8-10Driving tips
leading to loss of vehicle control.
An anti-lock brake system (ABS) en-
hances your vehicle ’s braking perfor-
mance on snowy and icy roads. For
information about braking on slippery
surfaces, refer to “ABS (Anti-lock Brake
System) ”F 7-25 and “Vehicle Dynamics
Control system ”F 7-28.
! Wiper operation when snowing
Before driving in cold weather, make sure
the wiper blades are not frozen to the
windshield or rear window.
If the wiper blades are frozen to the
windshield or rear window, perform the
following procedure. . To thaw the windshield wiper blades,
use the defroster with the airflow selection in “
”and the temperature set for
maximum warmth until the wiper blades
are completely thawed. Refer to “Climate
control ”F 4-1.
. If your vehicle is equipped with a wiper
deicer, use it. It is helpful to thaw the
windshield wiper blades. Refer to “Defog-
ger and deicer ”F 3-34.
. To thaw the rear wiper blade, use the
rear window defogger. Refer to “Defogger
and deicer ”F 3-34.
When driving in snow, if frozen snow starts
to stick on the surface of the windshield despite wiper operation, use the defroster
with the airflow selection in
“
”and the
temperature set for maximum warmth.
After the windshield gets warmed enough
to melt the frozen snow on it, wash it away
using the windshield washer. Refer to“ Windshield washer ”F 3-33
Snow stuck on the wiper arm prevents the
wiper from working effectively. If snow is
stuck on the wiper arm, pull off the road to
a safe place, then remove it. If you stop
the vehicle at road side, use the hazard
warning flasher to alert other drivers.
Refer to “Hazard warning flasher ”F 3-5.
We recommend use of non-freezing type
wiper blades (winter blades) during the
seasons you could have snow and freez-
ing temperatures. Blades of this type give
superior wiping performance in snowy
conditions. Be sure to use blades that
are suitable for your vehicle.
CAUTION
During high-speed driving, non-
freezing type wiper blades may not
perform as well as standard wiper
blades. If this happens, reduce the
vehicle speed. NOTE
When the season requiring non-freez-
ing type wiper blades is over, replace
them with standard wiper blades. &
Corrosion protection
Refer to “Corrosion protection ”F 10-4.
& Snow tires
WARNING
. When replacing original tires with
winter (snow) tires, make sure
you use only the same size,
construction and load range as
the original tires listed on the tire
placard. Using other sizes and
construction may affect speed-
ometer/odometer calibration and
clearance between the body and
tires. It also may be dangerous
and lead to loss of vehicle con-trol.
. You must install four winter tires
that are of the same size, circum-
ferences, construction, brand,
andloadrange.Mixingother
sizes, circumferences or con-
structions may result in severe
mechanical damage to the drive

Exterior care....................................................... 10-2
Washing ............................................................. 10-2
Waxing and polishing ......................................... 10-3
Cleaning aluminum wheels ................................. 10-3
Corrosion protection .......................................... 10-4
Most common causes of corrosion ..................... 10-4
To help prevent corrosion ................................... 10-4 Cleaning the interior
.......................................... 10-5
Seat fabric ......................................................... 10-5
Leather seat materials ........................................ 10-5
Synthetic leather upholstery ............................... 10-5
Climate control panel, audio panel, instrument panel, console panel, switches, combination
meter, and other plastic surface ....................... 10-5
Navigation monitor (if equipped) ........................ 10-6
Appearance care
10

Cleaning the interior
Use a soft, damp cloth to clean the climate
control panel, audio equipment, instru-
ment panel, center console, combination
meter panel, and switches. (Do not use
organic solvents.) &Seat fabric
Remove loose dirt, dust or debris with a
vacuum cleaner. If the dirt is caked on the
fabric or hard to remove with a vacuum
cleaner, use a soft brush then vacuum it.
Wipe the fabric surface with a tightly
wrung cloth and dry the seat fabric
thoroughly. If the fabric is still dirty, wipe
using a solution of mild soap and luke-
warm water then dry thoroughly.
If the stain does not come out, try a
commercially-available fabric cleaner. Use
the cleaner on a hidden place and make
sure it does not affect the fabric adversely.
Use the cleaner according to its instruc-tions. NOTE
When cleaning the seat, do not use
benzine, paint thinner, or any similarmaterials. &
Leather seat materials
The leather used by SUBARU is a high
quality natural product which will retain its
distinctive appearance and feel for many
years with proper care.
Allowing dust or road dirt to build up on the
surface can cause the material to become
brittle and to wear prematurely. Regular
cleaning with a soft, moist, natural fiber
cloth should be performed monthly, taking
care not to soak the leather or allow water
to penetrate the stitched seams.
A mild detergent suitable for cleaning
woolen fabrics may be used to remove
difficult dirt spots, rubbing with a soft, dry
cloth afterwards to restore the luster. If
your SUBARU is to be parked for a long
time in bright sunlight, it is recommended
that the seats and headrests be covered,
or the windows shaded, to prevent fading
or shrinkage.
Minor surface blemishes or bald patches
may be treated with a commercial leather
spray lacquer. You will discover that each
leather seat section will develop soft folds
or wrinkles, which is characteristic of
genuine leather. & Synthetic leather upholstery
The synthetic leather material used on the
SUBARU may be cleaned using mild soap or detergent and water, after first vacuum-
ing or brushing away loose dirt. Allow the
soap to soak in for a few minutes and wipe
off with a clean, damp cloth. Commercial
foam-type cleaners suitable for synthetic
leather materials may be used when
necessary.
NOTE
Strong cleaning agents such as sol-
vents, paint thinners, window cleaner
or gasoline must never be used on
leather or synthetic interior materials. & Climate control panel, audio
panel, instrument panel,
console panel, switches,
combination meter, and other
plastic surface
Use a soft, damp cloth to clean the climate
control panel, audio equipment, instru-
ment panel, center console, combination
meter panel, and switches. NOTE
Do not use organic solvents such as
paint thinners or gasoline, or strong
cleaning agents that contain thosesolvents. Appearance care
10-5
– CONTINUED –

13-16Consumer information and Reporting safety defects
form to Federal Safety Require-
ments in addition to these grades. &Treadwear
The treadwear grade is a compara-
tive rating based on the wear rate of
the tire when tested under con-
trolled conditions on a specified
government test course.
For example, a tire graded 150
would wear one and one-half (1-
1/2) times as well on the govern-
ment course as a tire graded 100.
The relative performance of tires
depends upon the actual conditions
of their use, however, and may
depart significantly from the norm
due to variations in driving habits,
service practices and differences in
road characteristics and climate. & Traction AA, A, B, C
The traction grades, from highest to
lowest, are AA, A, B and C. Those
grades represent the tire ’s ability to
stop on wet pavement as measured
under controlled conditions on spe- cified government test surfaces of
asphalt and concrete. A tire marked
C may have poor traction perfor- mance.
WARNING
The traction grade assigned to
this tire is based on straight-
ahead braking traction tests,
and does not include accel-
eration, cornering, hydroplan-
ing, or peak traction charac-teristics.
& Temperature A, B, C
The temperature grades are A (the
highest), B, and C, representing thetire ’s resistance to the generation of
heat and its ability to dissipate heat
when tested under controlled con-
ditions on a specified indoor labora-
tory test wheel. Sustained high
temperature can cause the material
of the tire to degenerate and reduce
tire life, and excessive temperature
can lead to sudden tire failure. The grade C corresponds to a level of
performance which all passenger
car tires must meet under the
Federal Motor Vehicle Safety Stan-
dards No. 109. Grades B and A
represent higher levels of perfor-
mance on the laboratory test wheel
than the minimum required by law.
WARNING
The temperature grade for this
tire is established for a tire
that is properly inflated and
not overloaded. Excessive
speed, underinflation, or ex-
cessive loading, either sepa-
rately or in combination, can
cause heat buildup and possi-
ble tire failure.

14-2Index
A
ABS (Anti-lock Brake System) ..................................... 7-25
Warning light ................................................. 3-16, 7-25
Accessories ....................................................... 5-4, 11-50
Accessory power outlet ............................................... 6-10
Air cleaner element ................................................... 11-20
Air conditioner Automatic climate control system ............................. 4-12
Manual climate control system ................................... 4-7
Air filtration system ..................................................... 4-15
Air flow selection .......................................................... 4-2
Automatic climate control system ............................. 4-12
Manual climate control system ................................... 4-5
Alarm system ............................................................ 2-16
All-Wheel Drive warning light ....................................... 3-20
Aluminum wheel ....................................................... 11-42
Cleaning ............................................................... 10-3
Antenna system ........................................................... 5-2
Anti-lock Brake System (ABS) ..................................... 7-25
Arming the system ..................................................... 2-17
Armrest ..................................................................... 1-12
Ashtray ..................................................................... 6-12
AT OIL TEMP warning light ......................................... 3-15
Audio Antenna system ....................................................... 5-2
AUX unit operation ................................................. 5-28
CD player operation ............................................... 5-18
Control button ........................................................ 5-30
FM/AM radio operation ........................................... 5-10
Power and sound controls ......................................... 5-7
Satellite radio operations ......................................... 5-14 Set ........................................................................ 5-4XM
TMsatellite radio reception
................................... 5-2
Auto on/off headlights ................................................. 3-27
Sensor .................................................................. 3-28
Auto-dimming mirror/compass ...................................... 3-36
Automatic climate control system ................................... 4-8
Automatic transmission ............................................... 7-18
Capacities ............................................................. 12-4
Fluid ................................................................... 11-24
Manual mode ......................................................... 7-21
Oil temperature warning light (AT OIL TEMP) ............. 3-15
Select lever ........................................................... 7-19
Shift lock function ................................................... 7-20
Automatic/Emergency Locking Retractor (A/ELR) ........... 1-13
AUX unit operation ..................................................... 5-28
B Battery .................................................................... 11-47
Drainage prevention function ..................................... 2-6
Jump starting ......................................................... 9-10
Replacement (remote engine start transmitter) ........... 7-14
Replacement (remote keyless entry system) .............. 2-11
Booster seat .............................................................. 1-31
Bottle holder ............................................................... 6-9
Brake Assist .................................................................... 7-24
Booster ....................................................... 7-24, 11-32
Fluid ................................................................... 11-30
Pad and lining ...................................................... 11-34
Parking ................................................................. 7-34
Pedal .................................................................. 11-33

14-4Index
Climate control system Automatic ................................................................ 4-8
Manual ................................................................... 4-4
Clock ........................................................................ 3-24
Clutch Fluid .................................................................... 11-31
Pedal .................................................................. 11-33
Coat hook ................................................................. 6-13
Continuously variable transmission ............................... 7-18
Capacities ............................................................. 12-4
Fluid .................................................................... 11-26
Manual mode ........................................................ 7-21
Oil temperature warning light (AT OIL TEMP) ............ 3-15
Select lever ........................................................... 7-19
Shift lock function ................................................... 7-20
Coolant .................................................................... 11-18
Temperature high warning light ................................ 3-13
Temperature low indicator light. ................................ 3-13
Cooling system ......................................................... 11-17
Corrosion protection ................................................... 10-4
Crossbars ................................................................. 8-14
Cruise control ............................................................ 7-38
Indicator light ................................................. 3-23, 7-41
Set indicator light ........................................... 3-23, 7-41
Cup holder .................................................................. 6-8
Front passenger ’s .................................................... 6-9
Rear passenger ’s..................................................... 6-9
D
Daytime running light system ....................................... 3-29
Defogger ................................................................... 3-34 Deicer
....................................................................... 3-34
Differential gear oil
Front ................................................................... 11-26
Rear ................................................................... 11-27
Dimensions ................................................................ 12-2
Disarming the alarm system ......................................... 2-18
Disc brake pad wear warning indicators ........................ 7-24
Dome light ......................................................... 6-2, 11-58
Door
Locks ..................................................................... 2-5
Open indicator light ................................................. 3-20
Open warning light. ................................................. 3-20
Step light ............................................................. 11-60
Double trip meter ......................................................... 3-6
Drive belts ............................................................... 11-23
Driving
All-Wheel Drive warning light ................................... 3-20
AWD vehicles ......................................................... 8-5
Car phone/cell phone .................................................. 7
Drinking. .................................................................... 6
Drugs ........................................................................ 7
Foreign countries ..................................................... 8-4
Off road .................................................................. 8-6
Pets .......................................................................... 8
Snowy and icy roads ............................................... 8-9
Tips ................................................. 7-17, 7-23, 8-2, 8-5
Tired or sleepy ........................................................... 7
Winter .................................................................... 8-8
E
ECO gauge ................................................................ 3-8

14-6Index
Front seat ............................................................... 1-5
Rear seat .............................................................. 1-10
Headlight ......................................................... 3-27, 11-50
Flasher ................................................................. 3-28
Indicator light ......................................................... 3-23
Heater operation (manual climate control system) .. .......... 4-6
High beam indicator light ............................................ 3-23
High/low beam change (dimmer) .................................. 3-28
Hill Holder ................................................................. 7-35
Indicator light ................................................. 3-19, 7-36
Switch .................................................................. 7-35
Hook Coat ..................................................................... 6-13
Convenient tie-down ............................................... 6-17
Shopping bag ........................................................ 6-14
Towing and tie-down ............................................... 9-13
Horn ......................................................................... 3-39
Hose and connections ............................................... 11-17
I
Ignition switch .............................................................. 3-3
Light ....................................................................... 3-4
Illumination brightness control ...................................... 3-30
Immobilizer. ................................................................. 2-3
Indicator light (security indicator light) ................. 2-4, 3-22
Indicator light Coolant temperature low ......................................... 3-13
Cruise control ................................................ 3-23, 7-41
Cruise control set ........................................... 3-23, 7-41
Door open ............................................................. 3-20
Front fog light ........................................................ 3-23 Headlight
............................................................... 3-23
High beam ............................................................. 3-23
Security .......................................................... 2-4, 3-22
Select lever/Gear position ........................................ 3-22
Turn signal ............................................................ 3-23
Vehicle Dynamics Control OFF ......................... 3-21, 7-31
Vehicle Dynamics Control operation .. ................ 3-21, 7-30
Inside mirror .............................................................. 3-36
Interior lights ............................................................... 6-2
Internal trunk lid release handle .................................... 2-25
J
Jack-up point .............................................................. 9-6
Jump starting ............................................................. 9-10
K
Key............................................................................ 2-2 Number .................................................................. 2-2
Reminder chime ...................................................... 3-4
Replacement. .......................................................... 2-4
Keyless entry system ................................................... 2-8
L
Leather seat materials ................................................. 10-5
License plate light ..................................................... 11-57
Light Back-up (Legacy) ................................................. 11-54
Brake (Outback) ................................................... 11-55
Brake/Tail and rear side marker (Legacy). ................ 11-54
Cargo area .................................................... 6-3, 11-60
Control switch ........................................................ 3-27

Dome........................................................... 6-2, 11-58
Door step ............................................................. 11-60
Front fog ...................................................... 3-30, 11-53
Front position ....................................................... 11-53
Ignition switch .......................................................... 3-4
License plate ........................................................ 11-57
Map ............................................................. 6-2, 11-59
Rear combination .................................................. 11-54
Tail and rear side marker (Outback) ......................... 11-55
Tail/Back-up (Outback) ........................................... 11-56
Trunk ................................................................... 11-60
Turn signal ......................................... 3-29, 11-53, 11-54
Vanity mirror .................................................. 6-5, 11-59
Loading your vehicle .................................................. 8-12
Low fuel warning light ........................................... 3-8, 3-19
Low tire pressure warning light .................................... 3-15
Lower and tether anchorage ........................................ 1-33
M
Main fuse ................................................................. 11-50
Maintenance
Precautions ........................................................... 11-3
Schedule .............................................................. 11-3
Seatbelt ................................................................ 1-22
Tips...................................................................... 11-5
Tools ...................................................................... 9-3
Malfunction indicator lamp (check engine warning light) ..................................... 3-12
Manual Climate control system ............................................. 4-4
Mode .................................................................... 7-21 Seat
....................................................................... 1-3
Transmission ......................................................... 7-16
Transmission oil ................................................... 11-23
Map light ........................................................... 6-2, 11-59
Maximum load limits ................................................... 8-19
Meters and gauges ...................................................... 3-5
Mirror defogger .......................................................... 3-34
Mirrors ...................................................................... 3-36
Moonroof ........................................................... 2-28, 9-20
Multi function display ................................................... 3-24
N
New vehicle break-in driving ......................................... 8-2
OOdometer ................................................................... 3-6
Off road driving ........................................................... 8-6
Oil filter ................................................................... 11-14
Oil level
Engine ................................................................ 11-12
Front differential gear ............................................ 11-26
Manual transmission ............................................. 11-23
Rear differential gear ............................................ 11-27
Warning light .......................................................... 3-14
Oil pressure warning light ............................................ 3-14
Outside
Mirror defogger ...................................................... 3-34
Mirrors .................................................................. 3-38
Overhead console ....................................................... 6-8
Overheating engine .................................................... 9-12 Index
14-7
