2010 TOYOTA RAV4 load capacity

376
4-3. Do-it-yourself maintenance
Wheels
If a wheel is bent, cracked or heavily corroded, it should be
replaced.
Otherwise, the tire may separate from the wheel or cause loss of
handling control.
■Wheel selection
When replacing wheels, care should be taken to ensure that
they are equivalent to those removed in load capacity, diameter,
rim width, and inset*.
Replacement wheels are available at your Toyota dealer.
*: Conventionally referred to as “offset”.
Toyota does not recommend using:
●Wheels of different sizes or types
● Used wheels
● Bent wheels that have been straightened
■ Aluminum wheel precautions
●Use only Toyota wheel nuts and wrenches designed for use
with your aluminum wheels.
● When rotating, repairing or changing your tires, check that the
wheel nuts are still tight after driving 1000 miles (1600 km).
● Be careful not to damage the aluminum wheels when using
tire chains.
● Use only Toyota genuine balance weights or equivalent and a
plastic or rubber hammer when balancing your wheels.

482 6-1. Specifications
Warning: The temperature grades for this tire are established for a
tire that is properly inflated and not overloaded.
Excessive speed, underinflation, or excessive loading, either sepa-
rately or in combination, can cause heat buildup and possible tire fail-
ure.
Glossary of tire terminology
Tire related termMeaning
Cold tire inflation pres-
sure Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km under
that condition
Maximum inflation
pressure The maximum cold inflated
pressure to which a
tire may be inflated, s hown on the sidewall of
the tire
Recommended infla-
tion pressure Cold tire inflation pressure recommended by a
manufacturer
Accessory weight The combined weight (in excess of those stan-
dard items which may be replaced) of auto-
matic transmission, power steering, power
brakes, power windows, power seats, radio
and heater, to the extent that these items are
available as factory-installed equipment
(whether installed or not)
Curb weight The weight of a motor vehicle with standard
equipment, including the maximum capacity of
fuel, oil and coolant, and if so equipped, air
conditioning and additional weight optional
engine
Maximum loaded vehi-
cle weight The sum of:
(a) Curb weight
(b) Accessory weight
(c) Vehicle capacity weight
(d) Production options weight

483
6-1. Specifications
6
Vehicle specifications
Tire related termMeaning
Normal occupant
weight 150 lb. (68 kg) times the number of occupants
specified in the second column of Table 1
* that
follows
Occupant distribution Distribution of occupants in a vehicle as speci-
fied in the third column of Table 1
* below
Production options
weight The combined weight of installed regular pro-
duction options weighing over 5 lb. (2.3 kg) in
excess of the standard items which they
replace, not previously considered in curb
weight or accessory weight, including heavy
duty brakes, ride levelers, roof rack, heavy duty
battery, and special trim
Rim A metal support for a tire or a tire and tube
assembly upon which the tire beads are seated
Rim diameter
(Wheel diameter) Nominal diameter of the bead seat
Rim size designation Rim diameter and width
Rim type designation The industry manufacturer's designation for a
rim by style or code
Rim width Nominal distance between rim flanges
Vehicle capacity
weight (Total load
capacity) The rated cargo and luggage load plus 150 lb.
(68 kg) times the vehicl
e's designated seating
capacity
Vehicle maximum load
on the tire The load on an individual tire that is determined
by distributing to each axle its share of the
maximum loaded vehicle weight, and dividing
by two
Vehicle normal load
on the tire The load on an individual tire that is determined
by distributing to each axle its share of curb
weight, accessory weight, and normal occu-
pant weight (distributed in accordance with
Ta b l e 1
* below), and dividing by two

487
6-1. Specifications
6
Vehicle specifications
*:Table 1
 Occupant loading and distri bution for vehicle normal load
for various designated seating capacities
Tire related termMeaning
Tread That portion of a tire that comes into contact
with the road
Tread rib A tread section running circumferentially
around a tire
Tread separation Pulling away of the tread from the tire carcass
Treadwear indicators
(TWI) The projections within the principal grooves
designed to give a visual indication of the
degrees of wear of the tread
Wheel-holding fixture The fixture used to hold the wheel and tire
assembly securely
during testing
Designated seating
capacity, Number of occupantsVehicle normal load,
Number of occupantsOccupant distribution in a normally loaded vehi- cle
2 through 4 2 2 in front
5 through 10 3 2 in front, 1 in second
seat
11 through 15 5 2 in front, 1 in second
seat, 1 in third seat, 1
in fourth seat
16 through 20 7 2 in front, 2 in second
seat, 2 in third seat, 1
in fourth seat

504 Alphabetical index
I/M test....................................... 341
IdentificationEngine ................................... 464
Vehicle .................................. 464
Ignition switch .................. 144, 147
Illuminated entry system ......... 300
Indicator lights ......................... 159
Initialization
Items to initialize.................... 491
Inside rear view mirror ..............77
Interior lights Interior lights.......................... 300
Switch............................ 302, 301
Wattage ................................. 473
Jack Positioning a floor jack .......... 348
Vehicle-equipped jack ........... 430
Jack handle .............................. 430
Keyless entry..............................38
Keys
Electronic key ..........................24
Engine switch ................ 144, 147
If the electronic key does not operate properly............ 451
If you lose your keys/
wireless remote control
transmitter ........................... 450
Ignition switch................ 144, 147 Key number............................. 24
Keyless entry .......................... 38
Keys ........................................ 24
Mechanical key ....................... 24
Wireless remote control
key ........................................ 38
License plate lights Replacing light bulbs ............. 396
Wattage................................. 473
Light bulbs Replacing .............................. 396
Wattage................................. 473
Lights Door courtesy lights .............. 300
Emergency flasher switch ..... 406
Fog light switch ..................... 168
Hazard light switch ................ 406
Headlight switch .................... 165
Interior light switch ........ 301, 302
Luggage compartment light ..................................... 302
Personal light switch ............. 301
Replacing light bulbs ............. 396
Turn signal lever ................... 153
Vanity lights........................... 313
Wattage................................. 473
Load capacity ........................... 204
Lock steering column...... 145, 148
Luggage cover ......................... 325I
J
K
L

507
Alphabetical index
Stop lights
Replacing light bulbs ............ 396
Wattage ................................ 473
Storage feature ........................ 304
Storage precautions ............... 201
Stuck If your vehicle becomes stuck................................... 458
Sun visors ................................ 312
Switch Emergency flasher switch .... 406
Engine switch ............... 144, 147
Fog light switch..................... 168
Hazard light switch ............... 406
Ignition switch ............... 144, 147
Light switches ....................... 165
Power door lock switch........... 43
Power window switches ......... 81
Window lock switch ................ 81
Wiper and washer
switch ......................... 169, 171
Tachometer .............................. 156
Tail lights Replacing light bulbs ............ 396
Switch ................................... 165
Wattage ................................ 473
Talk switch ............................... 271
Telephone switch .................... 271
Theft deterrent system Engine immobilizer system..... 92
Theft prevention labels ............. 95
Tire inflation pressure ............ 372 Tire information
Glossary ................................482
Size .......................................479
Tire identification number ......478
Uniform tire quality
grading ................................480
Tires Chains ...................................206
Checking ...............................365
If you have a flat tire ..............430
Inflation pressure...................372
Information ............................477
Replacing ..............................430
Rotating tires .........................365
Size .......................................472
Snow tires .............................206
Tire pressure warning
system ........................365, 421
Tools .........................................430
Total load capacity...................204
Towing Dinghy towing........................218
Emergency towing.................408
Trailer towing.........................210
Traction control........................180
TRAC .........................................180
Trip information .......................162
Trip meter .................................156
Turn signal lights Replacing light bulbs .............396
Switch....................................153
Wattage .................................473
T

508 Alphabetical index
Utility vehicle precautions ...... 193
Valet key .....................................24
Vanity lightsVanity lights ........................... 313
Wattage ................................. 473
Vanity mirrors........................... 313
Vehicle identification
number ................................... 464
Warning buzzers Brake system ........................ 418
Seat belt reminder ................. 421
Warning lights Active torque control
4WD system ............... 419, 421
Anti-lock brake system .......... 419
Automatic transmission fluid temperature ................. 421
Brake assist system .............. 419
Brake system ........................ 418
Charging system .... ............... 419
Cruise control indicator light ..................................... 419
Electric power steering system ................................ 419
Engine oil pressure ............... 419
Engine oil replacement
reminder light ...................... 421
Low fuel level ........................ 421
Low washer fluid ................... 421
Malfunction indicator lamp .... 419
Open door ............................. 421
Pretensioners ........................ 419
Seat belt reminder light ......... 421
Slip indicator light .................. 419
Smart key system... ............... 423
SRS airbags .......................... 419
Tire pressure warning light .... 421 Washer
Checking ............................... 364
Preparing and checking
before winter ....................... 206
Switch ........................... 169, 171
Washing and waxing ............... 330
Weight Cargo capacity ...................... 198
Load limits ............................. 204
Weight ................................... 462
Wheels ...................................... 376
Window glasses ........................ 81
Window lock switch................... 81
Windows
Power windows ....................... 81
Rear window defogger .......... 233
Washer.......................... 169, 171
Windshield wiper de-icer ........ 235
Windshield wipers ................... 169
Wireless remote control key Replacing the battery ............ 380
Wireless remote control key.... 38
WMA disc.................................. 252U
V
W
