2010 SUZUKI KIZASHI sensor

3-39OPERATING YOUR VEHICLE
57L20-03E
NOTE:
A TPMS sensor is not installed in the spare
tire. You should use the spare tire only in
an emergency situation, and should
replace the spare tire as soon as possible
to restore normal TPMS operation.For Vehicles Sold in U.S.A.This device complies with Part 15 of the
FCC Rules.
Operation is subject to the following two
conditions:
1) This device may not cause harmful
interference.
2) This device must accept any interfer-
ence received, including interference
that may cause undesired operation.
NOTE:
Changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user’s authority to
operate the equipment.
Traveling to CANADAPlease note that service for the tire pres-
sure monitoring system may not be avail-
able in CANADA should there be any
problems or malfunctions in the system.
WARNING
Only use tires and wheels recom-
mended by SUZUKI as standard or
optional equipment for your vehicle.
Use of tires or wheels not recom-
mended by SUZUKI can result in
TPMS failure. Refer to “Tires” in the
“INSPECTION AND MAINTENANCE”
section for additional information.

5-8
OTHER CONTROLS AND EQUIPMENT
57L20-03E
To turn the climate control system off, push
the “OFF” switch (10).
NOTE:
If the “AUTO” on the display blinks, there is
a problem in the heating system and/or air
conditioning system. You should have the
system inspected by an authorized
SUZUKI dealer.
NOTE:
 To find the temperature at which you are
most comfortable, start with the 72°F
(25°C) setting, for example.
 If you turn the temperature selector (1)
until “HI” or “LO” appears on the display,
the climate control system will operate at
the maximum heating or cooling and the
blower will run at full speed.
 To avoid blowing cold air in cold weather
or hot air in hot weather, the system will
delay turning on the blower until warmed
or chilled air is available.
 If your vehicle has been left in the sun
with the windows closed, it will cool
faster if you open the windows briefly. Even under automatic operation, you
can set individual selectors to the man-
ual mode. The manually selected func-
tions are maintained, and the other
functions remain under automatic opera-
tion.
 To return the blower speed selector (4),
air intake selector (5), and “MODE”
switch (6) to automatic operation, push
the “AUTO” switch (9).
57L51014
Be careful not to cover the interior temper-
ature sensor (12) located between the
steering wheel and the climate control
panel, or the solar sensor (13) located at
the top of the central part of the dash-
board. These sensors are used by the
automatic system to regulate temperature.
Manual operationYou can manually control the climate con-
trol system. Set the selectors to the
desired positions.
57L51015
NOTE:
If you need maximum defrosting:
 push the defrost switch (7) to turn on the
defroster (the air conditioning system will
come on and the “FRESH AIR” mode will
be selected automatically),
 set the blower speed selector to HIGH,
 adjust the temperature selector to the
“HI” indication on the display, and
 adjust the side outlets so the air blows
on the side windows.
(13)
(12)
EXAMPLE
EXAMPLE
Folding Rear Seats: 3

7-41INSPECTION AND MAINTENANCE
57L20-03E
The main fuse, primary fuses and some of
the individual fuses are located in the
engine compartment. If the main fuse
blows, no electrical component will func-
tion. If a primary fuse blows, no electrical
component in the corresponding load
group will function. When replacing the
main fuse, a primary fuse or an individual
fuse, use a genuine SUZUKI replacement.
To remove a fuse, use the fuse puller pro-
vided in the fuse box. The amperage of
each fuse is shown in the back of the fuse
box cover.
60A243
NOTE:
Make sure that the fuse box always carries
spare fuses. (20) 15A Head light low (Right)
(21) 15A Head light high (Left)
(22) 15A Head light high (Right)
(23) 15A CVT
(24) 20A Front fog light
(25) 15A O2 sensor heater
(26) 15A Horn
(27) –Head light low relay
(Left)
(28) –Head light low relay
(Right)
(29) – Blank
(30) – Blank
(31) – Blank
(32) –Air conditioning com-
pressor relay
(33) – Rear defogger relay
(34) – Blank
(35) –Windshield wiper relay
2
(36) – Blank
(37) –Windshield wiper relay
1
(38) – Starting motor relay
(39) – Fuel pump relay
(40) – Radiator fan relay 3
(41) – Radiator fan relay 1
(42) –Door mirror heater
relay
(43) – Radiator fan relay 2
(44) – Main relay
(45) – Throttle motor relay
WARNING
If the main fuse or a primary fuse
blows, be sure to have your vehicle
inspected by an authorized SUZUKI
dealer. Always use a genuine SUZUKI
replacement. Never use a substitute
such as a wire even for a temporary
fix, or extensive electrical damage
and a fire can result.
BLOWNOK

10-3GENERAL INFORMATION
57L20-03E
On-Board Vehicle Computers
and Event Data RecordersYour vehicle is equipped with on-board
computer systems which monitor and
control several aspects of vehicle per-
formance, including the following:
 Emission-related components and
engine parameters such as engine
speed and throttle position are moni-
tored to provide emissions control
and to provide optimum fuel econ-
omy. Your vehicle also has an on-
board diagnostic system which mon-
itors and records information about
emission-related malfunctions.
 Signals from various sensors are
monitored to provide air bag deploy-
ment.
 If your vehicle is equipped with
antilock brakes, conditions such as
vehicle speed and brake perfor-
mance are monitored, so that the
ABS system can provide effective
antilock braking. If your vehicle has
an Electronic Stability Program
(ESP
®) system, conditions such as
yaw rate, lateral acceleration, and
brake fluid pressure are monitored,
so that the ESP
® system can help
the driver control the vehicle in diffi-
cult driving situations.
Some information may be stored by
the on-board computers during normaloperation of the vehicle. This stored
information can assist technicians in
repairing the vehicle when malfunc-
tions occur. Other information is stored
only in the event of crash, by computer
systems that are commonly called
Event Data Recorders (EDRs).
In a crash event, EDRs such as the
Airbag Sensing and Diagnostic Mod-
ule (SDM) in your vehicle may record
information about the condition of the
vehicle and how it was operated, such
as data related to airbag readiness,
airbag performance, safety belt usage,
and the severity of the collision. These
data can help provide a better under-
standing of the circumstances in which
crashes and injuries occur and lead to
the designing of safer vehicles. The
SDM in your vehicle does not collect
or store personal information. Also, the
EDRs in your vehicle do not have the
ability to transmit information to a cen-
tral communications system or any
other external devices.
To read the stored information, special
equipment is needed and access to
the vehicle or storage device is
required. SUZUKI will not access infor-
mation about a crash event or share it
with others other than with the consent
of the vehicle owner or lessee, in
response to an official request fromthe police or similar government office,
as part of SUZUKI’s defense of litiga-
tion through the discovery process, or
as required by law.
In addition, once SUZUKI collects or
receives data, SUZUKI may use the
data for research conducted by
SUZUKI, make the data available for
outside research if need is shown and
confidentiality is assured, or make
summary data which does not identify
specific vehicles available for outside
research.
Others, such as law enforcement per-
sonnel, may have access to the spe-
cial equipment that can read the
information if they have access to the
vehicle or storage device.
Jacking Instructions: 5

11-3
FUSES AND PROTECTED CIRCUITS
57L20-03E57L71037
COLOR/SIZE (AMPS)
FUSE NAME
PROTECTED CIRCUIT
In engine
compartment MAIN
FUSE
BOX(18) WHITE (25) B/U Back up
(19) BLUE (15) H/L LO L Head light low (Left)
(20) BLUE (15) H/L LO R Head light low (Right)
(21) BLUE (15) H/L L Head light high (Left)
(22) BLUE (15) H/L R Head light high (Right)
(23) BLUE (15) AT CVT
(24) YELLOW (20) FR FOG Front fog light
(25) BLUE (15) O2 HTR O2 sensor heater
(26) BLUE (15) HORN Horn
1
10
11
12
13
14
15
16
1719
20
21
22
23
24
25
26 29
30
31
3233
34 27
28
37
38
39
40
41
444342
4535
36
18
2
3
4
5
6
7
8
9
USE THE DESIGNATED
FUSES AND RELAYS ONLY
Fuses and Protected Circuits: 7

13-4INDEX
57L20-03E
NNet/Rope Hooks ................................................................... 5-92OOdometer .............................................................................. 2-84
Oil Level Check .................................................................... 7-15
Oil Pressure Light ................................................................ 2-72
On-Board Vehicle Computers and Event Data
Recorders ............................................................................. 10-3
Open Door Warning Light ................................................... 2-75
Outside Rearview Mirrors ................................................... 2-22
Overhead Console ............................................................... 5-86PParking Brake Lever ................................................... 3-10, 7-27
Parking Sensors .................................................................. 3-23
Pedals ................................................................................... 3-11
Periodic Maintenance Schedule ........................................... 7-3
Power Door Locking System ................................................ 2-4
Power Mirror Control ........................................................... 2-22
Power Window Controls ..................................................... 2-17
Power-Assisted Brakes ....................................................... 3-28RRadio Antenna ....................................................................... 5-9
Rain-sensing Wipers ......................................................... 2-108
Rain-sensing Wipers and Washer Lever ......................... 2-107
Rear Center Seat Belt .......................................................... 2-38
Rear Seats ............................................................................ 2-29
Refill with Oil and Check for Leaks .................................... 7-18
Refilling................................................................................. 7-16
Replace the Oil Filter ........................................................... 7-17
Replacing Tires and/or Wheels .......................................... 3-38
Reporting Safety Defects .................................................... 10-4 Roof Rack Anchors .............................................................. 5-92
SSafety Certification Label .................................................... 10-2
Seat Belt Extender ............................................................... 2-53
Seat Belt Inspection ............................................................. 2-43
Seat Belt Pretensioner System ........................................... 2-54
Seat Belt Reminder .............................................................. 2-40
Seat Belts and Child Restraint Systems ............................ 2-34
Seat Position Memory System ............................................ 2-26
Selection of Coolant ............................................................ 7-18
Selection of Power Supply Modes........................................ 3-4
Setting Mode......................................................................... 2-85
Shoulder Anchor Height Adjuster ...................................... 2-43
Side Air Bags and Side Curtain Air Bags .......................... 2-59
Side Door Locks ..................................................................... 2-3
Snow Tires ............................................................................ 7-35
Spark Plugs .......................................................................... 7-20
SPECIFICATIONS .......
.......................................................... 12-1
Specified Fluid...................................................................... 7-24
Specified Gear Oil ................................................................ 7-22
Specified Oil ......................................................................... 7-15
Speedometer ........................................................................ 2-78
Spot Light ............................................................................. 5-80
Stability Control System...................................................... 3-31
Starting the Engine ................................................................ 3-7
Steering Wheel ..................................................................... 7-27
Sun Visor .............................................................................. 5-77
Sunroof ................................................................................. 5-83
Supplemental Restraint System (a ir bags) ........................ 2-55TTachometer ........................................................................... 2-78
