2010 SUBARU OUTBACK clock

11-54Maintenance and service
2. Disconnect the electrical connector.
1) For left-hand side
2) For right-hand side
3. Turn the socket clockwise (right-hand
side) or counterclockwise (left-hand side). 4. Pull out the socket.
5. Pull out the bulb from the socket and
replace the bulb with a new one.
6. After replacing the bulb, reattach the
fender lining.
&
Rear combination lights
! Legacy
NOTE
It may be difficult to replace the bulbs.
We recommend that you have the bulbs
replaced by your SUBARU dealer if
necessary.
1. Turn the knobs of the cover 90
degrees counterclockwise to remove the
cover.

1) Brake/tail and rear side marker light
2) Rear turn signal light
3) Back-up light
2. Remove the bulb holder from the rear
combination light assembly by turning it
counterclockwise. Use pliers if necessary.
3. Pull the bulb out of the bulb holder and
replace it with a new one.
4. Set the bulb holder into the rear
combination light assembly and turn it
clockwise until it locks.
5. Securely lock the cover against the
trunk trim. !
Outback
1. Undo the clips. For the method to undo
the clips, refer to “Type C clips ”F 11-6.
2. Remove the cover.
3. Remove the upper and lower screws.
4. Slide the rear combination light as-
sembly straight rearward and remove it
from the vehicle. Maintenance and service
11-55
– CONTINUED –

11-56Maintenance and service
1) Tail and rear side marker light
2) Brake light
3) Rear turn signal light
5. Remove the bulb holder from the rear
combination light assembly by turning itcounterclockwise.
6. Pull the bulb out of the bulb holder and
replace it with a new one.
7. Set the bulb holder into the rear
combination light assembly and turn it
clockwise until it locks.8. Reinstall the rear combination light
assembly by sliding the two-pronged part
of the combination light assembly securely
to each holder of the vehicle side.
9. Tighten the upper and lower screws.
10. Reinstall the side cover. &
Tail/Back-up light (Outback)
1. Apply a flat-head screwdriver to the
light cover as shown in the illustration, and
pry the light cover off from the rear gatetrim.

1) Back-up light
2) Tail light
2. Turn the bulb socket counterclockwise
and remove it.
3. Pull the bulb out of the bulb socket and
replace it with a new one. 4. Install the bulb socket by turning itclockwise.
5. Install the light cover on the rear gate.
& License plate light
! Legacy
NOTE
It may be difficult to replace the bulbs.
We recommend that you have the bulbs
replaced by your SUBARU dealer if
necessary.
1. Open the trunk.
2. Remove the trunk trim lining by re-
moving the 12 clips and the trunk trimhandle.
3. Turn the bulb socket counterclockwise
and remove it.
4. Pull the bulb out of the bulb socket and
replace it with a new one.
5. Install the bulb socket by turning it clockwise.
6. Reinstall the trunk trim lining. Maintenance and service
11-57
– CONTINUED –

14-4Index
Climate control system Automatic ................................................................ 4-8
Manual ................................................................... 4-4
Clock ........................................................................ 3-24
Clutch Fluid .................................................................... 11-31
Pedal .................................................................. 11-33
Coat hook ................................................................. 6-13
Continuously variable transmission ............................... 7-18
Capacities ............................................................. 12-4
Fluid .................................................................... 11-26
Manual mode ........................................................ 7-21
Oil temperature warning light (AT OIL TEMP) ............ 3-15
Select lever ........................................................... 7-19
Shift lock function ................................................... 7-20
Coolant .................................................................... 11-18
Temperature high warning light ................................ 3-13
Temperature low indicator light. ................................ 3-13
Cooling system ......................................................... 11-17
Corrosion protection ................................................... 10-4
Crossbars ................................................................. 8-14
Cruise control ............................................................ 7-38
Indicator light ................................................. 3-23, 7-41
Set indicator light ........................................... 3-23, 7-41
Cup holder .................................................................. 6-8
Front passenger ’s .................................................... 6-9
Rear passenger ’s..................................................... 6-9
D
Daytime running light system ....................................... 3-29
Defogger ................................................................... 3-34 Deicer
....................................................................... 3-34
Differential gear oil
Front ................................................................... 11-26
Rear ................................................................... 11-27
Dimensions ................................................................ 12-2
Disarming the alarm system ......................................... 2-18
Disc brake pad wear warning indicators ........................ 7-24
Dome light ......................................................... 6-2, 11-58
Door
Locks ..................................................................... 2-5
Open indicator light ................................................. 3-20
Open warning light. ................................................. 3-20
Step light ............................................................. 11-60
Double trip meter ......................................................... 3-6
Drive belts ............................................................... 11-23
Driving
All-Wheel Drive warning light ................................... 3-20
AWD vehicles ......................................................... 8-5
Car phone/cell phone .................................................. 7
Drinking. .................................................................... 6
Drugs ........................................................................ 7
Foreign countries ..................................................... 8-4
Off road .................................................................. 8-6
Pets .......................................................................... 8
Snowy and icy roads ............................................... 8-9
Tips ................................................. 7-17, 7-23, 8-2, 8-5
Tired or sleepy ........................................................... 7
Winter .................................................................... 8-8
E
ECO gauge ................................................................ 3-8
