333 4-3. Do-it-yourself maintenance
4
Maintenance and care
24 ECU-B 10 AMain body ECU, gauge and
meters, daytime running light sys-
tem, air conditioning system, wire-
less remote control
25 RAD NO. 1 15 A Audio system
26 DOME 10 A Interior lights, personal light, clock
27 SPARE 10 A Spare fuse
28 SPARE 30 A Spare fuse
29 SPARE 20 A Spare fuse
30 AMP 30 A Audio system
31 MAYDAY 10 A No circuit
32 EFI MAIN 20 AMultiport fuel injection system/
sequential multiport fuel injection
system, EFI NO. 1, EFI NO. 2
33 HORN 10 A Horn
34 IG2 15 AMultiport fuel injection system/
sequential multiport fuel injection
system, starting system, IGN,
METER
35HTR SUB
NO. 130 A PTC heater
36HTR SUB
NO. 330 A PTC heater
37PWR OUTLET/
INVERTER15 A AC inverter
FuseAmpereCircuit
