Technical Data
260
Engine oil specificationsThe engine of your vehicle has been factory-filled with a high-grade oil which you can
use throughout the year - except in extreme climatic regions.
You can mix various oils together with each other when refilling with oil. This does not,
however, apply for models with flexible service intervals (QG1).
Engine oils are, of course, undergoing co ntinuous further development. Thus the
information stated in this Owner's Manual is only correct at the time of publication.
Authorised Škoda Service Partners are inform ed by Škoda Auto about current changes.
This why you should always have engine oi l changed by an authorised Škoda Service
Par tner.
The specifications (VW standards) stated in the following must be indicated separately
or together with other specifications on the bottle.
Engine oil specifications for models with flexible service intervals (QG1) Engine oil specifications for vehicles with fixed service intervals (QG2)
If the oils specified above are not available, oils according to ACEA A3 or ACEA A4 can
be used once for refilling. ACEA A3.
If the oils specified above are not available,
oils according to ACEA B3 or ACEA B4 can
be used once for refilling.
Caution
Only the above-mentioned oils may be used on vehicles with flexible service intervals
(QG1). We recommend always refilling with oi l of the same specification since this will
maintain the properties of the oil. In exce ptional cases, you must top up only once
engine oil complying with Specification VW 50 2 00 (only for petrol engines) or Specifi-
cation VW 505 01 (only for diesel engines) to maximum 0.5 litres. You must not use
other engine oils - risk of engine damage!
Petrol engines
Specification
Content
a)
a)Oil capacity with oil filter change. Inspect oil leve l when filling; do not fill up too much. The oil
level must be between the markings page 217.1.4 ltr./92 kW TSI - EU5
VW 503 00, VW 504 00
3,6
1.8 ltr./118 (112) kW TSI - EU5 / EU2 /
BS4
VW 504 00
4,6
2.0 ltr./147 kW TSI - EU5
VW 504 00
4,6
3.6 ltr./191 kW FSI - EU5 / EU2 / (BS4)
VW 504 00
5,5
Diesel engines
Specification
Content
a)
1.9 ltr./77 kW TDI PD - EU4
VW 506 01, VW 507 00
3,8
1.9 ltr./77 kW TDI PD DPF - EU4
VW 507 00
4,3
2.0 ltr./103 kW TDI CR DPF - EU5
VW 507 00
4,3
2.0 ltr./103 kW TDI CR - EU5 / EU4 / BS4
VW 507 00
4,0
2.0 ltr./125 kW TDI CR DPF - EU5
VW 507 00
4,3
Petrol engines
Specification
Content
a)
a)Oil capacity with oil filter change. Inspect oil le vel when filling; do not fill up too much. The oil
level must be between the markings page 217.1.4 ltr./92 kW TSI - EU5
VW 501 01, VW 502 00
3,6
1.8 ltr./118 (112) kW TSI - EU5 / EU2 /
BS4
VW 502 00
4,6
2.0 ltr./147 kW TSI - EU5
VW 502 00
4,6
3.6 ltr./191 kW FSI - EU5 / EU2 / (BS4)
VW 502 00
5,5
Diesel engines
Specification
Content
a)
1.9 ltr./77 kW TDI PD - EU4
VW 505 01
3,8
1.9 ltr./77 kW TDI PD DPF - EU4
VW 507 00
4,3
2.0 ltr./103 kW TDI CR DPF - EU5
VW 507 00
4,3
2.0 ltr./103 kW TDI CR - EU5 / EU4 / BS4
VW 507 00
4,0
2.0 ltr./125 kW TDI CR DPF - EU5
VW 507 00
4,3
s3fg.2.book Page 260 Friday, April 30, 2010 12:17 PM

Technical Data261
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Note

Before a long drive we recommend that you purchase and carry with you engine
oil which complies with the specification for your vehicle. Consequently, you will
always have the correct engine oil for refilling.

We recommend using a preservative from the Škoda original accessories offered
by your Škoda dealer.

For further information - see Service shedule.
s3fg.2.book Page 261 Friday, April 30, 2010 12:17 PM

Index281
Using the system
Safety
Driving Tips
General Maintenance
Breakdown assistance
Technical Data
Park Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Parking aid
rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
parking aid Front and rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Parking light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Parking lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 252
Parking the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Passive Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Petrol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212
Petrol engines Starting the engine . . . . . . . . . . . . . . . . . . . . . . . 123
Polishing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Power socket in the luggage compartment . . . . . 100
Power steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192 Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Power windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Button in the driver's door . . . . . . . . . . . . . . . . . 52
Button in the front passenger door and in the rear doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Operational faults . . . . . . . . . . . . . . . . . . . . . . . . . 54
with central locking system . . . . . . . . . . . . . . . . . 54
RRadiator fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Rear armrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86, 104
Rear fog light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65 Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Rear light unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Rear light unit (Combi) . . . . . . . . . . . . . . . . . . . . . . . 255 Rear seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Rear window
Heater . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Rear window heater . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Rear-view mirror Exterior mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Interior mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Recharge battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Recommendation for changing gears . . . . . . . . . . . 19
Refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 213
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Synchronisation process . . . . . . . . . . . . . . . . . . . 50
Replacing fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246
Replacing the wiper blade fo r rear window (Combi) 76
Replacing the wiper blades . . . . . . . . . . . . . . . . . . . . 76
Roof aerial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205
Running in the car . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
SSafe securing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161
Safety information Engine compartment . . . . . . . . . . . . . . . . . . . . . 216
Safety wheel bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240
Saving electrical energy . . . . . . . . . . . . . . . . . . . . . . . 196
Seat belt height adjuster . . . . . . . . . . . . . . . . . . . . . . 167
Seat belt warning light . . . . . . . . . . . . . . . . . . . . . . . . 167
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165, 168 Belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
fastening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Height adjustment . . . . . . . . . . . . . . . . . . . . . . . . 167 Safety information . . . . . . . . . . . . . . . . . . . . . . . 166
taking off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Seat heaters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Selector lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Selector lever lock Warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Selector lever positions . . . . . . . . . . . . . . . . . . . . . . 137
Selector lever-emergency unl ocking (DSG) . . . . 140
Service Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Service Interval Display . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the top position of the lid . . . . . . . . . . . . . . . 45
Shifting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Side airbag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Side lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
Spare wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 236
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Stability system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . . 122 after fuel tank has run empty . . . . . . . . . . . . . 123
Diesel engines . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Petrol engines . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Steering active driver-steering recommendation . . . 189
Steering force assistance . . . . . . . . . . . . . . . . . . . . . 192
Storage compartment Lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Umbrella . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Storage compartments . . . . . . . . . . . . . . . . . . . . . . 100
Storage facilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
s3fg.2.book Page 281 Friday, April 30, 2010 12:17 PM

Škoda Auto pursues a policy of constant product and model development. We trust
that you will understand that changes to models in terms of shape, equipment and
engineering, may be introduced at any time . The information about scope of delivery,
appearance, performances, di mensions, weight, fuel consumption, standards and
functions of the vehicle is only correct at the time of publication. Certain items of
equipment might only be installed later on (information given by the local authorised
Škoda Service Partner) and only envisaged fo r particular markets. It is therefore not
possible for legal claims to be made based on the data, illustrations and descriptions
contained in this Owner's Manual. Reprinting, reproduction or translation, eith
er in whole or in part, is not permitted
without the written consent of Škoda Auto.
Škoda Auto expressly reserves all rights relating to copyright laws.
We reserve the right to make changes to this document.
Issued by: ŠKODA AUTO a.s.
© ŠKODA AUTO a.s. 2010s3fg.2.book Page 284 Friday, April 30, 2010 12:17 PM
