2010 TOYOTA CAMRY remove seats

56 1-3. Adjustable components (seats, mirrors, steering wheel)
■Adjusting the height of the head restraints
■ Adjusting the rear cent er seat head restraint
Always raise the head restraint one level from the stowed position when
using.
CAUTION
■ Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
●Use the head restraints designed for each respective seat.
● Adjust the head restraints to the correct position at all times.
● After adjusting the head restraints, push down on them and make sure
they are locked in position.
● Do not drive with the head restraints removed.
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.

64 1-3. Adjustable components (seats, mirrors, steering wheel)
CAUTION
■Using a seat belt comfort guide
●Make sure the belt is not twisted and that it lies flat. The elastic cord must
be behind the belt and the guide must be on the front.
● To reduce the chance of injury in case of a sudden stop, sudden swerve or\
accident while driving, remove and store the comfort guide in its pocket
when it is not in use.
● Always make sure the shoulder belt is positioned across the center of the
shoulder. The belt should be kept away from the neck, and should not fall
off the shoulder.
Failure to observe these precautions could reduce the effectiveness of the
seat belt in an accident, causing death or serious injury.
■ Using a seat belt extender
●Do not wear the seat belt extender if you can fasten the seat belt without
the extender.
● Do not use the seat belt extender when installing a child restraint system
because the belt will not securely hold the child restraint system, increas-
ing the risk of death or serious injury in the event of an accident.
● The personalized extender may not be safe on another vehicle, when
used by another person, or at a different seating position other than the
one originally intended.
NOTICE
■When using a seat belt extender
When releasing the seat belt, press on the buckle release button on the
extender, not on the seat belt.
This helps prevent damage to the vehicle interior and the extender itself.

103
1-7. Safety information
1
Before driving
CAUTION
■
Front passenger occupant cl assification system precautions
● Do not recline the front passenger seatback so far that it touches a rear
seat. This may cause the “AIR BAG OFF” indicator light to be illuminated,
which indicates that the passenger’s airbags will not deploy in the event of
a severe accident. If the seatback touches the rear seat, return the seat-
back to a position where it does not touch the rear seat. Keep the front\
passenger seatback as upright as possible when the vehicle is moving.
Reclining the seatback excessively may lessen the effectiveness of the
seat belt system.
● If an adult sits in the front passenger seat, the “AIR BAG ON” indicator
light is illuminated. If the “AIR BAG OFF” indicator is illuminated, ask the
passenger to sit up straight, well back in the seat, feet on the floor, and
with the seat belt worn correctly. If the “AIR BAG OFF” indicator still
remain illuminated, either ask the passenger to move to the rear seat, or if
that is not possible, move the front passenger seat fully rearward.
● When it is unavoidable to install the forward-facing child restraint system
on the front passenger seat, install the child restraint system on the front
passenger seat in the proper order. ( P. 108)
● Do not modify or remove the front seats.
● Do not kick the front passenger seat or subject it to severe impact. Other-
wise, the SRS warning light may come on to indicate a malfunction of the
detection system. In this case, contact your Toyota dealer immediately.
● Child restraint systems installed on the rear seat should not contact the
front seatbacks.
● Do not use a seat accessory, such as a cushion or seat cover, that covers
the seat cushion surface.
● Do not modify or replace the upholstery of the front seat.

524 Alphabetical index
Back-up lightsWattage ................................. 494
Battery Checking ............................... 378
If the vehicle has discharged battery ................................. 471
Preparing and checking before winter .................................. 179
Bluetooth
® audio ..................... 263
Bluetooth® phone .................... 279
Brake
Fluid ...................................... 375
Parking brake ........................ 145
Brake assist .............................. 170
Break-in tips ............................. 122
Care
Exterior .................................. 348
Interior ................................... 350
Seat belts .............................. 351
Cargo capacity ......................... 175
Cargo net .................................. 337
CD changer ............................... 223
CD player .................................. 223
Chains ....................................... 179
Child restraint system Booster seats, definition ........ 104
Booster seats, installation ..... 108
Convertible seats, definition ............................. 104
Convertible seats,
installation ........................... 108
Front passenger occupant classification system .............99
Infant seats, definition ........... 104
Infant seats, installation......... 108
Installing CRS with LATCH anchors ............................... 109
Installing CRS with seat belts ............................ 111
Installing CRS with top straps .................................. 114 Child safety
Airbag precautions .................. 94
Battery precautions ....... 380, 473
Child restraint system ........... 104
Child-protectors....................... 43
How your child should wear
the seat belt .......................... 61
Installing child restraints........ 108
Moon roof precautions ............ 75
Power window lock switch ...... 70
Power window precautions ..... 71
Removed key battery
precautions ......................... 403
Seat belt comfort guide ........... 58
Seat belt extender
precautions ........................... 64
Seat belt precautions .............. 62
Seat heater precautions ........ 330
Trunk precautions ................... 49
Child-protectors ......................... 43
Cleaning
Exterior.................................. 348
Interior ................................... 350
Seat belts .............................. 351
Clock ......................................... 326
Compass................................... 343
Condenser ................................ 374
Console box ............................. 317
Cooling system Engine overheating ............... 475
Cruise control .......................... 166
Cup holder ................................ 319
Curtain shield airbags ............... 87
Customizable features ............ 510
B
C
