Interior
INSTRUMENTS AND CONTROLS
1. Lighting and direction indicators
stalk.
2. I n s t r u m e n t p a n e l w i t h d i s p l a y .
3. Wipers, screenwash, trip
computer controls.
4. I g n i t i o n .
5. Audio equipment.
6. Driver's airbag, horn.
7. Steering wheel height and reach
adjustment.
8. Cruise control, speed limiter
switch.
9. Control panel, parking
assistance, headlamp beam
a d j u s t m e n t , E S P .
10. B o n n e t r e l e a s e .
11. E l e c t r i c e x t e r i o r m i r r o r
adjustment.
Page 5 of 214
2
34
3
3
10
Interior
Steering wheel Storage compartments
1.
Forwards-backwards
adjustment.
2. Angle.
3.
Seat cushion
height.
4. Head restraint
height and
angle.
Driver's seat
59 40
78
107 96
SIT COMFORTABLY
The tools are stored under the right-
hand seat.
Adjust the height and reach of the
steering wheel.
Mirrors
Manual adjustments.
E l e c t r i c a d j u s t m e n t s .
Seat belts
Height adjustment.
Fastening.
Page 40 of 214
40
Good practice when stopping
Good practice when starting
Diesel pre-heating warning
light
If the temperature is high
enough, the warning light
comes on for less than one
second, you can start without
waiting.
In cold weather, wait for this warning
light to switch off then operate the
starter (Starting position) until the
engine starts. Door or bonnet open
warning light
If this comes on, a door or the bonnet
is not closed correctly, check!
Minimise engine and gearbox wear
When switching off the ignition, let the
engine run for a few seconds to allow
the turbocharger (Diesel engine) to
return to idle.
Do not press the accelerator when
switching off the ignition.
There is no need to engage a gear
after parking the vehicle.
STARTING AND STOPPING
Running and accessories position.
To unlock the steering, turn the
steering wheel gently while turning the
key, without forcing. In this position,
certain accessories can be used.
Starting position.
The starter is operated, the engine
turns over, release the key.
STOP position: steering lock.
The ignition is off. Turn the steering
wheel until the steering locks. Remove
the key.
STEERING WHEEL ADJUSTMENT
When the vehicle is stationary, unlock
the steering wheel by pulling the lever.
Adjust the height and depth of the
steering wheel, then lock by pushing
the lever fully. Gearbox and steering wheel Starting and stopping
Page 61 of 214
5 9
ERGONOMICS
and
COMFORT
3
Seats
FRONT SEATS
T h e f o l l o w i n g a d j u s t m e n t s a r e
a v a i l a b l e : 1 - Forwards/backwards adjustment
L i f t t h e b a r a n d s l i d e t h e s e a t f o r w a r d s
o r b a c k w a r d s .
3 - Driver's seat height adjustment
T o r a i s e t h e s e a t , p u l l t h e c o n t r o l
u p w a r d s t h e n t a k e y o u r w e i g h t o f f t h e
s e a t c u s h i o n .
T o l o w e r t h e s e a t , p u l l t h e c o n t r o l
u p w a r d s t h e n p u s h o n t h e s e a t
cushion.
2 - Seat back angle adjustment
W i t h y o u r b a c k p r e s s e d a g a i n s t t h e
s e a t b a c k , m o v e t h e l e v e r f o r w a r d s
a n d s e t t h e r e q u i r e d a n g l e .
Page 62 of 214
60
Seats
N e v e r d r i v e w i t h t h e h e a d
r e s t r a i n t s r e m o v e d ; t h e y m u s t b e
i n p l a c e a n d c o r r e c t l y a d j u s t e d . Adjustable armrest
T o a c c e s s t h e v e r t i c a l p o s i t i o n , r a i s e
t h e a r m r e s t u n t i l i t l o c k s .
L o w e r t h e a r m r e s t t o r e t u r n i t t o a
position for use.
T o r e m o v e t h e a r m r e s t , p r e s s t h e
r e l e a s e b u t t o n f r o m t h e v e r t i c a l p o s i t i o n
a n d m o v e a s i d e t h e a r m r e s t .
T o p u t t h e a r m r e s t b a c k i n p l a c e , c l i p i t
i n t h e v e r t i c a l p o s i t i o n .
I f t h e v e h i c l e i s fi t t e d w i t h t h e a d d i t i o n a l
c o n s o l e a n d a n a r m r e s t , t o f o l d t h e
p a s s e n g e r s e a t t o t h e t a b l e p o s i t i o n
r e m o v e t h e c o n s o l e o r t h e a r m r e s t .
Head restraint height adjustment
T o r a i s e t h e h e a d r e s t r a i n t , s l i d e i t
v e r t i c a l l y u p w a r d s .
T o l o w e r t h e h e a d r e s t r a i n t , p r e s s t h e
b u t t o n a n d s l i d e t h e h e a d r e s t r a i n t
v e r t i c a l l y d o w n w a r d s .
T h e a d j u s t m e n t i s c o r r e c t w h e n t h e
u p p e r e d g e o f t h e h e a d r e s t r a i n t i s
l e v e l w i t h t h e t o p o f t h e h e a d .
T o r e m o v e t h e h e a d r e s t r a i n t , p r e s s
t h e b u t t o n a n d p u l l t h e h e a d r e s t r a i n t
u p w a r d s .
T o r e - i n s t a l l t h e h e a d r e s t r a i n t , e n g a g e
t h e r o d s i n t h e h o l e s m a k i n g s u r e t h e y
a r e a l i g n e d w i t h t h e s e a t b a c k .
Page 110 of 214
107
SAFETY
4
Seat belts
SEAT BELTS
Height adjustment
Squeeze the control with the return and
slide the assembly on the driver's seat
side and on the individual passenger
seat side.
Fastening
Pull the strap, then insert the tongue
into the buckle.
Check that the seat belt is fastened
correctly by pulling the strap. Driver's seat belt not fastened
warning light
Unfastening
Press the red button.
When the vehicle is started,
this warning light comes on if
the driver has not fastened his
seat belt. Good practice
The driver must ensure that
passengers use the seat belts correctly
and that they are all strapped in
securely before moving off.
Wherever you are seated in the
vehicle, always fasten your seat belt,
even for short journeys.
T h e s e a t b e l t s a r e fi t t e d w i t h a n i n e r t i a
reel which automatically adjusts the
length of the strap to your size.
D o n o t u s e a c c e s s o r i e s ( c l o t h e s p e g s ,
clips, safety pins, etc.) which permit a
clearance with the seat belt straps.
Ensure that the seat belt is rolled up
correctly after use.
After folding or moving a seat or a rear
bench seat, ensure that the seat belt is
rolled up correctly and that the buckle
is ready to accommodate the tongue.
Depending on the nature and
seriousness of any impact, the
pretensioning device may be triggered
b e f o r e a n d i n d e p e n d e n t l y o f i n fl a t i o n
of the airbags. It instantly tightens
the seat belts against the body of the
occupants.
Triggering of the pretensioners is
accompanied by a slight discharge
of harmless smoke and a noise, due
to the activation of the pyrotechnic
cartridge incorporated in the system.
