen is displayed. You can do the op-
eration below on the screen.
To adjust the volume of the other party’s
voice: Touch “
–” or “+” or use the volume
switch of the steering wheel.
To hang up the phone:
Touch
or push of the steering
wheel.
To mute your voice: Touch “Mute”.
To input a Key: Touch “0 9”.
To transfer the call: Touch “Call Transfer” .
You cannot change from Hands −free call
to cellular phone call while driving.
When you change from cellular phone call
to Hands− free call, the Hands −free screen
will be displayed and you can operate it on
the screen.
Transferring method and behavior are dif-
ferent depending on the cellular phone
which you have.
For the operation of the phone, see the
manual that comes with your cellular
phone. When you touch “0 9”
Touch the desired number to input the
key.
To hang up the phone:
Touch
or push of the steering
wheel.
This cannot be operated while driving.
— Talk on the Bluetooth
phone
