2010 SATURN AURA audio

For optimal audio performance, the headphones must
be worn correctly. Headphones should be worn with the
headband over the top of the head for best audio
reception. The symbol L (Left) appears on the upper left
side, above the ear pad and should be positioned on
the left ear. The symbol R (Right) appears on the upper
right side, above the ear pad and should be positioned
on the right ear.
Notice:Do not store the headphones in heat or
direct sunlight. This could damage the headphones
and repairs will not be covered by the warranty.
Storage in extreme cold can weaken the batteries.
Keep the headphones stored in a cool, dry place.
If the foam ear pads attached to the headphones
become worn or damaged, the pads can be replaced
separately from the headphone set. Contact your
dealer/retailer for more information.Battery Replacement
To change the batteries on the headphones, do the
following:
1. Turn the screw to loosen the battery door located
on the left side of the headphones. Slide the
battery door open.
2. Replace the two batteries in the compartment.
Make sure that they are installed correctly, using
the diagram on the inside of the battery
compartment.
3. Replace the battery door and tighten the door
screw.
If the headphones are to be stored for a long period of
time, remove the batteries and keep them in a cool,
dry place.
Theft-Deterrent Feature
THEFTLOCK®is designed to discourage theft of the
vehicle’s radio by learning a portion of the Vehicle
Identification Number (VIN). The radio does not operate
if it is stolen or moved to a different vehicle.
4-81
ProCarManuals.com

Audio Steering Wheel Controls
Vehicles with audio
steering wheel controls
could differ depending on
the vehicle’s options.
Some audio controls can
be adjusted at the steering
wheel.
e+/e−(Volume):Press to increase or to decrease
the radio volume.
w/x(Next / Previous):Press to change radio
stations, select tracks on a CD, or to select tracks and
navigate folders on an iPod
®or USB device.
To change radio stations:
•Press and releaseworxto go to the next or
previous radio station stored as a preset.
•Press and holdworxto go to the next or
previous radio station in the selected band with a
strong signal.To select tracks on a CD:
Press and release
worxto go to the next or previous
track.
To select tracks on an iPod or USB device:
1. Press and hold
worxwhile listening to a song
until the contents of the current folder display on
the radio display.
2. Press and release
worxto scroll up or down the
list, then press and hold
wto play the highlighted
track.
To navigate folders on an iPod or USB device:
1. Press and hold
worxwhile listening to a song
until the contents of the current folder display on
the radio display.
2. Press and hold
xto go back to the previous
folder list.
3. Press and release
worxto scroll up or down
the list.
•To select a folder, press and holdwwhen the
folder is highlighted.
•To go back further in the folder list, press and
hold
x.
4-82
ProCarManuals.com

Fuses Usage
POWER
MIRRORSPower Mirrors
EPS Electronic Power Steering
RUN/CRANKCruise Control Switch, Passenger
Airbag Status Indicator
HVAC
BLOWER HIGHHeating Ventilation Air Conditioning
Blower - High Speed Relay
CLUSTER/
THEFTInstrument Panel Cluster, Theft
Deterrent System
ONSTAR OnStar
®
NOT
INSTALLEDNot Used
AIRBAG (IGN) Airbag (Ignition)
HVAC CTRL
(BATT)Heating Ventilation Air Conditioning
Control Diagnostic Link Connector
(Battery)
PEDAL Not Used
WIPER SW Windshield Wiper/Washer Switch
IGN SENSOR Ignition Switch
STRG WHL
ILLUMSteering Wheel Illumination
NOT
INSTALLEDNot Used
RADIO Audio System
INTERIOR
LIGHTSInterior Lamps
Fuses Usage
NOT
INSTALLEDNot Used
POWER
WINDOWSPower Windows
HVAC
CTRL (IGN)Heating Ventilation Air Conditioning
Control (Ignition)
HVAC
BLOWERHeating Ventilation Air Conditioning
Blower Switch
DOOR LOCK Door Locks
ROOF/HEAT
SEATSunroof, Heated Seat
NOT
INSTALLEDNot Used
NOT
INSTALLEDNot Used
AIRBAG
(BATT)Airbag (Battery)
SPARE FUSE
HOLDERSpare Fuse Holder
SPARE FUSE
HOLDERSpare Fuse Holder
SPARE FUSE
HOLDERSpare Fuse Holder
SPARE FUSE
HOLDERSpare Fuse Holder
FUSE PULLER Fuse Puller
6-99
ProCarManuals.com

Fuses Usage
9 Not Used
10 Sunroof Controls
11 Not Used
12 Not Used
13 Audio Amplifier
14 Heated Seat Controls
15 Not Used
16Remote Keyless Entry (RKE)
System, XM™ Satellite
Radio, UGDO
17 Back-up Lamps
18 Not Used
19 Not Used
20 Auxiliary Power Outlets
21 Not Used
22 Trunk Release
23 Rear Defog
24 Heated Mirrors
25 Fuel PumpRelays Usage
26 Rear Window Defogger
27 Park Lamps
28 Not Used
29 Not Used
30 Not Used
31 Not Used
32 Not Used
33 Back-up Lamps
34 Not Used
35 Not Used
36 Trunk Release
37 Fuel Pump
38 (Diode) Cargo Lamp
6-104
ProCarManuals.com

Arming the System.........................................3-16
Assistance Program, Roadside........................... 8-6
Audio System.........................................4-50, 4-69
Audio Steering Wheel Controls......................4-82
Radio Reception..........................................4-83
Rear Seat (RSA).........................................4-79
Setting the Clock.........................................4-51
Theft-Deterrent Feature................................4-81
XM™ Satellite Radio Antenna System............4-84
Audio System(s).............................................4-52
Automatic Climate Control System.....................4-19
Automatic Dimming Mirror Operation..................3-32
Automatic Headlamp System............................4-11
Automatic Transmission
Fluid..........................................................6-23
Operation...................................................3-23
Automatic Transmission Shift Lock Control
System Check.............................................. 7-8
B
Backglass Antenna..........................................4-84
Backing Up....................................................5-31
Battery..........................................................6-35
Electric Power Management..........................4-14
Run-Down Protection...................................4-14
Battery Replacement......................................... 3-5Belt Routing, Engine.......................................7-12
Blizzard Conditions..........................................5-16
Bluetooth Controls...........................................4-69
Bluetooth
®.....................................................4-68
Brake
Emergencies................................................ 5-5
Brake Adjustment............................................6-35
Brake Fluid....................................................6-33
Brake Pedal Travel.........................................6-35
Brake Wear...................................................6-34
Brakes..........................................................6-33
Antilock....................................................... 5-4
Parking......................................................3-26
System Warning Light..................................4-30
Braking........................................................... 5-3
Braking in Emergencies..................................... 5-5
Break-In, New Vehicle.....................................3-19
Bulb Replacement...........................................6-43
Fog Lamps .................................................4-12
Halogen Bulbs............................................6-41
Headlamp Aiming........................................6-40
Headlamps.................................................6-41
License Plate Lamps....................................6-43
Taillamps, Turn Signal, Sidemarker, Stoplamps,
and Back-Up Lamps.................................6-41
Buying New Tires...........................................6-60
2
ProCarManuals.com

Power Door Locks............................................ 1-5
Power Lumbar ................................................. 1-7
Power Reclining Seatbacks................................ 2-8
Power Reclining Seatbacks (If Equipped)............. 1-7
Power Seats (If Equipped)................................. 1-6
Pregnancy, Using Safety Belts..........................2-31
Privacy..........................................................8-15
Navigation System.......................................8-16
Radio Frequency Identification (RFID).............8-17
Program
Courtesy Transportation.................................. 8-9
Programmable Automatic Door Locks.................. 3-9
Programming the Power Windows.....................3-14
Programming Transmitters to the Vehicle............. 3-4
Programming Universal Home
Remote — Fixed Code.................................3-37
Programming Universal Home
Remote — Rolling Code...............................3-35
Proposition 65 Warning, California....................... 6-4
Propriétaires Canadiens....................................... iii
Pulling A Trailer..............................................5-28
Q
Questions and Answers About Safety Belts.........2-16
R
Radio Data System (RDS)...............................4-53
Radio Frequency
Identification (RFID).....................................8-17
Statement...................................................8-17
Radio Messages.............................................4-57
Radio(s)........................................................4-52
Radios
Reception...................................................4-83
Setting the Clock.........................................4-51
Theft-Deterrent............................................4-81
Reading Lamps..............................................4-13
Rear Door Security Locks................................3-10
Rear Safety Belt Comfort Guides......................2-28
Rear Seat....................................................... 1-8
Rear Seat Air Outlet........................................4-23
Rear Seat Audio Controls.................................4-80
Rear Seat Audio (RSA) System........................4-79
Rear Window Defogger............................4-18, 4-22
Rearview Mirrors.............................................3-32
Automatic Dimming......................................3-32
Receiving a Call.............................................4-75
Reclining Seatbacks.......................................... 2-6
Recommended Fluids and Lubricants.................7-10
Recreational Vehicle Towing.............................5-24
12
ProCarManuals.com

Reimbursement Program, GM Mobility................. 8-6
Remote Keyless Entry (RKE) System.................. 3-3
Remote Trunk Release....................................3-12
Remote Vehicle Start........................................ 3-5
Removal and Installation of the Sealant
Canister.....................................................6-73
Removing the Flat Tire and Installing the
Spare Tire..................................................6-78
Removing the Spare Tire and Tools...................6-76
Repair Facility................................................8-11
Replacement Bulbs.........................................6-43
Replacement Parts
Maintenance...............................................7-11
Replacing Brake System Parts..........................6-35
Reporting Safety Defects
Canadian Government..................................8-14
Saturn.......................................................8-14
U.S. Government.........................................8-13
Reprogramming Universal Home
Remote Buttons..........................................3-40
Restraint System Check
Checking the Restraint Systems....................2-75
Replacing Restraint System Parts After
a Crash..................................................2-76
Retained Accessory Power (RAP)......................3-20
Ride Control Systems....................................... 5-5
Electronic Stability (ESC)................................ 5-5Roadside Assistance Program............................ 8-6
Rocking Your Vehicle to Get it Out....................5-18
Roof
Sunroof......................................................3-42
Rear Seat Entertainment System, Rear Seat
Audio (RSA)............................................4-79
Running the Vehicle While Parked.....................3-31
S
Safety Belt Pretensioners.................................2-27
Safety Belt Reminder Light...............................4-26
Safety Belts...................................................2-75
Care of ......................................................6-91
Extender....................................................2-31
How to Wear Safety Belts Properly................2-17
Lap-Shoulder Belt........................................2-25
Reminders..................................................4-26
Safety Belts Are for Everyone.......................2-12
Use During Pregnancy.................................2-31
Safety Chains.................................................5-30
Safety Defects Reporting
Canadian Government..................................8-14
Saturn.......................................................8-14
U.S. Government.........................................8-13
13
ProCarManuals.com

Speedometer..................................................4-26
Split Folding Rear Seat....................................2-10
Start Vehicle, Remote....................................... 3-5
Starter Switch Check........................................ 7-8
Starting the Engine.........................................3-20
Starting the Vehicle........................................... 1-4
Steering.......................................................... 5-9
Steering in Emergencies..................................5-10
Steering Tips................................................... 5-9
Steering Wheel Controls, Audio.........................4-82
Steering Wheel, Tilt and Telescopic..................... 4-3
Steps for Determining Correct Load Limit...........5-20
Storage Areas
Center Console...........................................3-41
Convenience Net.........................................3-42
Cupholders.................................................3-41
Glove Box..................................................3-41
Storing a Favorite Station.................................1-16
Storing a Flat Tire and Tools............................6-84
Storing a Radio Station....................................4-54
Storing Name Tags.........................................4-71
Storing the Spare Tire and Tools.......................6-86
Storing the Tire Sealant and Compressor Kit......6-74
Stuck in Sand, Mud, Ice, or Snow.....................5-18
Sun Visors.....................................................3-15
Sunroof.........................................................3-42
Sunshade......................................................3-43T
Tachometer....................................................4-26
Taillamps
Turn Signal, Sidemarker, Stoplamps, and
Back-Up Lamps.......................................6-41
Telescopic Wheel.............................................. 4-3
Temperature – A, B, C....................................6-63
Text Telephone (TTY) Users............................... 8-5
Theft-Deterrent Feature....................................4-81
Theft-Deterrent Systems...................................3-15
Content Theft-Deterrent................................3-16
PASS-Key
®III+ Electronic Immobilizer............3-17
PASS-Key®III+ Electronic Immobilizer
Operation................................................3-17
Three-Way Calling..........................................4-76
Tilt Wheel........................................................ 4-3
Time, Setting..................................................4-51
Tire and Loading Information Label....................5-19
Tire Sealant...................................................6-68
15
ProCarManuals.com
