2010 SUBARU TRIBECA rear view mirror

create a traffic safety hazard.
For safety, always connect the towing
vehicle and trailer with trailer safety
chains. Pass the chains crossing each
other under the trailer tongue to prevent
the trailer from dropping onto the ground
in case the trailer tongue should discon-
nect from the hitch ball. Allow sufficient
slack in the chains taking tight-turn situa-
tions into account; however, be careful not
to let them drag on the ground.
For more information about the safety
chain connection, refer to the instructions
for your hitch and trailer. !Side mirrors
After hitching a trailer to your vehicle,
check that the standard side mirrors
provide a good rearward field of view
without significant blind spots. If significant blind spots occur with the vehicle
’s stan-
dard side mirrors, use towing mirrors that
conform with Federal, state/province and/
or other applicable regulations. ! Trailer lights
CAUTION
Direct splicing or other improper
connection of trailer lights may
damage your vehicle ’s electrical
system and cause a malfunction of
your vehicle ’s lighting system.
Connection of trailer lights to your vehi-cle ’s electrical system requires modifica-
tions to the vehicle ’s lighting circuit to
increase its capacity and accommodate
wiring changes. To ensure the trailer lights
are connected properly, please consult
your SUBARU dealer. Check for proper
operation of the turn signals, the brake
lights and parking lights each time you
hitch up. ! Tires
WARNING
Never tow a trailer when the tem-
porary spare tire is used. The tem-
porary spare tire is not designed to
sustain the towing load. Use of the temporary spare tire when towing
can result in failure of the spare tire
and/or less stability of the vehicle.
Make sure that all the tires on your vehicle
are properly inflated.
The recommended cold tire pressure
under trailer towing conditions is shownin “Tires ”F 12-3 and in “GAS STATION
REFERENCE ”at the end of this manual.
Adjust the rear tire pressure to the
recommended pressure when the tires
are cold. Normal pressure should be
maintained in the front tires.
Trailer tire condition, size, load rating and
proper inflation pressure should be in
accordance with the trailer manufacturer ’s
specifications.
In the event your vehicle gets a flat tire
when towing a trailer, ask a commercial
road service to repair the flat tire.
If you carry a regular size spare tire in your
vehicle or trailer as a precaution against
getting a flat tire, be sure that the spare
tire is firmly secured. Driving tips
8-25
– CONTINUED –

8-26Driving tips
&Trailer towing tips
CAUTION
. Never exceed 45 mph (72 km/h)
when towing a trailer in hilly
country on hot days.
. When towing a trailer, steering,
stability, stopping distance and
braking performance will be dif-
ferent from normal operation. Forsafety ’s sake, you should employ
extra caution when towing a
trailer and you should never
speed. You should also keep the
following tips in mind:
! Before starting out on a trip
. Check that the vehicle and vehicle-to-
hitch mounting are in good condition. If
any problems are apparent, do not tow the
trailer. . Check that the vehicle sits horizontally
with the trailer attached. If the vehicle is
tipped sharply up at the front and down at
the rear, check the total trailer weight,
GVW, GAWs and tongue load again, then
confirm that the load and its distribution
are acceptable. . Check that the tire pressures are
correct. .
Check that the vehicle and trailer are
connected properly. Confirm that
–the trailer tongue is connected
properly to the hitch ball. – the trailer lights connector is con-
nected properly and trailer ’sbrake
lights illuminate when the vehicle ’s
brake pedal is pressed, and that the trailer ’s turn signal lights flash when
the vehicle ’s turn signal lever is oper-
ated. – the safety chains are connected
properly.– all cargo in the trailer is secured
safely in position.– the side mirrors provide a good
rearward field of view without a sig-
nificant blind spot.
. Sufficient time should be taken to learn
the “feel ”of the vehicle/trailer combination
before starting out on a trip. In an area free
of traffic, practice turning, stopping and
backing up. ! Driving with a trailer
. You should allow for considerably more
stopping distance when towing a trailer.
Avoid sudden braking because it may
result in skidding or jackknifing and loss ofcontrol. . Avoid uneven steering, sharp turns and
rapid lane changes. .
Slow down before turning. Make a
longer than normal turning radius because
the trailer wheels will be closer than the
vehicle wheels to the inside of the turn. In
a tight turn, the trailer could hit yourvehicle. . Crosswinds will adversely affect the
handling of your vehicle and trailer, caus-
ing sway. Crosswinds can be due to
weather conditions or the passing of large
trucks or buses. If swaying occurs, firmly
grip the steering wheel and slow down
immediately but gradually. . When passing other vehicles, consid-
erable distance is required because of the
added weight and length caused by
attaching the trailer to your vehicle.
1) Left turn
2) Right turn

Fuses and circuits &Fuse panel located in the passenger compartmentFuse
panel Fuse
rating Circuit
1 20A .Trailer hitch connector
2 Empty
3 15A .Door locking
4 7.5A .Front wiper deicer relay
. Moonroof
5 7.5A .Combination meter
6 7.5A .Remote control rear
view mirrors
. Seat heater relay
7 15A .Combination meter
. Integrated unit
8 15A .Stop light
9 20A .Mirror heater
. Front wiper deicer
10 7.5A .Power supply (battery)
11 7.5A .Turn signal unit
12 15A .Automatic transmission
unit
. SRS airbag system
(sub)
. Engine control unit
. Integrated unitSpecifications
12-5
– CONTINUED –

14-4Index
Cup holder .................................................................. 6-8
Front passenger ’s .................................................... 6-8
Rear seat (5-seater models)/Second-row seat (7-seater models) passenger ’s................................. 6-9
Third-row seat (7-seater models) ................................ 6-9
D
Daytime running light system ....................................... 3-27
Differential gear oil Front ................................................................... 11-17
Rear .................................................................... 11-18
Dimensions ............................................................... 12-2
Disarming the alarm system ........................................ 2-18
Disc brake pad wear warning indicators ........................ 7-20
Dome light ........................................................ 6-2, 11-46
Door Locks ..................................................................... 2-5
Open warning light ................................................. 3-17
Step light ............................................................. 11-47
Drive belts. ............................................................... 11-15
Driving All-Wheel Drive warning light ................................... 3-18
AWD vehicles .......................................................... 8-4
Car phone/cell phone .................................................. 7
Drinking ..................................................................... 6
Drugs ........................................................................ 6
Foreign countries ..................................................... 8-4
Pets .......................................................................... 7
Snowy and icy roads ................................................ 8-9
Tips.................................................................. 8-2, 8-4
Tired or sleepy. ........................................................... 7 Winter
.................................................................... 8-7
E
Electrical system ........................................................ 12-3
Electronic Brake Force Distribution (EBD) system... 3-17, 7-22
Emergency Locking Retractor (ELR) ............................. 1-18
Engine Compartment overview ............................................ 11-6
Coolant ............................................................... 11-11
Exhaust gas (carbon monoxide) ............................. 5, 8-2
Hood .................................................................... 11-4
Oil ........................................................................ 11-7 Overheating ........................................................... 9-14
Starting .................................................................. 7-7
Stopping ................................................................. 7-8
Exterior care .............................................................. 10-2
F
Flat tires ..................................................................... 9-6
Floor mat ................................................................... 6-13
Fluid level Automatic transmission ......................................... 11-16
Brake .................................................................. 11-20
Power steering ..................................................... 11-19
Fog light Bulb .................................................................... 11-43
Indicator light ......................................................... 3-21
Switch ................................................................... 3-32
Folding mirror switch ................................................... 3-43
Front
Differential gear oil ................................................ 11-17

Oil filter..................................................................... 11-8
Oil level Engine .................................................................. 11-7
Front differential gear ............................................ 11-17
Rear differential gear ............................................. 11-18
Oil pressure warning light ............................................ 3-13
On-pavement and off-road driving .................................. 8-5
Outside Mirror defogger ...................................................... 3-43
Mirrors .................................................................. 3-42
Temperature indicator ............................................. 3-22
Overhead console ........................................................ 6-8
Overheating engine .................................................... 9-14
P Parking Brake ................................................................... 7-29
Brake stroke ......................................................... 11-23
Light .................................................................... 11-42
Light switch ........................................................... 3-32
Tips...................................................................... 7-30
Periodic inspections ..................................................... 8-4
Petrol fuel ................................................................... 7-2
Power
Door locking switch .................................................. 2-7
Outside mirrors ...................................................... 3-43
Seat ....................................................................... 1-3
Steering ................................................................ 7-18
Steering fluid ........................................................ 11-19
Windows ............................................................... 2-21
Precautions against vehicle modification ............... 1-31, 1-72Preparing to drive
........................................................ 7-7
Printed antenna ........................................................... 5-2
R Rear Air conditioner ......................................................... 4-8
Combination lights ................................................ 11-43
Differential gear oil ................................................ 11-18
Gate ............................................................. 2-24, 9-18
Gate light ...................................................... 6-3, 11-45
Seats ..................................................................... 1-7
Turn signal light .................................................... 11-43
Rear differential Oil temperature warning light ................................... 3-14
Rear seat Folding down ......................................................... 1-10
Reclining ................................................................ 1-9
Rear view camera ...................................................... 6-22
Rear window
Defogger button ..................................................... 3-37
Wiper and washer switch ......................................... 3-35
Wiper blades ........................................................ 11-35
Recommended
Automatic transmission fluid ................................... 11-17
Brake fluid ........................................................... 11-21
Engine oil .................................................... 11-9, 11-10
Front differential gear oil ........................................ 11-18
Power steering fluid .............................................. 11-20
Rear differential gear oil ........................................ 11-19
Spark plugs ......................................................... 11-15
Refueling .................................................................... 7-3
Remote engine start system ......................................... 7-8Index
14-7
